1 - Azure Local Support Matrix (Dell 2606)
1.1 - Azure Local Support Matrix for 14G-15G (Dell 2606)
Supported Platforms
| Model | Supported Operating System |
|---|---|
| AX-640 | Windows Server 2022 Datacenter Azure Stack HCI-24H2 |
| AX-740xd | Windows Server 2022 Datacenter Azure Stack HCI-24H2 |
| AX-6515 | Windows Server 2022 Datacenter Windows Server 2025 Datacenter Azure Stack HCI-24H2 |
| AX-7525 | Windows Server 2022 Datacenter Windows Server 2025 Datacenter Azure Stack HCI-24H2 |
| AX-650 | Windows Server 2022 Datacenter Windows Server 2025 Datacenter Azure Stack HCI-24H2 |
| AX-750 | Windows Server 2022 Datacenter Windows Server 2025 Datacenter Azure Stack HCI-24H2 |
Base Components
| Component | Type | Software Bundle | Minimum Supported Version | Supported Platforms | Supported OS |
|---|---|---|---|---|---|
| BIOS | Firmware DUP | N5C9K | 2.27.0 | AX-640 AX-740xd | NA |
| BIOS | Firmware DUP | HJHHX | 2.24.1 | AX-6515 | NA |
| BIOS | Firmware DUP | RWK5K | 2.24.1 | AX-7525 | NA |
| BIOS | Firmware DUP | DCFN9 | 1.21.1 | AX-650 AX-750 | NA |
| iDRAC9 with Lifecycle Controller | Firmware DUP | FWMWV | 7.00.00.184 | AX-640 AX-740xd | NA |
| iDRAC9 with Lifecycle Controller | Firmware DUP | 924YT | 7.30.10.50 | AX-6515 AX-7525 AX-650 AX-750 | NA |
| Non-expander Storage Backplane | Firmware DUP | VV85D | 4.35 | AX-6515 AX-640 AX-740xd | NA |
| Non-expander Storage Backplane | Firmware DUP | G69W6 | 7.16 | AX-7525 AX-750 | NA |
| Non-expander Storage Backplane | Firmware DUP | 5DV1W | 7.16 | AX-650 | NA |
| NVMe Switch Storage Backplane | Firmware DUP | 5XJWN | 1.05 | AX-750 | NA |
| Expander Storage Backplane | Firmware DUP | H9PV3 | 1.20 | AX-7525 AX-750 | NA |
| Expander Storage Backplane | Firmware DUP | 60K1J | 2.52 | AX-640 AX-740xd | NA |
| Expander Storage Backplane | Firmware DUP | 2F90T | 2.46 | AX-6515 | NA |
| Chipset driver for 14G Intel platforms | Driver DUP | 4DDMJ | 10.1.19913.8607 | AX-640 AX-740xd | Windows Server 2022 Datacenter Azure Stack HCI-24H2 |
| Chipset driver for 15G AMD platforms | Driver DUP | GM2KH | 8.03.14.329 | AX-6515 AX-7525 | Windows Server 2022 Datacenter Windows Server 2025 Datacenter Azure Stack HCI-24H2 |
| Chipset driver for 15G Intel platforms | Driver DUP | C2MC3 | 10.1.19928.8615 | AX-650 AX-750 | Windows Server 2022 Datacenter Windows Server 2025 Datacenter Azure Stack HCI-24H2 |
| iDRAC Service Module | Firmware DUP | 238XW | 6.1.0.0 | AX-640 AX-740xd AX-6515 AX-7525 AX-650 AX-750 | NA |
| CPLD | Firmware DUP | 9N4DH | 1.0.6 | AX-640 | NA |
| CPLD | Firmware DUP | G65GH | 1.1.4 | AX-740xd | NA |
| CPLD | Firmware DUP | 79XGF | 1.0.7 | AX-6515 | NA |
| CPLD | Firmware DUP | 4NMC7 | 1.2.0 | AX-7525 | NA |
| CPLD | Firmware DUP | FCTDF | 1.1.1 | AX-650 AX-750 | NA |
Network Adapters
| Component | Part Number | SDDC Advanced Qualification | RDMA Protocol | Firmware Software Bundle | Firmware Minimum Supported Version | Driver Software Bundle | Driver Minimum Supported Version | Supported OS | Supported Platforms |
|---|---|---|---|---|---|---|---|---|---|
| Broadcom 57504 Quad Port 10/25GbE SFP28 Adapter, PCIe FH | J3D14 | Management Compute (Premium) Storage (Premium) | RoCEv2 | 2MY7D | 36.11.73.00 | 78X9T | 36.11.52.00 | Windows Server 2025 Datacenter Azure Stack HCI-24H2 | AX-4520c |
| Broadcom 57412 2 Port 10Gb SRP+ + 5720 2 Port 1 GB Base-T, rNDC | NWMNX | Management Compute (Standard) | Not Supported | 2MY7D | 36.11.73.00 | 78X9T | 36.11.52.00 | Windows Server 2022 Datacenter Windows Server 2025 Datacenter Azure Stack HCI-24H2 | AX-640 AX-740xd |
| Broadcom BCM57414 25G SFP Dual Port OCP3 Mezz, V3 | 24FG6 | Management Compute (Standard) | Not Supported | 2MY7D | 36.11.73.00 | 78X9T | 36.11.52.00 | Windows Server 2022 Datacenter Windows Server 2025 Datacenter Azure Stack HCI-24H2 | AX-6515 |
| Broadcom 57416 Dual Port 10 GbE SFP+ Network LOM Mezz Card | 6XH9X | ||||||||
| Broadcom 57414 Dual Port 25 Gb E SFP+ Network LOM Mezz Card | 930PP | ||||||||
| Broadcom 57416 Dual Port 10 GbE BaseT Network LOM Mezz Card | J4RN3 | ||||||||
| Broadcom BCM57414 25G SFP Dual Port OCP3 Mezz | NHN45 | ||||||||
| Broadcom 57416 Dual Port 10 Gb E SFP+ Network LOM Mezz Card | WC9TR | ||||||||
| Broadcom 57412 Dual Port 10GbE SFP+, OCP NIC 3.0 | CP610 | Management Compute (Standard) | Not Supported | 2MY7D | 36.11.73.00 | 78X9T | 36.11.52.00 | Windows Server 2022 Datacenter Windows Server 2025 Datacenter Azure Stack HCI-24H2 | AX-7525 AX-650 AX-750 |
| Broadcom 57414 Dual Port 10/25GbE SFP28, OCP NIC 3.0 | KHCTP | ||||||||
| Broadcom 57416 Dual Port 10GbE BASE-T Adapter, OCP NIC 3.0 | T6HR8 | ||||||||
| Broadcom 57504 Quad Port 10/25GbE,SFP28, OCP NIC 3.0 | X1KR4 | ||||||||
| Broadcom 5720 Dual Port 1GbE On-Board LOM | JDN4V | Management | NA | 32W7Y | 23.61.3 | WYPPJ | 23.21.5 | Windows Server 2022 Datacenter Windows Server 2025 Azure Stack HCI-24H2 | AX-650 |
| Broadcom 5720 Dual Port 1 GbE Network LOM Mezz Card | KJMHJ | Management | N/A | 32W7Y | 23.61.3 | WYPPJ | 23.21.5 | Windows Server 2022 Datacenter Windows Server 2025 Azure Stack HCI-24H2 | AX-6515 |
| Broadcom 5720 Dual Port 1GbE On-Board LOM | 6V45N | Management | NA | 32W7Y | 23.61.3 | WYPPJ | 23.21.5 | Windows Server 2022 Datacenter Windows Server 2025 Azure Stack HCI-24H2 | AX-750 |
| Broadcom 5720 Dual Port 1GbE On-Board LOM | 74H08 | Management | NA | 32W7Y | 23.61.3 | WYPPJ | 23.21.5 | Windows Server 2022 Datacenter Windows Server 2025 Azure Stack HCI-24H2 | AX-7525 |
| Intel E823 | KJMHJ | Management Compute (Premium) Storage (Premium) | iWARP,RoCEv2 | FCG2V | 25.0.4 | 3VT4C | 25.0.4 | Windows Server 2022 Datacenter Windows Server 2025 Datacenter Azure Stack HCI-24H2 | AX-4510c AX-4520c |
| Intel E810-XXV Dual Port 25GbE SFP28 Adapter, PCIe LP | 6J1N1 | Management Compute (Premium) Storage (Premium) | iWARP,RoCEv2 | FCG2V | 25.0.4 | 3VT4C | 25.0.4 | Windows Server 2022 Datacenter Windows Server 2025 Datacenter Azure Stack HCI-24H2 | AX-7525 AX-650 AX-750 |
| Intel E810-CQDA2 Dual Port 100GbE QSFP28 Adapter, PCIe FH | 85F8F | ||||||||
| Intel E810-XXV Dual Port 25GbE SFP28 Adapter, PCIe FH | CD16M | ||||||||
| Intel E810-CQDA2 Dual Port 100GbE QSFP28 Adapter, PCIe LP | DWNRF | ||||||||
| Intel X710 DP 10Gb DA/SFP+ Ethernet, NDC | 6VDPG | Management Compute (Standard) | N/A | PJDHV | 25.0.4 | 3VT4C | 25.0.4 | Windows Server 2022 Datacenter Windows Server 2025 Datacenter Azure Stack HCI-24H2 | AX-640 AX-740xd |
| Intel X710-T4L Quad Port 10GbE BASE-T, OCP NIC 3.0 | 50RV4 | Management Compute (Standard) | N/A | PJDHV | 25.0.4 | 3VT4C | 25.0.4 | Windows Server 2022 Datacenter Windows Server 2025 Datacenter Azure Stack HCI-24H2 | AX-7525 AX-650 AX-750 |
| Intel(R) Ethernet 10G 4P X710-T4L-t Adapter | ND4PT | ||||||||
| Intel X710 Quad Port 10GbE SFP+, OCP NIC 3.0 | VF81P | ||||||||
| Intel X710-T2L Dual Port 10GbE BASE-T, OCP NIC 3.0 | VMFKR | ||||||||
| Intel X710 Dual Port 10GbE SFP+, OCP NIC 3.0 | YJYK1 | ||||||||
| Mellanox ConnectX-6 Dx Dual Port 100GbE QSFP56 PCIe Adapter, LP | F6FXM | Management Compute (Premium) Storage (Premium) | RoCEv2 | 81T4K | 22.48.10.00 | 3T3MK | 26.001.03 | Windows Server 2022 Datacenter Windows Server 2025 Datacenter Azure Stack HCI-24H2 | AX-6515 AX-7525 AX-650 AX-750 |
| Mellanox ConnectX-6 Dx Dual Port 100GbE QSFP56 PCIe Adapter, FH | 8P2T2 | Management Compute (Premium) Storage (Premium) | RoCEv2 | 81T4K | 22.48.10.00 | 3T3MK | 26.001.03 | Windows Server 2022 Datacenter Windows Server 2025 Datacenter Azure Stack HCI-24H2 | AX-7525 AX-650 AX-750 |
| Mellanox ConnextX-4 Lx Dual Port 25Gbe DA/SFP Network Adapter, LP | 20NJD | Management Compute (Premium) Storage (Premium) | RoCEv2 | N62GF | 14.32.21.04 | 3T3MK | 26.001.03 | Windows Server 2022 Datacenter Windows Server 2025 Datacenter Azure Stack HCI-24H2 | AX-640 AX-740xd |
| Mellanox ConnectX-4 Lx Dual Port 25GbE DA/SFP rNDC | R887V | Management Compute (Premium) Storage (Premium) | RoCEv2 | N62GF | 14.32.21.04 | 3T3MK | 26.001.03 | Windows Server 2022 Datacenter Windows Server 2025 Datacenter Azure Stack HCI-24H2 | AX-640 R640 Storage Spaces Direct RN |
| Mellanox ConnextX-4 Lx Dual Port 25Gbe DA/SFP Network Adapter, FH | MRT0D | Management Compute (Premium) Storage (Premium) | RoCEv2 | N62GF | 14.32.21.04 | 3T3MK | 26.001.03 | Windows Server 2022 Datacenter Windows Server 2025 Datacenter Azure Stack HCI-24H2 | AX-740xd |
| Mellanox ConnectX-4 LX Dual Port 10/25GbE SFP28 Adapter, FH, V2 | YGRX3 | ||||||||
| Mellanox Connectx-5 EX Dual Port 100GbE QSFP20 PCIe Adapter, FH | 71C1T | Management Compute (Premium) Storage (Premium) | RoCEv2 | P5F14 | 16.35.80.02 | 3T3MK | 26.001.03 | Windows Server 2022 Datacenter Windows Server 2025 Datacenter Azure Stack HCI-24H2 | AX-6515 AX-7525 AX-640 AX-740xd AX-650 AX-750 |
| Mellanox Connectx-5 EX Dual Port 100GbE QSFP20 PCIe Adapter, LP | 9FTMY | ||||||||
| Mellanox ConnectX-5 Dual Port 10/25GbE SFP28 Adapter, PCIe FH, V2 | F7V1F | ||||||||
| Mellanox ConnectX-5 Dual Port 10/25GbE SFP28 Adapter, PCIe LP, V2 | JGWVY | ||||||||
| Mellanox ConnectX-5 Dual Port 25GbE SFP28 Adapter, FH | TDNNT | ||||||||
| Mellanox ConnectX-5 Dual Port 25GbE SFP28 Adapter, LP | V5DG9 | ||||||||
| NVIDIA ConnectX-6LX Dual Port 25G GbE SFP28 | DN78C | Management Compute (Premium) Storage (Premium) | RoCEv2 | NMDJG | 26.48.10.00 | 3T3MK | 26.001.03 | Windows Server 2022 Datacenter Windows Server 2025 Datacenter Azure Stack HCI-24H2 | AX-650 AX-750 AX-7525 |
| Nvidia ConnectX-6 Lx Dual Port 10/25GbE SFP28 Adapter, PCIe LP | 6XJXK | Management Compute (Premium) Storage (Premium) | RoCEv2 | NMDJG | 26.48.10.00 | 3T3MK | 26.001.03 | Windows Server 2022 Datacenter Windows Server 2025 Datacenter Azure Stack HCI-24H2 | AX-6515 AX-7525 AX-650 AX-750 |
| Nvidia ConnectX-6 Lx Dual Port 10/25GbE SFP28 Adapter, PCIe FH | R5WK9 | ||||||||
| QLogic 57800 2x10Gb DA/SFP+ +2x1Gb BT NDC | 165T0 | Management | N/A | 9KYR0 | 16.20.00 | VYWY1 | 36.20.02 | Windows Server 2022 Datacenter Azure Stack HCI-24H2 | AX-640 AX-740xd |
| QLogic 57800 2x10Gb BT + 2x1Gb BT NDC | G8RPD | ||||||||
| QLogic FastLinQ 41162 Dual Port 10GbE BASE-T and Dual Port 1GbE BASE-T, rNDC | 0D1WT | Management Compute (Premium) | iWARP | W93NY | 16.30.09 | RXJPP | 36.30.16 | Windows Server 2022 Datacenter Windows Server 2025 Datacenter Azure Stack HCI-24H2 | AX-640 AX-740xd |
| QLogic FastLinQ 41164 Quad Port 10GbE BASE-T, rNDC | X1TD1 | Management Compute (Premium) | iWARP | W93NY | 16.30.09 | RXJPP | 36.30.16 | Windows Server 2022 Datacenter Windows Server 2025 Datacenter Azure Stack HCI-24H2 | AX-6515 AX-7525 AX-640 AX-740xd AX-650 AX-750 |
| QLogic FastLinQ 41164 Quad Port 10GbE SFP+, rNDC | XVVY1 | ||||||||
| QLogic FastLinQ 41262 Dual Port 25Gb SFP28 Adapter, LP | 415DX | Management Compute (Premium) Storage (Premium) | iWARP | W93NY | 16.30.09 | RXJPP | 36.30.16 | Windows Server 2022 Datacenter Windows Server 2025 Datacenter Azure Stack HCI-24H2 | AX-6515 AX-7525 AX-640 AX-740xd |
| QLogic FastLinQ 41262 Dual Port 25Gbe SFP28, rNDC | 4KF8J | ||||||||
| QLogic FastLinQ 41262 Dual Port 25Gb SFP28 Adapter, FH | 51GRM |
Network Switches
NOTE
A list of supported Network Switch models along with the supported firmware versions can be found here, Physical network requirements for Azure Local.GPUs
| GPU Model | Vendor | Description | Part Number | Firmware version | Driver Version | GPU-P capable | Supported Platform | Supported OS |
|---|---|---|---|---|---|---|---|---|
| A10 | NVIDIA | NVIDIA Ampere A10, PCIe, 150W, 24GB,GPU, V2 | 6KNWW | 94.02.5C.00.04 | 528.89 WHQL | Yes | AX-750 AX-7525 | Windows Server 2025 Datacenter Azure Stack HCI-24H2 |
| A16 | NVIDIA | NVIDIA Ampere A16, PCIe, 250W, 64GB Passive, Double Wide, Full Height GPU | 8F04V | 94.07.54.00.45 | 528.89 WHQL | Yes | AX-750 AX-7525 | Windows Server 2025 Datacenter Azure Stack HCI-24H2 |
| A16 | NVIDIA | NVIDIA Ampere A16, PCIe, 250W, 64GB Passive, Double Wide, Full Height GPU,V2 | D1P1T | 94.07.54.00.45 | 528.89 WHQL | Yes | AX-750 AX-7525 | Windows Server 2025 Datacenter Azure Stack HCI-24H2 |
| A2 | NVIDIA | NVIDIA Ampere A2, PCIe, 60W, 16GB Passive, Single Wide, Low Profile GPU, V2 | H98K0 | 94.07.5B.00.55 | 528.89 WHQL | Yes | AX-650 AX-750 AX-7525 | Windows Server 2025 Datacenter Azure Stack HCI-24H2 |
| A2 | NVIDIA | NVIDIA Ampere A2, PCIe, 60W, 16GB Passive, Single Wide, Full Height GPU, V2 | MG5JX | 94.07.5B.00.55 | 528.89 WHQL | Yes | AX-750 AX-7525 | Windows Server 2025 Datacenter Azure Stack HCI-24H2 |
| A30 | NVIDIA | NVIDIA Ampere A30, PCIe, 165W, 24GB Passive, Double Wide, Full Height GPU | W3C1G | 92.00.58.00.01 | 528.89 WHQL | No | AX-750 AX-7525 | Windows Server 2025 Datacenter Azure Stack HCI-24H2 |
| A30 | NVIDIA | NVIDIA Ampere A30, PCIe, 165W, 24GB Passive, Double Wide, Full Height GPU, V2 | RV08M | 92.00.58.00.01 | 528.89 WHQL | No | AX-750 AX-7525 | Windows Server 2025 Datacenter Azure Stack HCI-24H2 |
| A40 | NVIDIA | NVIDIA Ampere A40, PCIe, 300W, 48GB Passive, Double Wide, Full Height GPU | W6GX6 | 94.02.5C.00.0F | 528.89 WHQL | Yes | AX-750 AX-7525 | Windows Server 2025 Datacenter Azure Stack HCI-24H2 |
| L4 | NVIDIA | NVIDIA L4, PCIe, 72W, 24GB Passive, Single Wide Low Profile GPU | V9XT2 | 95.04.29.00.06 | 528.89 WHQL | Yes | AX-650 AX-750 AX-7525 | Windows Server 2025 Datacenter Azure Stack HCI-24H2 |
| L4 | NVIDIA | NVIDIA L4, PCIe, 72W, 24GB Passive, Single Wide Full Height GPU | NG3PY | 95.04.29.00.06 | 528.89 WHQL | Yes | AX-750 AX-7525 | Windows Server 2025 Datacenter Azure Stack HCI-24H2 |
| L40 | NVIDIA | NVIDIA Ampere L40, PCIe, 300W, 48GB Passive, Double Wide, Full Height, Full Length, GPU with cable | VHNWT | 95.02.39.00.01 | 553.62 | Yes | AX-750 AX-7525 | Windows Server 2025 Datacenter Azure Stack HCI-24H2 |
| T4 | NVIDIA | NVIDIA Tesla T4 16GB, PCIe, 70W, 16GB Passive, Single Wide, Full Height GPU | HCKJM | 90.04.96.00.01 | 528.89 WHQL | No | AX-750 | Windows Server 2025 Datacenter Azure Stack HCI-24H2 |
| T4 | NVIDIA | NVIDIA Tesla T4 16GB, PCIe, 70W, Passive, Single Wide, Low Profile GPU | 7PH29 | 90.04.96.00.01 | 528.89 WHQL | No | AX-750 | Windows Server 2025 Datacenter Azure Stack HCI-24H2 |
NOTE
Dell update packages are not available for GPU cards, please download the latest driver version from NVIDIA driver download page.Storage Controllers
| Component | Dell Part Number | Firmware Software Bundle | Firmware Minimum Supported Version | Driver Software Bundle | Driver Minimum Supported Version | Supported Platforms | Supported OS |
|---|---|---|---|---|---|---|---|
| BOSS-S1 | 2MFVD | 3P39V | 2.5.13.3024 | 7004G | 1.2.0.1055 | AX-6515 AX-7525 AX-640 AX-740xd | Windows Server 2022 Datacenter Azure Stack HCI-24H2 |
| BOSS-S2 | FGNRW | TTR5R | 2.5.13.4009 | 7004G | 1.2.0.1055 | AX-7525 AX-650 AX-750 | Windows Server 2022 Datacenter Azure Stack HCI-24H2 |
| HBA330 Controller, 12Gps Mini Card | P2R3R | 124X2 | 16.17.01.00 | Inbox | 2.51.27.80 | AX-640 AX-740XD AX-6515 | Windows Server 2022 Datacenter Azure Stack HCI-24H2 |
| HBA330 Controller, 12Gps Mini Card, LP | J7TNV | NKNVC | 16.17.01.00 | Inbox | 2.51.27.80 | AX-740xd | Windows Server 2022 Datacenter Azure Stack HCI-24H2 |
| HBA355i | K6MCJ | CG0P9 | 33.15.00.00 | R31NP | 2.61.74.00 | AX-7525 AX-650 AX-750 | Windows Server 2022 Datacenter |
| HBA355i | K6MCJ | CG0P9 | 33.15.00.00 | HDH8G | 2.61.74.00 | AX-7525 AX-650 AX-750 | Windows Server 2025 Datacenter Azure Stack HCI-24H2 |
SATA M.2 SSD Boot Only
| Type | Drive Type | Form Factor | Endurance | Vendor | Series | Model | Device Part Number (P/N) | Firmware Software Bundle | Firmware Minimum Supported Version | Capacity | Use |
|---|---|---|---|---|---|---|---|---|---|---|---|
| SSD | SATA | M.2 | NA | Intel | S3520 | SSDSC2BB120G7R | 394XT | CHJGV | DL43 | 120 GB | Boot |
| SSD | SATA | M.2 | NA | Micron | 5100 | MTFDDAV240TCB | TC2RP | H6NHD | E013 | 240 GB | Boot |
| SSD | SATA | M.2 | NA | Micron | 5100 | MTFDDAV480TCB | GPGC0 | H6NHD | E013 | 480 GB | Boot |
| SSD | SATA | M.2 | NA | Micron | 5300 | MTFDDAV240TDU | T2GFX | KT63Y | J008 | 240 GB | Boot |
| SSD | SATA | M.2 | NA | Micron | 5300 | MTFDDAV480TDS | 7RKD7 | KT63Y | J008 | 480 GB | Boot |
| SSD | SATA | M.2 | Read Intensive | Intel | Youngsville RR S4520 | SSDSCKKB240GZR | CM88M | VJPKG | DL7C | 240 GB | Boot |
| SSD | SATA | M.2 | Read Intensive | Intel | Youngsville S4510 | SSDSCKKB240G8R | DMC15 | Y1P10 | DL6R | 240 GB | Boot |
| SSD | SATA | M.2 | Read Intensive | Micron | 5400 | MTFDDAV240TGC-1BC1ZABDA | T4MJ3 | RJ0WY | K003 | 240 GB | Boot |
SAS 2.5" HDD Capacity Only
| Type | Drive Type | Form Factor | Endurance | Vendor | Series | Model | Device Part Number (P/N) | Firmware Software Bundle | Firmware Minimum Supported Version | Capacity | Use |
|---|---|---|---|---|---|---|---|---|---|---|---|
| HDD | SAS | 2.5 | NA | Seagate | Avenger | ST2000NX0463 | TMVN7 | GW3V7 | NT32 | 2 TB | Capacity |
| HDD | SAS | 2.5 | NA | Seagate | Skybolt | DL2400MM0159 | RWR8F | DRHV4 | ST5J | 2.4 TB | Capacity |
| HDD | SAS | 2.5 | NA | Seagate | Skybolt | ST2400MM0159 | 36YG1 | 7N5DH | ST7G | 2.4 TB | Capacity |
| HDD | SAS | 2.5 | NA | Toshiba | AL15SE | AL15SEB24EQY | F9NWJ | J11N2 | EF09 | 2.4 TB | Capacity |
| HDD | SAS | 2.5 | NA | Seagate | Skybolt ServoBP | BL2400MM0159 | 1D0F5 | 00P56 | SBSA | 2.4 TB | Capacity |
SATA 2.5" HDD Capacity Only
| Type | Drive Type | Form Factor | Endurance | Vendor | Series | Model | Device Part Number (P/N) | Firmware Software Bundle | Firmware Minimum Supported Version | Capacity | Use |
|---|---|---|---|---|---|---|---|---|---|---|---|
| HDD | SATA | 2.5 | NA | Seagate | Avenger | ST2000NX0423 | VR92X | GMW4P | NB33 | 2 TB | Capacity |
SATA 3.5" HDD Capacity Only
| Type | Drive Type | Form Factor | Endurance | Vendor | Series | Model | Device Part Number (P/N) | Firmware Software Bundle | Firmware Minimum Supported Version | Capacity | Use |
|---|---|---|---|---|---|---|---|---|---|---|---|
| HDD | SATA | 3.5 | NA | HGST | Aries K Plus | HUS726020ALA610 | 8NP2N | KH52Y | KV46 | 2 TB | Capacity |
| HDD | SATA | 3.5 | NA | HGST | Aries K Plus | HUS726040ALA610 | 61FFW | KH52Y | KV46 | 4 TB | Capacity |
| HDD | SATA | 3.5 | NA | HGST | Rainier MLK | HUS722T2TALA600 | V9H6C | V3DJM | MU03 | 2 TB | Capacity |
| HDD | SATA | 3.5 | NA | Toshiba | Tomcat R | MG04ACA200NY | NPVM6 | 6D4CG | FK5D | 2 TB | Capacity |
| HDD | SATA | 3.5 | NA | Toshiba | Tomcat R | MG04ACA400NY | 95M6K | 6D4CG | FK5D | 4 TB | Capacity |
| HDD | SATA | 3.5 | NA | Seagate | Nemo | ST2000NM0018-2F3 | W8FW5 | CMK5N | EA04 | 2 TB | Capacity |
| HDD | SATA | 3.5 | NA | Seagate | Makara BP | ST2000NM0145-2DC | WG9R0 | M5GJ1 | DB34 | 2 TB | Capacity |
| HDD | SATA | 3.5 | NA | Seagate | Makara BP | ST4000NM0265-2DC | MWHY9 | M5GJ1 | DB34 | 4 TB | Capacity |
| HDD | SATA | 3.5 | NA | HGST | Vela-A | HUS726T4TALA6L0 | YH3T9 | HV5HH | PV09 | 4 TB | Capacity |
| HDD | SATA | 3.5 | NA | HGST | Vela-AP | HUS728T8TALE6L0 | 1WMVC | T0RX4 | RT09 | 8 TB | Capacity |
| HDD | SATA | 3.5 | NA | HGST | Libra HE10 | HUH721008ALE600 | KRV2W | H12N2 | LT21 | 8 TB | Capacity |
| HDD | SATA | 3.5 | NA | Seagate | Makara Plus | ST8000NM0205-2FF | 92MDW | MR6RH | PB53 | 8 TB | Capacity |
| HDD | SATA | 3.5 | NA | Toshiba | MG06 | MG06ACA800EY | 9X09C | PT7D8 | GA09 | 8 TB | Capacity |
| HDD | SATA | 3.5 | NA | HGST | Leo-A He12 | HUH721212ALE600 | T2YHT | JCYF6 | NT11 | 12 TB | Capacity |
| HDD | SATA | 3.5 | NA | Toshiba | MG07 | MG07ACA12TEY | 753F0 | 0942Y | GB03 | 12 TB | Capacity |
| HDD | SATA | 3.5 | NA | Toshiba | MG08AC | MG08ACA16TEY | HPGJ4 | 3FWPH | GC05 | 16 TB | Capacity |
| HDD | SATA | 3.5 | NA | Toshiba | MG08AD | MG08ADA400NY | W2M9N | NK38K | GD06 | 4 TB | Capacity |
| HDD | SATA | 3.5 | NA | Seagate | Cimarron | ST4000NM016A-2HZ | XPJ47 | RWK48 | CAJD | 4 TB | Capacity |
| HDD | SATA | 3.5 | NA | Seagate | Cimarron | ST8000NM012A-2KE | F4JXT | TF6TF | CALF | 8 TB | Capacity |
| HDD | SATA | 3.5 | NA | Seagate | Evans BP | ST12000NM002J-2T | KTJTY | 4MPD6 | PALB | 12 TB | Capacity |
| HDD | SATA | 3.5 | NA | Seagate | Evans BP | ST16000NM002J-2T | JWV1P | 4MPD6 | PALB | 16 TB | Capacity |
| HDD | SATA | 3.5 | NA | Toshiba | MG08AD | MG08ADA800EY | T5XR5 | 2HN47 | GE04 | 8 TB | Capacity |
| HDD | SATA | 3.5 | NA | Seagate | Cimarron BP | ST8000NM023B-2TJ | J7W80 | P183W | LA0C | 8 TB | Capacity |
| HDD | SATA | 3.5 | NA | Seagate | Cimarron BP | ST4000NM018B-2TF | 6KR2M | T04YV | LC0A | 4 TB | Capacity |
| HDD | SATA | 3.5 | NA | Seagate | Cimarron BP | ST8000NM023B-2TJ | J7W80 | P183W | LA0C | 8 TB | Capacity |
SAS 3.5" HDD Capacity Only
| Type | Drive Type | Form Factor | Endurance | Vendor | Series | Model | Device Part Number (P/N) | Firmware Software Bundle | Firmware Minimum Supported Version | Capacity | Use |
|---|---|---|---|---|---|---|---|---|---|---|---|
| HDD | SAS | 3.5 | NA | HGST | Aries K Plus | HUS726020ALS210 | VH6FW | 8W7XP | KU46 | 2 TB | Capacity |
| HDD | SAS | 3.5 | NA | HGST | Aries K Plus | HUS726040ALS210 | X4FKY | 8W7XP | KU46 | 4 TB | Capacity |
| HDD | SAS | 3.5 | NA | Toshiba | Tomcat R | MG04SCA20ENY | HHX14 | RG9MK | EG03 | 2 TB | Capacity |
| HDD | SAS | 3.5 | NA | Toshiba | Tomcat R | MG04SCA40ENY | 1MVTT | RG9MK | EG03 | 4 TB | Capacity |
| HDD | SAS | 3.5 | NA | Seagate | Makara BP | ST2000NM0155 | 7RCGV | XKD4M | DT34 | 2 TB | Capacity |
| HDD | SAS | 3.5 | NA | Seagate | Makara BP | ST4000NM0295 | 5JH5X | XKD4M | DT34 | 4 TB | Capacity |
| HDD | SAS | 3.5 | NA | HGST | Vela-A | HUS726T4TALS200 | NT1X2 | J5K8G | PU09 | 4 TB | Capacity |
| HDD | SAS | 3.5 | NA | HGST | Vela-AP | HUS728T8TAL5200 | 44YFV | 8GM6M | RS09 | 8 TB | Capacity |
| HDD | SAS | 3.5 | NA | HGST | Libra HE10 | HUH721008AL5200 | KRDKK | MGW91 | LS21 | 8 TB | Capacity |
| HDD | SAS | 3.5 | NA | Seagate | Makara Plus | ST8000NM0185 | M40TH | 6421F | PT55 | 8 TB | Capacity |
| HDD | SAS | 3.5 | NA | Toshiba | MG06 | MG06SCA800EY | FV725 | 4G5GY | EH0D | 8 TB | Capacity |
| HDD | SAS | 3.5 | NA | HGST | Leo-A He12 | HUH721212AL5200 | 9HXK6 | 04PM5 | NS11 | 12 TB | Capacity |
| HDD | SAS | 3.5 | NA | Seagate | Mobula BP | ST12000NM0158 | YMN53 | VTX9C | RSL5 | 12 TB | Capacity |
| HDD | SAS | 3.5 | NA | Toshiba | MG07 | MG07SCA12TEY | DK7C9 | NFFHM | EI0D | 12 TB | Capacity |
| HDD | SAS | 3.5 | NA | Toshiba | MG07 | MG07SCA12TEY | KFJ7G | NFFHM | EI0D | 12 TB | Capacity |
| HDD | SAS | 3.5 | NA | Toshiba | MG09 | MG09SCA12TEY | 0N96X | 20Y02 | EM06 | 12 TB | Capacity |
| HDD | SAS | 3.5 | NA | Toshiba | MG08SC | MG08SCA16TEY | 8MG73 | 9N3RR | EJ09 | 16 TB | Capacity |
| HDD | SAS | 3.5 | NA | Toshiba | MG08SC | MG08SCA16TEY | 4N7V0 | 9N3RR | EJ09 | 16 TB | Capacity |
| HDD | SAS | 3.5 | NA | Toshiba | MG08SC | MG08SCA16TEY | 24HF9 | 9N3RR | EJ09 | 16 TB | Capacity |
| HDD | SAS | 3.5 | NA | Seagate | Evans | ST16000NM010G | CNXPV | 3YP54 | ESL9 | 16 TB | Capacity |
| HDD | SAS | 3.5 | NA | WD | Paris-C | WUH721816AL5200 | VF206 | GY6MD | US09 | 16 TB | Capacity |
| HDD | SAS | 3.5 | NA | Seagate | Cimarron | ST4000NM017A | KRM6X | J12RT | CSJA | 4 TB | Capacity |
| HDD | SAS | 3.5 | NA | Seagate | Cimarron | ST8000NM014A | 0N660 | 0HG6Y | CSLE | 8 TB | Capacity |
| HDD | SAS | 3.5 | NA | Seagate | Cimarron BP | ST4000NM019B | 10N7R | 3P5N0 | LW0B | 4 TB | Capacity |
| HDD | SAS | 3.5 | NA | Seagate | Cimarron BP | ST8000NM024B | C5HD0 | NM6GP | LS0C | 8 TB | Capacity |
| HDD | SAS | 3.5 | NA | Toshiba | MG08SD | MG08SDA400NY | FN2YX | GTG81 | EK06 | 4 TB | Capacity |
| HDD | SAS | 3.5 | NA | Seagate | Evans BP | ST12000NM006J | M1C0T | XF65R | PSLG | 12 TB | Capacity |
| HDD | SAS | 3.5 | NA | Seagate | Evans BP | ST16000NM006J | 41DXR | XF65R | PSLG | 16 TB | Capacity |
| HDD | SAS | 3.5 | NA | Toshiba | MG08SD | MG08SDA800EY | NJWMG | F95CX | EL02 | 8 TB | Capacity |
| HDD | SAS | 3.5 | NA | Seagate | Cimarron BP | ST8000NM024B | C5HD0 | NM6GP | LS0C | 8 TB | Capacity |
| HDD | SAS | 3.5 | NA | Seagate | EvansBP | ST16000NM006J | 41DXR | XF65R | PSLG | 16 TB | Capacity |
| HDD | SAS | 3.5 | NA | Seagate | LongsPeak | ST20000NM004D | R3G03 | WCTTD | GS09 | 20 TB | Capacity |
| HDD | SAS | 3.5 | NA | Toshiba | MG10SD | MG10SDA800EY | VJDMM | 99TKP | EP02 | 8 TB | Capacity |
| HDD | SAS | 3.5 | NA | WD | Paris-CP | WUH722012CL5200 | 849H4 | VK0PK | AS05 | 12TB | Capacity |
| HDD | SAS | 3.5 | NA | WD | Paris-CP | WUH722016CL5200 | H8HN1 | VK0PK | AS05 | 16 TB | Capacity |
| HDD | SAS | 3.5 | NA | Toshiba | MG11SC | MG11SCA16TEY | GGWNH | 9GW4N | ES02 | 16 TB | Capacity |
| HDD | SAS | 3.5 | NA | Toshiba | MG11SC | MG11SCA20TEY | 2FX1T | 9GW4N | ES02 | 20 TB | Capacity |
SATA 2.5" SSD Cache or Capacity
| Type | Drive Type | Form Factor | Endurance | Vendor | Series | Model | Device Part Number (P/N) | Firmware Software Bundle | Firmware Minimum Supported Version | Capacity | Use |
|---|---|---|---|---|---|---|---|---|---|---|---|
| SSD | SATA | 2.5 | Mixed Use | Intel | Youngsville-RR | SSDSC2KG019TZR | 8RXV5 | VJPKG | DL7C | 1.92 TB | Cache, Capacity |
| SSD | SATA | 2.5 | Mixed Use | Toshiba | HK4 | THNSF8800CCSE | VCRY6 | H3XHN | DACB | 800 GB | Cache, Capacity |
| SSD | SATA | 2.5 | Mixed Use | Toshiba | HK4 | THNSF81D60CSE | DMF5Y | H3XHN | DACB | 1.6 TB | Cache, Capacity |
| SSD | SATA | 2.5 | Mixed Use | Micron | 5300 | MTFDDAK960TDT | XMWMK | KT63Y | J008 | 960 GB | Cache, Capacity |
| SSD | SATA | 2.5 | Mixed Use | Micron | 5300 | MTFDDAK1T9TDT | MMCDY | KT63Y | J008 | 1.92 TB | Cache, Capacity |
| SSD | SATA | 2.5 | Mixed Use | Micron | 5400 | MTFDDAK3T8TGB-1B | 34JK8 | JTW3W | K403 | 3.84 TB | Cache,Capacity |
| SSD | SATA | 2.5 | Mixed Use | Samsung | SM863a | MZ7KM960HMJP0D3 | DD4G0 | 97D8J | GD57 | 960 GB | Cache, Capacity |
| SSD | SATA | 2.5 | Mixed Use | Samsung | SM863a | MZ7KM1T9HMJP0D3 | K5P0T | 97D8J | GD57 | 1.92 TB | Cache, Capacity |
| SSD | SATA | 2.5 | Mixed Use | Samsung | SM883 | MZ7KH960HAJR0D3 | YDHYX | 3J3JR | HF58 | 960 GB | Cache, Capacity |
| SSD | SATA | 2.5 | Mixed Use | Samsung | SM883 | MZ7KH1T9HAJR0D3 | 71K37 | 3J3JR | HF58 | 1.92 TB | Cache, Capacity |
| SSD | SATA | 2.5 | Mixed Use | Intel | S4600 | SSDSC2KG960G7R | TR3MY | V141M | DL5C | 960 GB | Cache, Capacity |
| SSD | SATA | 2.5 | Mixed Use | Intel | S4600 | SSDSC2KG019T7R | MWKF2 | V141M | DL5C | 1.92 TB | Cache, Capacity |
| SSD | SATA | 2.5 | Mixed Use | Intel | S4610 | SSDSC2KG960G8R | X31G3 | 4DW70 | DL6B | 960 GB | Cache, Capacity |
| SSD | SATA | 2.5 | Mixed Use | Intel | S4610 | SSDSC2KG019T8R | F8N2K | 4DW70 | DL6B | 1.92 TB | Cache, Capacity |
| SSD | SATA | 2.5 | Mixed Use | Intel | S4610 | SSDSC2KG019T8R | 55J8H | 4DW70 | DL6B | 1.92 TB | Cache, Capacity |
| SSD | SATA | 2.5 | Mixed Use | Micron | 5200 | MTFDDAK960TDN | HY1F8 | W2X8N | F005 | 960 GB | Cache, Capacity |
| SSD | SATA | 2.5 | Mixed Use | Micron | 5200 | MTFDDAK1T9TDN | XKF5Y | W2X8N | F005 | 1.92 TB | Cache, Capacity |
| SSD | SATA | 2.5 | Mixed Use | Kioxia | HK6-V | KHK6YVSE960G | XW4D1 | W0YR1 | DBC4 | 960 GB | Cache, Capacity |
| SSD | SATA | 2.5 | Mixed Use | Kioxia | HK6-V | KHK6YVSE1T92 | 0DXJ7 | W0YR1 | DBC4 | 1.92 TB | Cache, Capacity |
| SSD | SATA | 2.5 | Mixed Use | Hynix | SE5130 | HFS960G3E2X149N | G162V | 17C3M | DG02 | 960 GB | Cache,Capacity |
| SSD | SATA | 2.5 | Mixed Use | Hynix | SE5130 | HFS1T9G3E2X149N | HCR09 | 17C3M | DG02 | 1.92 TB | Cache,Capacity |
| SSD | SATA | 2.5 | Mixed Use | Intel | Youngsville-RR | SSDSC2KG960GZR | 8MHYH | VJPKG | DL7C | 960 GB | Cache,Capacity |
| SSD | SATA | 2.5 | Mixed Use | Intel | Youngsville-RR | SSDSC2KG019TZR | 8RXV5 | VJPKG | DL7C | 1.92 TB | Cache,Capacity |
| SSD | SATA | 2.5 | Mixed Use | Intel | Youngsville RR (New) (S4620) | SSDSC2KG960GZR | DYMD0 | VJPKG | DL7C | 960 GB | Cache,Capacity |
| SSD | SATA | 2.5 | Mixed Use | Intel | Youngsville RR (New) (S4620) | SSDSC2KG019TZR | 6XW3M | VJPKG | DL7C | 1.92 TB | Cache,Capacity |
| SSD | SATA | 2.5 | Mixed Use | Samsung | PM897 | MZ7L3960HBLTAD3 | 96KT6 | VRG4Y | HH64 | 960 GB | Cache,Capacity |
| SSD | SATA | 2.5 | Mixed Use | Samsung | PM897 | MZ7L31T9HBNAAD3 | RRR7M | VRG4Y | HH64 | 1.92 TB | Cache,Capacity |
SATA 2.5" SSD Capacity Only
| Type | Drive Type | Form Factor | Endurance | Vendor | Series | Model | Device Part Number (P/N) | Firmware Software Bundle | Firmware Minimum Supported Version | Capacity | Use |
|---|---|---|---|---|---|---|---|---|---|---|---|
| SSD | SATA | 2.5 | Read Intensive | Intel | Youngsville-RR | SSDSC2KB960GZR | F6H8H | VJPKG | DL7C | 960 GB | Capacity |
| SSD | SATA | 2.5 | Read Intensive | Intel | Youngsville-RR | SSDSC2KB019TZR | VYYW8 | VJPKG | DL7C | 1.92 TB | Capacity |
| SSD | SATA | 2.5 | Read Intensive | Intel | Youngsville-RR | SSDSC2KB038TZR | WNPN1 | VJPKG | DL7C | 3.84 TB | Capacity |
| SSD | SATA | 2.5 | Read Intensive | Intel | Youngsville RR (New) (S4520) | SSDSC2KB960GZR | 5M8Y4 | VJPKG | DL7C | 960 GB | Capacity |
| SSD | SATA | 2.5 | Read Intensive | Intel | Youngsville RR (New) (S4520) | SSDSC2KB019TZR | 6J65H | VJPKG | DL7C | 1.92 TB | Capacity |
| SSD | SATA | 2.5 | Read Intensive | Intel | Youngsville RR (New) (S4520) | SSDSC2KB038TZR | KM4C4 | VJPKG | DL7C | 3.84 TB | Capacity |
| SSD | SATA | 2.5 | Read Intensive | Micron | 5200 | MTFDDAK1T9TDD | VJ36D | W2X8N | F005 | 1.92 TB | Capacity |
| SSD | SATA | 2.5 | Read Intensive | Micron | 5300 | MTFDDAK1T9TDS | GYGVV | KT63Y | J008 | 1.92 TB | Capacity |
| SSD | SATA | 2.5 | Read Intensive | Micron | 5400 | MTFDDAK3T8TGA-1B | CHF46 | JTW3W | K403 | 3.84 TB | Capacity |
| SSD | SATA | 2.5 | Read Intensive | Micron | 5400 SED | MTFDDAK3T8TGA-1B | 2DXDK | JTW3W | K403 | 3.84 TB | Capacity |
| SSD | SATA | 2.5 | Read Intensive | Kioxia | HK6-R | KHK6YRSE1T92 | 919J7 | W0YR1 | DBC4 | 1.92 TB | Capacity |
| SSD | SATA | 2.5 | Read Intensive | Kioxia | HK6-R | KHK6YRSE3T84 | 8PYG5 | W0YR1 | DBC4 | 3.84 TB | Capacity |
| SSD | SATA | 2.5 | Read Intensive | Samsung | PM883a | MZ7LH1T9HALT0D3 | 9F9Y6 | 3GHD6 | HG61 | 1.92 TB | Capacity |
| SSD | SATA | 2.5 | Read Intensive | Samsung | PM883 | MZ7LH1T9HMLT0D3 | Y24T6 | 93P7P | HE59 | 1.92 TB | Capacity |
| SSD | SATA | 2.5 | Read Intensive | Hynix | SE5110 | HFS1T9G3H2X069N | 962FP | HFTMG | DZ04 | 1.92 TB | Capacity |
| SSD | SATA | 2.5 | Read Intensive | Hynix | SE4011 | HFS1T9G32FEH-7A1 | 0XMV9 | 3DTV4 | DE08 | 1.92 TB | Capacity |
| SSD | SATA | 2.5 | Read Intensive | Intel | S4510 | SSDSC2KB019T8R | 33R2T | 4DW70 | DL6B | 1.92 TB | Capacity |
| SSD | SATA | 2.5 | Read Intensive | Intel | S4500 | SSDSC2KB019T7R | XCN15 | V141M | DL5C | 1.92 TB | Capacity |
| SSD | SATA | 2.5 | Read Intensive | Intel | P89110 | SSDSC2KB038T7R | 3RRN8 | V141M | DL5C | 3.84 TB | Capacity |
| SSD | SATA | 2.5 | Read Intensive | Intel | S4510 | SSDSC2KB038T8R | 1RHK2 | 4DW70 | DL6B | 3.84 TB | Capacity |
| SSD | SATA | 2.5 | Read Intensive | Samsung | PM883 | MZ7LH3T8HMLT0D3 | FYP5F | 93P7P | HE59 | 3.84 TB | Capacity |
| SSD | SATA | 2.5 | Read Intensive | Samsung | PM883a | MZ7LH3T8HALT0D3 | 5TVXD | 3GHD6 | HG61 | 3.84 TB | Capacity |
| SSD | SATA | 2.5 | Read Intensive | Hynix | SE4011 | HFS3T8G32FEH-741 | D6C0R | 3DTV4 | DE08 | 3.84 TB | Capacity |
| SSD | SATA | 2.5 | Read Intensive | Hynix | SE5110 | HFS3T8G3H2X069N | 3GDK0 | HFTMG | DZ04 | 3.84 TB | Capacity |
| SSD | SATA | 2.5 | Read Intensive | Micron | 5300 | MTFDDAK3T8TDT | 4H1RX | R9YDC | J408 | 3.84 TB | Capacity |
| SSD | SATA | 2.5 | Read Intensive | Intel | Youngsville-RR | SSDSC2KB019TZR | VYYW8 | VJPKG | DL7C | 1.92 TB | Capacity |
| SSD | SATA | 2.5 | Read Intensive | Intel | Youngsville-RR | SSDSC2KB038TZR | WNPN1 | VJPKG | DL7C | 3.84 TB | Capacity |
| SSD | SATA | 2.5 | Read Intensive | Samsung | PM893 | MZ7L31T9HBLTAD3 | 0KYP4 | T3HX9 | HJ64 | 1.92 TB | Capacity |
| SSD | SATA | 2.5 | Read Intensive | Samsung | PM893 | MZ7L33T8HBLTAD3 | GCN5W | T3HX9 | HJ64 | 3.84 TB | Capacity |
| SSD | SATA | 2.5 | Mixed Use | Hynix | SE5031 | HFS960G32FEH-BA1 | 7GR2K | 174WY | DD03 | 960 GB | Capacity |
| SSD | SATA | 2.5 | Mixed Use | Hynix | SE5031 | HFS1T9G32FEH-BA1 | GKTF1 | 174WY | DD03 | 1.92 TB | Capacity |
| SSD | SATA | 2.5 | Read Intensive | Samsung | PM863a | MZ7LM960HMJP0D3 | T2G0Y | P2YRJ | GC5B | 960 GB | Capacity |
SAS 2.5" SSD Cache or Capacity
| Type | Drive Type | Form Factor | Endurance | Vendor | Series | Model | Device Part Number (P/N) | Firmware Software Bundle | Firmware Minimum Supported Version | Capacity | Use |
|---|---|---|---|---|---|---|---|---|---|---|---|
| SSD | SAS | 2.5 | Mixed Use | Samsung | PM1655 | MZILG800HCHQAD3 | 3CHC8 | 7MTXM | DWG9 | 800 GB | Cache,Capacity |
| SSD | SAS | 2.5 | Mixed Use | Samsung | PM1655 | MZILG1T6HCJRAD3 | 5RJND | 7MTXM | DWG9 | 1.6 TB | Cache,Capacity |
| SSD | SAS | 2.5 | Write Intensive | Kioxia | PM6 | KPM6XMUG800G | H6GCD | NGPR2 | BA48 | 800 GB | Cache, Capacity |
| SSD | SAS | 2.5 | Write Intensive | Kioxia | PM6 | KPM6XMUG1T60 | 5GDXH | NGPR2 | BA48 | 1.6 TB | Cache, Capacity |
| SSD | SAS | 2.5 | Mixed Use | Kioxia | PM6 | KPM6XVUG800G | JTKH5 | NGPR2 | BA48 | 800 GB | Cache, Capacity |
| SSD | SAS | 2.5 | Mixed Use | Kioxia | PM6 | KPM6XVUG1T60 | GD3N0 | NGPR2 | BA48 | 1.6 TB | Cache, Capacity |
| SSD | SAS | 2.5 | Mixed Use | Kioxia | PM6 | KPM6XVUG3T20 | NKM7P | NGPR2 | BA48 | 3.2 TB | Cache,Capacity |
| SSD | SAS | 2.5 | Mixed Use | Kioxia | PM6 | KPM6XVUG6T40 | 6NW3J | NGPR2 | BA48 | 6.4 TB | Cache,Capacity |
| SSD | SAS | 2.5 | Write Intensive | Kioxia | Phoenix M4 | PX05SMB080Y | CN3JH | 1DJXX | AS10 | 800 GB | Cache, Capacity |
| SSD | SAS | 2.5 | Mixed Use | Kioxia | Phoenix M4 | PX05SVB096Y | 503M7 | 1DJXX | AS10 | 960 GB | Cache, Capacity |
| SSD | SAS | 2.5 | Write Intensive | Kioxia | Phoenix M4 | PX05SMB160Y | GVTYD | 1DJXX | AS10 | 1.6 TB | Cache, Capacity |
| SSD | SAS | 2.5 | Mixed Use | Kioxia | Phoenix M4 | PX05SVB192Y | V0K7V | 1DJXX | AS10 | 1.92 TB | Cache, Capacity |
| SSD | SAS | 2.5 | Mixed Use | Kioxia | Phoenix M4 | PX05SVB384Y | 3DDFT | 1DJXX | AS10 | 3.84 TB | Cache, Capacity |
| SSD | SAS | 2.5 | Write Intensive | Kioxia | Phoenix M5-M | KPM5XMUG800G | DHRVV | CPP97 | B02A | 800 GB | Cache, Capacity |
| SSD | SAS | 2.5 | Write Intensive | Kioxia | Phoenix M5-M | KPM5XMUG1T60 | W9G88 | CPP97 | B02A | 1.6 TB | Cache, Capacity |
| SSD | SAS | 2.5 | Mixed Use | Samsung | PM1645a | MZILT800HBHQ0D3 | GW8T1 | VJY6V | DWA4 | 800 GB | Cache, Capacity |
| SSD | SAS | 2.5 | Mixed Use | Samsung | PM1645a | MZILT1T6HBJR0D3 | 3TCV6 | VJY6V | DWA4 | 1.6 TB | Cache, Capacity |
| SSD | SAS | 2.5 | Mixed Use | Samsung | PM1645 | MZILT1T6HAJQ0D3 | DR0HX | 4PPHJ | DWF8 | 1.6 TB | Cache, Capacity |
| SSD | SAS | 2.5 | Mixed Use | WD | Bear Cove Quantum | WUSTR6480BSS200 | 6VJC9 | 8W5WF | G138 | 800 GB | Cache, Capacity |
| SSD | SAS | 2.5 | Mixed Use | WD | Bear Cove Quantum | WUSTR6416BSS200 | 6NF96 | 8W5WF | G138 | 1.6 TB | Cache, Capacity |
| SSD | SAS | 2.5 | Mixed Use | Kioxia | Phoenix M5-V | KPM5XVUG960G | WFGTH | CPP97 | B02A | 960 GB | Cache, Capacity |
| SSD | SAS | 2.5 | Mixed Use | Kioxia | Phoenix M5-V | KPM5XVUG1T92 | 2WVYG | CPP97 | B02A | 1.92 TB | Cache, Capacity |
| SSD | SAS | 2.5 | Mixed Use | Kioxia | Phoenix M5-V | KPM5XVUG3T84 | 91W3V | CPP97 | B02A | 3.84 TB | Cache, Capacity |
| SSD | SAS | 2.5 | Mixed Use | Kioxia | PM6 FIPS | KPM6WVUG960G | WMWKG | 6DH0W | BD48 | 960 GB | Cache, Capacity |
| SSD | SAS | 2.5 | Mixed Use | Kioxia | PM6 FIPS | KPM6WVUG1T92 | DHWH5 | 6DH0W | BD48 | 1.92 TB | Cache, Capacity |
| SSD | SAS | 2.5 | Mixed Use | Kioxia | PM6 FIPS | KPM6WVUG3T84 | 81H9C | 6DH0W | BD48 | 3.84 TB | Cache, Capacity |
| SSD | SAS | 2.5 | Mixed Use | Kioxia | PM7 | KPM7XVUG800G | X96H8 | T21WT | C10E | 800 GB | Cache,Capacity |
| SSD | SAS | 2.5 | Mixed Use | Kioxia | PM7 | KPM7XVUG1T60 | 4TRHM | T21WT | C10E | 1.6 TB | Cache,Capacity |
| SSD | SAS | 2.5 | Mixed Use | Kioxia | PM7 (FIPS) | KPM7WVUG800G | 81G77 | 57MM2 | C40E | 800 GB | Cache,Capacity |
| SSD | SAS | 2.5 | Mixed Use | Kioxia | PM7 (FIPS) | KPM7WVUG1T60 | G4NY4 | 57MM2 | C40E | 1.6 TB | Cache,Capacity |
| SSD | SAS | 2.5 | Mixed Use | Kioxia | PM7 (FIPS) | KPM7WVUG3T20 | RGP9J | 57MM2 | C40E | 3.2 TB | Cache,Capacity |
| SSD | SAS | 2.5 | Mixed Use | Kioxia | PM7 (FIPS) | KPM7WVUG3T84 | FMP6K | 57MM2 | C40E | 3.84 TB | Cache,Capacity |
| SSD | SAS | 2.5 | Mixed Use | Kioxia | PM6 | KPM6WVUG960G | J92FY | 6DH0W | BD48 | 960 GB | Cache,Capacity |
| SSD | SAS | 2.5 | Mixed Use | Kioxia | PM6 | KPM6WVUG1T92 | 1081V | 6DH0W | BD48 | 1.92 TB | Cache,Capacity |
| SSD | SAS | 2.5 | Mixed Use | Kioxia | PM6 | KPM6WVUG3T84 | MD4YN | 6DH0W | BD48 | 3.84 TB | Cache,Capacity |
| SSD | SAS | 2.5 | Mixed Use | Kioxia | PM6 | KPM6XVUG800G | NNGV4 | NGPR2 | BA48 | 800 GB | Cache,Capacity |
| SSD | SAS | 2.5 | Mixed Use | Kioxia | PM6 | KPM6XVUG1T60 | CHJJJ | NGPR2 | BA48 | 1.6 TB | Cache,Capacity |
| SSD | SAS | 2.5 | Mixed Use | WD | Bear Cove Plus | WUSTR6416ASS200 | 8W6HC | 7HYHH | K968 | 1.6 TB | Cache,Capacity |
| SSD | SAS | 2.5 | Mixed Use | Samsung | PM1655a | MZILG1T6HFJAAD3 | J7MWC | 42TFH | DWB1 | 1.6 TB | Cache, Capacity |
| SSD | SAS | 2.5 | Mixed Use | Samsung | PM1655a | MZILG3T2HFLTAD3 | 03P3V | 42TFH | DWB1 | 3.2 TB | Cache, Capacity |
| SSD | SAS | 2.5 | Mixed Use | Samsung | PM1655a | MZILG6T4HBLCAD3 | 24VJM | 42TFH | DWB1 | 6.4 TB | Cache, Capacity |
SAS 2.5" SSD Capacity Only
| Type | Drive Type | Form Factor | Endurance | Vendor | Series | Model | Device Part Number (P/N) | Firmware Software Bundle | Firmware Minimum Supported Version | Capacity | Use |
|---|---|---|---|---|---|---|---|---|---|---|---|
| SSD | SAS | 2.5 | Read Intensive | WD | Bear Cove Plus | WUSTR1519ASS200 | 5ND33 | 7HYHH | K968 | 1.92 TB | Capacity |
| SSD | SAS | 2.5 | Read Intensive | WD | Bear Cove Plus | WUSTR1538ASS200 | YW17N | 7HYHH | K968 | 3.84 TB | Capacity |
| SSD | SAS | 2.5 | Read Intensive | WD | Bear Cove Quantum | WUSTVA119BSS200 | 02X38 | 8W5WF | G138 | 1.92 TB | Capacity |
| SSD | SAS | 2.5 | Read Intensive | WD | Bear Cove Quantum | WUSTVA138BSS200 | FP1KF | 8W5WF | G138 | 3.84 TB | Capacity |
| SSD | SAS | 2.5 | Read Intensive | Samsung | PM1643 | MZILT1T9HAJQ0D3 | F0VFY | J3RRK | DSF8 | 1.92 TB | Capacity |
| SSD | SAS | 2.5 | Read Intensive | Samsung | PM1643 | MZILT3T8HALS0D3 | X8F87 | J3RRK | DSF8 | 3.84 TB | Capacity |
| SSD | SAS | 2.5 | Read Intensive | Samsung | PM1643 | MZILT7T6HMLA0D3 | RVYD5 | J3RRK | DSF8 | 7.68 TB | Capacity |
| SSD | SAS | 2.5 | Read Intensive | Samsung | PM1643a | MZILT1T9HBJR0D3 | TMTW9 | D7RNT | DSA4 | 1.92 TB | Capacity |
| SSD | SAS | 2.5 | Read Intensive | Samsung | PM1643a | MZILT3T8HBLS0D3 | CRNPH | D7RNT | DSA4 | 3.84 TB | Capacity |
| SSD | SAS | 2.5 | Read Intensive | Samsung | PM1633a | MZILS1T9HEJH0D3 | 086DD | XNGNT | DSLA | 1.92 TB | Capacity |
| SSD | SAS | 2.5 | Read Intensive | Samsung | PM1633a | MZILS3T8HMLH0D3 | JR1HP | XNGNT | DSLA | 3.84 TB | Capacity |
| SSD | SAS | 2.5 | Read Intensive | Samsung | PM1643a | MZILT960HBHQ0D3 | K74WN | D7RNT | DSA4 | 960 GB | Capacity |
| SSD | SAS | 2.5 | Read Intensive | Samsung | PM1643a | MZILT7T6HALA0D3 | 84C40 | D7RNT | DSA4 | 7.68 TB | Capacity |
| SSD | SAS | 2.5 | Read Intensive | Samsung | PM1653 | MZILG1T9HCJRAD3 | NRR34 | 3MV58 | DSG9 | 1.92 TB | Capacity |
| SSD | SAS | 2.5 | Read Intensive | Samsung | PM1653 | MZILG3T8HCLSAD3 | 9N32F | 3MV58 | DSG9 | 3.84 TB | Capacity |
| SSD | SAS | 2.5 | Read Intensive | Samsung | PM1653 | MZILG7T6HBLAAD3 | Y8H7M | 3MV58 | DSG9 | 7.68 TB | Capacity |
| SSD | SAS | 2.5 | Read Intensive | Kioxia | PM6 | KPM6XRUG1T92 | 4CN85 | NGPR2 | BA48 | 1.92 TB | Capacity |
| SSD | SAS | 2.5 | Read Intensive | Kioxia | PM6 | KPM6XRUG3T84 | H9TT5 | NGPR2 | BA48 | 3.84 TB | Capacity |
| SSD | SAS | 2.5 | Read Intensive | Kioxia | PM6 | KPM6XRUG7T68 | PD02Y | NGPR2 | BA48 | 7.68 TB | Capacity |
| SSD | SAS | 2.5 | Read Intensive | Kioxia | PM6 FIPS | KPM6WRUG1T92 | 7F2D1 | 6DH0W | BD48 | 1.92 TB | Capacity |
| SSD | SAS | 2.5 | Read Intensive | Kioxia | PM6 FIPS | KPM6WRUG3T84 | FH1W9 | 6DH0W | BD48 | 3.84 TB | Capacity |
| SSD | SAS | 2.5 | Read Intensive | Kioxia | PM6 | KPM6WRUG1T92 | H1P07 | 6DH0W | BD48 | 1.92 TB | Capacity |
| SSD | SAS | 2.5 | Read Intensive | Kioxia | PM6 | KPM6WRUG3T84 | 3VHY3 | 6DH0W | BD48 | 3.84 TB | Capacity |
| SSD | SAS | 2.5 | Read Intensive | Kioxia | PM6 | KPM6WRUG7T68 | 5T78C | 6DH0W | BD48 | 7.68 TB | Capacity |
| SSD | SAS | 2.5 | Read Intensive | Kioxia | PM6 | KPM6XRUG1T92 | VRTN9 | NGPR2 | BA48 | 1.92 TB | Capacity |
| SSD | SAS | 2.5 | Read Intensive | Kioxia | PM6 | KPM6XRUG3T84 | 2XVX2 | NGPR2 | BA48 | 3.84 TB | Capacity |
| SSD | SAS | 2.5 | Read Intensive | Kioxia | PM6 | KPM6XRUG7T68 | YM0T1 | NGPR2 | BA48 | 7.68 TB | Capacity |
| SSD | SAS | 2.5 | Read Intensive | Kioxia | PM7 (FIPS) | KPM7WRUG1T92 | VGMCD | 57MM2 | C40E | 1.92 TB | Capacity |
| SSD | SAS | 2.5 | Read Intensive | Kioxia | PM7 (FIPS) | KPM7WRUG3T84 | YTVTF | 57MM2 | C40E | 3.84 TB | Capacity |
| SSD | SAS | 2.5 | Read Intensive | Kioxia | PM7 (FIPS) | KPM7WRUG7T68 | HCTYM | 57MM2 | C40E | 7.68 TB | Capacity |
| SSD | SAS | 2.5 | Read Intensive | Kioxia | Phoenix M5-R | KPM5XRUG1T92 | TDNP7 | CPP97 | B02A | 1.92 TB | Capacity |
| SSD | SAS | 2.5 | Read Intensive | Kioxia | Phoenix M5-R | KPM5XRUG3T84 | N85XX | CPP97 | B02A | 3.84 TB | Capacity |
| SSD | SAS | 2.5 | Read Intensive | Kioxia | Phoenix M4 | PX05SRB384Y | XCRDV | 1DJXX | AS10 | 3.84 TB | Capacity |
| SSD | SAS | 2.5 | Read Intensive | Seagate | LangeBP | XS3840SE70114 | KXDCD | NKGWD | 3D03 | 3.84 TB | Capacity |
| SSD | SAS | 2.5 | Read Intensive | Seagate | LangeBP | XS1920SE70114 | D4VFW | NKGWD | 3D03 | 1.92 TB | Capacity |
| SSD | SAS | 2.5 | Read Intensive | Kioxia | PM7 | KPM7XRUG1T92 | 6K35K | T21WT | C10E | 1.92 TB | Capacity |
| SSD | SAS | 2.5 | Read Intensive | Kioxia | PM7 | KPM7XRUG3T84 | MT0R5 | T21WT | C10E | 3.84 TB | Capacity |
| SSD | SAS | 2.5 | Read Intensive | Kioxia | PM7 | KPM7XRUG7T68 | 7N1WT | T21WT | C10E | 7.68 TB | Capacity |
| SSD | SAS | 2.5 | Read Intensive | Samsung | PM1653a | MZILG1T9HFJAAD3 | 8WKDX | 862D9 | DSB1 | 1.92 TB | Capacity |
| SSD | SAS | 2.5 | Read Intensive | Samsung | PM1653a | MZILG3T8HFLTAD3 | MP2TJ | 862D9 | DSB1 | 3.84 TB | Capacity |
| SSD | SAS | 2.5 | Read Intensive | Samsung | PM1653a | MZILG7T6HBLCAD3 | 00CK9 | 862D9 | DSB1 | 7.68 TB | Capacity |
Value SAS 2.5" SSD
| Type | Drive Type | Form Factor | Endurance | Vendor | Series | Model | Device Part Number (P/N) | Firmware Software Bundle | Firmware Minimum Supported Version | Capacity | Use |
|---|---|---|---|---|---|---|---|---|---|---|---|
| SSD | VSAS | 2.5 | Read Intensive | Seagate | LangeBP SED | XS1920SE70134 | K9T53 | G04C8 | 4S0C | 1.92 TB | Capacity |
| SSD | VSAS | 2.5 | Read Intensive | Seagate | LangeBP SED | XS3840SE70134 | 4KPKF | G04C8 | 4S0C | 3.84 TB | Capacity |
| SSD | VSAS | 2.5 | Read Intensive | Seagate | LangeBP SED | XS7680SE70134 | 2THYF | G04C8 | 4S0C | 7.68 TB | Capacity |
| SSD | VSAS | 2.5 | Mixed Use | Kioxia | Phoenix RM5 | KRM5XVUG3T84 | X78JM | NDG7N | B710 | 3.84 TB | Cache, Capacity |
| SSD | VSAS | 2.5 | Mixed Use | Seagate | LangeBP ISE | XS3840LE70154 | NWGX3 | NX13G | 4D0C | 3.84 TB | Cache, Capacity |
| SSD | VSAS | 2.5 | Mixed Use | Seagate | Cooper (Nytro 2550) | XS960LE70095 | 2M1NG | RRWVT | CPE9 | 960 GB | Cache,Capacity |
| SSD | VSAS | 2.5 | Mixed Use | Seagate | Cooper (Nytro 2550) | XS1920LE70095 | K805Y | RRWVT | CPE9 | 1.92 TB | Cache,Capacity |
| SSD | VSAS | 2.5 | Mixed Use | Seagate | Cooper (Nytro 2550) | XS3840LE70095 | FT95M | RRWVT | CPE9 | 3.84 TB | Cache,Capacity |
| SSD | VSAS | 2.5 | Read Intensive | Kioxia | Phoenix RM5 | KRM5XRUG7T68 | 5XD2F | NDG7N | B710 | 7.68 TB | Capacity |
| SSD | VSAS | 2.5 | Read Intensive | Seagate | Lange ISE | XS7680SE70074 | 2PKRH | H3VHX | EC16 | 7.68 TB | Capacity |
| SSD | VSAS | 2.5 | Read Intensive | Seagate | LangeBP ISE | XS7680SE70154 | 5KW0F | NX13G | 4D0C | 7.68 TB | Capacity |
| SSD | VSAS | 2.5 | Mixed Use | Seagate | LangeBP SED | XS960LE70134 | 2RDWT | G04C8 | 4S0C | 960 GB | Cache, Capacity |
| SSD | VSAS | 2.5 | Mixed Use | Seagate | LangeBP SED | XS1920LE70134 | N6DRV | G04C8 | 4S0C | 1.92 TB | Cache, Capacity |
| SSD | VSAS | 2.5 | Mixed Use | Seagate | LangeBP SED | XS3840LE70134 | YM9HP | G04C8 | 4S0C | 3.84 TB | Cache, Capacity |
| SSD | VSAS | 2.5 | Mixed Use | Kioxia | RM6 | KRM6VVUG960G | 42XXC | 5WMK8 | BJ07 | 960 GB | Cache, Capacity |
| SSD | VSAS | 2.5 | Mixed Use | Kioxia | RM6 | KRM6VVUG1T92 | N15JP | 5WMK8 | BJ07 | 1.92 TB | Cache, Capacity |
| SSD | VSAS | 2.5 | Mixed Use | Kioxia | RM6 | KRM6VVUG3T84 | FXYGR | 5WMK8 | BJ07 | 3.84 TB | Cache, Capacity |
| SSD | VSAS | 2.5 | Read Intensive | Kioxia | RM6 | KRM6VRUG1T92 | 1FGWG | 5WMK8 | BJ07 | 1.92 TB | Capacity |
| SSD | VSAS | 2.5 | Read Intensive | Kioxia | RM6 | KRM6VRUG3T84 | XNXD2 | 5WMK8 | BJ07 | 3.84 TB | Capacity |
| SSD | VSAS | 2.5 | Read Intensive | Kioxia | RM6 | KRM6VRUG7T68 | 5MHY8 | 5WMK8 | BJ07 | 7.68 TB | Capacity |
| SSD | VSAS | 2.5 | Read Intensive | Kioxia | RM7 | KRM7VVUG960G | 05MT7 | 1YD58 | CA0C | 960 GB | Capacity |
| SSD | VSAS | 2.5 | Read Intensive | Kioxia | RM7 | KRM7VVUG1T92 | 59XF2 | 1YD58 | CA0C | 1.92 TB | Capacity |
| SSD | VSAS | 2.5 | Read Intensive | Kioxia | RM7 | KRM7VVUG3T84 | M0JVN | 1YD58 | CA0C | 3.84 TB | Capacity |
| SSD | vSAS | 2.5 | Read Intensive | Kioxia | RM7 | KRM7VRUG7T68 | D480G | 1YD58 | CA0C | 7.68 TB | Capacity |
| SSD | vSAS | 2.5 | Read Intensive | Seagate | Cooper | XS7680SE70145 | 1J46N | RRWVT | CPE9 | 7.68 TB | Capacity |
NVMe 2.5" Cache or Capacity
| Type | Drive Type | Form Factor | Endurance | Vendor | Series | Model | Device Part Number (P/N) | Firmware Software Bundle | Firmware Minimum Supported Version | Capacity | Use |
|---|---|---|---|---|---|---|---|---|---|---|---|
| NVMe | PCIe | 2.5 | Write Intensive | Intel | Optane P4800x SSD/NVMe, 375GB U.2 2.5" SFF | SSDPE21K375GAT | 3DM57 | HMRK7 | E201DP38 | 375 GB | Cache, Capacity |
| NVMe | PCIe | 2.5 | Mixed Use | Samsung | PM1725A, Dell Express Flash NVMe 1.6TB 2.5" SFF | MZWLL1T6HEHP-000D3 | JD6CH | 34C36 | 1.2.1 | 1.6 TB | Cache, Capacity |
| NVMe | PCIe | 2.5 | Mixed Use | Samsung | PM1725A, Dell Express Flash NVMe 3.2TB 2.5" SFF | MZWLL3T2HMJP-000D3 | JDMHM | 34C36 | 1.2.1 | 3.2 TB | Cache, Capacity |
| NVMe | PCIe | 2.5 | Mixed Use | Samsung | PM1725A, Dell Express Flash NVMe 6.4TB 2.5" SFF | MZWLL6T4HMLS-000D3 | Y3XT2 | 34C36 | 1.2.1 | 6.4 TB | Cache, Capacity |
| NVMe | PCIe | 2.5 | Mixed Use | Samsung | PM1725b, Dell Express Flash NVMe 1.6TB 2.5" SFF | MZWLL1T6HAJQ-000D3 | 4WDXY | NC07Y | 1.2.2 | 1.6 TB | Cache, Capacity |
| NVMe | PCIe | 2.5 | Mixed Use | Samsung | PM1725b, Dell Express Flash NVMe 3.2TB 2.5" SFF | MZWLL3T2HAJQ-000D3 | K60N7 | NC07Y | 1.2.2 | 3.2 TB | Cache, Capacity |
| NVMe | PCIe | 2.5 | Mixed Use | Samsung | PM1725b, Dell Express Flash NVMe 6.4TB 2.5" SFF | MZWLL6T4HMLA-000D3 | 08NMX | NC07Y | 1.2.2 | 6.4 TB | Cache, Capacity |
| NVMe | PCIe | 2.5 | Mixed Use | Intel | P4600, Dell Express Flash NVMe 1.6TB 2.5" SFF | SSDPE2KE016T7T | F5P84 | CR0HC | QDV1DP17 | 1.6 TB | Cache, Capacity |
| NVMe | PCIe | 2.5 | Mixed Use | Intel | P4600, Dell Express Flash NVMe 3.2TB 2.5" SFF | SSDPE2KE032T7T | MCV6J | CR0HC | QDV1DP17 | 3.2 TB | Cache, Capacity |
| NVMe | PCIe | 2.5 | Mixed Use | Intel | P4610, Dell Express Flash NVMe 1.6TB 2.5" SFF | SSDPE2KE016T8T | 58V30 | 7VJGR | VDV1DP25 | 1.6 TB | Cache, Capacity |
| NVMe | PCIe | 2.5 | Mixed Use | Intel | P4610, Dell Express Flash NVMe 3.2TB 2.5" SFF | SSDPE2KE032T8T | 2CN1T | 7VJGR | VDV1DP25 | 3.2 TB | Cache, Capacity |
| NVMe | PCIe | 2.5 | Mixed Use | Intel | P4610, Dell Express Flash NVMe 6.4TB 2.5" SFF | SSDPE2KE064T8T | X27HY | 7VJGR | VDV1DP25 | 6.4 TB | Cache, Capacity |
| NVMe | PCIe | 2.5 | Mixed Use | KIOXIA | DELL EXPRESS FLASH KIOXIA CM6 MU 1.6TB U.2 FIPS | KCM6FVUL1T60 | G7N00 | WJD95 | 3.1.7 | 1.6 TB | Cache, Capacity |
| NVMe | PCIe | 2.5 | Mixed Use | Samsung | PM1735 SP 3WPD, SSD, NVMe, 2.5, 512e, ISE | MZWLJ1T6HBJRAD3 | 6GK00 | 5CM3G | 2.5.0 | 1.6 TB | Cache, Capacity |
| NVMe | PCIe | NA | Mixed Use | Samsung | PM1735 SP 3WPD, SSD, Gen4 NVMe, 2.5, 512e, ISE | MZWLJ3T2HBJRAD3 | 15TVC | 5CM3G | 2.5.0 | 3.2TB | Cache,Capacity |
| NVMe | PCIe | NA | Mixed Use | Samsung | PM1735 SP 3WPD, SSD, Gen4 NVMe, 2.5, 512e, ISE | MZWLJ6T4HALAAD3 | F6V5P | 5CM3G | 2.5.0 | 6.4TB | Cache,Capacity |
| NVMe | PCIe | 2.5 | Mixed Use | Kioxia | CM6 SP | KCM6XVUL1T60 | P03YC | GMM6V | 2.2.2 | 1.6 TB | Cache, Capacity |
| NVMe | PCIe | 2.5 | Mixed Use | Kioxia | CM6 SP | KCM6XVUL3T20 | 97GR0 | GMM6V | 2.2.2 | 3.2 TB | Cache, Capacity |
| NVMe | PCIe | 2.5 | Mixed Use | Kioxia | CM6 SP | KCM6XVUL6T40 | K916X | GMM6V | 2.2.2 | 6.4 TB | Cache, Capacity |
| NVMe | PCIe | 2.5 | Mixed Use | Intel | P5600 SP 3WPD | D7 P5600 Series 1.6TB | C9X5T | CGXH7 | 1.2.4 | 1.6 TB | Cache, Capacity |
| NVMe | PCIe | 2.5 | Mixed Use | Intel | P5600 SP 3WPD | D7 P5600 Series 3.2TB | PRKTM | CGXH7 | 1.2.4 | 3.2 TB | Cache, Capacity |
| NVMe | PCIe | 2.5 | Mixed Use | Intel | Arbordale Plus RR P5620 | SSDPF2KE016T1E | 82TVJ | 12W9R | 1.5.0 | 1.6 TB | Cache,Capacity |
| NVMe | PCIe | 2.5 | Mixed Use | Intel | Arbordale Plus RR P5620 | SSDPF2KE032T1E | TY3M5 | 12W9R | 1.5.0 | 3.2 TB | Cache,Capacity |
| NVMe | PCIe | 2.5 | Mixed Use | Intel | Arbordale Plus RR P5620 | SSDPF2KE064T1E | 5WCR8 | 12W9R | 1.5.0 | 6.4TB | Cache, Capacity |
| NVMe | PCIe | 2.5 | Mixed Use | Samsung | PM1735 V2 SP 3WPD | MZWLR1T6HBJRAD3 | 0MNMV | 5V3P7 | 2.5.0 | 1.6 TB | Cache, Capacity |
| NVMe | PCIe | 2.5 | Mixed Use | Samsung | PM1735 V2 SP 3WPD | MZWLR3T2HBLSAD3 | V69W3 | 5V3P7 | 2.5.0 | 3.2 TB | Cache, Capacity |
| NVMe | PCIe | 2.5 | Mixed Use | Samsung | PM1735 V2 SP 3WPD | MZWLR6T4HALAAD3 | H8D5M | 5V3P7 | 2.5.0 | 6.4 TB | Cache, Capacity |
| NVMe | PCIe | 2.5 | Mixed Use | Samsung | PM1735a | MZWLR1T6HCJRAD3 | H8GHV | 71KRG | 1.2.0 | 1.6 TB | Cache,Capacity |
| NVMe | PCIe | 2.5 | Mixed Use | Samsung | PM1735a | MZWLR3T2HCLSAD3 | 617H6 | 71KRG | 1.2.0 | 3.2 TB | Cache,Capacity |
| NVMe | PCIe | 2.5 | Mixed Use | Samsung | PM1735a | MZWLR6T4HBLAAD3 | 9F6Y3 | 71KRG | 1.2.0 | 6.4 TB | Cache,Capacity |
| NVMe | PCIe | 2.5 | Mixed Use | Kioxia | CM7 | KCM7XVUG1T60 | MP4F2 | K1JTM | 2.0.3 | 1.6 TB | Cache, Capacity |
| NVMe | PCIe | 2.5 | Mixed Use | Kioxia | CM7 | KCM7XVUG3T20 | XFNX0 | K1JTM | 2.0.3 | 3.2 TB | Cache, Capacity |
| NVMe | PCIe | 2.5 | Mixed Use | Kioxia | CM7 | KCM7XVUG6T40 | 8RJJ9 | K1JTM | 2.0.3 | 6.4 TB | Cache, Capacity |
| NVMe | PCIe | 2.5 | Mixed Use | Hynix | PS1030 | HFS1T6GEJVX171N | 1HYKD | VNYK2 | 1.3.0 | 1.6 TB | Cache, Capacity |
| NVMe | PCIe | 2.5 | Mixed Use | Hynix | PS1030 | HFS3T2GEJVX171N | 9VWPD | VNYK2 | 1.3.0 | 3.2 TB | Cache, Capacity |
| NVMe | PCIe | 2.5 | Mixed Use | Hynix | PS1030 | HFS6T4GEJVX171N | PYMY6 | VNYK2 | 1.3.0 | 6.4 TB | Cache, Capacity |
| NVMe | PCIe | 2.5 | Mixed Use | Samsung | PM1745 | MZWLO1T6HCJR-00AD3 | FVC2P | V7V0K | 1.0.0 | 1.6 TB | Cache, Capacity |
| NVMe | PCIe | 2.5 | Mixed Use | Samsung | PM1745 | MZWLO3T2HCLS-00AD3 | FDNHD | V7V0K | 1.0.0 | 3.2 TB | Cache, Capacity |
| NVMe | PCIe | 2.5 | Mixed Use | Samsung | PM1745 | MZWLO6T4HBLA-00AD3 | 64K9C | V7V0K | 1.0.0 | 6.4 TB | Cache, Capacity |
| NVMe | PCIe | 2.5 | Mixed Use | Micron | 7600 | MTFDLAL1T6THS | DCR2M | VJXKC | 1.0.0 | 1.6 TB | Cache, Capacity |
| NVMe | PCIe | 2.5 | Mixed Use | Micron | 7600 | MTFDLAL3T2THS | J9TN7 | VJXKC | 1.0.0 | 3.2 TB | Cache, Capacity |
| NVMe | PCIe | 2.5 | Mixed Use | Samsung | PM9D5a | MZWL6800H | 53M2M | X5N7N | 1.0.1 | 800 GB | Cache, Capacity |
| NVMe | PCIe | 2.5 | Mixed Use | Samsung | PM9D5a | MZWL61T6H | 2M4HN | X5N7N | 1.0.1 | 1.6 TB | Cache, Capacity |
| NVMe | PCIe | 2.5 | Mixed Use | Samsung | PM9D5a | MZWL63T2H | 85GHX | X5N7N | 1.0.1 | 3.2 TB | Cache, Capacity |
| NVMe | PCIe | 2.5 | Mixed Use | Samsung | PM9D5a | MZWL66T4H | D68YV | X5N7N | 1.0.1 | 6.4 TB | Cache, Capacity |
| NVMe | PCIe | 2.5 | Mixed Use | Micron | 9550 | MTFDLAL3T2THB | D0GXJ | 4WN4V | 1.1.0 | 3.2 TB | Cache, Capacity |
| NVMe | PCIe | 2.5 | Mixed Use | Micron | 9550 | MTFDLAL6T4THB | WC68V | 4WN4V | 1.1.0 | 6.4 TB | Cache, Capacity |
| NVMe | 2.5 | Mixed Use | Kioxia | CD9P SP | KCD9XPUG1T60 | TXJPH | 33P3K | 1.0.0 | 1.6 TB | Cache, Capacity | |
| NVMe | 2.5 | Mixed Use | Kioxia | CD9P SP | KCD9XPUG3T20 | 1N3NW | 33P3K | 1.0.0 | 3.2 TB | Cache, Capacity | |
| NVMe | 2.5 | Mixed Use | Kioxia | CD9P SP | KCD9XPUG6T40 | VD4P0 | 33P3K | 1.0.0 | 6.4 TB | Cache, Capacity | |
| NVMe | 2.5 | Mixed Use | Kioxia | CM9 DP | KCM9XVUL1T60 | D9GTD | HJ15N | 1.0.0 | 1.6 TB | Cache, Capacity | |
| NVMe | 2.5 | Mixed Use | Kioxia | CM9 DP | KCM9XVUL3T20 | V57TP | HJ15N | 1.0.0 | 3.2 TB | Cache, Capacity | |
| NVMe | 2.5 | Mixed Use | Kioxia | CM9 DP | KCM9XVUL6T40 | 3161Y | HJ15N | 1.0.0 | 6.4 TB | Cache, Capacity | |
| NVMe | 2.5 | Mixed Use | Samsung | PM1755 | MZWL91T6HFJAAD3 | Y8RH3 | 40KGW | 1.0.0 | 1.6 TB | Cache, Capacity | |
| NVMe | 2.5 | Mixed Use | Samsung | PM1755 | MZWL93T2HFLTAD3 | K89MG | 40KGW | 1.0.0 | 3.2 TB | Cache, Capacity | |
| NVMe | 2.5 | Mixed Use | Samsung | PM1755 | MZWL96T4HBLCAD3 | JHYJ5 | 40KGW | 1.0.0 | 6.4 TB | Cache, Capacity |
NVMe 2.5" Capacity Only
| Type | Drive Type | Form Factor | Endurance | Vendor | Series | Model | Device Part Number (P/N) | Firmware Software Bundle | Firmware Minimum Supported Version | Capacity | Use |
|---|---|---|---|---|---|---|---|---|---|---|---|
| NVMe | PCIe | 2.5 | Read Intensive | Toshiba | CD5 | KCD5XLUG960G | DRC9H | T79D5 | 1.2.0 | 960 GB | Capacity |
| NVMe | PCIe | 2.5 | Read Intensive | Toshiba | CD5 | KCD5XLUG3T84 | 17C57 | T79D5 | 1.2.0 | 3.84 TB | Capacity |
| NVMe | PCIe | 2.5 | Read Intensive | Intel | P4510 | SSDPE2KX040T8T | 5GMK0 | 7VJGR | VDV1DP25 | 4 TB | Capacity |
| NVMe | PCIe | 2.5 | Read Intensive | KIOXIA | DELL EXPRESS FLASH KIOXIA CM6 RI 1.92TB U.2 FIPS | KCM6FRUL1T92 | TXP72 | WJD95 | 3.1.7 | 1.92 TB | Capacity |
| NVMe | PCIe | 2.5 | Read Intensive | Intel | P5500 | SSDPF2KX019T9T | WPP9G | CGXH7 | 1.2.4 | 1.92 TB | Capacity |
| NVMe | PCIe | 2.5 | Read Intensive | Intel | P5500 | SSDPF2KX038T9T | KRT3G | CGXH7 | 1.2.4 | 3.84 TB | Capacity |
| NVMe | PCIe | 2.5 | Read Intensive | Intel | P5500 | SSDPF2KX076T9T | RNN67 | CGXH7 | 1.2.4 | 7.68 TB | Capacity |
| NVMe | PCIe | 2.5 | Read Intensive | Samsung | PM1733 V2 | MZWLR3T8HBLSAD3 | G5N65 | 5V3P7 | 2.5.0 | 3.84 TB | Capacity |
| NVMe | PCIe | 2.5 | Read Intensive | Samsung | PM1733 V2 | MZWLR7T6HALAAD3 | DX74Y | 5V3P7 | 2.5.0 | 7.68 TB | Capacity |
| NVMe | PCIe | 2.5 | Read Intensive | Samsung | PM1733 V2 | MZWLR15THALAAD3 | 182NW | 5V3P7 | 2.5.0 | 15.36 TB | Capacity |
| NVMe | PCIe | 2.5 | Read Intensive | Samsung | PM1733a | MZWLR1T9HCJRAD3 | 8PMRM | 71KRG | 1.2.0 | 1.92 TB | Capacity |
| NVMe | PCIe | 2.5 | Read Intensive | Samsung | PM1733a | MZWLR3T8HCLSAD3 | RJKM5 | 71KRG | 1.2.0 | 3.84 TB | Capacity |
| NVMe | PCIe | 2.5 | Read Intensive | Samsung | PM1733a | MZWLR7T6HBLAAD3 | R1J8J | 71KRG | 1.2.0 | 7.68 TB | Capacity |
| NVMe | PCIe | 2.5 | Read Intensive | Samsung | PM1733a | MZWLR15THBLAAD3 | D4CJG | 71KRG | 1.2.0 | 15.36 TB | Capacity |
| NVMe | PCIe | 2.5 | Read Intensive | Kioxia | CM6 | KCM6XRUL1T92 | N0VK0 | GMM6V | 2.2.2 | 1.92 TB | Capacity |
| NVMe | PCIe | 2.5 | Read Intensive | Kioxia | CM6 | KCM6XRUL3T84 | 8W2G5 | GMM6V | 2.2.2 | 3.84 TB | Capacity |
| NVMe | PCIe | 2.5 | Read Intensive | Kioxia | CM6 | KCM6XRUL7T68 | VD0JX | GMM6V | 2.2.2 | 7.68 TB | Capacity |
| NVMe | PCIe | 2.5 | Read Intensive | Kioxia | CM6 | KCM6XRUL15T3 | J91CR | GMM6V | 2.2.2 | 15.36 TB | Capacity |
| NVMe | PCIe | 2.5 | Read Intensive | Intel | Arbordale Plus RR P5520 | SSDPF2KX019T1E | 0HVC7 | 12W9R | 1.5.0 | 1.92 TB | Capacity |
| NVMe | PCIe | 2.5 | Read Intensive | Intel | Arbordale Plus RR P5520 | SSDPF2KX038T1E | 77MRY | 12W9R | 1.5.0 | 3.84 TB | Capacity |
| NVMe | PCIe | 2.5 | Read Intensive | Intel | Arbordale Plus RR P5520 | SSDPF2KX076T1E | 90M2J | 12W9R | 1.5.0 | 7.68 TB | Capacity |
| NVMe | PCIe | 2.5 | Read Intensive | Intel | Arbordale Plus R P5316 | SSDPF2NV307TZ | 4KCVT | D6RJK | 1.7.0 | 30.72 TB | Capacity |
| NVMe | PCIe | 2.5 | Mixed Use | Kioxia | CM7 | KCM7XRUG1T92 | M8YW0 | K1JTM | 2.0.3 | 1.92 TB | Capacity |
| NVMe | PCIe | 2.5 | Mixed Use | Kioxia | CM7 | KCM7XRUG3T84 | XHYGF | K1JTM | 2.0.3 | 3.84 TB | Capacity |
| NVMe | PCIe | 2.5 | Mixed Use | Kioxia | CM7 | KCM7XRUG7T68 | VV2M7 | K1JTM | 2.0.3 | 7.68 TB | Capacity |
| NVMe | PCIe | 2.5 | Mixed Use | Kioxia | CM7 | KCM7XRUG15T3 | DX2PD | K1JTM | 2.0.3 | 15.36 TB | Capacity |
| NVMe | PCIe | 2.5 | Read Intensive | Kioxia | CD7 | KCD7XRUG7T68 | 0RD61 | K6597 | 2.0.1 | 7.68 TB | Capacity |
| NVMe | PCIe | 2.5 | Read Intensive | Kioxia | CD8 | KCD8XRUG1T92 | NNKCT | 17R29 | 2.0.2 | 1.92 TB | Capacity |
| NVMe | PCIe | 2.5 | Read Intensive | Kioxia | CD8 | KCD8XRUG3T84 | N1MK1 | 17R29 | 2.0.2 | 3.84 TB | Capacity |
| NVMe | PCIe | 2.5 | Read Intensive | Kioxia | CD8 | KCD8XRUG7T68 | MXD8J | 17R29 | 2.0.2 | 7.68 TB | Capacity |
| NVMe | PCIe | 2.5 | Read Intensive | Hynix | PS1010 | HFS1T9GEJVX171N | 7GGK1 | VNYK2 | 1.3.0 | 1.92 TB | Capacity |
| NVMe | PCIe | 2.5 | Read Intensive | Hynix | PS1010 | HFS3T8GEJVX171N | J4TDK | VNYK2 | 1.3.0 | 3.84 TB | Capacity |
| NVMe | PCIe | 2.5 | Read Intensive | Hynix | PS1010 | HFS7T6GEJVX171N | 2533N | VNYK2 | 1.3.0 | 7.68 TB | Capacity |
| NVMe | PCIe | 2.5 | Read Intensive | Hynix | PS1010 | HFS15T3EJVX171N | 8TY8G | VNYK2 | 1.3.0 | 15.36 TB | Capacity |
| NVMe | PCIe | 2.5 | Read Intensive | Hynix | PE8110 | HFS7T6GEETX099N | RG3T2 | TDGKY | 1.1.0 | 7.68 TB | Capacity |
| NVMe | PCIe | 2.5 | Read Intensive | Samsung | PM1743 | MZWLO3T8HCLS-00AD3 | 9GXVF | V7V0K | 1.0.0 | 3.84 TB | Capacity |
| NVMe | PCIe | 2.5 | Read Intensive | Samsung | PM1743 | MZWLO7T6HBLA-00AD3 | DNPR4 | V7V0K | 1.0.0 | 7.68 TB | Capacity |
| NVMe | PCIe | 2.5 | Read Intensive | Samsung | PM9D3a | MZWL6960HFJA-00AD3 | 71Y2J | X5N7N | 1.0.1 | 960 GB | Capacity |
| NVMe | PCIe | 2.5 | Read Intensive | Samsung | PM9D3a | MZVL61T9HBL1-00AD3 | NYPRM | FTVJG | 1.0.1 | 1.92 TB | Capacity |
| NVMe | PCIe | 2.5 | Read Intensive | Samsung | PM9D3a | MZWL63T8HFLT-00AD3 | 2H60T | X5N7N | 1.0.1 | 3.84 TB | Capacity |
| NVMe | PCIe | 2.5 | Read Intensive | Samsung | PM9D3a | MZWL67T6HBLC-00AD3 | VYT6X | X5N7N | 1.0.1 | 7.68 TB | Capacity |
| NVMe | PCIe | 2.5 | Read Intensive | Micron | 7600 | MTFDLAL1T9THG | N6RN7 | VJXKC | 1.0.0 | 1.92 TB | Capacity |
| NVMe | PCIe | 2.5 | Read Intensive | Micron | 7600 | MTFDLAL3T8THG | 7X0XC | VJXKC | 1.0.0 | 3.84 TB | Capacity |
| NVMe | PCIe | 2.5 | Read Intensive | Micron | 7600 | MTFDLAL7T6THG | Y4GJR | VJXKC | 1.0.0 | 7.68 TB | Capacity |
| NVMe | PCIe | 2.5 | Read Intensive | Micron | 7600 | MTFDLAL15T3THG | 5J26R | VJXKC | 1.0.0 | 15.36 TB | Capacity |
| NVMe | PCIe | 2.5 | Read Intensive | Micron | 9550 | MTFDLAL3T8THA | PFV73 | 4WN4V | 1.1.0 | 3.84 TB | Capacity |
| NVMe | PCIe | 2.5 | Read Intensive | Micron | 9550 | MTFDLAL7T6THA | 39JW6 | 4WN4V | 1.1.0 | 7.68 TB | Capacity |
| NVMe | PCIe | 2.5 | Read Intensive | Micron | 9550 | MTFDLAL15T3THA | R3GD7 | 4WN4V | 1.1.0 | 15.36 TB | Capacity |
| NVMe | PCIe | 2.5 | Read Intensive | Kioxia | CD9P SP | KCD9XPUG1T92 | CW1VK | 33P3K | 1.0.0 | 1.92 TB | Capacity |
| NVMe | PCIe | 2.5 | Read Intensive | Kioxia | CD9P SP | KCD9XPUG3T84 | VJ8RW | 33P3K | 1.0.0 | 3.84 TB | Capacity |
| NVMe | PCIe | 2.5 | Read Intensive | Kioxia | CD9P SP | KCD9XPUG7T68 | 5C8M1 | 33P3K | 1.0.0 | 7.68 TB | Capacity |
| NVMe | PCIe | 2.5 | Read Intensive | Kioxia | CD9P SP | KCD9XPUG15T3 | 1MFNC | 33P3K | 1.0.0 | 15.36 TB | Capacity |
| NVMe | PCIe | 2.5 | Read Intensive | Kioxia | CM9 DP | KCM9XRUL1T92 | R83Y1 | HJ15N | 1.0.0 | 1.92 TB | Capacity |
| NVMe | PCIe | 2.5 | Read Intensive | Kioxia | CM9 DP | KCM9XRUL3T84 | M5PRJ | HJ15N | 1.0.0 | 3.84 TB | Capacity |
| NVMe | PCIe | 2.5 | Read Intensive | Kioxia | CM9 DP | KCM9XRUL7T68 | KP77M | HJ15N | 1.0.0 | 7.68 TB | Capacity |
| NVMe | PCIe | 2.5 | Read Intensive | Kioxia | CM9 DP | KCM9XRUL15T3 | F89P6 | HJ15N | 1.0.0 | 15.36 TB | Capacity |
| NVMe | PCIe | 2.5 | Read Intensive | Samsung | PM1753 | MZWL91T9HFJAAD3 | R0H08 | 40KGW | 1.0.0 | 1.92 TB | Capacity |
| NVMe | PCIe | 2.5 | Read Intensive | Samsung | PM1753 | MZWL93T8HFLTAD3 | K4XRJ | 40KGW | 1.0.0 | 3.84 TB | Capacity |
| NVMe | PCIe | 2.5 | Read Intensive | Samsung | PM1753 | MZWL97T6HBLCAD3 | P7DD3 | 40KGW | 1.0.0 | 7.68 TB | Capacity |
| NVMe | PCIe | 2.5 | Read Intensive | Samsung | PM1753 | MZWL915THBLFAD3 | KX76K | 40KGW | 1.0.0 | 15.36 TB | Capacity |
NVMe Add-in Cards
| Type | Drive Type | Form Factor | Endurance | Vendor | Series | Model | Device Part Number (P/N) | Firmware Software Bundle | Firmware Minimum Supported Version | Capacity | Use |
|---|---|---|---|---|---|---|---|---|---|---|---|
| NVMe | PCIe | AIC | Mixed Use | Samsung | PM1725A, Dell Express Flash NVMe 1.6TB HHHL AIC | MZPLL1T6HEHP-000D3 | 06V6M | 34C36 | 1.2.1 | 1.6 TB | Cache, Capacity |
| NVMe | PCIe | AIC | Mixed Use | Samsung | PM1725A, Dell Express Flash NVMe 3.2TB HHHL AIC | MZPLL3T2HMLS-00003 | C2KKH | 34C36 | 1.2.1 | 3.2 TB | Cache, Capacity |
| NVMe | PCIe | AIC | Mixed Use | Samsung | PM1725A, Dell Express Flash NVMe 6.4TB HHHL AIC | MZPLL6T4HMLS-000D3 | 604N5 | 34C36 | 1.2.1 | 6.4 TB | Cache, Capacity |
| NVMe | PCIe | AIC | Mixed Use | Samsung | PM1725b, Dell Express Flash NVMe 1.6TB (MU) HHHL AIC | MZPLL1T6HAJQ-000D3 | FTX2R | NC07Y | 1.2.2 | 1.6 TB | Cache, Capacity |
| NVMe | PCIe | AIC | Mixed Use | Samsung | PM1725b, Dell Express Flash NVMe 3.2TB (MU) HHHL AIC | MZPLL3T2HAJQ-00005 | 73KJ7 | NC07Y | 1.2.2 | 3.2 TB | Cache, Capacity |
| NVMe | PCIe | AIC | Mixed Use | Samsung | PM1725b, Dell Express Flash NVMe 6.4TB (MU) HHHL AIC | MZPLL6T4HMLA-000D3 | FW2K0 | NC07Y | 1.2.2 | 6.4 TB | Cache, Capacity |
| NVMe | PCIe | AIC | Mixed Use | Samsung | PM1735 SP 3WPD, SSD, NVMe, HHHL, 512e, ISE | MZPLJ1T6HBJRAD3 | Y7D7D | 5CM3G | 2.5.0 | 1.6 TB | Cache, Capacity |
| NVMe | PCIe | AIC | Mixed Use | Samsung | PM1735 SP 3WPD, SSD, NVMe, HHHL, 512e, ISE | MZPLJ6T4HALAAD3 | 91FXC | 5CM3G | 2.5.0 | 6.4 TB | Cache, Capacity |
1.2 - Azure Local Support Matrix for 16G (Dell 2606)
Supported Platforms
| Model | Supported Operating System |
|---|---|
| AX-760 | Windows Server 2022 Datacenter Windows Server 2025 Datacenter Azure Stack HCI-24H2 |
| AX-660 | Windows Server 2025 Datacenter Azure Stack HCI-24H2 |
| APEX MC-660 | Azure Stack HCI-24H2 |
| APEX MC-760 | Azure Stack HCI-24H2 |
Base Components
| Component | Type | Software Bundle | Minimum Supported Version | Supported Platforms | Supported OS |
|---|---|---|---|---|---|
| BIOS | Firmware DUP | G93PH | 2.10.1 | AX-660 AX-760 APEX MC-660 APEX MC-760 | NA |
| Chipset driver for 16G Intel platforms | Driver DUP | R40PW | 10.1.19928.8615 | AX-660 AX-760 APEX MC-660 APEX MC-760 | Windows Server 2022 Datacenter Windows Server 2025 Datacenter Azure Stack HCI-24H2 |
| iDRAC9 with Lifecycle Controller | Firmware DUP | 924YT | 7.30.10.50 | AX-660 AX-760 APEX MC-660 APEX MC-760 | NA |
| Expander Storage Backplane | Firmware DUP | J9JW2 | 1.61 | AX-760 APEX MC-760 | NA |
| NVMe Switch Storage Backplane | Firmware DUP | R39FM | 3.33 | AX-760 APEX MC-760 | NA |
| Non-expander Storage Backplane | Firmware DUP | 58MWX | 7.20 | AX-760 APEX MC-760 | NA |
| Non-expander Storage Backplane | Firmware DUP | 9T7YG | 7.20 | AX-660 APEX MC-660 | NA |
| iDRAC Service Module | Firmware DUP | 238XW | 6.1.0.0 | AX-660 AX-760 APEX MC-660 APEX MC-760 | NA |
| CPLD | Firmware DUP | XJG0V | 1.2.7 | AX-660 AX-760 APEX MC-660 APEX MC-760 | NA |
Network Adapters
| Component | Part Number | SDDC Advanced Qualification | RDMA Protocol | Firmware Software Bundle | Firmware Minimum Supported Version | Driver Software Bundle | Driver Minimum Supported Version | Supported OS | Supported Platforms |
|---|---|---|---|---|---|---|---|---|---|
| Broadcom 57504 Quad Port 10/25GbE, SFP28 Adapter, OCP NIC 3.0 | 3Y64D | Management Compute (Premium) Storage (Premium) | RoCEv2 | 2MY7D | 36.11.73.00 | 78X9T | 36.11.52.00 | Windows Server 2025 Datacenter Azure Stack HCI-24H2 | AX-660 AX-760 APEX MC-660 APEX MC-760 |
| Broadcom 57504 Quad Port 10/25GbE SFP28 Adapter, PCIe FH | J3D14 | ||||||||
| Broadcom 57416 Dual Port 10Gb, Base-T, PCIe Adapter, Full Height | 3TM39 | Management Compute (Standard) | Not Supported | 2MY7D | 36.11.73.00 | 78X9T | 36.11.52.00 | Windows Server 2025 Datacenter Azure Stack HCI-24H2 | AX-660 AX-760 APEX MC-660 APEX MC-760 |
| Broadcom 57416 Dual Port 10GbE BASE-T Adapter, PCIe Low Profile | NC5VD | ||||||||
| Broadcom 57416 Dual Port 10GbE BASE-T Adapter, OCP NIC 3.0 | RN1M5 | ||||||||
| Broadcom 5720 Dual Port 1 GbE Network LOM Mezz Card | 5NN70 | Management | N/A | 32W7Y | 23.61.3 | WYPPJ | 23.21.5 | Windows Server 2022 Datacenter Windows Server 2025 Datacenter Azure Stack HCI-24H2 | AX-660 AX-760 APEX MC-660 APEX MC-760 |
| Emulex LPe36002 Dual Port Fibre Channel 64Gb Adapter, PCIe LP | 39T9X | N/A | N/A | 15J5T | 03.10.12 | 8XGGG | 12.34.10 | Azure Stack HCI-24H2 | AX-660 AX-760 |
| Emulex LightPulse LPe35002-M2 2-Port 32Gb Fibre Channel Adapter LP | 5KW3M | ||||||||
| Emulex LightPulse LPe35002-M2 2-Port 32Gb Fibre Channel Adapter FH | CGT2C | ||||||||
| Emulex LPe36002 Dual Port Fibre Channel 64Gb Adapter, PCIe FH | D1XM2 | ||||||||
| Intel E810-XXV Dual Port 25GbE SFP28 Adapter, PCIe LP | 6J1N1 | Management Compute (Premium) Storage (Premium) | iWARP,RoCEv2 | FCG2V | 25.0.4 | 3VT4C | 25.0.4 | Windows Server 2022 Datacenter Windows Server 2025 Datacenter Azure Stack HCI-24H2 | AX-660 AX-760 APEX MC-660 APEX MC-760 |
| Intel E810-CQDA2 Dual Port 100GbE QSFP28 Adapter, PCIe FH | 85F8F | ||||||||
| Intel E810-XXV Dual Port 25GbE SFP28 Adapter, PCIe FH | CD16M | ||||||||
| Intel E810-CQDA2 Dual Port 100GbE QSFP28 Adapter, PCIe LP | DWNRF | ||||||||
| Intel E810-XXVDA2 Dual Port 1/10/25GbE SFP28 Adapter, OCP NIC 3.0 | PWH3C | ||||||||
| Intel E810-XXVDA4 Quad Port 1/10/25GbE SFP28 Adapter, PCIe FH | VK88G | ||||||||
| Intel E810-XXVDA4 Quad Port 1/10/25GbE SFP28 Adapter, OCP NIC 3.0 | Y4VV5 | ||||||||
| Mellanox ConnectX-6 Dx Dual Port 100GbE QSFP56 PCIe Adapter, FH | 8P2T2 | Management Compute (Premium) Storage (Premium) | RoCEv2 | 81T4K | 22.48.10.00 | 3T3MK | 26.001.03 | Windows Server 2022 Datacenter Windows Server 2025 Datacenter Azure Stack HCI-24H2 | AX-660 AX-760 APEX MC-660 APEX MC-760 |
| Mellanox ConnectX-6 Dx Dual Port 100GbE QSFP56 PCIe Adapter, LP | F6FXM | ||||||||
| Nvidia ConnectX-6 Lx Dual Port 10/25GbE SFP28 Adapter, PCIe LP | 6XJXK | Management Compute (Premium) Storage (Premium) | RoCEv2 | NMDJG | 26.48.10.00 | 3T3MK | 26.001.03 | Windows Server 2022 Datacenter Windows Server 2025 Datacenter Azure Stack HCI-24H2 | AX-660 AX-760 APEX MC-660 APEX MC-760 |
| Nvidia ConnectX-6 Lx Dual Port 10/25GbE SFP28 Adapter, OCP NIC 3.0 | DN78C | ||||||||
| Nvidia ConnectX-6 Lx Dual Port 10/25GbE SFP28 Adapter, PCIe FH | R5WK9 | Management Compute (Premium) Storage (Premium) | RoCEv2 | NMDJG | 26.48.10.00 | 3T3MK | 26.001.03 | Windows Server 2022 Datacenter Windows Server 2025 Datacenter Azure Stack HCI-24H2 | AX-760 APEX MC-760 |
| Marvell QLogic 2x32Gb QLE2772 FC HBA LP | JJW53 | N/A | N/A | 3XDWV | 17.10.04 | RF21G | 37.10.04 | Azure Stack HCI-24H2 | AX-660 AX-760 |
| Marvell QLogic 2x32Gb QLE2772 FC HBA FH | YM4FH | ||||||||
| Marvell QLogic 2x64Gb QLE2872C FC HBA LP | W72F2 | N/A | N/A | XMXP3 | 17.10.04 | RF21G | 37.10.04 | Azure Stack HCI-24H2 | AX-660 AX-760 |
| Marvell QLogic 2x64Gb QLE2872C FC HBA FH | X29W4 |
Network Switches
NOTE
A list of supported Network Switch models along with the supported firmware versions can be found here, Physical network requirements for Azure Local.PowerFlex
| Component | PowerFlex SDC Driver Version | Validated Platforms | Supported OS | Download Link | Extracted Package Location |
|---|---|---|---|---|---|
| PowerFlex Storage Data Client (SDC) | 4.5.2.2 | AX-660 AX-760 | Azure Stack HCI-24H2 | https://dl.dell.com/downloads/41X88_PowerFlex-Software-4.5.5.2-SDC-Driver.zip | PowerFlex_4.5.5200.104_Windows_SDC: EMC-ScaleIO-sdc-4.5-5200.104.msi |
| PowerFlex Storage Data Client (SDC) | 5 | AX-660 AX-760 | Azure Stack HCI-24H2 | https://dl.dell.com/downloads/09J62_PowerFlex-Software-5.0.0.0-SDC-Driver.zip | PowerFlex_5.0.0.941_Windows_SDC: EMC-ScaleIO-sdc-5.0-0.941.msi |
GPUs
| GPU Model | Vendor | Description | Part Number | Firmware version | Driver Version | GPU-P capable | Supported Platform | Supported OS |
|---|---|---|---|---|---|---|---|---|
| A16 | NVIDIA | NVIDIA Ampere A16, PCIe, 250W, 64GB Passive, Double Wide, Full Height GPU,V2 | D1P1T | 94.07.54.00.45 | 553.62 | Yes | AX-760 APEX MC-760 | Windows Server 2025 Datacenter Azure Stack HCI-24H2 |
| A2 | NVIDIA | NVIDIA Ampere A2, PCIe, 60W, 16GB Passive, Single Wide, Low Profile GPU, V2 | H98K0 | 94.07.5B.00.55 | 553.62 | Yes | AX-660 AX-760 APEX MC-660 APEX MC-760 | Windows Server 2025 Datacenter Azure Stack HCI-24H2 |
| A2 | NVIDIA | NVIDIA Ampere A2, PCIe, 60W, 16GB Passive, Single Wide, Full Height GPU, V2 | MG5JX | 94.07.5B.00.55 | 553.62 | Yes | AX-660 AX-760 APEX MC-660 APEX MC-760 | Windows Server 2025 Datacenter Azure Stack HCI-24H2 |
| A40 | NVIDIA | NVIDIA Ampere A40, PCIe, 300W, 48GB Passive, Double Wide, Full Height GPU | W6GX6 | 94.02.5C.00.0F | 553.62 | Yes | AX-760 APEX MC-760 | Windows Server 2025 Datacenter Azure Stack HCI-24H2 |
| L4 | NVIDIA | NVIDIA L4, PCIe, 72W, 24GB Passive, Single Wide Full Height GPU | NG3PY | 95.04.29.00.06 | 553.62 | Yes | AX-660 AX-760 APEX MC-660 APEX MC-760 | Windows Server 2025 Datacenter Azure Stack HCI-24H2 |
| L4 | NVIDIA | NVIDIA L4, PCIe, 72W, 24GB Passive, Single Wide Low Profile GPU | V9XT2 | 95.04.29.00.06 | 553.62 | Yes | AX-660 AX-760 APEX MC-660 APEX MC-760 | Windows Server 2025 Datacenter Azure Stack HCI-24H2 |
| L40 | NVIDIA | NVIDIA Ampere L40, PCIe, 300W, 48GB Passive, Double Wide, Full Height, Full Length, GPU with cable | VHNWT | 95.02.39.00.01 | 553.62 | Yes | AX-760 APEX MC-760 | Windows Server 2025 Datacenter Azure Stack HCI-24H2 |
| L40S | NVIDIA | NVIDIA Ampere L40S, PCIe, 350W, 48GB Passive, Double Wide, Full Height, Full Length, GPU with cable | 7WK28 | 95.02.66.00.02 | 553.62 | Yes | AX-760 APEX MC-760 | Windows Server 2025 Datacenter Azure Stack HCI-24H2 |
NOTE
Dell update packages are not available for GPU cards, please download the latest driver version from NVIDIA driver download page.Storage Controllers
| Component | Dell Part Number | Firmware Software Bundle | Firmware Minimum Supported Version | Driver Software Bundle | Driver Minimum Supported Version | Supported Platforms | Supported OS |
|---|---|---|---|---|---|---|---|
| BOSS-N1 | WW56V | WGYK7 | 2.1.13.2038 | Inbox | Inbox | AX-660 AX-760 APEX MC-660 APEX MC-760 | Windows Server 2022 Datacenter Windows Server 2025 Datacenter Azure Stack HCI-24H2 |
| HBA355i | K6MCJ | CG0P9 | 33.15.00.00 | HDH8G | 2.61.74.00 | AX-660 AX-760 APEX MC-660 APEX MC-760 | Windows Server 2025 Datacenter Azure Stack HCI-24H2 |
| HBA355i | K6MCJ | CG0P9 | 33.15.00.00 | R31NP | 2.61.74.00 | AX-660 AX-760 APEX MC-660 APEX MC-760 | Windows Server 2022 Datacenter |
SATA M.2 SSD Boot Only
| Type | Drive Type | Form Factor | Endurance | Vendor | Series | Model | Device Part Number (P/N) | Firmware Software Bundle | Firmware Minimum Supported Version | Capacity | Use |
|---|---|---|---|---|---|---|---|---|---|---|---|
| NVMe | PCIe | M.2 | Read Intensive | Micron | 7400 | MTFDKBA960TDZ | PRV6C | N71F4 | 1.6.0 | 960 GB | Boot |
| NVMe | PCIe | M.2 | Read Intensive | Micron | 7400 | MTFDKBG960TDZ | 0V8F7 | N71F4 | 1.6.0 | 960 GB | Boot |
| NVMe | PCIe | M.2 | Read Intensive | Hynix | PE8010 | HFS960GDC8X099N | 21GXV | R2TTT | 1.3.0 | 960 GB | Boot |
| NVMe | PCIe | M.2 | Read Intensive | Hynix | PE9010 | HFS960GEJ8X167N | 4H05X | YJG7C | 1.3.1 | 960 GB | Boot |
| NVMe | PCIe | M.2 | Read Intensive | Micron | 7450 | MTFDKBAXXXTFR | PH7J6 | JHKXR | 1.4.0 | 960 GB | Boot |
| NVMe | PCIe | M.2 | Read Intensive | Hynix | PE9010 | HFS960GDJ8X167N | XN5KG | 8X8YR | 1.2.1 | 960 GB | Boot |
| NVMe | PCIe | M.2 | Read Intensive | Samsung | PM9D3a | MZVL6480HFLUAD3 | C82V9 | FTVJG | 1.0.1 | 480 GB | Boot |
| NVMe | PCIe | M.2 | Read Intensive | Samsung | PM9D3a | MZVL6960HFLBAD3 | 8M3JN | FTVJG | 1.0.1 | 960 GB | Boot |
SAS 3.5" HDD Capacity Only
| Type | Drive Type | Form Factor | Endurance | Vendor | Series | Model | Device Part Number (P/N) | Firmware Software Bundle | Firmware Minimum Supported Version | Capacity | Use |
|---|---|---|---|---|---|---|---|---|---|---|---|
| HDD | SAS | 3.5 | NA | HGST | Vela-A | HUS726T4TALS200 | NT1X2 | J5K8G | PU09 | 4 TB | Capacity |
| HDD | SAS | 3.5 | NA | Toshiba | MG10 | MG10SDA400NY | 9VN79 | 99TKP | EP02 | 4 TB | Capacity |
| HDD | SAS | 3.5 | NA | HGST | Vela-AP | HUS728T8TAL5200 | 44YFV | 8GM6M | RS09 | 8 TB | Capacity |
| HDD | SAS | 3.5 | NA | Toshiba | MG06 | MG06SCA800EY | FV725 | 4G5GY | EH0D | 8 TB | Capacity |
| HDD | SAS | 3.5 | NA | HGST | Leo-A He12 | HUH721212AL5200 | 9HXK6 | 04PM5 | NS11 | 12 TB | Capacity |
| HDD | SAS | 3.5 | NA | WD | Paris-C | WUH721816AL5200 | VF206 | GY6MD | US09 | 16 TB | Capacity |
| HDD | SAS | 3.5 | NA | Seagate | Cimarron BP | ST4000NM019B | 10N7R | 3P5N0 | LW0B | 4 TB | Capacity |
| HDD | SAS | 3.5 | NA | Seagate | Cimarron BP | ST8000NM024B | C5HD0 | NM6GP | LS0C | 8 TB | Capacity |
| HDD | SAS | 3.5 | NA | Toshiba | MG08SD | MG08SDA400NY | FN2YX | GTG81 | EK06 | 4 TB | Capacity |
| HDD | SAS | 3.5 | NA | Seagate | Evans BP | ST12000NM006J | M1C0T | XF65R | PSLG | 12 TB | Capacity |
| HDD | SAS | 3.5 | NA | Seagate | Evans BP | ST16000NM006J | 41DXR | XF65R | PSLG | 16 TB | Capacity |
| HDD | SAS | 3.5 | NA | Toshiba | MG08SD | MG08SDA800EY | NJWMG | F95CX | EL02 | 8 TB | Capacity |
| HDD | SAS | 3.5 | Read Intensive | Seagate | LongsPeak | ST20000NM004D | R3G03 | WCTTD | GS09 | 20 TB | Capacity |
| HDD | SAS | 3.5 | NA | Toshiba | MG10SD | MG10SDA800EY | VJDMM | 99TKP | EP02 | 8 TB | Capacity |
| HDD | SAS | 3.5 | NA | Seagate | CimarronBP(EWP) | DL4000NM019B | F7DTR | M7PKX | LBW4 | 4 TB | Capacity |
| HDD | SAS | 3.5 | NA | Toshiba | MG09 | MG09SCA12TEY | 0N96X | 20Y02 | EM06 | 12 TB | Capacity |
| HDD | SAS | 3.5 | NA | Seagate | Summit | ST12000NM007H | FN7VR | 3VY0D | SWS9 | 12 TB | Capacity |
| HDD | SAS | 3.5 | NA | Toshiba | MG09 | MG09SCA16TEY | MXC46 | 20Y02 | EM06 | 16 TB | Capacity |
| HDD | SAS | 3.5 | NA | Seagate | Summit | ST16000NM007H | R0G8W | C50CR | SYS9 | 16 TB | Capacity |
| HDD | SAS | 3.5 | NA | Toshiba | MG10 | MG10SCA20TEY | NT45N | 0H3CX | EN04 | 20 TB | Capacity |
| HDD | SAS | 3.5 | NA | WD | Paris-D PR2 | WUH722020BL5200 | 1D4CR | XRFX3 | VS19 | 20 TB | Capacity |
| HDD | SAS | 3.5 | NA | Seagate | Summit | ST20000NM007H | R5KP7 | C50CR | SYS9 | 20 TB | Capacity |
| HDD | SAS | 3.5 | NA | WD | London DP | WUH722420AL5200 | MTTCF | 444T3 | YS04 | 20 TB | Capacity |
| HDD | SAS | 3.5 | NA | WD | Paris-CP | WUH722012CL5200 | 849H4 | VK0PK | AS05 | 12 TB | Capacity |
| HDD | SAS | 3.5 | NA | WD | Paris-CP | WUH722016CL5200 | H8HN1 | VK0PK | AS05 | 16 TB | Capacity |
| HDD | SAS | 3.5 | NA | Toshiba | MG11SC | MG11SCA16TEY | GGWNH | 9GW4N | ES02 | 16 TB | Capacity |
| HDD | SAS | 3.5 | NA | Toshiba | MG11SC | MG11SCA20TEY | 2FX1T | 9GW4N | ES02 | 20 TB | Capacity |
SATA 2.5" SSD Capacity Only
| Type | Drive Type | Form Factor | Endurance | Vendor | Series | Model | Device Part Number (P/N) | Firmware Software Bundle | Firmware Minimum Supported Version | Capacity | Use |
|---|---|---|---|---|---|---|---|---|---|---|---|
| SSD | SATA | 2.5 | Read Intensive | Intel | S4520 | SSDSC2KB019TZR | 6J65H | VJPKG | DL7C | 1.92 TB | Capacity |
| SSD | SATA | 2.5 | Read Intensive | SK Hynix | SE5110 | HFS1T9G3H2X069N | 962FP | HFTMG | DZ04 | 1.92 TB | Capacity |
| SSD | SATA | 2.5 | Read Intensive | Samsung | PM883a | MZ7LH1T9HALT0D3 | 9F9Y6 | 3GHD6 | HG61 | 1.92 TB | Capacity |
| SSD | SATA | 2.5 | Read Intensive | Samsung | PM893 | MZ7L31T9HBLTAD3 | 0KYP4 | T3HX9 | HJ64 | 1.92 TB | Capacity |
| SSD | SATA | 2.5 | Read Intensive | Samsung | PM893a | MZ7L31T9HELAAD3 | PTD53 | D5D3W | HL58 | 1.92 TB | Capacity |
| SSD | SATA | 2.5 | Read Intensive | Micron | 5300 | MTFDDAK1T9TDS | GYGVV | KT63Y | J008 | 1.92 TB | Capacity |
| SSD | SATA | 2.5 | Read Intensive | Micron | 5400 | MTFDDAK1T9TGA-1B | KXNX5 | RJ0WY | K003 | 1.92 TB | Capacity |
| SSD | SATA | 2.5 | Read Intensive | Intel | S4520 | SSDSC2KB038TZR | KM4C4 | VJPKG | DL7C | 3.84 TB | Capacity |
| SSD | SATA | 2.5 | Read Intensive | SK Hynix | SE5110 | HFS3T8G3H2X069N | 3GDK0 | HFTMG | DZ04 | 3.84 TB | Capacity |
| SSD | SATA | 2.5 | Read Intensive | Samsung | PM883a | MZ7LH3T8HALT0D3 | 5TVXD | 3GHD6 | HG61 | 3.84 TB | Capacity |
| SSD | SATA | 2.5 | Read Intensive | Samsung | PM893 | MZ7L33T8HBLTAD3 | GCN5W | T3HX9 | HJ64 | 3.84 TB | Capacity |
| SSD | SATA | 2.5 | Read Intensive | Samsung | PM893a | MZ7L33T8HELAAD3 | D7V89 | D5D3W | HL58 | 3.84 TB | Capacity |
| SSD | SATA | 2.5 | Read Intensive | Micron | 5300 | MTFDDAK3T8TDT | 4H1RX | R9YDC | J408 | 3.84 TB | Capacity |
| SSD | SATA | 2.5 | Read Intensive | Micron | 5400 | MTFDDAK3T8TGA-1B | CHF46 | JTW3W | K403 | 3.84 TB | Capacity |
| SSD | SATA | 2.5 | Mixed Use | Intel | S4620 | SSDSC2KG019TZR | 6XW3M | VJPKG | DL7C | 1.92 TB | Capacity |
| SSD | SATA | 2.5 | Mixed Use | SK Hynix | SE5130 | HFS1T9G3E2X149N | HCR09 | 17C3M | DG02 | 1.92 TB | Capacity |
| SSD | SATA | 2.5 | Mixed Use | SK Hynix | SE5031 | HFS1T9G32FEH-BA1 | GKTF1 | 174WY | DD03 | 1.92 TB | Capacity |
| SSD | SATA | 2.5 | Mixed Use | Samsung | PM897a | MZ7L31T9HENAAD3 | GR4WN | V5XNY | HK58 | 1.92 TB | Capacity |
| SSD | SATA | 2.5 | Mixed Use | Samsung | PM897 | MZ7L31T9HBNAAD3 | RRR7M | VRG4Y | HH64 | 1.92 TB | Capacity |
| SSD | SATA | 2.5 | Mixed Use | Micron | 5300 | MTFDDAK1T9TDT | MMCDY | KT63Y | J008 | 1.92 TB | Capacity |
| SSD | SATA | 2.5 | Mixed Use | Micron | 5400 | MTFDDAK1T9TGB-1B | XRXX2 | RJ0WY | K003 | 1.92 TB | Capacity |
SAS 2.5" SSD Cache or Capacity
| Type | Drive Type | Form Factor | Endurance | Vendor | Series | Model | Device Part Number (P/N) | Firmware Software Bundle | Firmware Minimum Supported Version | Capacity | Use |
|---|---|---|---|---|---|---|---|---|---|---|---|
| SSD | SAS | 2.5 | Mixed Use | Samsung | PM1655 | MZILG800HCHQAD3 | 3CHC8 | 7MTXM | DWG9 | 800 GB | Cache,Capacity |
| SSD | SAS | 2.5 | Mixed Use | Samsung | PM1655 | MZILG1T6HCJRAD3 | 5RJND | 7MTXM | DWG9 | 1.6 TB | Cache,Capacity |
| SSD | SAS | 2.5 | Mixed Use | Kioxia | PM7 | KPM7XVUG1T60 | 4TRHM | T21WT | C10E | 1.6 TB | Cache,Capacity |
| SSD | SAS | 2.5 | Mixed Use | Kioxia | PM6 | KPM6XVUG800G | NNGV4 | NGPR2 | BA48 | 800 GB | Cache,Capacity |
| SSD | SAS | 2.5 | Mixed Use | Kioxia | PM7 | KPM7XVUG800G | X96H8 | T21WT | C10E | 800 GB | Cache,Capacity |
| SSD | SAS | 2.5 | Mixed Use | Samsung | PM1655a | MZILG1T6HFJAAD3 | J7MWC | 42TFH | DWB1 | 1.6 TB | Cache, Capacity |
| SSD | SAS | 2.5 | Mixed Use | Samsung | PM1655a | MZILG3T2HFLTAD3 | 03P3V | 42TFH | DWB1 | 3.2 TB | Cache, Capacity |
| SSD | SAS | 2.5 | Mixed Use | Samsung | PM1655a | MZILG6T4HBLCAD3 | 24VJM | 42TFH | DWB1 | 6.4 TB | Cache, Capacity |
SAS 2.5" SSD Capacity Only
| Type | Drive Type | Form Factor | Endurance | Vendor | Series | Model | Device Part Number (P/N) | Firmware Software Bundle | Firmware Minimum Supported Version | Capacity | Use |
|---|---|---|---|---|---|---|---|---|---|---|---|
| SSD | SAS | 2.5 | Read Intensive | Samsung | PM1653 | MZILG1T9HCJRAD3 | NRR34 | 3MV58 | DSG9 | 1.92 TB | Capacity |
| SSD | SAS | 2.5 | Read Intensive | Samsung | PM1653 | MZILG3T8HCLSAD3 | 9N32F | 3MV58 | DSG9 | 3.84 TB | Capacity |
| SSD | SAS | 2.5 | Read Intensive | Samsung | PM1653 | MZILG7T6HBLAAD3 | Y8H7M | 3MV58 | DSG9 | 7.68 TB | Capacity |
| SSD | SAS | 2.5 | Read Intensive | Kioxia | PM7 | KPM7XRUG1T92 | 6K35K | T21WT | C10E | 1.92 TB | Capacity |
| SSD | SAS | 2.5 | Read Intensive | Kioxia | PM7 | KPM7XRUG3T84 | MT0R5 | T21WT | C10E | 3.84 TB | Capacity |
| SSD | SAS | 2.5 | Read Intensive | Kioxia | PM7 | KPM7XRUG7T68 | 7N1WT | T21WT | C10E | 7.68 TB | Capacity |
| SSD | SAS | 2.5 | Read Intensive | Samsung | PM1653a | MZILG1T9HFJAAD3 | 8WKDX | 862D9 | DSB1 | 1.92 TB | Capacity |
| SSD | SAS | 2.5 | Read Intensive | Samsung | PM1653a | MZILG3T8HFLTAD3 | MP2TJ | 862D9 | DSB1 | 3.84 TB | Capacity |
| SSD | SAS | 2.5 | Read Intensive | Samsung | PM1653a | MZILG7T6HBLCAD3 | 00CK9 | 862D9 | DSB1 | 7.68 TB | Capacity |
NVMe 2.5" Cache or Capacity
| Type | Drive Type | Form Factor | Endurance | Vendor | Series | Model | Device Part Number (P/N) | Firmware Software Bundle | Firmware Minimum Supported Version | Capacity | Use |
|---|---|---|---|---|---|---|---|---|---|---|---|
| NVMe | PCIe | 2.5 | Mixed Use | Samsung | PM1735 SP 3WPD, SSD, NVMe, 2.5, 512e, ISE | MZWLJ1T6HBJRAD3 | 6GK00 | 5CM3G | 2.5.0 | 1.6 TB | Cache, Capacity |
| NVMe | PCIe | 2.5 | Mixed Use | Samsung | PM1735 SP 3WPD, SSD, Gen4 NVMe, 2.5, 512e, ISE | MZWLJ3T2HBJRAD3 | 15TVC | 5CM3G | 2.5.0 | 3.2TB | Cache,Capacity |
| NVMe | PCIe | 2.5 | Mixed Use | Samsung | PM1735 SP 3WPD, SSD, Gen4 NVMe, 2.5, 512e, ISE | MZWLJ6T4HALAAD3 | F6V5P | 5CM3G | 2.5.0 | 6.4TB | Cache,Capacity |
| NVMe | PCIe | 2.5 | Mixed Use | Kioxia | CM6 SP | KCM6XVUL1T60 | P03YC | GMM6V | 2.2.2 | 1.6 TB | Cache, Capacity |
| NVMe | PCIe | 2.5 | Mixed Use | Kioxia | CM6 SP | KCM6XVUL3T20 | 97GR0 | GMM6V | 2.2.2 | 3.2 TB | Cache, Capacity |
| NVMe | PCIe | 2.5 | Mixed Use | Kioxia | CM6 SP | KCM6XVUL6T40 | K916X | GMM6V | 2.2.2 | 6.4 TB | Cache, Capacity |
| NVMe | PCIe | 2.5 | Mixed Use | Samsung | PM1735 V2 SP 3WPD | MZWLR3T2HBLSAD3 | V69W3 | 5V3P7 | 2.5.0 | 3.2 TB | Cache, Capacity |
| NVMe | PCIe | 2.5 | Mixed Use | Samsung | PM1735 V2 SP 3WPD | MZWLR6T4HALAAD3 | H8D5M | 5V3P7 | 2.5.0 | 6.4 TB | Cache, Capacity |
| NVMe | PCIe | 2.5 | Mixed Use | Samsung | PM1735a | MZWLR1T6HCJRAD3 | H8GHV | 71KRG | 1.2.0 | 1.6 TB | Cache,Capacity |
| NVMe | PCIe | 2.5 | Mixed Use | Samsung | PM1735a | MZWLR3T2HCLSAD3 | 617H6 | 71KRG | 1.2.0 | 3.2 TB | Cache,Capacity |
| NVMe | PCIe | 2.5 | Mixed Use | Samsung | PM1735a | MZWLR6T4HBLAAD3 | 9F6Y3 | 71KRG | 1.2.0 | 6.4 TB | Cache,Capacity |
| NVMe | PCIe | 2.5 | Mixed Use | Kioxia | CM7 | KCM7XVUG1T60 | MP4F2 | K1JTM | 2.0.3 | 1.6 TB | Cache, Capacity |
| NVMe | PCIe | 2.5 | Mixed Use | Kioxia | CM7 | KCM7XVUG3T20 | XFNX0 | K1JTM | 2.0.3 | 3.2 TB | Cache, Capacity |
| NVMe | PCIe | 2.5 | Mixed Use | Kioxia | CM7 | KCM7XVUG6T40 | 8RJJ9 | K1JTM | 2.0.3 | 6.4 TB | Cache, Capacity |
| NVMe | PCIe | 2.5 | Mixed Use | Hynix | PS1030 | HFS1T6GEJVX171N | 1HYKD | VNYK2 | 1.3.0 | 1.6 TB | Cache, Capacity |
| NVMe | PCIe | 2.5 | Mixed Use | Hynix | PS1030 | HFS3T2GEJVX171N | 9VWPD | VNYK2 | 1.3.0 | 3.2 TB | Cache, Capacity |
| NVMe | PCIe | 2.5 | Mixed Use | Hynix | PS1030 | HFS6T4GEJVX171N | PYMY6 | VNYK2 | 1.3.0 | 6.4 TB | Cache, Capacity |
| NVMe | PCIe | 2.5 | Mixed Use | Samsung | PM1745 | MZWLO1T6HCJR-00AD3 | FVC2P | V7V0K | 1.0.0 | 1.6 TB | Cache, Capacity |
| NVMe | PCIe | 2.5 | Mixed Use | Samsung | PM1745 | MZWLO3T2HCLS-00AD3 | FDNHD | V7V0K | 1.0.0 | 3.2 TB | Cache, Capacity |
| NVMe | PCIe | 2.5 | Mixed Use | Samsung | PM1745 | MZWLO6T4HBLA-00AD3 | 64K9C | V7V0K | 1.0.0 | 6.4 TB | Cache, Capacity |
| NVMe | PCIe | 2.5 | Mixed Use | Micron | 7600 | MTFDLAL1T6THS | DCR2M | VJXKC | 1.0.0 | 1.6 TB | Cache, Capacity |
| NVMe | PCIe | 2.5 | Mixed Use | Micron | 7600 | MTFDLAL3T2THS | J9TN7 | VJXKC | 1.0.0 | 3.2 TB | Cache, Capacity |
| NVMe | PCIe | 2.5 | Mixed Use | Samsung | PM9D5a | MZWL6800H | 53M2M | X5N7N | 1.0.1 | 800 GB | Cache, Capacity |
| NVMe | PCIe | 2.5 | Mixed Use | Samsung | PM9D5a | MZWL61T6H | 2M4HN | X5N7N | 1.0.1 | 1.6 TB | Cache, Capacity |
| NVMe | PCIe | 2.5 | Mixed Use | Samsung | PM9D5a | MZWL63T2H | 85GHX | X5N7N | 1.0.1 | 3.2 TB | Cache, Capacity |
| NVMe | PCIe | 2.5 | Mixed Use | Samsung | PM9D5a | MZWL66T4H | D68YV | X5N7N | 1.0.1 | 6.4 TB | Cache, Capacity |
| NVMe | PCIe | 2.5 | Mixed Use | Micron | 9550 | MTFDLAL3T2THB | D0GXJ | 4WN4V | 1.1.0 | 3.2 TB | Cache, Capacity |
| NVMe | PCIe | 2.5 | Mixed Use | Micron | 9550 | MTFDLAL6T4THB | WC68V | 4WN4V | 1.1.0 | 6.4 TB | Cache, Capacity |
| NVMe | 2.5 | Mixed Use | Kioxia | CD9P SP | KCD9XPUG1T60 | TXJPH | 33P3K | 1.0.0 | 1.6 TB | Cache, Capacity | |
| NVMe | 2.5 | Mixed Use | Kioxia | CD9P SP | KCD9XPUG3T20 | 1N3NW | 33P3K | 1.0.0 | 3.2 TB | Cache, Capacity | |
| NVMe | 2.5 | Mixed Use | Kioxia | CD9P SP | KCD9XPUG6T40 | VD4P0 | 33P3K | 1.0.0 | 6.4 TB | Cache, Capacity | |
| NVMe | 2.5 | Mixed Use | Kioxia | CM9 DP | KCM9XVUL1T60 | D9GTD | HJ15N | 1.0.0 | 1.6 TB | Cache, Capacity | |
| NVMe | 2.5 | Mixed Use | Kioxia | CM9 DP | KCM9XVUL3T20 | V57TP | HJ15N | 1.0.0 | 3.2 TB | Cache, Capacity | |
| NVMe | 2.5 | Mixed Use | Kioxia | CM9 DP | KCM9XVUL6T40 | 3161Y | HJ15N | 1.0.0 | 6.4 TB | Cache, Capacity | |
| NVMe | 2.5 | Mixed Use | Samsung | PM1755 | MZWL91T6HFJAAD3 | Y8RH3 | 40KGW | 1.0.0 | 1.6 TB | Cache, Capacity | |
| NVMe | 2.5 | Mixed Use | Samsung | PM1755 | MZWL93T2HFLTAD3 | K89MG | 40KGW | 1.0.0 | 3.2 TB | Cache, Capacity | |
| NVMe | 2.5 | Mixed Use | Samsung | PM1755 | MZWL96T4HBLCAD3 | JHYJ5 | 40KGW | 1.0.0 | 6.4 TB | Cache, Capacity |
NVMe 2.5" Capacity Only
| Type | Drive Type | Form Factor | Endurance | Vendor | Series | Model | Device Part Number (P/N) | Firmware Software Bundle | Firmware Minimum Supported Version | Capacity | Use |
|---|---|---|---|---|---|---|---|---|---|---|---|
| NVMe | PCIe | 2.5 | Read Intensive | Samsung | PM1733 V2 | MZWLR3T8HBLSAD3 | G5N65 | 5V3P7 | 2.5.0 | 3.84 TB | Capacity |
| NVMe | PCIe | 2.5 | Read Intensive | Samsung | PM1733 V2 | MZWLR7T6HALAAD3 | DX74Y | 5V3P7 | 2.5.0 | 7.68 TB | Capacity |
| NVMe | PCIe | 2.5 | Read Intensive | Samsung | PM1733a | MZWLR1T9HCJRAD3 | 8PMRM | 71KRG | 1.2.0 | 1.92 TB | Capacity |
| NVMe | PCIe | 2.5 | Read Intensive | Samsung | PM1733a | MZWLR3T8HCLSAD3 | RJKM5 | 71KRG | 1.2.0 | 3.84 TB | Capacity |
| NVMe | PCIe | 2.5 | Read Intensive | Samsung | PM1733a | MZWLR7T6HBLAAD3 | R1J8J | 71KRG | 1.2.0 | 7.68 TB | Capacity |
| NVMe | PCIe | 2.5 | Read Intensive | Samsung | PM1733a | MZWLR15THBLAAD3 | D4CJG | 71KRG | 1.2.0 | 15.36 TB | Capacity |
| NVMe | PCIe | 2.5 | Read Intensive | Kioxia | CM6 | KCM6XRUL1T92 | N0VK0 | GMM6V | 2.2.2 | 1.92 TB | Capacity |
| NVMe | PCIe | 2.5 | Read Intensive | Kioxia | CM6 | KCM6XRUL3T84 | 8W2G5 | GMM6V | 2.2.2 | 3.84 TB | Capacity |
| NVMe | PCIe | 2.5 | Read Intensive | Kioxia | CM6 | KCM6XRUL7T68 | VD0JX | GMM6V | 2.2.2 | 7.68 TB | Capacity |
| NVMe | PCIe | 2.5 | Read Intensive | Kioxia | CM6 | KCM6XRUL15T3 | J91CR | GMM6V | 2.2.2 | 15.36 TB | Capacity |
| NVMe | PCIe | 2.5 | Read Intensive | Kioxia | CM7 | KCM7XRUG1T92 | M8YW0 | K1JTM | 2.0.3 | 1.92 TB | Capacity |
| NVMe | PCIe | 2.5 | Read Intensive | Kioxia | CM7 | KCM7XRUG3T84 | XHYGF | K1JTM | 2.0.3 | 3.84 TB | Capacity |
| NVMe | PCIe | 2.5 | Read Intensive | Kioxia | CM7 | KCM7XRUG7T68 | VV2M7 | K1JTM | 2.0.3 | 7.68 TB | Capacity |
| NVMe | PCIe | 2.5 | Read Intensive | Kioxia | CM7 | KCM7XRUG15T3 | DX2PD | K1JTM | 2.0.3 | 15.36 TB | Capacity |
| NVMe | PCIe | 2.5 | Read Intensive | Kioxia | CD7 | KCD7XRUG7T68 | 0RD61 | K6597 | 2.0.1 | 7.68 TB | Capacity |
| NVMe | PCIe | 2.5 | Read Intensive | Kioxia | CD8 | KCD8XRUG3T84 | N1MK1 | 17R29 | 2.0.2 | 3.84 TB | Capacity |
| NVMe | PCIe | 2.5 | Read Intensive | Hynix | PS1010 | HFS1T9GEJVX171N | 7GGK1 | VNYK2 | 1.3.0 | 1.92 TB | Capacity |
| NVMe | PCIe | 2.5 | Read Intensive | Hynix | PS1010 | HFS3T8GEJVX171N | J4TDK | VNYK2 | 1.3.0 | 3.84 TB | Capacity |
| NVMe | PCIe | 2.5 | Read Intensive | Hynix | PS1010 | HFS7T6GEJVX171N | 2533N | VNYK2 | 1.3.0 | 7.68 TB | Capacity |
| NVMe | PCIe | 2.5 | Read Intensive | Hynix | PS1010 | HFS15T3EJVX171N | 8TY8G | VNYK2 | 1.3.0 | 15.36 TB | Capacity |
| NVMe | PCIe | 2.5 | Read Intensive | Hynix | PE8010 | HFS960GECTX088N | WR2FG | T1XKD | 1.3.0 | 960 GB | Capacity |
| NVMe | PCIe | 2.5 | Read Intensive | Hynix | PE8110 | HFS7T6GEETX099N | RG3T2 | TDGKY | 1.1.0 | 7.68 TB | Capacity |
| NVMe | PCIe | 2.5 | Read Intensive | Kioxia | CD8 | KCD8XRUG960G | YNGYD | 17R29 | 2.0.2 | 960 GB | Capacity |
| NVMe | PCIe | 2.5 | Read Intensive | Micron | 7450 | MTFDKCC960TFR | KXT48 | TVCWT | 1.4.0 | 960 GB | Capacity |
| NVMe | PCIe | 2.5 | Read Intensive | Micron | 7500 | MTFDKCC960TGP | G7NCH | N78NP | 1.3.1 | 960 GB | Capacity |
| NVMe | PCIe | 2.5 | Read Intensive | Samsung | PM9A3 | MZQL2960HCJRAD3 | 6HYWM | XMFKX | 1.1.1 | 960 GB | Capacity |
| NVMe | PCIe | 2.5 | Read Intensive | Samsung | PM1733 V2 | MZWLR1T9HBJRAD3 | WPR17 | 5V3P7 | 2.5.0 | 1.92 TB | Capacity |
| NVMe | PCIe | 2.5 | Read Intensive | Samsung | PM9A3 | MZQL21T9H | TGYF5 | XMFKX | 1.1.1 | 1.92 TB | Capacity |
| NVMe | PCIe | 2.5 | Read Intensive | Micron | 7450 | MTFDKCC1T9TFR | JH61J | TVCWT | 1.4.0 | 1.92 TB | Capacity |
| NVMe | PCIe | 2.5 | Read Intensive | Micron | 7500 | MTFDKCC1T9TGP | M7RHM | N78NP | 1.3.1 | 1.92 TB | Capacity |
| NVMe | PCIe | 2.5 | Read Intensive | Hynix | PE8110 | HFS1T9GEETX099N | 147DR | TDGKY | 1.1.0 | 1.92 TB | Capacity |
| NVMe | PCIe | 2.5 | Read Intensive | Micron | 7450 | MTFDKCC3T8TFR | NDK2D | TVCWT | 1.4.0 | 3.84 TB | Capacity |
| NVMe | PCIe | 2.5 | Read Intensive | Kioxia | CD7 | KCD7XRUG3T84 | RFYP9 | K6597 | 2.0.1 | 3.84 TB | Capacity |
| NVMe | PCIe | 2.5 | Read Intensive | Hynix | PE8010 | HFS3T8GECTX088N | V6WP5 | T1XKD | 1.3.0 | 3.84 TB | Capacity |
| NVMe | PCIe | 2.5 | Read Intensive | Samsung | PM9A3 | MZQL23T8HCLSAD3 | P7G03 | XMFKX | 1.1.1 | 3.84 TB | Capacity |
| NVMe | PCIe | 2.5 | Read Intensive | Micron | 7500 | MTFDKCC3T8TGP | GT3F3 | N78NP | 1.3.1 | 3.84 TB | Capacity |
| NVMe | PCIe | 2.5 | Read Intensive | Intel | Arbordale Plus R P5316 | SSDPF2NV307TZ | 4KCVT | D6RJK | 1.7.0 | 30.72 TB | Capacity |
| NVMe | PCIe | 2.5 | Read Intensive | Samsung | PM1743 | MZWLO3T8HCLS-00AD3 | 9GXVF | V7V0K | 1.0.0 | 3.84 TB | Capacity |
| NVMe | PCIe | 2.5 | Read Intensive | Samsung | PM1743 | MZWLO7T6HBLA-00AD3 | DNPR4 | V7V0K | 1.0.0 | 7.68 TB | Capacity |
| NVMe | PCIe | 2.5 | Read Intensive | Kioxia | CD8 | KCD8XRUG1T92 | NNKCT | 17R29 | 2.0.2 | 1.92 TB | Capacity |
| NVMe | PCIe | 2.5 | Read Intensive | Samsung | PM9A3 | MZQL27T6HBLAAD3 | 30FX3 | XMFKX | 1.1.1 | 7.68 TB | Capacity |
| NVMe | PCIe | 2.5 | Read Intensive | Micron | 7450 | MTFDKCC7T6TFR | 91KYJ | TVCWT | 1.4.0 | 7.68 TB | Capacity |
| NVMe | PCIe | 2.5 | Read Intensive | Micron | 7500 | MTFDKCC7T6TGP | RTJFW | N78NP | 1.3.1 | 7.68 TB | Capacity |
| NVMe | PCIe | 2.5 | Read Intensive | Kioxia | CD8 | KCD8XRUG7T68 | MXD8J | 17R29 | 2.0.2 | 7.68 TB | Capacity |
| NVMe | PCIe | 2.5 | Read Intensive | SK Hynix | PE8110 | HFS960GEETX099N | 26WJ0 | TDGKY | 1.1.0 | 960 GB | Capacity |
| NVMe | PCIe | 2.5 | Read Intensive | Samsung | PM1743 | MZWLO1T9HCJR-00AD3 | G64N5 | V7V0K | 1.0.0 | 1.92 TB | Capacity |
| NVMe | PCIe | 2.5 | Read Intensive | SK Hynix | PE8110 | HFS3T8GEETX099N | 2V97V | TDGKY | 1.1.0 | 3.84 TB | Capacity |
| NVMe | PCIe | 2.5 | Read Intensive | Samsung | PM1743 | MZWLO15THBLA-00AD3 | VPWMR | V7V0K | 1.0.0 | 15.36 TB | Capacity |
| NVMe | PCIe | 2.5 | Read Intensive | Samsung | PM9D3a | MZWL6960HFJA-00AD3 | 71Y2J | X5N7N | 1.0.1 | 960 GB | Capacity |
| NVMe | PCIe | 2.5 | Read Intensive | Samsung | PM9D3a | MZVL61T9HBL1-00AD3 | 9MNPJ | FTVJG | 1.0.1 | 1.92 TB | Capacity |
| NVMe | PCIe | 2.5 | Read Intensive | Samsung | PM9D3a | MZWL63T8HFLT-00AD3 | 2H60T | X5N7N | 1.0.1 | 3.84 TB | Capacity |
| NVMe | PCIe | 2.5 | Read Intensive | Samsung | PM9D3a | MZWL67T6HBLC-00AD3 | VYT6X | X5N7N | 1.0.1 | 7.68 TB | Capacity |
| NVMe | PCIe | 2.5 | Read Intensive | Micron | 7600 | MTFDLAL1T9THG | N6RN7 | VJXKC | 1.0.0 | 1.92 TB | Capacity |
| NVMe | PCIe | 2.5 | Read Intensive | Micron | 7600 | MTFDLAL3T8THG | 7X0XC | VJXKC | 1.0.0 | 3.84 TB | Capacity |
| NVMe | PCIe | 2.5 | Read Intensive | Micron | 7600 | MTFDLAL7T6THG | Y4GJR | VJXKC | 1.0.0 | 7.68 TB | Capacity |
| NVMe | PCIe | 2.5 | Read Intensive | Micron | 7600 | MTFDLAL15T3THG | 5J26R | VJXKC | 1.0.0 | 15.36 TB | Capacity |
| NVMe | PCIe | 2.5 | Read Intensive | Micron | 9550 | MTFDLAL3T8THA | PFV73 | 4WN4V | 1.1.0 | 3.84 TB | Capacity |
| NVMe | PCIe | 2.5 | Read Intensive | Micron | 9550 | MTFDLAL7T6THA | 39JW6 | 4WN4V | 1.1.0 | 7.68 TB | Capacity |
| NVMe | PCIe | 2.5 | Read Intensive | Micron | 9550 | MTFDLAL15T3THA | R3GD7 | 4WN4V | 1.1.0 | 15.36 TB | Capacity |
| NVMe | 2.5 | Read Intensive | Kioxia | CD9P SP | KCD9XPUG1T92 | CW1VK | 33P3K | 1.0.0 | 1.92 TB | Capacity | |
| NVMe | 2.5 | Read Intensive | Kioxia | CD9P SP | KCD9XPUG3T84 | VJ8RW | 33P3K | 1.0.0 | 3.84 TB | Capacity | |
| NVMe | 2.5 | Read Intensive | Kioxia | CD9P SP | KCD9XPUG7T68 | 5C8M1 | 33P3K | 1.0.0 | 7.68 TB | Capacity | |
| NVMe | 2.5 | Read Intensive | Kioxia | CD9P SP | KCD9XPUG15T3 | 1MFNC | 33P3K | 1.0.0 | 15.36 TB | Capacity | |
| NVMe | 2.5 | Read Intensive | Kioxia | CM9 DP | KCM9XRUL1T92 | R83Y1 | HJ15N | 1.0.0 | 1.92 TB | Capacity | |
| NVMe | 2.5 | Read Intensive | Kioxia | CM9 DP | KCM9XRUL3T84 | M5PRJ | HJ15N | 1.0.0 | 3.84 TB | Capacity | |
| NVMe | 2.5 | Read Intensive | Kioxia | CM9 DP | KCM9XRUL7T68 | KP77M | HJ15N | 1.0.0 | 7.68 TB | Capacity | |
| NVMe | 2.5 | Read Intensive | Kioxia | CM9 DP | KCM9XRUL15T3 | F89P6 | HJ15N | 1.0.0 | 15.36 TB | Capacity | |
| NVMe | 2.5 | Read Intensive | Samsung | PM1753 | MZWL91T9HFJAAD3 | R0H08 | 40KGW | 1.0.0 | 1.92 TB | Capacity | |
| NVMe | 2.5 | Read Intensive | Samsung | PM1753 | MZWL93T8HFLTAD3 | K4XRJ | 40KGW | 1.0.0 | 3.84 TB | Capacity | |
| NVMe | 2.5 | Read Intensive | Samsung | PM1753 | MZWL97T6HBLCAD3 | P7DD3 | 40KGW | 1.0.0 | 7.68 TB | Capacity | |
| NVMe | 2.5 | Read Intensive | Samsung | PM1753 | MZWL915THBLFAD3 | KX76K | 40KGW | 1.0.0 | 15.36 TB | Capacity |
1.3 - Azure Local Support Matrix for 17G (Dell 2606)
Supported Platforms
| Model | Supported Operating System |
|---|---|
| AX-770 | Windows Server 2025 Datacenter Azure Stack HCI-24H2 |
| AX-670 | Windows Server 2025 Datacenter Azure Stack HCI-24H2 |
Base Components
| Component | Type | Software Bundle | Minimum Supported Version | Supported Platforms | Supported OS |
|---|---|---|---|---|---|
| BIOS | Firmware DUP | VTF4T | 1.8.5 | AX-670 AX-770 | NA |
| Chipset driver for 17G Intel platforms | Driver DUP | 7TXYY | 10.1.19928.8615 | AX-670 AX-770 | Windows Server 2025 Datacenter Azure Stack HCI-24H2 |
| iDRAC10 with Lifecycle Controller | Firmware DUP | 11F63 | 1.30.30.50 | AX-670 AX-770 | NA |
| YP95X | 1.30.10.50 | ||||
| Passive Backplane (1U 8xE3 x2) | Firmware DUP | 0M4TD | 1.92 | AX-670 | NA |
| Passive Backplane (2U 8xE3 x2) | Firmware DUP | 7P6P5 | 1.92 | AX-770 | NA |
| iDRAC Service Module | Firmware DUP | 238XW | 6.1.0.0 | AX-670 AX-770 | NA |
| FPGA | Firmware DUP | WTG14 | 109.128.104 | AX-670 AX-770 | NA |
Network Adapters
| Component | Part Number | SDDC Advanced Qualification | RDMA Protocol | Firmware Software Bundle | Firmware Minimum Supported Version | Driver Software Bundle | Driver Minimum Supported Version | Supported OS | Supported Platforms |
|---|---|---|---|---|---|---|---|---|---|
| Broadcom 57412 Quad Port 10GbE Base-T, OCP 3.0 NIC +Sec | 59JPJ | Management Compute (Premium) | NA | FF94T | 236.1.173.0 | 78X9T | 36.11.52.00 | Windows Server 2025 Datacenter Azure Stack HCI-24H2 | AX-670 AX-770 |
| Broadcom 57412 Dual Port 10GbE BASE-T Adapter, OCP 3.0 NIC +Sec | MN1T3 | ||||||||
| Emulex LPe37102 SecureHBA Dual Port Fibre Channel 32Gb Adapter, PCIe Low Profile +Sec | 2HGNX | NA | NA | 15J5T | 03.10.12 | 8XGGG | 12.34.10 | Windows Server 2025 Datacenter Azure Stack HCI-24H2 | AX-670 |
| Emulex LPe38102 SecureHBA Dual Port Fibre Channel 64Gb Adapter, PCIe Low Profile +Sec | TF3HV | ||||||||
| Emulex LPe38102 SecureHBA Dual Port Fibre Channel 64Gb Adapter, PCIe Full Height +Sec | D6PNX | NA | NA | 15J5T | 03.10.12 | 8XGGG | 12.34.10 | Windows Server 2025 Datacenter Azure Stack HCI-24H2 | AX-770 |
| Emulex LPe37102 SecureHBA Dual Port Fibre Channel 32Gb Adapter, PCIe Full Height +Sec | JWVMH | ||||||||
| NVIDIA/Mellanox ConnectX-6 Dx OCP3 | 769PV | Management Compute (Premium) Storage (Premium) | RoCEv2 | 0WM7T | 22.48.1000 | 3T3MK | 26.001.03 | Windows Server 2025 Datacenter Azure Stack HCI-24H2 | AX-670 AX-770 |
| NVIDIA/Mellanox ConnectX-6 Dx PCIe LP | PXKX5 | ||||||||
| NVIDIA/Mellanox ConnectX-6 Dx PCIe FH | 6PKY5 | Management Compute (Premium) Storage (Premium) | RoCEv2 | 0WM7T | 22.48.1000 | 3T3MK | 26.001.03 | Windows Server 2025 Datacenter Azure Stack HCI-24H2 | AX-770 |
| NVIDIA/Mellanox ConnectX-6 Lx PCIe LP | 74GDV | Management Compute (Premium) Storage (Premium) | RoCEv2 | KX0W4 | 26.48.1000 | 3T3MK | 26.001.03 | Windows Server 2025 Datacenter Azure Stack HCI-24H2 | AX-670 AX-770 |
| NVIDIA/Mellanox ConnectX-6 Lx OCP3 | 7GGY4 | ||||||||
| NVIDIA/Mellanox ConnectX-6 Lx PCIe FH | 17W36 | Management Compute (Premium) Storage (Premium) | RoCEv2 | KX0W4 | 26.48.1000 | 3T3MK | 26.001.03 | Windows Server 2025 Datacenter Azure Stack HCI-24H2 | AX-770 |
| QLogic QLE2772C Dual Port 32Gb Fibre Channel, PCIe Low Profile +Sec | K10X5 | NA | NA | 3XDWV | 17.10.04 | RF21G | 37.10.04 | Windows Server 2025 Datacenter Azure Stack HCI-24H2 | AX-670 |
| QLogic QLE2772C Dual Port 32Gb Fibre Channel, PCIe Full Height +Sec | 663P2 | NA | NA | 3XDWV | 17.10.04 | RF21G | 37.10.04 | Windows Server 2025 Datacenter Azure Stack HCI-24H2 | AX-770 |
| QLogic QLE2872C Dual Port 64Gb Fibre Channel, PCIe Low Profile +Sec | W72F2 | NA | NA | XMXP3 | 17.10.04 | RF21G | 37.10.04 | Windows Server 2025 Datacenter Azure Stack HCI-24H2 | AX-670 |
| QLogic QLE2872C Dual Port 64Gb Fibre Channel, PCIe Full Height +Sec | X29W4 | NA | NA | XMXP3 | 17.10.04 | RF21G | 37.10.04 | Windows Server 2025 Datacenter Azure Stack HCI-24H2 | AX-770 |
Network Switches
NOTE
A list of supported Network Switch models along with the supported firmware versions can be found here, Physical network requirements for Azure Local.PowerFlex
| Component | PowerFlex SDC Driver Version | Validated Platforms | Supported OS | Download Link | Extracted Package Location |
|---|---|---|---|---|---|
| PowerFlex Storage Data Client (SDC) | 4.5.2.2 | AX-670 AX-770 | Azure Stack HCI-24H2 | https://dl.dell.com/downloads/41X88_PowerFlex-Software-4.5.5.2-SDC-Driver.zip | PowerFlex_4.5.5200.104_Windows_SDC: EMC-ScaleIO-sdc-4.5-5200.104.msi |
| PowerFlex Storage Data Client (SDC) | 5 | AX-670 AX-770 | Azure Stack HCI-24H2 | https://dl.dell.com/downloads/09J62_PowerFlex-Software-5.0.0.0-SDC-Driver.zip | PowerFlex_5.0.0.941_Windows_SDC: EMC-ScaleIO-sdc-5.0-0.941.msi |
GPUs
| GPU Model | Vendor | Description | Part Number | Firmware version | Driver Version | GPU-P capable | Supported Platform | Supported OS |
|---|---|---|---|---|---|---|---|---|
| A16 | NVIDIA | NVIDIA Ampere A16, PCIe, 250W, 64GB Passive, Double Wide, Full Height GPU,V2 | D1P1T | 94.07.54.00.45 | 553.62 | AX-770 | Windows Server 2025 Datacenter Azure Stack HCI-24H2 | |
| L4 | NVIDIA | NVIDIA L4, PCIe, 72W, 24GB Passive, Single Wide Low Profile GPU | V9XT2 | 95.04.29.00.06 | 553.62 | AX-670 | Windows Server 2025 Datacenter Azure Stack HCI-24H2 | |
| L4 | NVIDIA | NVIDIA L4, PCIe, 72W, 24GB Passive, Single Wide Full Height GPU | NG3PY | 95.04.29.00.06 | 553.62 | AX-770 | Windows Server 2025 Datacenter Azure Stack HCI-24H2 | |
| L40S | NVIDIA | NVIDIA Ampere L40S, PCIe, 350W, 48GB Passive, Double Wide, Full Height, Full Length, GPU with cable | 7WK28 | 95.02.66.00.02 | 553.62 | AX-770 | Windows Server 2025 Datacenter Azure Stack HCI-24H2 | |
| RTX PRO 6000 | NVIDIA | NVIDIA RTX PRO 6000 BSE 96GB 600W PCIe GPU | THH68 | 98.02.74.00.01 | 582.53 | AX-770 | Windows Server 2025 Datacenter Azure Stack HCI-24H2 |
NOTE
Dell update packages are not available for GPU cards, please download the latest driver version from NVIDIA driver download page.Storage Controllers
| Component | Dell Part Number | Firmware Software Bundle | Firmware Minimum Supported Version | Driver Software Bundle | Driver Minimum Supported Version | Supported Platforms | Supported OS |
|---|---|---|---|---|---|---|---|
| BOSS-N1 | NH7WD | GDT3C | 2.2.13.2038 | Inbox | Inbox | AX-670 AX-770 | Windows Server 2025 Datacenter Azure Stack HCI-24H2 |
SATA M.2 SSD Boot Only
| Type | Drive Type | Form Factor | Endurance | Vendor | Series | Model | Device Part Number (P/N) | Firmware Software Bundle | Firmware Minimum Supported Version | Capacity | Use |
|---|---|---|---|---|---|---|---|---|---|---|---|
| NVMe | PCIe | M.2 | NA | Solidigm | PE9010 | HFS960GDJ8X167N | XN5KG | 8X8YR | 1.2.1 | 960 GB | Boot |
| NVMe | PCIe | M.2 | NA | Solidigm | PE9010 | HFS960GEJ8X167N | 4H05X | YJG7C | 1.3.1 | 960 GB | Boot |
| NVMe | PCIe | M.2 | NA | Micron | 7450 | MTFDKBAXXXTFR | PH7J6 | JHKXR | 1.4.0 | 960 GB | Boot |
NVMe 2.5" Cache or Capacity
| Type | Drive Type | Form Factor | Endurance | Vendor | Series | Model | Device Part Number (P/N) | Firmware Software Bundle | Firmware Minimum Supported Version | Capacity | Use |
|---|---|---|---|---|---|---|---|---|---|---|---|
| NVMe | PCIe | E3.s | Mixed Use | Kioxia | CD8P | KCD8XPJE1T60 | R64H4 | 34VN7 | 2.0.5 | 1.6 TB | Cache, Capacity |
| NVMe | PCIe | E3.s | Mixed Use | Hynix | PE1030 | HFS1T6GFJCX180N | MXDXH | 0930W | 1.1.0 | 1.6 TB | Cache, Capacity |
| NVMe | PCIe | E3.s | Mixed Use | Samsung | PM1745 | MZ3LO3T2HCLSAD3 | 7R3TT | 694C5 | 1.1.0 | 3.2 TB | Cache, Capacity |
| NVMe | PCIe | E3.s | Mixed Use | Kioxia | CM7 | KCM7XVJE3T20 | 6J3Y1 | 0822W | 2.0.4 | 3.2 TB | Cache, Capacity |
| NVMe | PCIe | E3.s | Mixed Use | Kioxia | CD8P | KCD8XPJE3T20 | GP5GV | 34VN7 | 2.0.5 | 3.2 TB | Cache, Capacity |
| NVMe | PCIe | E3.s | Mixed Use | Hynix | PS1030 | HFS3T2GFJCX171N | 734CX | WHGGM | 1.1.0 | 3.2 TB | Cache, Capacity |
| NVMe | PCIe | E3.s | Mixed Use | Hynix | PE1030 | HFS3T2GFJCX180N | HCDFH | 0930W | 1.1.0 | 3.2 TB | Cache, Capacity |
| NVMe | PCIe | E3.s | Mixed Use | Hynix | PS1030 | HFS6T4GFJCX171N | DH5XD | WHGGM | 1.1.0 | 6.4 TB | Cache, Capacity |
| NVMe | PCIe | E3.s | Mixed Use | Samsung | PM1745 | MZ3LO6T4HBLAAD3 | FNPJC | 694C5 | 1.1.0 | 6.4 TB | Cache, Capacity |
| NVMe | PCIe | E3.s | Mixed Use | Kioxia | CM7 | KCM7XVJE6T40 | V4DNH | 0822W | 2.0.4 | 6.4 TB | Cache, Capacity |
| NVMe | PCIe | E3.s | Mixed Use | Kioxia | CM9 DP | KCM9XVJE1T60 | 3WJ8J | HJ15N | 1.0.0 | 1.6 TB | Cache, Capacity |
| NVMe | PCIe | E3.s | Mixed Use | Kioxia | CM9 DP | KCM9XVJE3T20 | GD7TT | HJ15N | 1.0.0 | 3.2 TB | Cache, Capacity |
| NVMe | PCIe | E3.s | Mixed Use | Kioxia | CM9 DP | KCM9XVJE6T40 | 979HD | HJ15N | 1.0.0 | 6.4 TB | Cache, Capacity |
| NVMe | PCIe | E3.s | Mixed Use | Samsung | PM1755 | MZ3L93T2HFJA-00AD3 | W30JJ | JYF3Y | 1.0.0 | 3.2 TB | Cache, Capacity |
| NVMe | PCIe | E3.s | Mixed Use | Samsung | PM1755 | MZ3L696T4HFLT-00AD3 | WG6RH | JYF3Y | 1.0.0 | 6.4 TB | Cache, Capacity |
NVMe 2.5" Capacity Only
| Type | Drive Type | Form Factor | Endurance | Vendor | Series | Model | Device Part Number (P/N) | Firmware Software Bundle | Firmware Minimum Supported Version | Capacity | Use |
|---|---|---|---|---|---|---|---|---|---|---|---|
| NVMe | PCIe | E3.s | Read Intensive | Kioxia | CD8P | KCD8XPJE1T92 | 59Y5J | 34VN7 | 2.0.5 | 1.92 TB | Capacity |
| NVMe | PCIe | E3.s | Read Intensive | Hynix | PE1010 | HFS1T9GFJCX180N | 9CC5X | 0930W | 1.1.0 | 1.92 TB | Capacity |
| NVMe | PCIe | E3.s | Read Intensive | Samsung | PM1743 | MZ3LO3T8HCLSAD3 | 831H5 | 8K2NH | 1.1.0 | 3.84 TB | Capacity |
| NVMe | PCIe | E3.s | Read Intensive | Kioxia | CM7 | KCM7XRJE3T84 | YGK8R | 0822W | 2.0.4 | 3.84 TB | Capacity |
| NVMe | PCIe | E3.s | Read Intensive | Hynix | PS1010 | HFS3T8GFJCX171N | 84M8H | WHGGM | 1.1.0 | 3.84 TB | Capacity |
| NVMe | PCIe | E3.s | Read Intensive | Kioxia | CD8P | KCD8XPJE3T84 | 6RC59 | 34VN7 | 2.0.5 | 3.84 TB | Capacity |
| NVMe | PCIe | E3.s | Read Intensive | Hynix | PE1010 | HFS3T8GFJCX180N | 1NFG2 | 0930W | 1.1.0 | 3.84 TB | Capacity |
| NVMe | PCIe | E3.s | Read Intensive | Samsung | PM1743 | MZ3LO7T6HBLAAD3 | NKGTX | 8K2NH | 1.1.0 | 7.68 TB | Capacity |
| NVMe | PCIe | E3.s | Read Intensive | Kioxia | CM7 | KCM7XRJE7T68 | G27W5 | 0822W | 2.0.4 | 7.68 TB | Capacity |
| NVMe | PCIe | E3.s | Read Intensive | Hynix | PS1010 | HFS7T6GFJCX171N | DDKCG | WHGGM | 1.1.0 | 7.68 TB | Capacity |
| NVMe | PCIe | E3.s | Read Intensive | Samsung | PM1743 | MZ3LO15THBLAAD3 | RRYKC | 8K2NH | 1.1.0 | 15.36 TB | Capacity |
| NVMe | PCIe | E3.s | Read Intensive | Kioxia | CM7 | KCM7XRJE15T3 | YRN98 | 0822W | 2.0.4 | 15.36 TB | Capacity |
| NVMe | PCIe | E3.s | Read Intensive | Hynix | PS1010 | HFS15T3FJCX171N | HK6WK | WHGGM | 1.1.0 | 15.36 TB | Capacity |
| NVMe | PCIe | E3.s | Read Intensive | Kioxia | CM9 DP | KCM9XRJE1T92 | W7Y1X | HJ15N | 1.0.0 | 1.92 TB | Capacity |
| NVMe | PCIe | E3.s | Read Intensive | Kioxia | CM9 DP | KCM9XRJE3T84 | NR5RF | HJ15N | 1.0.0 | 3.84 TB | Capacity |
| NVMe | PCIe | E3.s | Read Intensive | Kioxia | CM9 DP | KCM9XRJE7T68 | 7P31X | HJ15N | 1.0.0 | 7.68 TB | Capacity |
| NVMe | PCIe | E3.s | Read Intensive | Kioxia | CM9 DP | KCM9XRJE15T3 | 3HTR9 | HJ15N | 1.0.0 | 15.36 TB | Capacity |
| NVMe | PCIe | E3.s | Read Intensive | Samsung | PM1753 | MZ3L93T8HFJA-00AD3 | DRH2Y | JYF3Y | 1.0.0 | 3.84 TB | Capacity |
| NVMe | PCIe | E3.s | Read Intensive | Samsung | PM1753 | MZ3L97T6HFLT-00AD3 | 6G50R | JYF3Y | 1.0.0 | 7.68 TB | Capacity |
| NVMe | PCIe | E3.s | Read Intensive | Samsung | PM1753 | MZ3L915THBLC-00AD3 | JVVWW | JYF3Y | 1.0.0 | 15.36 TB | Capacity |
1.4 - Azure Local Support Matrix for 45n0c (Dell 2606)
Supported Platforms
| Model | Supported Operating System |
|---|---|
| AX-4510c | Windows Server 2022 Datacenter Windows Server 2025 Datacenter Azure Stack HCI-24H2 |
| AX-4520c | Windows Server 2022 Datacenter Windows Server 2025 Datacenter Azure Stack HCI-24H2 |
| APEX MC-4510c | Azure Stack HCI-24H2 |
| APEX MC-4520c | Azure Stack HCI-24H2 |
Base Components
| Component | Type | Software Bundle | Minimum Supported Version | Supported Platforms | Supported OS |
|---|---|---|---|---|---|
| BIOS | Firmware DUP | DV9VR | 1.23.1 | AX-4510c AX-4520c APEX MC-4510c APEX MC-4520c | NA |
| iDRAC9 with Lifecycle Controller | Firmware DUP | 924YT | 7.30.10.50 | AX-4510c AX-4520c APEX MC-4510c APEX MC-4520c | NA |
| Chipset driver for 15G Intel platforms | Driver DUP | C2MC3 | 10.1.19928.8615 | AX-4510c AX-4520c APEX MC-4510c APEX MC-4520c | Windows Server 2022 Datacenter Windows Server 2025 Datacenter Azure Stack HCI-24H2 |
| iDRAC Service Module | Firmware DUP | 238XW | 6.1.0.0 | AX-4510c AX-4520c APEX MC-4510c APEX MC-4520c | NA |
| Chassis Manager | Firmware DUP | WC84H | 5 | AX-4510c AX-4520c APEX MC-4510c APEX MC-4520c | NA |
| CPLD | Firmware DUP | G1YRC | 1.0.5 | AX-4510c AX-4520c APEX MC-4510c APEX MC-4520c | NA |
Network Adapters
| Component | Part Number | SDDC Advanced Qualification | RDMA Protocol | Firmware Software Bundle | Firmware Minimum Supported Version | Driver Software Bundle | Driver Minimum Supported Version | Supported OS | Supported Platforms |
|---|---|---|---|---|---|---|---|---|---|
| Broadcom 57504 Quad Port 10/25GbE SFP28 Adapter, PCIe FH | J3D14 | Management Compute (Premium) Storage (Premium) | RoCEv2 | 2MY7D | 36.11.73.00 | 78X9T | 36.11.52.00 | Windows Server 2025 Datacenter Azure Stack HCI-24H2 | AX-4520c APEX MC-4520c |
| Intel E823 | KJMHJ | Management Compute (Premium) Storage (Premium) | iWARP,RoCEv2 | FCG2V | 25.0.4 | 3VT4C | 25.0.4 | Windows Server 2022 Datacenter Windows Server 2025 Datacenter Azure Stack HCI-24H2 | AX-4510c AX-4520c APEX MC-4510c APEX MC-4520c |
| Intel E810-CQDA2 Dual Port 100GbE QSFP28 Adapter, PCIe FH | 85F8F | Management Compute (Premium) Storage (Premium) | iWARP,RoCEv2 | FCG2V | 25.0.4 | 3VT4C | 25.0.4 | Windows Server 2022 Datacenter Windows Server 2025 Datacenter Azure Stack HCI-24H2 | AX-4520c APEX MC-4520c |
| Intel E810-XXV Dual Port 25GbE SFP28 Adapter, PCIe FH | CD16M | ||||||||
| Mellanox ConnectX-6 Dx Dual Port 100GbE QSFP56 PCIe Adapter, FH | 8P2T2 | Management Compute (Premium) Storage (Premium) | RoCEv2 | 81T4K | 22.48.10.00 | 3T3MK | 26.001.03 | Windows Server 2022 Datacenter Windows Server 2025 Datacenter Azure Stack HCI-24H2 | AX-4520c APEX MC-4520c |
| Nvidia ConnectX-6 Lx Dual Port 10/25GbE SFP28 Adapter, PCIe FH | R5WK9 | Management Compute (Premium) Storage (Premium) | RoCEv2 | NMDJG | 26.48.10.00 | 3T3MK | 26.001.03 | Windows Server 2022 Datacenter Windows Server 2025 Datacenter Azure Stack HCI-24H2 | AX-4520c APEX MC-4520c |
Network Switches
NOTE
A list of supported Network Switch models along with the supported firmware versions can be found here, Physical network requirements for Azure Local.GPUs
| GPU Model | Vendor | Description | Part Number | Firmware version | Driver Version | GPU-P capable | Supported Platform | Supported OS |
|---|---|---|---|---|---|---|---|---|
| A2 | NVIDIA | NVIDIA Ampere A2, PCIe, 60W, 16GB Passive, Single Wide, Full Height GPU, V2 | MG5JX | 94.07.5B.00.55 | 528.89 WHQL | Yes | AX-4520c APEX MC-4520c | Windows Server 2025 Datacenter Azure Stack HCI-24H2 |
| L4 | NVIDIA | NVIDIA L4, PCIe, 72W, 24GB Passive, Single Wide Full Height GPU | NG3PY | 95.04.29.00.06 | 528.89 WHQL | Yes | AX-4520c APEX MC-4520c | Windows Server 2025 Datacenter Azure Stack HCI-24H2 |
NOTE
Dell update packages are not available for GPU cards, please download the latest driver version from NVIDIA driver download page.Storage Controllers
| Component | Dell Part Number | Firmware Software Bundle | Firmware Minimum Supported Version | Driver Software Bundle | Driver Minimum Supported Version | Supported Platforms | Supported OS |
|---|---|---|---|---|---|---|---|
| BOSS-N1 | M88HH | YVYW4 | 2.1.13.2038 | Inbox | AX-4510c AX-4520c APEX MC-4510c APEX MC-4520c | Windows Server 2022 Datacenter Windows Server 2025 Datacenter Azure Stack HCI-24H2 |
NVMe 2.5" Capacity Only
| Type | Drive Type | Form Factor | Endurance | Vendor | Series | Model | Device Part Number (P/N) | Firmware Software Bundle | Firmware Minimum Supported Version | Capacity | Use |
|---|---|---|---|---|---|---|---|---|---|---|---|
| NVMe | PCIe | M.2 | Read Intensive | Micron | 7400 | MTFDKBG1T9TDZ | G18YX | N71F4 | 1.6.0 | 1.92 TB | Capacity |
| NVMe | PCIe | M.2 | Read Intensive | Micron | 7400 | MTFDKBG3T8TDZ | 2RN2N | N71F4 | 1.6.0 | 3.84 TB | Capacity |
| NVMe | PCIe | M.2 | Read Intensive | Hynix | PE8010 | HFS960GDC8X099N | 21GXV | R2TTT | 1.3.0 | 960 GB | Capacity |
| NVMe | PCIe | M.2 | Mixed Use | Hynix | PE8030 | HFS800GDC8X088N | 31XDY | R2TTT | 1.3.0 | 800 GB | Capacity |
| NVMe | PCIe | M.2 | Mixed Use | Micron | 7450 | MTFDKBA800TFS | F9MKX | JHKXR | 1.4.0 | 800 GB | Capacity |
| NVMe | PCIe | M.2 | Mixed Use | Hynix | PE9030 | HFS800GDJ8X167N | FYWN9 | 9GH86 | 1.2.1 | 800 GB | Capacity |
| NVMe | PCIe | M.2 | Read Intensive | Hynix | PE9010 | HFS960GDJ8X167N | XN5KG | 8X8YR | 1.2.1 | 960 GB | Capacity |
| NVMe | PCIe | M.2 | Read Intensive | Hynix | PE9010 | HFS960GEJ8X167N | 4H05X | YJG7C | 1.3.1 | 960 GB | Capacity |
| NVMe | PCIe | M.2 | Read Intensive | Micron | 7450 | MTFDKBA960TFR | PH7J6 | JHKXR | 1.4.0 | 960 GB | Capacity |
| NVMe | PCIe | M.2 | Read Intensive | Micron | 7450 | MTFDKBG1T9TFR | J927V | JHKXR | 1.4.0 | 1.92 TB | Capacity |
| NVMe | PCIe | M.2 | Read Intensive | Hynix | PE8110 | HFS1T9GDE0X088N | MY5M4 | 19H08 | 1.1.0 | 1.92 TB | Capacity |
| NVMe | PCIe | M.2 | Read Intensive | Micron | 7450 | MTFDKBG3T8TFR | 5FP33 | JHKXR | 1.4.0 | 3.84 TB | Capacity |
| NVMe | PCIe | M.2 | Read Intensive | Hynix | PE8110 | HFS3T8GDE0X088N | 5JR5H | 19H08 | 1.1.0 | 3.84 TB | Capacity |
| NVMe | PCIe | M.2 | Read Intensive | Samsung | PM9D3a | MZVL6960HFLBAD3 | 8M3JN | FTVJG | 1.0.1 | 960 GB | Capacity |
| NVMe | PCIe | M.2 | Read Intensive | Samsung | PM9D3a | MZVL61T9HBL1AD3 | NYPRM | FTVJG | 1.0.1 | 1.92 TB | Capacity |
1.5 - Azure Local Golden Images (Dell 2606)
NOTE
PowerEdge branded servers can only be deployed with Azure Local when enabled with Dell Private Cloud.The Dell Technologies provided operating system golden image for Azure Local instances is for imaging servers prior to deploying an Azure Local instance. This image is based on the Azure Stack HCI OS, with Microsoft customization and Dell Technologies customization. This image includes drivers provided by Dell Technologies.
Azure Local Golden Images for Solution versions 12.2604.1003.* - 12.2609.1003.* with Dell SBE 5.0.2606.*
1.6 - Azure Local Dell Solution Builder Extensions Release Notes (Dell 2606)
Overview
Solution Builder Extensions (SBE) for Azure Local. Firmware, Driver, and WDAC Supplemental policy for lifecycle management for Azure Local instances running on Dell AX servers.
Note
PowerEdge branded servers are supported with Azure Local only when enabled with Dell Private Cloud.Important Caveats
-
AX 17G SBE 5.0.2606.1713 does not contain the NVIDIA ConnectX-6 NIC firmware. This is due to an iDRAC defect that prevents the SBE from updating the NVIDIA ConnectX-6 NIC firmware. The NVIDIA ConnectX-6 NIC firmware in 17G AX servers must be manually updated to version 26.48.1000 for ConnectX-6 LX and version 22.48.1000 for ConnectX-6 DX prior to Azure Local instance creation.
-
Secure Boot 2023 Certificates must be installed on each instance machine in order for the BIOS version to be upgraded to the versions that are included in this SBE release. The Secure Boot 2023 Certificates are installed as part of installing solution version
12.2603.1002.*or newer, which is a prerequisite for installing these new SBE versions.
New for This Release
SBE 5.0.2606.1713
- Added support for PowerEdge R670 and R770 Platforms. PowerEdge branded servers are supported with Azure Local only when enabled with Dell Private Cloud.
- Driver and Firmware 2606 Update for 17G platforms.
- To install this SBE version, Azure Local instances that are already deployed must be running solution versions
12.*.1003.*or12.2603.1002.*. - Automated remediation for most common CAU scan failures that result from iDRAC returning invalid data. The SBE firmware CAU plug-in will automatically restart iDRAC when iDRAC returns invalid data.
SBE 5.0.2606.1616
- Driver and Firmware 2606 Update for 16G platforms.
- NVIDIA ConnectX-6 NIC firmware and driver upgrade.
- Added Intel QuickAssist Technology (QAT) driver installation.
- To install this SBE version, Azure Local instances that are already deployed must be running solution versions
12.*.1003.*or12.2603.1002.*. - Automated remediation for most common CAU scan failures that result from iDRAC returning invalid data. The SBE firmware CAU plug-in will automatically restart iDRAC when iDRAC returns invalid data.
SBE 5.0.2606.1510
- Driver and Firmware 2606 Update for 15G platforms.
- NVIDIA ConnectX-6 and ConnectX-5 NIC firmware and driver upgrade.
- To install this SBE version, Azure Local instances that are already deployed must be running solution versions
12.*.1003.*or12.2603.1002.*. - Automated remediation for most common CAU scan failures that result from iDRAC returning invalid data. The SBE firmware CAU plug-in will automatically restart iDRAC when iDRAC returns invalid data.
SBE 5.0.2606.1407
- Driver and Firmware 2606 Update for 14G platforms.
- NVIDIA ConnectX-5 and ConnectX-4 NIC firmware and driver upgrade.
- To install this SBE version, Azure Local instances that are already deployed must be running solution versions
12.*.1003.*or12.2603.1002.*. - Automated remediation for most common CAU scan failures that result from iDRAC returning invalid data. The SBE firmware CAU plug-in will automatically restart iDRAC when iDRAC returns invalid data.
Prerequisites
Update Firmware and Drivers Prior to Azure Local Instance Deployment
Drivers and firmware need to be installed on the servers that will be the instance members prior to deployment from the Azure Portal or using an ARM Template. This requirement is independent of the installation of the SBE. Machines imaged with Dell provided golden images will include the required Dell provided Out-of-Box drivers, but the firmware versions must still be validated and possibly updated prior to the instance deployment. The most current driver and firmware versions listed in the support matrix are recommended.
The Azure Local support matrix for Dell AX servers can be found here, Support Matrix | Solutions for Microsoft Azure.
iDRAC Access from Host OS
The iDRAC pass-through NIC must be enabled and have an IP address assigned to it. iDRAC pass-through NIC is enabled by default and has an APIPA (Automatic Private IP Addressing) IP address assigned. This IP address must be accessible by the iDRAC NIC Remote NDIS Compatible Device in the host operating system. This is a dedicated link to the host OS and cannot be accessed outside the host OS.
iDRAC access health checks are introduced starting with the December 2024 SBE releases. These health checks verify that the required iDRAC access has been implemented on each server that will be an instance member. The iDRAC access health checks run automatically as part of the standard built-in SBE health checks. These health checks must complete successfully for the SBE installation to proceed. Failure remediation instructions are provided in case the health check fails.
Manual iDRAC Access Verification
The following procedures provide a manual method for verifying the required iDRAC access. The iDRAC access health checks provide automated and more comprehensive verification method.
Example iDRAC Pass-through settings
The iDRAC NIC Remote NDIS Compatible Device in the host operating system is used by the SBE CAU plug-in to update firmware. This NIC must be enabled and have an IP address assigned to it. By default, this NIC is enabled and has an APIPA IP address assigned to it that can access the iDRAC pass-through IP address. DHCP client should not be disabled on this NIC.
This is a dedicated link to iDRAC from the host OS and cannot be accessed outside the host OS.
The IP address can be obtained using the following PowerShell command:
Get-NetAdapter -InterfaceDescription "Remote NDIS Compatible Device" | Get-NetIPAddress -AddressFamily IPv4 | Select-Object -Property IPAddress
Example:
IPAddress
---------
169.254.0.2
Azure Local instances using Non-Transparent, Unauthenticated Network Proxy
Azure Local instances using non-transparent, unauthenticated network proxy must have the iDRAC pass-through IP address in the network proxy exclusion list. For information on how to configure the non-transparent, unauthenticated network proxy see, Configure proxy settings for Azure Local.
The following example shows how to configure the APIPA IP address range 169.254.0.0/16 to be in the network proxy exclusion list.
$NoProxy = "localhost,127.0.0.1,.svc,10.0.0.0/8,172.16.0.0/12,192.168.0.0/16,.contoso.com,node1,node2,ClusterName,169.254.0.0/16"
[Environment]::SetEnvironmentVariable("NO_PROXY", $NoProxy, "Machine")
Download Connector – Automated download of future SBE release
Overview
Download Connector is a component in the SBE (Solutions Builder Extensions) that automates the downloading of new SBE bundles as they become available for your cluster. Once an SBE that includes the Download Connector is installed on your cluster, manually downloading and importing follow-on SBE version is no longer required. The update service will automate the downloading of the next available SBE for your Azure Local instance in a similar manner to how the download of the solution upgrade is automated. The Download Connector is part of the SBE version 4.1.2505.1501 and newer.
SBE versions that include the Download Connector also include system and update health checks that proactively verify the ability of the Download Connector to access the required remote resource when it comes time to download the next SBE for your cluster. System health checks are run once per day and update health checks are run at the initial phase of the update process.
Firewall Requirements
The SBE Download Connector running in the Azure Local instance needs to periodically connect to the internet resources to download SBE bundles for your cluster. The following outbound connectivity is required.
| Endpoint Description | Endpoint URL | Port |
|---|---|---|
| SBE bundle download | dl.dell.com/* | 443 |
| SBE download catalog | downloads.dell.com/filestore/Prod/SbeDownloadCatalog/AX_SBE_Download_Catalog.xml | 443 |
| SBE download catalog redirection | aka.ms/DellAzureLocalSBEDownloadCatalog | 443 |
| Digicert Certificate Revocation Status | http://crl3.digicert.com/* | 80 |
| Digicert Certificate Revocation Status | http://crl4.digicert.com/* | 80 |
Installation
Automated Download and Extraction
SBE releases starting with 4.1.2505.1501 and newer include the Download Connector that automates downloading and extracting the SBE.
Note
Manual download and SBE bundle extraction are unnecessary when an SBE with this capability is already installed or partially installed on the Azure Local instance.Manual Download and Extract
CAUTION
Steps 3 and 4 must be completed to ensure that the latest SBE Discovery manifest is used.This step is required only when an SBE is not installed in the Azure Local instance (SBE version ‘2.1.0.0’) or the installed SBE is older than version ‘4.1.2505.1501’
SBE bundle zip file has the naming convention Bundle_SBE_Dell_AS-HCI-AX-GenerationNumber_VersionNumber.zip.
-
Download the SBE bundle zip file for your Dell AX server generation using the download link above. The SBE bundles are specific to the AX 14G platforms, AX 15G platforms, and AX 16G platforms
-
Extract the three SBE files from the SBE bundle zip file. There are two xml files and one zip file. Example:
- SBE_Dell_AS-HCI-AX-16G-45n0c_4.2.2506.1600.xml
- SBE_Dell_AS-HCI-AX-16G-45n0c_4.2.2506.1600.zip
- SBE_Discovery_Dell.xml
-
Navigate to https://aka.ms/AzureStackSBEUpdate/DellEMC and press
Ctrl + Sto download the SBE_Discovery_Dell.xml file -
Replace the SBE_Discovery_Dell.xml file that was in the SBE bundle zip with the file downloaded in step 3
There are two options for installing the SBE package. The SBE package can be installed as part of instance creation or imported after instance creation is successfully completed. The importing method is also used to update the SBE to a newer version when the currently running SBE does not include Download Connector capability.
Installing SBE as Part of Instance Creation
Starting with June 2025 Dell golden image release, the SBE files are included in the golden image and already placed in the C:\SBE directory. The following 3 steps do not need to be performed.
- On each server that will be an instance member, create the following directory:
C:\SBE - Copy the three SBE files to the directory
C:\SBEon each server that will be an instance member - Proceed to deploying the instance from the Azure Portal or an ARM template
Importing the SBE After Successful Azure Local Instance Creation
-
Create a directory on a cluster shared volume (CSV) for sideloading the SBE, e.g.,
C:\ClusterStorage\Infrastructure_1\SBE\SBE-AX-16G-45n0c_4.2.2506.1600 -
Copy the three extracted SBE files to this directory
-
Load the SBE files by running the following command with the path to the directory that holds the three extracted SBE files
Add-SolutionUpdate -SourceFolder "C:\ClusterStorage\Infrastructure_1\SBE\SBE-AX-16G-45n0c_4.2.2506.1600" -
Check the state of the SBE that was just added. The state needs to be
Ready.Get-SolutionUpdate | Where-Object -Property PackageType -EQ "SBE" -
Verify that the Azure Local instance is in a healthy state and is ready for the SBE installation by running the following commands on one of the Azure Local instance machines:
Get-SolutionUpdate | Where-Object { $_.State -imatch "Ready" -and $_.PackageType -eq "SBE" } | Start-SolutionUpdate -PrepareOnly -
Wait for the health check to complete. The solution update state will report
HealthCheckingwhile the health check is in progress. -
After the health check completes, run the following command if the solution update state reports
HealthCheckFailed:$Result = (Get-SolutionUpdate | Where-Object {$_.State -imatch "Ready" -and $_.PackageType -eq "SBE"}).HealthCheckResult $Result | Where-Object { ($_.Status -ne "SUCCESS" -and $_.Severity -eq "CRITICAL" ) } | Format-List -Property Title, Status, Severity, Description, Remediation, TargetResourceName, TargetResourceType
All tests with Critical severity must have the Success status before continuing to the next step.
-
Start the SBE installation by running the following command:
Get-SolutionUpdate | Where-Object { $_.State -imatch "Ready" -and $_.PackageType -eq "SBE" } | Start-SolutionUpdate -
The SBE installation progress can be checked by running the following command:
Get-SolutionUpdate | Where-Object -Property PackageType -EQ "SBE" | Format-List -Property ResourceID, Description, State, SBEVersion, UpdateStateProperties, HealthState
For more information see, Update Azure Local via PowerShell.
Known Issues
SBE Installation May Fail with Firmware CAU plug-in CAU scan Error
Description
The SBE installation may fail when the Dell firmware CAU plug-in is running the CAU scan operation to identify server components that require firmware updates. The SBE installation workflow terminates and reports the following error when this condition occurs.
Microsoft.HardwareUpdatePlugin (2) plug-in reported a failure while attempting to scan for applicable updates on node <NodeName>
Additional information reported by the plug-in: (ClusterUpdateException) Encountered Exception while running ScanAsync
Note
HardwareUpdatePlugin (2) refers to the firmware CAU plug-in in the Dell SBE.Workaround
-
Identify the failing node name from the error message.
-
Reboot iDRAC on that node via WebUI by logging in to iDRAC, selecting the menu Maintenance > Diagnostics > Reboot iDRAC.
Note
iDRAC takes a few minutes to reboot. The session to the iDRAC WebUI will drop and automatically re-establish when iDRAC completes the reboot process. -
Wait for iDRAC to complete its reboot and verify you can log in.
-
Restart the SBE installation from Azure Update Manager or from PowerShell by running the following command on one of the Azure Local instance nodes:
Get-SolutionUpdate | Where-Object { $_.State -eq "InstallationFailed" -and $_.PackageType -eq "SBE" } | Start-SolutionUpdate
Background
The Dell firmware CAU plug-in implements the CAU scan operation to identify components that require firmware updates prior to running the CAU run operation. Azure Local machine components that do not require firmware updates are excluded from the CAU run operation. The firmware CAU plug-in obtains a list of machine components and their firmware versions from iDRAC. This error occurs when iDRAC does not respond correctly to the component inventory request issued by the firmware CAU plug-in.
Partially Installed SBE Version 4.0.0.0 When SBE Is Installed as Part of Cluster Deployment
Description
Get-SolutionUpdateEnvironment reports partially installed SBE when installing the SBE as part of Azure Local instance deployment. SBE version 4.0.0.0 indicates a partially installed Solution Builder Extension (SBE).
Get-SolutionUpdateEnvironment
ResourceId : redmond
SbeFamily : AX-16G-45n0c
HardwareModel : AX-760
LastChecked : 08/01/2026 14:09:31
PackageVersions : {Solution: 12.2512.1002.16, Services: 10.2512.0.9, Platform: 12.2512.0.3021, SBE: 4.0.0.0}
CurrentVersion : 12.2512.1002.16
CurrentSbeVersion : 4.0.0.0
LastUpdated :
State : UpdateAvailable
HealthState : Success
HealthCheckResult : {Storage Services Physical Disks Summary, Storage Services Physical Disks Summary, Storage Services Physical Disks Summary, Storage Services Physical Disks Summary...}
HealthCheckDate : 07/01/2026 17:50:07
AdditionalData : {[SBEAdditionalData, Solution Builder extension is partially installed. Please install the latest Solution Builder Extension provided by your hardware vendor. For more information, see https://aka.ms/SBE.]}
Workaround
Reinstall the same SBE version using the SBE import method or automated download method after Azure Local instance deployment successfully completes.
Background
The SBE driver CAU plug-in expects all drivers and firmware in the SBE payload to be installed on the server during or prior to deployment. However, some of the drivers in the SBE payload may not apply to the server model or components in the server model. Microsoft is aware of this limitation and is working to resolve this issue in a future release.
The partially installed SBE issue can also occur if a component firmware version installed on the server is different than what is in the SBE payload. The SBE cannot update firmware or drivers during Azure Local instance deployment.
SBE installation will not downgrade drivers that have a newer version than the same driver in the SBE payload
Dell supports the driver and firmware versions listed here, Support Matrix | Solutions for Microsoft Azure.
Description
The SBE driver CAU plug-in will not attempt to downgrade installed drivers that are higher version than the ones in its payload unless otherwise specified by Dell.
AMD DRTM (Dynamic Root of Trust for Measurement) Driver Fails to Update on AX AMD Platforms When the DRTM Device Was Originally Enabled at Azure Local Instance Deployment Time and Later Disabled
Description
SBE installation fails because the driver CAU plug-in in the SBE is unable to update the AMD DRTM driver to a newer version that is in the SBE payload. The AMD DRTM driver is one of the AMD Chipset drivers in the SBE package. The AMD DRTM driver update fails because the AMD DRTM setting was originally enabled but later disabled.
Workaround
Verify that the AMD DRTM BIOS setting is on. Re-enable the AMD DRTM setting if it is off.
The DRTM option is in the BIOS configuration: System Security -> TPM Advanced Settings -> AMD DRTM
Make sure to suspend and drain the Azure Local cluster node prior to rebooting the node. Make sure that BitLocker protection is disabled for the boot volume on the cluster node before making BIOS configuration changes. Disable BitLocker if it is enabled for the boot volume C:\ prior to rebooting the server for the BIOS changes to take effect. Reenable BitLocker for the boot drive after the server successfully reboots.
Background
AMD DRTM is an advanced security feature that is available on modern AMD CPUs and is used to protect the secure boot enclaves. The AMD DRTM setting is enabled by default on AX servers with AMD CPUs that support the DRTM feature. AMD DRTM should not be disabled.
Previous Releases
2 - Azure Local Support Matrix (Dell 2603)
2.1 - Azure Local Support Matrix for 14G-15G (Dell 2603)
NOTE
SBE package 4.2.2512.xxxx and newer will only support Azure Local solution versions 12.*.1001.* or 12.*.1002.* (HCI OS 24H2) and newer.
Dell will support the use of SBE package 4.2.2509.xxxx on Azure Local instances running version 11.* (HCI OS 23H2) until April 2026. Dell recommends that instances running version 11.* be upgraded to 12.* as soon as possible to remain in a supported state.
Supported Platforms
| Model | Supported Operating System |
|---|---|
| AX-640 | Windows Server 2022 Datacenter Azure Stack HCI-24H2 |
| AX-740xd | Windows Server 2022 Datacenter Azure Stack HCI-24H2 |
| AX-6515 | Windows Server 2022 Datacenter Windows Server 2025 Datacenter Azure Stack HCI-24H2 |
| AX-7525 | Windows Server 2022 Datacenter Windows Server 2025 Datacenter Azure Stack HCI-24H2 |
| AX-650 | Windows Server 2022 Datacenter Windows Server 2025 Datacenter Azure Stack HCI-24H2 |
| AX-750 | Windows Server 2022 Datacenter Windows Server 2025 Datacenter Azure Stack HCI-24H2 |
Base Components
| Component | Type | Software Bundle | Minimum Supported Version | Supported Platforms | Supported OS |
|---|---|---|---|---|---|
| BIOS | Firmware DUP | 9M80P | 2.25.0 | AX-640 AX-740xd | NA |
| BIOS | Firmware DUP | 0D4N7 | 2.23.1 | AX-6515 | NA |
| BIOS | Firmware DUP | JR4VV | 2.23.1 | AX-7525 | NA |
| BIOS | Firmware DUP | GWT21 | 1.20.2 | AX-650 AX-750 | NA |
| iDRAC9 with Lifecycle Controller | Firmware DUP | VP556 | 7.00.00.183 | AX-640 AX-740xd | NA |
| iDRAC9 with Lifecycle Controller | Firmware DUP | 924YT | 7.30.10.50 | AX-6515 AX-7525 AX-650 AX-750 | NA |
| Non-expander Storage Backplane | Firmware DUP | VV85D | 4.35 | AX-6515 AX-640 AX-740xd | NA |
| Non-expander Storage Backplane | Firmware DUP | G69W6 | 7.16 | AX-7525 AX-750 | NA |
| Non-expander Storage Backplane | Firmware DUP | 5DV1W | 7.16 | AX-650 | NA |
| NVMe Switch Storage Backplane | Firmware DUP | 5XJWN | 1.05 | AX-750 | NA |
| Expander Storage Backplane | Firmware DUP | H9PV3 | 1.2 | AX-7525 AX-750 | NA |
| Expander Storage Backplane | Firmware DUP | 60K1J | 2.52 | AX-640 AX-740xd | NA |
| Expander Storage Backplane | Firmware DUP | 2F90T | 2.46 | AX-6515 | NA |
| Chipset driver for 14G Intel platforms | Driver DUP | 4DDMJ | 10.1.19913.8607 | AX-640 AX-740xd | Windows Server 2022 Datacenter Azure Stack HCI-24H2 |
| Chipset driver for 15G AMD platforms | Driver DUP | N28TF | 6.11.12.245 | AX-6515 AX-7525 | Windows Server 2022 Datacenter Windows Server 2025 Datacenter Azure Stack HCI-24H2 |
| Chipset driver for 15G Intel platforms | Driver DUP | C2MC3 | 10.1.19928.8615 | AX-650 AX-750 | Windows Server 2022 Datacenter Windows Server 2025 Datacenter Azure Stack HCI-24H2 |
| iDRAC Service Module | Firmware DUP | 238XW | 6.1.0.0 | AX-640 AX-740xd AX-6515 AX-7525 AX-650 AX-750 | NA |
| CPLD | Firmware DUP | 9N4DH | 1.0.6 | AX-640 | NA |
| CPLD | Firmware DUP | G65GH | 1.1.4 | AX-740xd | NA |
| CPLD | Firmware DUP | 79XGF | 1.0.7 | AX-6515 | NA |
| CPLD | Firmware DUP | 4NMC7 | 1.2.0 | AX-7525 | NA |
| CPLD | Firmware DUP | FCTDF | 1.1.1 | AX-650 AX-750 | NA |
Network Adapters
| Component | Part Number | SDDC Advanced Qualification | RDMA Protocol | Firmware Software Bundle | Firmware Minimum Supported Version | Driver Software Bundle | Driver Minimum Supported Version | Supported OS | Supported Platforms |
|---|---|---|---|---|---|---|---|---|---|
| Broadcom 5720 Dual Port 1GbE On-Board LOM | JDN4V | Management | NA | 32W7Y | 23.61.3 | WYPPJ | 236.1.155.0 | Windows Server 2022 Datacenter Windows Server 2025 Azure Stack HCI-24H2 | AX-650 | CV5V6 |
| Broadcom 5720 Dual Port 1 GbE Network LOM Mezz Card | KJMHJ | Management | N/A | 32W7Y | 23.61.3 | WYPPJ | 236.1.155.0 | Windows Server 2022 Datacenter Windows Server 2025 Azure Stack HCI-24H2 | AX-6515 | CV5V6 |
| Broadcom 5720 Dual Port 1GbE On-Board LOM | 6V45N | Management | NA | 32W7Y | 23.61.3 | WYPPJ | 236.1.155.0 | Windows Server 2022 Datacenter Windows Server 2025 Azure Stack HCI-24H2 | AX-750 | CV5V6 |
| Broadcom 5720 Dual Port 1GbE On-Board LOM | 74H08 | Management | NA | 32W7Y | 23.61.3 | WYPPJ | 236.1.155.0 | Windows Server 2022 Datacenter Windows Server 2025 Azure Stack HCI-24H2 | AX-7525 | CV5V6 |
| Broadcom 57504 Quad Port 10/25GbE SFP28 Adapter, PCIe FH | J3D14 | Management Compute (Premium) Storage (Premium) | RoCEv2 | MJ0HT | 36.11.56.00 | 78X9T | 36.11.52.00 | Windows Server 2025 Datacenter Azure Stack HCI-24H2 | AX-4520c |
| Broadcom 57412 2 Port 10Gb SRP+ + 5720 2 Port 1 GB Base-T, rNDC | NWMNX | Management Compute (Standard) | Not Supported | MJ0HT | 36.11.56.00 | 78X9T | 36.11.52.00 | Windows Server 2022 Datacenter Windows Server 2025 Datacenter Azure Stack HCI-24H2 | AX-640 AX-740xd |
| Broadcom BCM57414 25G SFP Dual Port OCP3 Mezz, V3 | 24FG6 | Management Compute (Standard) | Not Supported | MJ0HT | 36.11.56.00 | 78X9T | 36.11.52.00 | Windows Server 2022 Datacenter Windows Server 2025 Datacenter Azure Stack HCI-24H2 | AX-6515 |
| Broadcom 57416 Dual Port 10 GbE SFP+ Network LOM Mezz Card | 6XH9X | ||||||||
| Broadcom 57414 Dual Port 25 Gb E SFP+ Network LOM Mezz Card | 930PP | ||||||||
| Broadcom 57416 Dual Port 10 GbE BaseT Network LOM Mezz Card | J4RN3 | ||||||||
| Broadcom BCM57414 25G SFP Dual Port OCP3 Mezz | NHN45 | ||||||||
| Broadcom 57416 Dual Port 10 Gb E SFP+ Network LOM Mezz Card | WC9TR | ||||||||
| Broadcom 57412 Dual Port 10GbE SFP+, OCP NIC 3.0 | CP610 | Management Compute (Standard) | Not Supported | MJ0HT | 36.11.56.00 | 78X9T | 36.11.52.00 | Windows Server 2022 Datacenter Windows Server 2025 Datacenter Azure Stack HCI-24H2 | AX-7525 AX-650 AX-750 |
| Broadcom 57414 Dual Port 10/25GbE SFP28, OCP NIC 3.0 | KHCTP | ||||||||
| Broadcom 57416 Dual Port 10GbE BASE-T Adapter, OCP NIC 3.0 | T6HR8 | ||||||||
| Broadcom 57504 Quad Port 10/25GbE,SFP28, OCP NIC 3.0 | X1KR4 | ||||||||
| Intel X710 DP 10Gb DA/SFP+ Ethernet, NDC | 6VDPG | Management Compute (Standard) | N/A | DC20J | 24.0.5 | PH5GK | 24.0.0 | Windows Server 2022 Datacenter Windows Server 2025 Datacenter Azure Stack HCI-24H2 | AX-640 AX-740xd |
| Intel X710-T4L Quad Port 10GbE BASE-T, OCP NIC 3.0 | 50RV4 | Management Compute (Standard) | N/A | DC20J | 24.0.5 | PH5GK | 24.0.0 | Windows Server 2022 Datacenter Windows Server 2025 Datacenter Azure Stack HCI-24H2 | AX-7525 AX-650 AX-750 |
| Intel(R) Ethernet 10G 4P X710-T4L-t Adapter | ND4PT | ||||||||
| Intel X710 Quad Port 10GbE SFP+, OCP NIC 3.0 | VF81P | ||||||||
| Intel X710-T2L Dual Port 10GbE BASE-T, OCP NIC 3.0 | VMFKR | ||||||||
| Intel X710 Dual Port 10GbE SFP+, OCP NIC 3.0 | YJYK1 | ||||||||
| Intel E823 | KJMHJ | Management Compute (Premium) Storage (Premium) | iWARP,RoCEv2 | N11TD | 24.0.5 | PH5GK | 24.0.0 | Windows Server 2022 Datacenter Windows Server 2025 Datacenter Azure Stack HCI-24H2 | AX-4510c AX-4520c |
| Intel E810-XXV Dual Port 25GbE SFP28 Adapter, PCIe LP | 6J1N1 | Management Compute (Premium) Storage (Premium) | iWARP,RoCEv2 | N11TD | 24.0.5 | PH5GK | 24.0.0 | Windows Server 2022 Datacenter Windows Server 2025 Datacenter Azure Stack HCI-24H2 | AX-7525 AX-650 AX-750 |
| Intel E810-CQDA2 Dual Port 100GbE QSFP28 Adapter, PCIe FH | 85F8F | ||||||||
| Intel E810-XXV Dual Port 25GbE SFP28 Adapter, PCIe FH | CD16M | ||||||||
| Intel E810-CQDA2 Dual Port 100GbE QSFP28 Adapter, PCIe LP | DWNRF | ||||||||
| Mellanox ConnectX-6 Dx Dual Port 100GbE QSFP56 PCIe Adapter, LP | F6FXM | Management Compute (Premium) Storage (Premium) | RoCEv2 | 2CMVW | 22.41.10.00 | G6M58 | 24.04.03 | Windows Server 2022 Datacenter Windows Server 2025 Datacenter Azure Stack HCI-24H2 | AX-6515 AX-7525 AX-650 AX-750 |
| Mellanox ConnectX-6 Dx Dual Port 100GbE QSFP56 PCIe Adapter, FH | 8P2T2 | Management Compute (Premium) Storage (Premium) | RoCEv2 | 2CMVW | 22.41.10.00 | G6M58 | 24.04.03 | Windows Server 2022 Datacenter Windows Server 2025 Datacenter Azure Stack HCI-24H2 | AX-7525 AX-650 AX-750 |
| Mellanox ConnextX-4 Lx Dual Port 25Gbe DA/SFP Network Adapter, LP | 20NJD | Management Compute (Premium) Storage (Premium) | RoCEv2 | XGP2X | 14.32.20.04 | G6M58 | 24.04.03 | Windows Server 2022 Datacenter Windows Server 2025 Datacenter Azure Stack HCI-24H2 | AX-640 AX-740xd |
| Mellanox ConnectX-4 Lx Dual Port 25GbE DA/SFP rNDC | R887V | Management Compute (Premium) Storage (Premium) | RoCEv2 | XGP2X | 14.32.20.04 | G6M58 | 24.04.03 | Windows Server 2022 Datacenter Windows Server 2025 Datacenter Azure Stack HCI-24H2 | AX-640 R640 Storage Spaces Direct RN |
| Mellanox ConnextX-4 Lx Dual Port 25Gbe DA/SFP Network Adapter, FH | MRT0D | Management Compute (Premium) Storage (Premium) | RoCEv2 | XGP2X | 14.32.20.04 | G6M58 | 24.04.03 | Windows Server 2022 Datacenter Windows Server 2025 Datacenter Azure Stack HCI-24H2 | AX-740xd |
| Mellanox ConnectX-4 LX Dual Port 10/25GbE SFP28 Adapter, FH, V2 | YGRX3 | ||||||||
| Mellanox Connectx-5 EX Dual Port 100GbE QSFP20 PCIe Adapter, FH | 71C1T | Management Compute (Premium) Storage (Premium) | RoCEv2 | XY16R | 16.35.30.06 | G6M58 | 24.04.03 | Windows Server 2022 Datacenter Windows Server 2025 Datacenter Azure Stack HCI-24H2 | AX-6515 AX-7525 AX-640 AX-740xd AX-650 AX-750 |
| Mellanox Connectx-5 EX Dual Port 100GbE QSFP20 PCIe Adapter, LP | 9FTMY | ||||||||
| Mellanox ConnectX-5 Dual Port 10/25GbE SFP28 Adapter, PCIe FH, V2 | F7V1F | ||||||||
| Mellanox ConnectX-5 Dual Port 10/25GbE SFP28 Adapter, PCIe LP, V2 | JGWVY | ||||||||
| Mellanox ConnectX-5 Dual Port 25GbE SFP28 Adapter, FH | TDNNT | ||||||||
| Mellanox ConnectX-5 Dual Port 25GbE SFP28 Adapter, LP | V5DG9 | ||||||||
| NVIDIA ConnectX-6LX Dual Port 25G GbE SFP28 | DN78C | Management Compute (Premium) Storage (Premium) | RoCEv2 | 1H4PM | 26.41.10.00 | G6M58 | 24.04.03 | Windows Server 2022 Datacenter Windows Server 2025 Datacenter Azure Stack HCI-24H2 | AX-650 AX-750 AX-7525 |
| Nvidia ConnectX-6 Lx Dual Port 10/25GbE SFP28 Adapter, PCIe LP | 6XJXK | Management Compute (Premium) Storage (Premium) | RoCEv2 | 1H4PM | 26.41.10.00 | G6M58 | 24.04.03 | Windows Server 2022 Datacenter Windows Server 2025 Datacenter Azure Stack HCI-24H2 | AX-6515 AX-7525 AX-650 AX-750 |
| Nvidia ConnectX-6 Lx Dual Port 10/25GbE SFP28 Adapter, PCIe FH | R5WK9 | ||||||||
| QLogic 57800 2x10Gb DA/SFP+ +2x1Gb BT NDC | 165T0 | Management | N/A | 9KYR0 | 16.20.00 | VYWY1 | 36.20.02 | Windows Server 2022 Datacenter Azure Stack HCI-24H2 | AX-640 AX-740xd |
| QLogic 57800 2x10Gb BT + 2x1Gb BT NDC | G8RPD | ||||||||
| QLogic FastLinQ 41162 Dual Port 10GbE BASE-T and Dual Port 1GbE BASE-T, rNDC | 0D1WT | Management Compute (Premium) | iWARP | W93NY | 16.30.09 | RXJPP | 36.30.16 | Windows Server 2022 Datacenter Windows Server 2025 Datacenter Azure Stack HCI-24H2 | AX-640 AX-740xd |
| QLogic FastLinQ 41164 Quad Port 10GbE BASE-T, rNDC | X1TD1 | Management Compute (Premium) | iWARP | W93NY | 16.30.09 | RXJPP | 36.30.16 | Windows Server 2022 Datacenter Windows Server 2025 Datacenter Azure Stack HCI-24H2 | AX-6515 AX-7525 AX-640 AX-740xd AX-650 AX-750 |
| QLogic FastLinQ 41164 Quad Port 10GbE SFP+, rNDC | XVVY1 | ||||||||
| QLogic FastLinQ 41262 Dual Port 25Gb SFP28 Adapter, LP | 415DX | Management Compute (Premium) Storage (Premium) | iWARP | W93NY | 16.30.09 | RXJPP | 36.30.16 | Windows Server 2022 Datacenter Windows Server 2025 Datacenter Azure Stack HCI-24H2 | AX-6515 AX-7525 AX-640 AX-740xd |
| QLogic FastLinQ 41262 Dual Port 25Gbe SFP28, rNDC | 4KF8J | ||||||||
| QLogic FastLinQ 41262 Dual Port 25Gb SFP28 Adapter, FH | 51GRM |
Network Switches
NOTE
A list of supported Network Switch models along with the supported firmware versions can be found here, Physical network requirements for Azure Local.GPUs
| GPU Model | Vendor | Description | Part Number | Firmware version | Driver Version | GPU-P capable | Supported Platform | Supported OS |
|---|---|---|---|---|---|---|---|---|
| A10 | NVIDIA | NVIDIA Ampere A10, PCIe, 150W, 24GB,GPU, V2 | 6KNWW | 94.02.5C.00.04 | 528.89 WHQL | Yes | AX-750 AX-7525 | Windows Server 2025 Datacenter Azure Stack HCI-24H2 |
| A16 | NVIDIA | NVIDIA Ampere A16, PCIe, 250W, 64GB Passive, Double Wide, Full Height GPU | 8F04V | 94.07.54.00.45 | 528.89 WHQL | Yes | AX-750 AX-7525 | Windows Server 2025 Datacenter Azure Stack HCI-24H2 |
| A16 | NVIDIA | NVIDIA Ampere A16, PCIe, 250W, 64GB Passive, Double Wide, Full Height GPU,V2 | D1P1T | 94.07.54.00.45 | 528.89 WHQL | Yes | AX-750 AX-7525 | Windows Server 2025 Datacenter Azure Stack HCI-24H2 |
| A2 | NVIDIA | NVIDIA Ampere A2, PCIe, 60W, 16GB Passive, Single Wide, Low Profile GPU, V2 | H98K0 | 94.07.5B.00.55 | 528.89 WHQL | Yes | AX-650 AX-750 AX-7525 | Windows Server 2025 Datacenter Azure Stack HCI-24H2 |
| A2 | NVIDIA | NVIDIA Ampere A2, PCIe, 60W, 16GB Passive, Single Wide, Full Height GPU, V2 | MG5JX | 94.07.5B.00.55 | 528.89 WHQL | Yes | AX-750 AX-7525 | Windows Server 2025 Datacenter Azure Stack HCI-24H2 |
| A30 | NVIDIA | NVIDIA Ampere A30, PCIe, 165W, 24GB Passive, Double Wide, Full Height GPU | W3C1G | 92.00.58.00.01 | 528.89 WHQL | No | AX-750 AX-7525 | Windows Server 2025 Datacenter Azure Stack HCI-24H2 |
| A30 | NVIDIA | NVIDIA Ampere A30, PCIe, 165W, 24GB Passive, Double Wide, Full Height GPU, V2 | RV08M | 92.00.58.00.01 | 528.89 WHQL | No | AX-750 AX-7525 | Windows Server 2025 Datacenter Azure Stack HCI-24H2 |
| A40 | NVIDIA | NVIDIA Ampere A40, PCIe, 300W, 48GB Passive, Double Wide, Full Height GPU | W6GX6 | 94.02.5C.00.0F | 528.89 WHQL | Yes | AX-750 AX-7525 | Windows Server 2025 Datacenter Azure Stack HCI-24H2 |
| L4 | NVIDIA | NVIDIA L4, PCIe, 72W, 24GB Passive, Single Wide Low Profile GPU | V9XT2 | 95.04.29.00.06 | 528.89 WHQL | Yes | AX-650 AX-750 AX-7525 | Windows Server 2025 Datacenter Azure Stack HCI-24H2 |
| L4 | NVIDIA | NVIDIA L4, PCIe, 72W, 24GB Passive, Single Wide Full Height GPU | NG3PY | 95.04.29.00.06 | 528.89 WHQL | Yes | AX-750 AX-7525 | Windows Server 2025 Datacenter Azure Stack HCI-24H2 |
| L40 | NVIDIA | NVIDIA Ampere L40, PCIe, 300W, 48GB Passive, Double Wide, Full Height, Full Length, GPU with cable | VHNWT | 95.02.39.00.01 | 553.62 | Yes | AX-750 AX-7525 | Windows Server 2025 Datacenter Azure Stack HCI-24H2 |
| T4 | NVIDIA | NVIDIA Tesla T4 16GB, PCIe, 70W, 16GB Passive, Single Wide, Full Height GPU | HCKJM | 90.04.96.00.01 | 528.89 WHQL | No | AX-750 | Windows Server 2025 Datacenter Azure Stack HCI-24H2 |
| T4 | NVIDIA | NVIDIA Tesla T4 16GB, PCIe, 70W, Passive, Single Wide, Low Profile GPU | 7PH29 | 90.04.96.00.01 | 528.89 WHQL | No | AX-750 | Windows Server 2025 Datacenter Azure Stack HCI-24H2 |
NOTE
Dell update packages are not available for GPU cards, please download the latest driver version from NVIDIA driver download page.Storage Controllers
| Component | Dell Part Number | Firmware Software Bundle | Firmware Minimum Supported Version | Driver Software Bundle | Driver Minimum Supported Version | Supported Platforms | Supported OS |
|---|---|---|---|---|---|---|---|
| BOSS-S1 | 2MFVD | 3P39V | 2.5.13.3024 | 7004G | 1.2.0.1055 | AX-6515 AX-7525 AX-640 AX-740xd | Windows Server 2022 Datacenter Azure Stack HCI-24H2 |
| BOSS-S2 | FGNRW | TTR5R | 2.5.13.4009 | 7004G | 1.2.0.1055 | AX-7525 AX-650 AX-750 | Windows Server 2022 Datacenter Azure Stack HCI-24H2 |
| HBA330 Controller, 12Gps Mini Card | P2R3R | 124X2 | 16.17.01.00 | Inbox | 2.51.27.80 | AX-640 AX-740XD AX-6515 | Windows Server 2022 Datacenter Azure Stack HCI-24H2 |
| HBA330 Controller, 12Gps Mini Card, LP | J7TNV | NKNVC | 16.17.01.00 | Inbox | 2.51.27.80 | AX-740xd | Windows Server 2022 Datacenter Azure Stack HCI-24H2 |
| HBA355i | K6MCJ | CG0P9 | 33.15.00.00 | R31NP | 2.61.74.00 | AX-7525 AX-650 AX-750 | Windows Server 2022 Datacenter |
| HBA355i | K6MCJ | CG0P9 | 33.15.00.00 | HDH8G | 2.61.74.00 | AX-7525 AX-650 AX-750 | Windows Server 2025 Datacenter Azure Stack HCI-24H2 |
SATA M.2 SSD Boot Only
| Type | Drive Type | Form Factor | Endurance | Vendor | Series | Model | Device Part Number (P/N) | Firmware Software Bundle | Firmware Minimum Supported Version | Capacity | Use |
|---|---|---|---|---|---|---|---|---|---|---|---|
| SSD | SATA | M.2 | NA | Intel | S3520 | SSDSC2BB120G7R | 394XT | CHJGV | DL43 | 120 GB | Boot |
| SSD | SATA | M.2 | NA | Micron | 5100 | MTFDDAV240TCB | TC2RP | H6NHD | E013 | 240 GB | Boot |
| SSD | SATA | M.2 | NA | Micron | 5100 | MTFDDAV480TCB | GPGC0 | H6NHD | E013 | 480 GB | Boot |
| SSD | SATA | M.2 | NA | Micron | 5300 | MTFDDAV240TDU | T2GFX | KT63Y | J008 | 240 GB | Boot |
| SSD | SATA | M.2 | NA | Micron | 5300 | MTFDDAV480TDS | 7RKD7 | KT63Y | J008 | 480 GB | Boot |
| SSD | SATA | M.2 | Read Intensive | Intel | Youngsville RR S4520 | SSDSCKKB240GZR | CM88M | VJPKG | DL7C | 240 GB | Boot |
| SSD | SATA | M.2 | Read Intensive | Intel | Youngsville S4510 | SSDSCKKB240G8R | DMC15 | Y1P10 | DL6R | 240 GB | Boot |
| SSD | SATA | M.2 | Read Intensive | Micron | 5400 | MTFDDAV240TGC-1BC1ZABDA | T4MJ3 | RJ0WY | K003 | 240 GB | Boot |
SAS 2.5" HDD Capacity Only
| Type | Drive Type | Form Factor | Endurance | Vendor | Series | Model | Device Part Number (P/N) | Firmware Software Bundle | Firmware Minimum Supported Version | Capacity | Use |
|---|---|---|---|---|---|---|---|---|---|---|---|
| HDD | SAS | 2.5 | NA | Seagate | Avenger | ST2000NX0463 | TMVN7 | GW3V7 | NT32 | 2 TB | Capacity |
| HDD | SAS | 2.5 | NA | Seagate | Skybolt | DL2400MM0159 | RWR8F | DRHV4 | ST5J | 2.4 TB | Capacity |
| HDD | SAS | 2.5 | NA | Seagate | Skybolt | ST2400MM0159 | 36YG1 | 7N5DH | ST7G | 2.4 TB | Capacity |
| HDD | SAS | 2.5 | NA | Toshiba | AL15SE | AL15SEB24EQY | F9NWJ | J11N2 | EF09 | 2.4 TB | Capacity |
| HDD | SAS | 2.5 | NA | Seagate | Skybolt ServoBP | BL2400MM0159 | 1D0F5 | 00P56 | SBSA | 2.4TB | Capacity |
SATA 2.5" HDD Capacity Only
| Type | Drive Type | Form Factor | Endurance | Vendor | Series | Model | Device Part Number (P/N) | Firmware Software Bundle | Firmware Minimum Supported Version | Capacity | Use |
|---|---|---|---|---|---|---|---|---|---|---|---|
| HDD | SATA | 2.5 | NA | Seagate | Avenger | ST2000NX0423 | VR92X | GMW4P | NB33 | 2 TB | Capacity |
SATA 3.5" HDD Capacity Only
| Type | Drive Type | Form Factor | Endurance | Vendor | Series | Model | Device Part Number (P/N) | Firmware Software Bundle | Firmware Minimum Supported Version | Capacity | Use |
|---|---|---|---|---|---|---|---|---|---|---|---|
| HDD | SATA | 3.5 | NA | HGST | Aries K Plus | HUS726020ALA610 | 8NP2N | KH52Y | KV46 | 2 TB | Capacity |
| HDD | SATA | 3.5 | NA | HGST | Aries K Plus | HUS726040ALA610 | 61FFW | KH52Y | KV46 | 4 TB | Capacity |
| HDD | SATA | 3.5 | NA | HGST | Rainier MLK | HUS722T2TALA600 | V9H6C | V3DJM | MU03 | 2 TB | Capacity |
| HDD | SATA | 3.5 | NA | Toshiba | Tomcat R | MG04ACA200NY | NPVM6 | 6D4CG | FK5D | 2 TB | Capacity |
| HDD | SATA | 3.5 | NA | Toshiba | Tomcat R | MG04ACA400NY | 95M6K | 6D4CG | FK5D | 4 TB | Capacity |
| HDD | SATA | 3.5 | NA | Seagate | Nemo | ST2000NM0018-2F3 | W8FW5 | CMK5N | EA04 | 2 TB | Capacity |
| HDD | SATA | 3.5 | NA | Seagate | Makara BP | ST2000NM0145-2DC | WG9R0 | M5GJ1 | DB34 | 2 TB | Capacity |
| HDD | SATA | 3.5 | NA | Seagate | Makara BP | ST4000NM0265-2DC | MWHY9 | M5GJ1 | DB34 | 4 TB | Capacity |
| HDD | SATA | 3.5 | NA | HGST | Vela-A | HUS726T4TALA6L0 | YH3T9 | HV5HH | PV09 | 4 TB | Capacity |
| HDD | SATA | 3.5 | NA | HGST | Vela-AP | HUS728T8TALE6L0 | 1WMVC | T0RX4 | RT09 | 8 TB | Capacity |
| HDD | SATA | 3.5 | NA | HGST | Libra HE10 | HUH721008ALE600 | KRV2W | H12N2 | LT21 | 8 TB | Capacity |
| HDD | SATA | 3.5 | NA | Seagate | Makara Plus | ST8000NM0205-2FF | 92MDW | MR6RH | PB53 | 8 TB | Capacity |
| HDD | SATA | 3.5 | NA | Toshiba | MG06 | MG06ACA800EY | 9X09C | PT7D8 | GA09 | 8 TB | Capacity |
| HDD | SATA | 3.5 | NA | HGST | Leo-A He12 | HUH721212ALE600 | T2YHT | JCYF6 | NT11 | 12 TB | Capacity |
| HDD | SATA | 3.5 | NA | Toshiba | MG07 | MG07ACA12TEY | 753F0 | 0942Y | GB03 | 12 TB | Capacity |
| HDD | SATA | 3.5 | NA | Toshiba | MG08AC | MG08ACA16TEY | HPGJ4 | 3FWPH | GC05 | 16 TB | Capacity |
| HDD | SATA | 3.5 | NA | Toshiba | MG08AD | MG08ADA400NY | W2M9N | F73C5 | GD05 | 4 TB | Capacity |
| HDD | SATA | 3.5 | NA | Seagate | Cimarron | ST4000NM016A-2HZ | XPJ47 | RWK48 | CAJD | 4 TB | Capacity |
| HDD | SATA | 3.5 | NA | Seagate | Cimarron | ST8000NM012A-2KE | F4JXT | TF6TF | CALF | 8 TB | Capacity |
| HDD | SATA | 3.5 | NA | Seagate | Evans BP | ST12000NM002J-2T | KTJTY | 4MPD6 | PALB | 12 TB | Capacity |
| HDD | SATA | 3.5 | NA | Seagate | Evans BP | ST16000NM002J-2T | JWV1P | 4MPD6 | PALB | 16 TB | Capacity |
| HDD | SATA | 3.5 | NA | Toshiba | MG08AD | MG08ADA800EY | T5XR5 | X5MGP | GE03 | 8 TB | Capacity |
| HDD | SATA | 3.5 | NA | Seagate | Cimarron BP | ST8000NM023B-2TJ | J7W80 | P183W | LA0C | 8 TB | Capacity |
| HDD | SATA | 3.5 | NA | Seagate | Cimarron BP | ST4000NM018B-2TF | 6KR2M | T04YV | LC0A | 4 TB | Capacity |
| HDD | SATA | 3.5 | NA | Seagate | Cimarron BP | ST8000NM023B-2TJ | J7W80 | P183W | LA0C | 8 TB | Capacity |
SAS 3.5" HDD Capacity Only
| Type | Drive Type | Form Factor | Endurance | Vendor | Series | Model | Device Part Number (P/N) | Firmware Software Bundle | Firmware Minimum Supported Version | Capacity | Use |
|---|---|---|---|---|---|---|---|---|---|---|---|
| HDD | SAS | 3.5 | NA | HGST | Aries K Plus | HUS726020ALS210 | VH6FW | 8W7XP | KU46 | 2 TB | Capacity |
| HDD | SAS | 3.5 | NA | HGST | Aries K Plus | HUS726040ALS210 | X4FKY | 8W7XP | KU46 | 4 TB | Capacity |
| HDD | SAS | 3.5 | NA | Toshiba | Tomcat R | MG04SCA20ENY | HHX14 | RG9MK | EG03 | 2 TB | Capacity |
| HDD | SAS | 3.5 | NA | Toshiba | Tomcat R | MG04SCA40ENY | 1MVTT | RG9MK | EG03 | 4 TB | Capacity |
| HDD | SAS | 3.5 | NA | Seagate | Makara BP | ST2000NM0155 | 7RCGV | XKD4M | DT34 | 2 TB | Capacity |
| HDD | SAS | 3.5 | NA | Seagate | Makara BP | ST4000NM0295 | 5JH5X | XKD4M | DT34 | 4 TB | Capacity |
| HDD | SAS | 3.5 | NA | HGST | Vela-A | HUS726T4TALS200 | NT1X2 | J5K8G | PU09 | 4 TB | Capacity |
| HDD | SAS | 3.5 | NA | HGST | Vela-AP | HUS728T8TAL5200 | 44YFV | 8GM6M | RS09 | 8 TB | Capacity |
| HDD | SAS | 3.5 | NA | HGST | Libra HE10 | HUH721008AL5200 | KRDKK | MGW91 | LS21 | 8 TB | Capacity |
| HDD | SAS | 3.5 | NA | Seagate | Makara Plus | ST8000NM0185 | M40TH | 6421F | PT55 | 8 TB | Capacity |
| HDD | SAS | 3.5 | NA | Toshiba | MG06 | MG06SCA800EY | FV725 | 4G5GY | EH0D | 8 TB | Capacity |
| HDD | SAS | 3.5 | NA | HGST | Leo-A He12 | HUH721212AL5200 | 9HXK6 | 04PM5 | NS11 | 12 TB | Capacity |
| HDD | SAS | 3.5 | NA | Seagate | Mobula BP | ST12000NM0158 | YMN53 | VTX9C | RSL5 | 12 TB | Capacity |
| HDD | SAS | 3.5 | NA | Toshiba | MG07 | MG07SCA12TEY | DK7C9 | NFFHM | EI0D | 12 TB | Capacity |
| HDD | SAS | 3.5 | NA | Toshiba | MG07 | MG07SCA12TEY | KFJ7G | NFFHM | EI0D | 12 TB | Capacity |
| HDD | SAS | 3.5 | NA | Toshiba | MG09 | MG09SCA12TEY | 0N96X | 20Y02 | EM06 | 12 TB | Capacity |
| HDD | SAS | 3.5 | NA | Toshiba | MG08SC | MG08SCA16TEY | 8MG73 | 9N3RR | EJ09 | 16 TB | Capacity |
| HDD | SAS | 3.5 | NA | Toshiba | MG08SC | MG08SCA16TEY | 4N7V0 | 9N3RR | EJ09 | 16 TB | Capacity |
| HDD | SAS | 3.5 | NA | Toshiba | MG08SC | MG08SCA16TEY | 24HF9 | 9N3RR | EJ09 | 16 TB | Capacity |
| HDD | SAS | 3.5 | NA | Seagate | Evans | ST16000NM010G | CNXPV | 3YP54 | ESL9 | 16 TB | Capacity |
| HDD | SAS | 3.5 | NA | WD | Paris-C | WUH721816AL5200 | VF206 | GY6MD | US09 | 16 TB | Capacity |
| HDD | SAS | 3.5 | NA | Seagate | Cimarron | ST4000NM017A | KRM6X | J12RT | CSJA | 4 TB | Capacity |
| HDD | SAS | 3.5 | NA | Seagate | Cimarron | ST8000NM014A | 0N660 | 0HG6Y | CSLE | 8 TB | Capacity |
| HDD | SAS | 3.5 | NA | Seagate | Cimarron BP | ST4000NM019B | 10N7R | 3P5N0 | LW0B | 4 TB | Capacity |
| HDD | SAS | 3.5 | NA | Seagate | Cimarron BP | ST8000NM024B | C5HD0 | NM6GP | LS0C | 8 TB | Capacity |
| HDD | SAS | 3.5 | NA | Toshiba | MG08SD | MG08SDA400NY | FN2YX | GTG81 | EK06 | 4 TB | Capacity |
| HDD | SAS | 3.5 | NA | Seagate | Evans BP | ST12000NM006J | M1C0T | XF65R | PSLG | 12 TB | Capacity |
| HDD | SAS | 3.5 | NA | Seagate | Evans BP | ST16000NM006J | 41DXR | XF65R | PSLG | 16 TB | Capacity |
| HDD | SAS | 3.5 | NA | Toshiba | MG08SD | MG08SDA800EY | NJWMG | F95CX | EL02 | 8 TB | Capacity |
| HDD | SAS | 3.5 | NA | Seagate | Cimarron BP | ST8000NM024B | C5HD0 | NM6GP | LS0C | 8 TB | Capacity |
| HDD | SAS | 3.5 | NA | Seagate | EvansBP | ST16000NM006J | 41DXR | XF65R | PSLG | 16 TB | Capacity |
| HDD | SAS | 3.5 | NA | Seagate | LongsPeak | ST20000NM004D | R3G03 | WCTTD | GS09 | 20 TB | Capacity |
| HDD | SAS | 3.5 | NA | Toshiba | MG10SD | MG10SDA800EY | VJDMM | 99TKP | EP02 | 8 TB | Capacity |
| HDD | SAS | 3.5 | NA | WD | Paris-CP | WUH722012CL5200 | 849H4 | VK0PK | AS05 | 12TB | Capacity |
| HDD | SAS | 3.5 | NA | WD | Paris-CP | WUH722016CL5200 | H8HN1 | VK0PK | AS05 | 16 TB | Capacity |
| HDD | SAS | 3.5 | NA | Toshiba | MG11SC | MG11SCA16TEY | GGWNH | 9GW4N | ES02 | 16 TB | Capacity |
| HDD | SAS | 3.5 | NA | Toshiba | MG11SC | MG11SCA20TEY | 2FX1T | 9GW4N | ES02 | 20 TB | Capacity |
SATA 2.5" SSD Cache or Capacity
| Type | Drive Type | Form Factor | Endurance | Vendor | Series | Model | Device Part Number (P/N) | Firmware Software Bundle | Firmware Minimum Supported Version | Capacity | Use |
|---|---|---|---|---|---|---|---|---|---|---|---|
| SSD | SATA | 2.5 | Mixed Use | Intel | Youngsville-RR | SSDSC2KG019TZR | 8RXV5 | VJPKG | DL7C | 1.92 TB | Cache, Capacity |
| SSD | SATA | 2.5 | Mixed Use | Toshiba | HK4 | THNSF8800CCSE | VCRY6 | H3XHN | DACB | 800 GB | Cache, Capacity |
| SSD | SATA | 2.5 | Mixed Use | Toshiba | HK4 | THNSF81D60CSE | DMF5Y | H3XHN | DACB | 1.6 TB | Cache, Capacity |
| SSD | SATA | 2.5 | Mixed Use | Micron | 5300 | MTFDDAK960TDT | XMWMK | KT63Y | J008 | 960 GB | Cache, Capacity |
| SSD | SATA | 2.5 | Mixed Use | Micron | 5300 | MTFDDAK1T9TDT | MMCDY | KT63Y | J008 | 1.92 TB | Cache, Capacity |
| SSD | SATA | 2.5 | Mixed Use | Micron | 5400 | MTFDDAK3T8TGB-1B | 34JK8 | JTW3W | K403 | 3.84 TB | Cache,Capacity |
| SSD | SATA | 2.5 | Mixed Use | Samsung | SM863a | MZ7KM960HMJP0D3 | DD4G0 | 97D8J | GD57 | 960 GB | Cache, Capacity |
| SSD | SATA | 2.5 | Mixed Use | Samsung | SM863a | MZ7KM1T9HMJP0D3 | K5P0T | 97D8J | GD57 | 1.92 TB | Cache, Capacity |
| SSD | SATA | 2.5 | Mixed Use | Samsung | SM883 | MZ7KH960HAJR0D3 | YDHYX | 3J3JR | HF58 | 960 GB | Cache, Capacity |
| SSD | SATA | 2.5 | Mixed Use | Samsung | SM883 | MZ7KH1T9HAJR0D3 | 71K37 | 3J3JR | HF58 | 1.92 TB | Cache, Capacity |
| SSD | SATA | 2.5 | Mixed Use | Intel | S4600 | SSDSC2KG960G7R | TR3MY | V141M | DL5C | 960 GB | Cache, Capacity |
| SSD | SATA | 2.5 | Mixed Use | Intel | S4600 | SSDSC2KG019T7R | MWKF2 | V141M | DL5C | 1.92 TB | Cache, Capacity |
| SSD | SATA | 2.5 | Mixed Use | Intel | S4610 | SSDSC2KG960G8R | X31G3 | 4DW70 | DL6B | 960 GB | Cache, Capacity |
| SSD | SATA | 2.5 | Mixed Use | Intel | S4610 | SSDSC2KG019T8R | F8N2K | 4DW70 | DL6B | 1.92 TB | Cache, Capacity |
| SSD | SATA | 2.5 | Mixed Use | Intel | S4610 | SSDSC2KG019T8R | 55J8H | 4DW70 | DL6B | 1.92 TB | Cache, Capacity |
| SSD | SATA | 2.5 | Mixed Use | Micron | 5200 | MTFDDAK960TDN | HY1F8 | W2X8N | F005 | 960 GB | Cache, Capacity |
| SSD | SATA | 2.5 | Mixed Use | Micron | 5200 | MTFDDAK1T9TDN | XKF5Y | W2X8N | F005 | 1.92 TB | Cache, Capacity |
| SSD | SATA | 2.5 | Mixed Use | Kioxia | HK6-V | KHK6YVSE960G | XW4D1 | W0YR1 | DBC4 | 960 GB | Cache, Capacity |
| SSD | SATA | 2.5 | Mixed Use | Kioxia | HK6-V | KHK6YVSE1T92 | 0DXJ7 | W0YR1 | DBC4 | 1.92 TB | Cache, Capacity |
| SSD | SATA | 2.5 | Mixed Use | Hynix | SE5130 | HFS960G3E2X149N | G162V | 17C3M | DG02 | 960GB | Cache,Capacity |
| SSD | SATA | 2.5 | Mixed Use | Hynix | SE5130 | HFS1T9G3E2X149N | HCR09 | 17C3M | DG02 | 1.92TB | Cache,Capacity |
| SSD | SATA | 2.5 | Mixed Use | Intel | Youngsville-RR | SSDSC2KG960GZR | 8MHYH | VJPKG | DL7C | 960 GB | Cache,Capacity |
| SSD | SATA | 2.5 | Mixed Use | Intel | Youngsville-RR | SSDSC2KG019TZR | 8RXV5 | VJPKG | DL7C | 1.92 TB | Cache,Capacity |
| SSD | SATA | 2.5 | Mixed Use | Intel | Youngsville RR (New) (S4620) | SSDSC2KG960GZR | DYMD0 | VJPKG | DL7C | 960 GB | Cache,Capacity |
| SSD | SATA | 2.5 | Mixed Use | Intel | Youngsville RR (New) (S4620) | SSDSC2KG019TZR | 6XW3M | VJPKG | DL7C | 1.92 TB | Cache,Capacity |
| SSD | SATA | 2.5 | Mixed Use | Samsung | PM897 | MZ7L3960HBLTAD3 | 96KT6 | VRG4Y | HH64 | 960 GB | Cache,Capacity |
| SSD | SATA | 2.5 | Mixed Use | Samsung | PM897 | MZ7L31T9HBNAAD3 | RRR7M | VRG4Y | HH64 | 1.92 TB | Cache,Capacity |
SATA 2.5" SSD Capacity Only
| Type | Drive Type | Form Factor | Endurance | Vendor | Series | Model | Device Part Number (P/N) | Firmware Software Bundle | Firmware Minimum Supported Version | Capacity | Use |
|---|---|---|---|---|---|---|---|---|---|---|---|
| SSD | SATA | 2.5 | Read Intensive | Intel | Youngsville-RR | SSDSC2KB960GZR | F6H8H | VJPKG | DL7C | 960 GB | Capacity |
| SSD | SATA | 2.5 | Read Intensive | Intel | Youngsville-RR | SSDSC2KB019TZR | VYYW8 | VJPKG | DL7C | 1.92 TB | Capacity |
| SSD | SATA | 2.5 | Read Intensive | Intel | Youngsville-RR | SSDSC2KB038TZR | WNPN1 | VJPKG | DL7C | 3.84 TB | Capacity |
| SSD | SATA | 2.5 | Read Intensive | Intel | Youngsville RR (New) (S4520) | SSDSC2KB960GZR | 5M8Y4 | VJPKG | DL7C | 960 GB | Capacity |
| SSD | SATA | 2.5 | Read Intensive | Intel | Youngsville RR (New) (S4520) | SSDSC2KB019TZR | 6J65H | VJPKG | DL7C | 1.92 TB | Capacity |
| SSD | SATA | 2.5 | Read Intensive | Intel | Youngsville RR (New) (S4520) | SSDSC2KB038TZR | KM4C4 | VJPKG | DL7C | 3.84 TB | Capacity |
| SSD | SATA | 2.5 | Read Intensive | Micron | 5200 | MTFDDAK1T9TDD | VJ36D | W2X8N | F005 | 1.92 TB | Capacity |
| SSD | SATA | 2.5 | Read Intensive | Micron | 5300 | MTFDDAK1T9TDS | GYGVV | KT63Y | J008 | 1.92 TB | Capacity |
| SSD | SATA | 2.5 | Read Intensive | Micron | 5400 | MTFDDAK3T8TGA-1B | CHF46 | JTW3W | K403 | 3.84 TB | Capacity |
| SSD | SATA | 2.5 | Read Intensive | Micron | 5400 SED | MTFDDAK3T8TGA-1B | 2DXDK | JTW3W | K403 | 3.84 TB | Capacity |
| SSD | SATA | 2.5 | Read Intensive | Kioxia | HK6-R | KHK6YRSE1T92 | 919J7 | W0YR1 | DBC4 | 1.92 TB | Capacity |
| SSD | SATA | 2.5 | Read Intensive | Kioxia | HK6-R | KHK6YRSE3T84 | 8PYG5 | W0YR1 | DBC4 | 3.84 TB | Capacity |
| SSD | SATA | 2.5 | Read Intensive | Samsung | PM883a | MZ7LH1T9HALT0D3 | 9F9Y6 | 3GHD6 | HG61 | 1.92 TB | Capacity |
| SSD | SATA | 2.5 | Read Intensive | Samsung | PM883 | MZ7LH1T9HMLT0D3 | Y24T6 | 93P7P | HE59 | 1.92 TB | Capacity |
| SSD | SATA | 2.5 | Read Intensive | Hynix | SE5110 | HFS1T9G3H2X069N | 962FP | HFTMG | DZ04 | 1.92 TB | Capacity |
| SSD | SATA | 2.5 | Read Intensive | Hynix | SE4011 | HFS1T9G32FEH-7A1 | 0XMV9 | 3DTV4 | DE08 | 1.92 TB | Capacity |
| SSD | SATA | 2.5 | Read Intensive | Intel | S4510 | SSDSC2KB019T8R | 33R2T | 4DW70 | DL6B | 1.92 TB | Capacity |
| SSD | SATA | 2.5 | Read Intensive | Intel | S4500 | SSDSC2KB019T7R | XCN15 | V141M | DL5C | 1.92 TB | Capacity |
| SSD | SATA | 2.5 | Read Intensive | Intel | P89110 | SSDSC2KB038T7R | 3RRN8 | V141M | DL5C | 3.84 TB | Capacity |
| SSD | SATA | 2.5 | Read Intensive | Intel | S4510 | SSDSC2KB038T8R | 1RHK2 | 4DW70 | DL6B | 3.84 TB | Capacity |
| SSD | SATA | 2.5 | Read Intensive | Samsung | PM883 | MZ7LH3T8HMLT0D3 | FYP5F | 93P7P | HE59 | 3.84 TB | Capacity |
| SSD | SATA | 2.5 | Read Intensive | Samsung | PM883a | MZ7LH3T8HALT0D3 | 5TVXD | 3GHD6 | HG61 | 3.84 TB | Capacity |
| SSD | SATA | 2.5 | Read Intensive | Hynix | SE4011 | HFS3T8G32FEH-741 | D6C0R | 3DTV4 | DE08 | 3.84 TB | Capacity |
| SSD | SATA | 2.5 | Read Intensive | Hynix | SE5110 | HFS3T8G3H2X069N | 3GDK0 | HFTMG | DZ04 | 3.84 TB | Capacity |
| SSD | SATA | 2.5 | Read Intensive | Micron | 5300 | MTFDDAK3T8TDT | 4H1RX | R9YDC | J408 | 3.84 TB | Capacity |
| SSD | SATA | 2.5 | Read Intensive | Intel | Youngsville-RR | SSDSC2KB019TZR | VYYW8 | VJPKG | DL7C | 1.92 TB | Capacity |
| SSD | SATA | 2.5 | Read Intensive | Intel | Youngsville-RR | SSDSC2KB038TZR | WNPN1 | VJPKG | DL7C | 3.84 TB | Capacity |
| SSD | SATA | 2.5 | Read Intensive | Samsung | PM893 | MZ7L31T9HBLTAD3 | 0KYP4 | T3HX9 | HJ64 | 1.92 TB | Capacity |
| SSD | SATA | 2.5 | Read Intensive | Samsung | PM893 | MZ7L33T8HBLTAD3 | GCN5W | T3HX9 | HJ64 | 3.84 TB | Capacity |
| SSD | SATA | 2.5 | Mixed Use | Hynix | SE5031 | HFS960G32FEH-BA1 | 7GR2K | 2CY65 | DD02 | 960 GB | Capacity |
| SSD | SATA | 2.5 | Mixed Use | Hynix | SE5031 | HFS1T9G32FEH-BA1 | GKTF1 | 2CY65 | DD02 | 1.92 TB | Capacity |
| SSD | SATA | 2.5 | Read Intensive | Samsung | PM863a | MZ7LM960HMJP0D3 | T2G0Y | P2YRJ | GC5B | 960 GB | Capacity |
SAS 2.5" SSD Cache or Capacity
| Type | Drive Type | Form Factor | Endurance | Vendor | Series | Model | Device Part Number (P/N) | Firmware Software Bundle | Firmware Minimum Supported Version | Capacity | Use |
|---|---|---|---|---|---|---|---|---|---|---|---|
| SSD | SAS | 2.5 | Mixed Use | Samsung | PM1655 | MZILG800HCHQAD3 | 3CHC8 | 7MTXM | DWG9 | 800 GB | Cache,Capacity |
| SSD | SAS | 2.5 | Mixed Use | Samsung | PM1655 | MZILG1T6HCJRAD3 | 5RJND | 7MTXM | DWG9 | 1.6 TB | Cache,Capacity |
| SSD | SAS | 2.5 | Write Intensive | Kioxia | PM6 | KPM6XMUG800G | H6GCD | NGPR2 | BA48 | 800 GB | Cache, Capacity |
| SSD | SAS | 2.5 | Write Intensive | Kioxia | PM6 | KPM6XMUG1T60 | 5GDXH | NGPR2 | BA48 | 1.6 TB | Cache, Capacity |
| SSD | SAS | 2.5 | Mixed Use | Kioxia | PM6 | KPM6XVUG800G | JTKH5 | NGPR2 | BA48 | 800 GB | Cache, Capacity |
| SSD | SAS | 2.5 | Mixed Use | Kioxia | PM6 | KPM6XVUG1T60 | GD3N0 | NGPR2 | BA48 | 1.6 TB | Cache, Capacity |
| SSD | SAS | 2.5 | Mixed Use | Kioxia | PM6 | KPM6XVUG3T20 | NKM7P | NGPR2 | BA48 | 3.2 TB | Cache,Capacity |
| SSD | SAS | 2.5 | Mixed Use | Kioxia | PM6 | KPM6XVUG6T40 | 6NW3J | NGPR2 | BA48 | 6.4 TB | Cache,Capacity |
| SSD | SAS | 2.5 | Write Intensive | Kioxia | Phoenix M4 | PX05SMB080Y | CN3JH | 1DJXX | AS10 | 800 GB | Cache, Capacity |
| SSD | SAS | 2.5 | Mixed Use | Kioxia | Phoenix M4 | PX05SVB096Y | 503M7 | 1DJXX | AS10 | 960 GB | Cache, Capacity |
| SSD | SAS | 2.5 | Write Intensive | Kioxia | Phoenix M4 | PX05SMB160Y | GVTYD | 1DJXX | AS10 | 1.6 TB | Cache, Capacity |
| SSD | SAS | 2.5 | Mixed Use | Kioxia | Phoenix M4 | PX05SVB192Y | V0K7V | 1DJXX | AS10 | 1.92 TB | Cache, Capacity |
| SSD | SAS | 2.5 | Mixed Use | Kioxia | Phoenix M4 | PX05SVB384Y | 3DDFT | 1DJXX | AS10 | 3.84 TB | Cache, Capacity |
| SSD | SAS | 2.5 | Write Intensive | Kioxia | Phoenix M5-M | KPM5XMUG800G | DHRVV | CPP97 | B02A | 800 GB | Cache, Capacity |
| SSD | SAS | 2.5 | Write Intensive | Kioxia | Phoenix M5-M | KPM5XMUG1T60 | W9G88 | CPP97 | B02A | 1.6 TB | Cache, Capacity |
| SSD | SAS | 2.5 | Mixed Use | Samsung | PM1645a | MZILT800HBHQ0D3 | GW8T1 | VJY6V | DWA4 | 800 GB | Cache, Capacity |
| SSD | SAS | 2.5 | Mixed Use | Samsung | PM1645a | MZILT1T6HBJR0D3 | 3TCV6 | VJY6V | DWA4 | 1.6 TB | Cache, Capacity |
| SSD | SAS | 2.5 | Mixed Use | Samsung | PM1645 | MZILT1T6HAJQ0D3 | DR0HX | 4PPHJ | DWF8 | 1.6 TB | Cache, Capacity |
| SSD | SAS | 2.5 | Mixed Use | WD | Bear Cove Quantum | WUSTR6480BSS200 | 6VJC9 | 8W5WF | G138 | 800 GB | Cache, Capacity |
| SSD | SAS | 2.5 | Mixed Use | WD | Bear Cove Quantum | WUSTR6416BSS200 | 6NF96 | 8W5WF | G138 | 1.6 TB | Cache, Capacity |
| SSD | SAS | 2.5 | Mixed Use | Kioxia | Phoenix M5-V | KPM5XVUG960G | WFGTH | CPP97 | B02A | 960 GB | Cache, Capacity |
| SSD | SAS | 2.5 | Mixed Use | Kioxia | Phoenix M5-V | KPM5XVUG1T92 | 2WVYG | CPP97 | B02A | 1.92 TB | Cache, Capacity |
| SSD | SAS | 2.5 | Mixed Use | Kioxia | Phoenix M5-V | KPM5XVUG3T84 | 91W3V | CPP97 | B02A | 3.84 TB | Cache, Capacity |
| SSD | SAS | 2.5 | Mixed Use | Kioxia | PM6 FIPS | KPM6WVUG960G | WMWKG | 6DH0W | BD48 | 960 GB | Cache, Capacity |
| SSD | SAS | 2.5 | Mixed Use | Kioxia | PM6 FIPS | KPM6WVUG1T92 | DHWH5 | 6DH0W | BD48 | 1.92 TB | Cache, Capacity |
| SSD | SAS | 2.5 | Mixed Use | Kioxia | PM6 FIPS | KPM6WVUG3T84 | 81H9C | 6DH0W | BD48 | 3.84 TB | Cache, Capacity |
| SSD | SAS | 2.5 | Mixed Use | Kioxia | PM7 | KPM7XVUG800G | X96H8 | T21WT | C10E | 800 GB | Cache,Capacity |
| SSD | SAS | 2.5 | Mixed Use | Kioxia | PM7 | KPM7XVUG1T60 | 4TRHM | T21WT | C10E | 1.6 TB | Cache,Capacity |
| SSD | SAS | 2.5 | Mixed Use | Kioxia | PM7 (FIPS) | KPM7WVUG800G | 81G77 | 57MM2 | C40E | 800GB | Cache,Capacity |
| SSD | SAS | 2.5 | Mixed Use | Kioxia | PM7 (FIPS) | KPM7WVUG1T60 | G4NY4 | 57MM2 | C40E | 1.6TB | Cache,Capacity |
| SSD | SAS | 2.5 | Mixed Use | Kioxia | PM7 (FIPS) | KPM7WVUG3T20 | RGP9J | 57MM2 | C40E | 3.2TB | Cache,Capacity |
| SSD | SAS | 2.5 | Mixed Use | Kioxia | PM7 (FIPS) | KPM7WVUG3T84 | FMP6K | 57MM2 | C40E | 3.84TB | Cache,Capacity |
| SSD | SAS | 2.5 | Mixed Use | Kioxia | PM6 | KPM6WVUG960G | J92FY | 6DH0W | BD48 | 960 GB | Cache,Capacity |
| SSD | SAS | 2.5 | Mixed Use | Kioxia | PM6 | KPM6WVUG1T92 | 1081V | 6DH0W | BD48 | 1.92 TB | Cache,Capacity |
| SSD | SAS | 2.5 | Mixed Use | Kioxia | PM6 | KPM6WVUG3T84 | MD4YN | 6DH0W | BD48 | 3.84 TB | Cache,Capacity |
| SSD | SAS | 2.5 | Mixed Use | Kioxia | PM6 | KPM6XVUG800G | NNGV4 | NGPR2 | BA48 | 800 GB | Cache,Capacity |
| SSD | SAS | 2.5 | Mixed Use | Kioxia | PM6 | KPM6XVUG1T60 | CHJJJ | NGPR2 | BA48 | 1.6 TB | Cache,Capacity |
| SSD | SAS | 2.5 | Mixed Use | WD | Bear Cove Plus | WUSTR6416ASS200 | 8W6HC | 7HYHH | K968 | 1.6 TB | Cache,Capacity |
| SSD | SAS | 2.5 | Mixed Use | Samsung | PM1655a | MZILG1T6HFJAAD3 | J7MWC | 42TFH | DWB1 | 1.6 TB | Cache, Capacity |
| SSD | SAS | 2.5 | Mixed Use | Samsung | PM1655a | MZILG3T2HFLTAD3 | 03P3V | 42TFH | DWB1 | 3.2 TB | Cache, Capacity |
| SSD | SAS | 2.5 | Mixed Use | Samsung | PM1655a | MZILG6T4HBLCAD3 | 24VJM | 42TFH | DWB1 | 6.4 TB | Cache, Capacity |
SAS 2.5" SSD Capacity Only
| Type | Drive Type | Form Factor | Endurance | Vendor | Series | Model | Device Part Number (P/N) | Firmware Software Bundle | Firmware Minimum Supported Version | Capacity | Use |
|---|---|---|---|---|---|---|---|---|---|---|---|
| SSD | SAS | 2.5 | Read Intensive | WD | Bear Cove Plus | WUSTR1519ASS200 | 5ND33 | 7HYHH | K968 | 1.92 TB | Capacity |
| SSD | SAS | 2.5 | Read Intensive | WD | Bear Cove Plus | WUSTR1538ASS200 | YW17N | 7HYHH | K968 | 3.84 TB | Capacity |
| SSD | SAS | 2.5 | Read Intensive | WD | Bear Cove Quantum | WUSTVA119BSS200 | 02X38 | 8W5WF | G138 | 1.92 TB | Capacity |
| SSD | SAS | 2.5 | Read Intensive | WD | Bear Cove Quantum | WUSTVA138BSS200 | FP1KF | 8W5WF | G138 | 3.84 TB | Capacity |
| SSD | SAS | 2.5 | Read Intensive | Samsung | PM1643 | MZILT1T9HAJQ0D3 | F0VFY | J3RRK | DSF8 | 1.92 TB | Capacity |
| SSD | SAS | 2.5 | Read Intensive | Samsung | PM1643 | MZILT3T8HALS0D3 | X8F87 | J3RRK | DSF8 | 3.84 TB | Capacity |
| SSD | SAS | 2.5 | Read Intensive | Samsung | PM1643 | MZILT7T6HMLA0D3 | RVYD5 | J3RRK | DSF8 | 7.68 TB | Capacity |
| SSD | SAS | 2.5 | Read Intensive | Samsung | PM1643a | MZILT1T9HBJR0D3 | TMTW9 | D7RNT | DSA4 | 1.92 TB | Capacity |
| SSD | SAS | 2.5 | Read Intensive | Samsung | PM1643a | MZILT3T8HBLS0D3 | CRNPH | D7RNT | DSA4 | 3.84 TB | Capacity |
| SSD | SAS | 2.5 | Read Intensive | Samsung | PM1633a | MZILS1T9HEJH0D3 | 086DD | XNGNT | DSLA | 1.92 TB | Capacity |
| SSD | SAS | 2.5 | Read Intensive | Samsung | PM1633a | MZILS3T8HMLH0D3 | JR1HP | XNGNT | DSLA | 3.84 TB | Capacity |
| SSD | SAS | 2.5 | Read Intensive | Samsung | PM1643a | MZILT960HBHQ0D3 | K74WN | D7RNT | DSA4 | 960 GB | Capacity |
| SSD | SAS | 2.5 | Read Intensive | Samsung | PM1643a | MZILT7T6HALA0D3 | 84C40 | D7RNT | DSA4 | 7.68 TB | Capacity |
| SSD | SAS | 2.5 | Read Intensive | Samsung | PM1653 | MZILG1T9HCJRAD3 | NRR34 | 3MV58 | DSG9 | 1.92 TB | Capacity |
| SSD | SAS | 2.5 | Read Intensive | Samsung | PM1653 | MZILG3T8HCLSAD3 | 9N32F | 3MV58 | DSG9 | 3.84 TB | Capacity |
| SSD | SAS | 2.5 | Read Intensive | Samsung | PM1653 | MZILG7T6HBLAAD3 | Y8H7M | 3MV58 | DSG9 | 7.68 TB | Capacity |
| SSD | SAS | 2.5 | Read Intensive | Kioxia | PM6 | KPM6XRUG1T92 | 4CN85 | NGPR2 | BA48 | 1.92 TB | Capacity |
| SSD | SAS | 2.5 | Read Intensive | Kioxia | PM6 | KPM6XRUG3T84 | H9TT5 | NGPR2 | BA48 | 3.84 TB | Capacity |
| SSD | SAS | 2.5 | Read Intensive | Kioxia | PM6 | KPM6XRUG7T68 | PD02Y | NGPR2 | BA48 | 7.68 TB | Capacity |
| SSD | SAS | 2.5 | Read Intensive | Kioxia | PM6 FIPS | KPM6WRUG1T92 | 7F2D1 | 6DH0W | BD48 | 1.92 TB | Capacity |
| SSD | SAS | 2.5 | Read Intensive | Kioxia | PM6 FIPS | KPM6WRUG3T84 | FH1W9 | 6DH0W | BD48 | 3.84 TB | Capacity |
| SSD | SAS | 2.5 | Read Intensive | Kioxia | PM6 | KPM6WRUG1T92 | H1P07 | 6DH0W | BD48 | 1.92 TB | Capacity |
| SSD | SAS | 2.5 | Read Intensive | Kioxia | PM6 | KPM6WRUG3T84 | 3VHY3 | 6DH0W | BD48 | 3.84 TB | Capacity |
| SSD | SAS | 2.5 | Read Intensive | Kioxia | PM6 | KPM6WRUG7T68 | 5T78C | 6DH0W | BD48 | 7.68 TB | Capacity |
| SSD | SAS | 2.5 | Read Intensive | Kioxia | PM6 | KPM6XRUG1T92 | VRTN9 | NGPR2 | BA48 | 1.92 TB | Capacity |
| SSD | SAS | 2.5 | Read Intensive | Kioxia | PM6 | KPM6XRUG3T84 | 2XVX2 | NGPR2 | BA48 | 3.84 TB | Capacity |
| SSD | SAS | 2.5 | Read Intensive | Kioxia | PM6 | KPM6XRUG7T68 | YM0T1 | NGPR2 | BA48 | 7.68 TB | Capacity |
| SSD | SAS | 2.5 | Read Intensive | Kioxia | PM7 (FIPS) | KPM7WRUG1T92 | VGMCD | 57MM2 | C40E | 1.92TB | Capacity |
| SSD | SAS | 2.5 | Read Intensive | Kioxia | PM7 (FIPS) | KPM7WRUG3T84 | YTVTF | 57MM2 | C40E | 3.84TB | Capacity |
| SSD | SAS | 2.5 | Read Intensive | Kioxia | PM7 (FIPS) | KPM7WRUG7T68 | HCTYM | 57MM2 | C40E | 7.68TB | Capacity |
| SSD | SAS | 2.5 | Read Intensive | Kioxia | Phoenix M5-R | KPM5XRUG1T92 | TDNP7 | CPP97 | B02A | 1.92 TB | Capacity |
| SSD | SAS | 2.5 | Read Intensive | Kioxia | Phoenix M5-R | KPM5XRUG3T84 | N85XX | CPP97 | B02A | 3.84 TB | Capacity |
| SSD | SAS | 2.5 | Read Intensive | Kioxia | Phoenix M4 | PX05SRB384Y | XCRDV | 1DJXX | AS10 | 3.84 TB | Capacity |
| SSD | SAS | 2.5 | Read Intensive | Seagate | LangeBP | XS3840SE70114 | KXDCD | NKGWD | 3D03 | 3.84 TB | Capacity |
| SSD | SAS | 2.5 | Read Intensive | Seagate | LangeBP | XS1920SE70114 | D4VFW | NKGWD | 3D03 | 1.92 TB | Capacity |
| SSD | SAS | 2.5 | Read Intensive | Kioxia | PM7 | KPM7XRUG1T92 | 6K35K | T21WT | C10E | 1.92 TB | Capacity |
| SSD | SAS | 2.5 | Read Intensive | Kioxia | PM7 | KPM7XRUG3T84 | MT0R5 | T21WT | C10E | 3.84 TB | Capacity |
| SSD | SAS | 2.5 | Read Intensive | Kioxia | PM7 | KPM7XRUG7T68 | 7N1WT | T21WT | C10E | 7.68 TB | Capacity |
| SSD | SAS | 2.5 | Read Intensive | Samsung | PM1653a | MZILG1T9HFJAAD3 | 8WKDX | 862D9 | DSB1 | 1.92 TB | Capacity |
| SSD | SAS | 2.5 | Read Intensive | Samsung | PM1653a | MZILG3T8HFLTAD3 | MP2TJ | 862D9 | DSB1 | 3.84 TB | Capacity |
| SSD | SAS | 2.5 | Read Intensive | Samsung | PM1653a | MZILG7T6HBLCAD3 | 00CK9 | 862D9 | DSB1 | 7.68 TB | Capacity |
Value SAS 2.5" SSD
| Type | Drive Type | Form Factor | Endurance | Vendor | Series | Model | Device Part Number (P/N) | Firmware Software Bundle | Firmware Minimum Supported Version | Capacity | Use |
|---|---|---|---|---|---|---|---|---|---|---|---|
| SSD | VSAS | 2.5 | Read Intensive | Seagate | LangeBP SED | XS1920SE70134 | K9T53 | G04C8 | 4S0C | 1.92 TB | Capacity |
| SSD | VSAS | 2.5 | Read Intensive | Seagate | LangeBP SED | XS3840SE70134 | 4KPKF | G04C8 | 4S0C | 3.84 TB | Capacity |
| SSD | VSAS | 2.5 | Read Intensive | Seagate | LangeBP SED | XS7680SE70134 | 2THYF | G04C8 | 4S0C | 7.68 TB | Capacity |
| SSD | VSAS | 2.5 | Mixed Use | Kioxia | Phoenix RM5 | KRM5XVUG3T84 | X78JM | NDG7N | B710 | 3.84 TB | Cache, Capacity |
| SSD | VSAS | 2.5 | Mixed Use | Seagate | LangeBP ISE | XS3840LE70154 | NWGX3 | NX13G | 4D0C | 3.84 TB | Cache, Capacity |
| SSD | VSAS | 2.5 | Mixed Use | Seagate | Cooper (Nytro 2550) | XS960LE70095 | 2M1NG | RRWVT | CPE9 | 960GB | Cache,Capacity |
| SSD | VSAS | 2.5 | Mixed Use | Seagate | Cooper (Nytro 2550) | XS1920LE70095 | K805Y | RRWVT | CPE9 | 1.92TB | Cache,Capacity |
| SSD | VSAS | 2.5 | Mixed Use | Seagate | Cooper (Nytro 2550) | XS3840LE70095 | FT95M | RRWVT | CPE9 | 3.84TB | Cache,Capacity |
| SSD | VSAS | 2.5 | Read Intensive | Kioxia | Phoenix RM5 | KRM5XRUG7T68 | 5XD2F | NDG7N | B710 | 7.68 TB | Capacity |
| SSD | VSAS | 2.5 | Read Intensive | Seagate | Lange ISE | XS7680SE70074 | 2PKRH | H3VHX | EC16 | 7.68 TB | Capacity |
| SSD | VSAS | 2.5 | Read Intensive | Seagate | LangeBP ISE | XS7680SE70154 | 5KW0F | NX13G | 4D0C | 7.68 TB | Capacity |
| SSD | VSAS | 2.5 | Mixed Use | Seagate | LangeBP SED | XS960LE70134 | 2RDWT | G04C8 | 4S0C | 960 GB | Cache, Capacity |
| SSD | VSAS | 2.5 | Mixed Use | Seagate | LangeBP SED | XS1920LE70134 | N6DRV | G04C8 | 4S0C | 1.92 TB | Cache, Capacity |
| SSD | VSAS | 2.5 | Mixed Use | Seagate | LangeBP SED | XS3840LE70134 | YM9HP | G04C8 | 4S0C | 3.84 TB | Cache, Capacity |
| SSD | VSAS | 2.5 | Mixed Use | Kioxia | RM6 | KRM6VVUG960G | 42XXC | 5WMK8 | BJ07 | 960 GB | Cache, Capacity |
| SSD | VSAS | 2.5 | Mixed Use | Kioxia | RM6 | KRM6VVUG1T92 | N15JP | 5WMK8 | BJ07 | 1.92 TB | Cache, Capacity |
| SSD | VSAS | 2.5 | Mixed Use | Kioxia | RM6 | KRM6VVUG3T84 | FXYGR | 5WMK8 | BJ07 | 3.84 TB | Cache, Capacity |
| SSD | VSAS | 2.5 | Read Intensive | Kioxia | RM6 | KRM6VRUG1T92 | 1FGWG | 5WMK8 | BJ07 | 1.92 TB | Capacity |
| SSD | VSAS | 2.5 | Read Intensive | Kioxia | RM6 | KRM6VRUG3T84 | XNXD2 | 5WMK8 | BJ07 | 3.84 TB | Capacity |
| SSD | VSAS | 2.5 | Read Intensive | Kioxia | RM6 | KRM6VRUG7T68 | 5MHY8 | 5WMK8 | BJ07 | 7.68 TB | Capacity |
| SSD | VSAS | 2.5 | Read Intensive | Kioxia | RM7 | KRM7VVUG960G | 05MT7 | 1YD58 | CA0C | 960 GB | Capacity |
| SSD | VSAS | 2.5 | Read Intensive | Kioxia | RM7 | KRM7VVUG1T92 | 59XF2 | 1YD58 | CA0C | 1.92 TB | Capacity |
| SSD | VSAS | 2.5 | Read Intensive | Kioxia | RM7 | KRM7VVUG3T84 | M0JVN | 1YD58 | CA0C | 3.84 TB | Capacity |
| SSD | vSAS | 2.5 | Read Intensive | Kioxia | RM7 | KRM7VRUG7T68 | D480G | 1YD58 | CA0C | 7.68 TB | Capacity |
| SSD | vSAS | 2.5 | Read Intensive | Seagate | Cooper | XS7680SE70145 | 1J46N | RRWVT | CPE9 | 7.68 TB | Capacity |
NVMe 2.5" Cache or Capacity
| Type | Drive Type | Form Factor | Endurance | Vendor | Series | Model | Device Part Number (P/N) | Firmware Software Bundle | Firmware Minimum Supported Version | Capacity | Use |
|---|---|---|---|---|---|---|---|---|---|---|---|
| NVMe | PCIe | 2.5 | Write Intensive | Intel | Optane P4800x SSD/NVMe, 375GB U.2 2.5" SFF | SSDPE21K375GAT | 3DM57 | HMRK7 | E201DP38 | 375 GB | Cache, Capacity |
| NVMe | PCIe | 2.5 | Mixed Use | Samsung | PM1725A, Dell Express Flash NVMe 1.6TB 2.5" SFF | MZWLL1T6HEHP-000D3 | JD6CH | 34C36 | 1.2.1 | 1.6 TB | Cache, Capacity |
| NVMe | PCIe | 2.5 | Mixed Use | Samsung | PM1725A, Dell Express Flash NVMe 3.2TB 2.5" SFF | MZWLL3T2HMJP-000D3 | JDMHM | 34C36 | 1.2.1 | 3.2 TB | Cache, Capacity |
| NVMe | PCIe | 2.5 | Mixed Use | Samsung | PM1725A, Dell Express Flash NVMe 6.4TB 2.5" SFF | MZWLL6T4HMLS-000D3 | Y3XT2 | 34C36 | 1.2.1 | 6.4 TB | Cache, Capacity |
| NVMe | PCIe | 2.5 | Mixed Use | Samsung | PM1725b, Dell Express Flash NVMe 1.6TB 2.5" SFF | MZWLL1T6HAJQ-000D3 | 4WDXY | NC07Y | 1.2.2 | 1.6 TB | Cache, Capacity |
| NVMe | PCIe | 2.5 | Mixed Use | Samsung | PM1725b, Dell Express Flash NVMe 3.2TB 2.5" SFF | MZWLL3T2HAJQ-000D3 | K60N7 | NC07Y | 1.2.2 | 3.2 TB | Cache, Capacity |
| NVMe | PCIe | 2.5 | Mixed Use | Samsung | PM1725b, Dell Express Flash NVMe 6.4TB 2.5" SFF | MZWLL6T4HMLA-000D3 | 08NMX | NC07Y | 1.2.2 | 6.4 TB | Cache, Capacity |
| NVMe | PCIe | 2.5 | Mixed Use | Intel | P4600, Dell Express Flash NVMe 1.6TB 2.5" SFF | SSDPE2KE016T7T | F5P84 | CR0HC | QDV1DP17 | 1.6 TB | Cache, Capacity |
| NVMe | PCIe | 2.5 | Mixed Use | Intel | P4600, Dell Express Flash NVMe 3.2TB 2.5" SFF | SSDPE2KE032T7T | MCV6J | CR0HC | QDV1DP17 | 3.2 TB | Cache, Capacity |
| NVMe | PCIe | 2.5 | Mixed Use | Intel | P4610, Dell Express Flash NVMe 1.6TB 2.5" SFF | SSDPE2KE016T8T | 58V30 | 7VJGR | VDV1DP25 | 1.6 TB | Cache, Capacity |
| NVMe | PCIe | 2.5 | Mixed Use | Intel | P4610, Dell Express Flash NVMe 3.2TB 2.5" SFF | SSDPE2KE032T8T | 2CN1T | 7VJGR | VDV1DP25 | 3.2 TB | Cache, Capacity |
| NVMe | PCIe | 2.5 | Mixed Use | Intel | P4610, Dell Express Flash NVMe 6.4TB 2.5" SFF | SSDPE2KE064T8T | X27HY | 7VJGR | VDV1DP25 | 6.4 TB | Cache, Capacity |
| NVMe | PCIe | 2.5 | Mixed Use | KIOXIA | DELL EXPRESS FLASH KIOXIA CM6 MU 1.6TB U.2 FIPS | KCM6FVUL1T60 | G7N00 | WJD95 | 3.1.7 | 1.6 TB | Cache, Capacity |
| NVMe | PCIe | 2.5 | Mixed Use | Samsung | PM1735 SP 3WPD, SSD, NVMe, 2.5, 512e, ISE | MZWLJ1T6HBJRAD3 | 6GK00 | 5CM3G | 2.5.0 | 1.6 TB | Cache, Capacity |
| NVMe | PCIe | NA | Mixed Use | Samsung | PM1735 SP 3WPD, SSD, Gen4 NVMe, 2.5, 512e, ISE | MZWLJ3T2HBJRAD3 | 15TVC | 5CM3G | 2.5.0 | 3.2TB | Cache,Capacity |
| NVMe | PCIe | NA | Mixed Use | Samsung | PM1735 SP 3WPD, SSD, Gen4 NVMe, 2.5, 512e, ISE | MZWLJ6T4HALAAD3 | F6V5P | 5CM3G | 2.5.0 | 6.4TB | Cache,Capacity |
| NVMe | PCIe | 2.5 | Mixed Use | Kioxia | CM6 SP | KCM6XVUL1T60 | P03YC | GMM6V | 2.2.2 | 1.6 TB | Cache, Capacity |
| NVMe | PCIe | 2.5 | Mixed Use | Kioxia | CM6 SP | KCM6XVUL3T20 | 97GR0 | GMM6V | 2.2.2 | 3.2 TB | Cache, Capacity |
| NVMe | PCIe | 2.5 | Mixed Use | Kioxia | CM6 SP | KCM6XVUL6T40 | K916X | GMM6V | 2.2.2 | 6.4 TB | Cache, Capacity |
| NVMe | PCIe | 2.5 | Mixed Use | Intel | P5600 SP 3WPD | D7 P5600 Series 1.6TB | C9X5T | CGXH7 | 1.2.4 | 1.6 TB | Cache, Capacity |
| NVMe | PCIe | 2.5 | Mixed Use | Intel | P5600 SP 3WPD | D7 P5600 Series 3.2TB | PRKTM | CGXH7 | 1.2.4 | 3.2 TB | Cache, Capacity |
| NVMe | PCIe | 2.5 | Mixed Use | Intel | Arbordale Plus RR P5620 | SSDPF2KE016T1E | 82TVJ | 12W9R | 1.5.0 | 1.6 TB | Cache,Capacity |
| NVMe | PCIe | 2.5 | Mixed Use | Intel | Arbordale Plus RR P5620 | SSDPF2KE032T1E | TY3M5 | 12W9R | 1.5.0 | 3.2 TB | Cache,Capacity |
| NVMe | PCIe | 2.5 | Mixed Use | Intel | Arbordale Plus RR P5620 | SSDPF2KE064T1E | 5WCR8 | 12W9R | 1.5.0 | 6.4TB | Cache, Capacity |
| NVMe | PCIe | 2.5 | Mixed Use | Samsung | PM1735 V2 SP 3WPD | MZWLR1T6HBJRAD3 | 0MNMV | 5V3P7 | 2.5.0 | 1.6 TB | Cache, Capacity |
| NVMe | PCIe | 2.5 | Mixed Use | Samsung | PM1735 V2 SP 3WPD | MZWLR3T2HBLSAD3 | V69W3 | 5V3P7 | 2.5.0 | 3.2 TB | Cache, Capacity |
| NVMe | PCIe | 2.5 | Mixed Use | Samsung | PM1735 V2 SP 3WPD | MZWLR6T4HALAAD3 | H8D5M | 5V3P7 | 2.5.0 | 6.4 TB | Cache, Capacity |
| NVMe | PCIe | 2.5 | Mixed Use | Samsung | PM1735a | MZWLR1T6HCJRAD3 | H8GHV | 71KRG | 1.2.0 | 1.6 TB | Cache,Capacity |
| NVMe | PCIe | 2.5 | Mixed Use | Samsung | PM1735a | MZWLR3T2HCLSAD3 | 617H6 | 71KRG | 1.2.0 | 3.2 TB | Cache,Capacity |
| NVMe | PCIe | 2.5 | Mixed Use | Samsung | PM1735a | MZWLR6T4HBLAAD3 | 9F6Y3 | 71KRG | 1.2.0 | 6.4 TB | Cache,Capacity |
| NVMe | PCIe | 2.5 | Mixed Use | Kioxia | CM7 | KCM7XVUG1T60 | MP4F2 | K1JTM | 2.0.3 | 1.6 TB | Cache, Capacity |
| NVMe | PCIe | 2.5 | Mixed Use | Kioxia | CM7 | KCM7XVUG3T20 | XFNX0 | K1JTM | 2.0.3 | 3.2 TB | Cache, Capacity |
| NVMe | PCIe | 2.5 | Mixed Use | Kioxia | CM7 | KCM7XVUG6T40 | 8RJJ9 | K1JTM | 2.0.3 | 6.4 TB | Cache, Capacity |
| NVMe | PCIe | 2.5 | Mixed Use | Hynix | PS1030 | HFS1T6GEJVX171N | 1HYKD | VNYK2 | 1.3.0 | 1.6 TB | Cache, Capacity |
| NVMe | PCIe | 2.5 | Mixed Use | Hynix | PS1030 | HFS3T2GEJVX171N | 9VWPD | VNYK2 | 1.3.0 | 3.2 TB | Cache, Capacity |
| NVMe | PCIe | 2.5 | Mixed Use | Hynix | PS1030 | HFS6T4GEJVX171N | PYMY6 | VNYK2 | 1.3.0 | 6.4 TB | Cache, Capacity |
| NVMe | PCIe | 2.5 | Mixed Use | Samsung | PM1745 | MZWLO1T6HCJR-00AD3 | FVC2P | V7V0K | 1.0.0 | 1.6 TB | Cache, Capacity |
| NVMe | PCIe | 2.5 | Mixed Use | Samsung | PM1745 | MZWLO3T2HCLS-00AD3 | FDNHD | V7V0K | 1.0.0 | 3.2 TB | Cache, Capacity |
| NVMe | PCIe | 2.5 | Mixed Use | Samsung | PM1745 | MZWLO6T4HBLA-00AD3 | 64K9C | V7V0K | 1.0.0 | 6.4 TB | Cache, Capacity |
| NVMe | PCIe | 2.5 | Mixed Use | Micron | 7600 | MTFDLAL1T6THS | DCR2M | VJXKC | 1.0.0 | 1.6 TB | Cache, Capacity |
| NVMe | PCIe | 2.5 | Mixed Use | Micron | 7600 | MTFDLAL3T2THS | J9TN7 | VJXKC | 1.0.0 | 3.2 TB | Cache, Capacity |
| NVMe | PCIe | 2.5 | Mixed Use | Samsung | PM9D5a | MZWL6800H | 53M2M | X5N7N | 1.0.1 | 800 GB | Cache, Capacity |
| NVMe | PCIe | 2.5 | Mixed Use | Samsung | PM9D5a | MZWL61T6H | 2M4HN | X5N7N | 1.0.1 | 1.6 TB | Cache, Capacity |
| NVMe | PCIe | 2.5 | Mixed Use | Samsung | PM9D5a | MZWL63T2H | 85GHX | X5N7N | 1.0.1 | 3.2 TB | Cache, Capacity |
| NVMe | PCIe | 2.5 | Mixed Use | Samsung | PM9D5a | MZWL66T4H | D68YV | X5N7N | 1.0.1 | 6.4 TB | Cache, Capacity |
| NVMe | PCIe | 2.5 | Mixed Use | Micron | 9550 | MTFDLAL3T2THB | D0GXJ | 4WN4V | 1.1.0 | 3.2 TB | Cache, Capacity |
| NVMe | PCIe | 2.5 | Mixed Use | Micron | 9550 | MTFDLAL6T4THB | WC68V | 4WN4V | 1.1.0 | 6.4 TB | Cache, Capacity |
NVMe 2.5" Capacity Only
| Type | Drive Type | Form Factor | Endurance | Vendor | Series | Model | Device Part Number (P/N) | Firmware Software Bundle | Firmware Minimum Supported Version | Capacity | Use |
|---|---|---|---|---|---|---|---|---|---|---|---|
| NVMe | PCIe | 2.5 | Read Intensive | Toshiba | CD5 | KCD5XLUG960G | DRC9H | T79D5 | 1.2.0 | 960 GB | Capacity |
| NVMe | PCIe | 2.5 | Read Intensive | Toshiba | CD5 | KCD5XLUG3T84 | 17C57 | T79D5 | 1.2.0 | 3.84 TB | Capacity |
| NVMe | PCIe | 2.5 | Read Intensive | Intel | P4510 | SSDPE2KX040T8T | 5GMK0 | 7VJGR | VDV1DP25 | 4 TB | Capacity |
| NVMe | PCIe | 2.5 | Read Intensive | KIOXIA | DELL EXPRESS FLASH KIOXIA CM6 RI 1.92TB U.2 FIPS | KCM6FRUL1T92 | TXP72 | WJD95 | 3.1.7 | 1.92 TB | Capacity |
| NVMe | PCIe | 2.5 | Read Intensive | Intel | P5500 | SSDPF2KX019T9T | WPP9G | CGXH7 | 1.2.4 | 1.92 TB | Capacity |
| NVMe | PCIe | 2.5 | Read Intensive | Intel | P5500 | SSDPF2KX038T9T | KRT3G | CGXH7 | 1.2.4 | 3.84 TB | Capacity |
| NVMe | PCIe | 2.5 | Read Intensive | Intel | P5500 | SSDPF2KX076T9T | RNN67 | CGXH7 | 1.2.4 | 7.68 TB | Capacity |
| NVMe | PCIe | 2.5 | Read Intensive | Samsung | PM1733 V2 | MZWLR3T8HBLSAD3 | G5N65 | 5V3P7 | 2.5.0 | 3.84 TB | Capacity |
| NVMe | PCIe | 2.5 | Read Intensive | Samsung | PM1733 V2 | MZWLR7T6HALAAD3 | DX74Y | 5V3P7 | 2.5.0 | 7.68 TB | Capacity |
| NVMe | PCIe | 2.5 | Read Intensive | Samsung | PM1733 V2 | MZWLR15THALAAD3 | 182NW | 5V3P7 | 2.5.0 | 15.36 TB | Capacity |
| NVMe | PCIe | 2.5 | Read Intensive | Samsung | PM1733a | MZWLR1T9HCJRAD3 | 8PMRM | 71KRG | 1.2.0 | 1.92 TB | Capacity |
| NVMe | PCIe | 2.5 | Read Intensive | Samsung | PM1733a | MZWLR3T8HCLSAD3 | RJKM5 | 71KRG | 1.2.0 | 3.84 TB | Capacity |
| NVMe | PCIe | 2.5 | Read Intensive | Samsung | PM1733a | MZWLR7T6HBLAAD3 | R1J8J | 71KRG | 1.2.0 | 7.68 TB | Capacity |
| NVMe | PCIe | 2.5 | Read Intensive | Samsung | PM1733a | MZWLR15THBLAAD3 | D4CJG | 71KRG | 1.2.0 | 15.36 TB | Capacity |
| NVMe | PCIe | 2.5 | Read Intensive | Kioxia | CM6 | KCM6XRUL1T92 | N0VK0 | GMM6V | 2.2.2 | 1.92 TB | Capacity |
| NVMe | PCIe | 2.5 | Read Intensive | Kioxia | CM6 | KCM6XRUL3T84 | 8W2G5 | GMM6V | 2.2.2 | 3.84 TB | Capacity |
| NVMe | PCIe | 2.5 | Read Intensive | Kioxia | CM6 | KCM6XRUL7T68 | VD0JX | GMM6V | 2.2.2 | 7.68 TB | Capacity |
| NVMe | PCIe | 2.5 | Read Intensive | Kioxia | CM6 | KCM6XRUL15T3 | J91CR | GMM6V | 2.2.2 | 15.36 TB | Capacity |
| NVMe | PCIe | 2.5 | Read Intensive | Intel | Arbordale Plus RR P5520 | SSDPF2KX019T1E | 0HVC7 | 12W9R | 1.5.0 | 1.92 TB | Capacity |
| NVMe | PCIe | 2.5 | Read Intensive | Intel | Arbordale Plus RR P5520 | SSDPF2KX038T1E | 77MRY | 12W9R | 1.5.0 | 3.84 TB | Capacity |
| NVMe | PCIe | 2.5 | Read Intensive | Intel | Arbordale Plus RR P5520 | SSDPF2KX076T1E | 90M2J | 12W9R | 1.5.0 | 7.68 TB | Capacity |
| NVMe | PCIe | 2.5 | Read Intensive | Intel | Arbordale Plus R P5316 | SSDPF2NV307TZ | 4KCVT | 4XT8T | 1.6.0 | 30.72 TB | Capacity |
| NVMe | PCIe | 2.5 | Mixed Use | Kioxia | CM7 | KCM7XRUG1T92 | M8YW0 | K1JTM | 2.0.3 | 1.92 TB | Capacity |
| NVMe | PCIe | 2.5 | Mixed Use | Kioxia | CM7 | KCM7XRUG3T84 | XHYGF | K1JTM | 2.0.3 | 3.84 TB | Capacity |
| NVMe | PCIe | 2.5 | Mixed Use | Kioxia | CM7 | KCM7XRUG7T68 | VV2M7 | K1JTM | 2.0.3 | 7.68 TB | Capacity |
| NVMe | PCIe | 2.5 | Mixed Use | Kioxia | CM7 | KCM7XRUG15T3 | DX2PD | K1JTM | 2.0.3 | 15.36 TB | Capacity |
| NVMe | PCIe | 2.5 | Read Intensive | Kioxia | CD7 | KCD7XRUG7T68 | 0RD61 | K6597 | 2.0.1 | 7.68 TB | Capacity |
| NVMe | PCIe | 2.5 | Read Intensive | Kioxia | CD8 | KCD8XRUG1T92 | NNKCT | HV8P1 | 2.0.1 | 1.92 TB | Capacity |
| NVMe | PCIe | 2.5 | Read Intensive | Kioxia | CD8 | KCD8XRUG3T84 | N1MK1 | HV8P1 | 2.0.1 | 3.84 TB | Capacity |
| NVMe | PCIe | 2.5 | Read Intensive | Kioxia | CD8 | KCD8XRUG7T68 | MXD8J | HV8P1 | 2.0.1 | 7.68 TB | Capacity |
| NVMe | PCIe | 2.5 | Read Intensive | Hynix | PS1010 | HFS1T9GEJVX171N | 7GGK1 | VNYK2 | 1.3.0 | 1.92 TB | Capacity |
| NVMe | PCIe | 2.5 | Read Intensive | Hynix | PS1010 | HFS3T8GEJVX171N | J4TDK | VNYK2 | 1.3.0 | 3.84 TB | Capacity |
| NVMe | PCIe | 2.5 | Read Intensive | Hynix | PS1010 | HFS7T6GEJVX171N | 2533N | VNYK2 | 1.3.0 | 7.68 TB | Capacity |
| NVMe | PCIe | 2.5 | Read Intensive | Hynix | PS1010 | HFS15T3EJVX171N | 8TY8G | VNYK2 | 1.3.0 | 15.36 TB | Capacity |
| NVMe | PCIe | 2.5 | Read Intensive | Hynix | PE8110 | HFS7T6GEETX099N | RG3T2 | TDGKY | 1.1.0 | 7.68 TB | Capacity |
| NVMe | PCIe | 2.5 | Read Intensive | Samsung | PM1743 | MZWLO3T8HCLS-00AD3 | 9GXVF | V7V0K | 1.0.0 | 3.84 TB | Capacity |
| NVMe | PCIe | 2.5 | Read Intensive | Samsung | PM1743 | MZWLO7T6HBLA-00AD3 | DNPR4 | V7V0K | 1.0.0 | 7.68 TB | Capacity |
| NVMe | PCIe | 2.5 | Read Intensive | Samsung | PM9D3a | MZWL6960HFJA-00AD3 | 71Y2J | X5N7N | 1.0.1 | 960 GB | Capacity |
| NVMe | PCIe | 2.5 | Read Intensive | Samsung | PM9D3a | MZVL61T9HBL1-00AD3 | NYPRM | FTVJG | 1.0.1 | 1.92 TB | Capacity |
| NVMe | PCIe | 2.5 | Read Intensive | Samsung | PM9D3a | MZWL63T8HFLT-00AD3 | 2H60T | X5N7N | 1.0.1 | 3.84 TB | Capacity |
| NVMe | PCIe | 2.5 | Read Intensive | Samsung | PM9D3a | MZWL67T6HBLC-00AD3 | VYT6X | X5N7N | 1.0.1 | 7.68 TB | Capacity |
| NVMe | PCIe | 2.5 | Read Intensive | Micron | 7600 | MTFDLAL1T9THG | N6RN7 | VJXKC | 1.0.0 | 1.92 TB | Capacity |
| NVMe | PCIe | 2.5 | Read Intensive | Micron | 7600 | MTFDLAL3T8THG | 7X0XC | VJXKC | 1.0.0 | 3.84 TB | Capacity |
| NVMe | PCIe | 2.5 | Read Intensive | Micron | 7600 | MTFDLAL7T6THG | Y4GJR | VJXKC | 1.0.0 | 7.68 TB | Capacity |
| NVMe | PCIe | 2.5 | Read Intensive | Micron | 7600 | MTFDLAL15T3THG | 5J26R | VJXKC | 1.0.0 | 15.36 TB | Capacity |
| NVMe | PCIe | 2.5 | Read Intensive | Micron | 9550 | MTFDLAL3T8THA | PFV73 | 4WN4V | 1.1.0 | 3.84 TB | Capacity |
| NVMe | PCIe | 2.5 | Read Intensive | Micron | 9550 | MTFDLAL7T6THA | 39JW6 | 4WN4V | 1.1.0 | 7.68 TB | Capacity |
| NVMe | PCIe | 2.5 | Read Intensive | Micron | 9550 | MTFDLAL15T3THA | R3GD7 | 4WN4V | 1.1.0 | 15.36 TB | Capacity |
NVMe Add-in Cards
| Type | Drive Type | Form Factor | Endurance | Vendor | Series | Model | Device Part Number (P/N) | Firmware Software Bundle | Firmware Minimum Supported Version | Capacity | Use |
|---|---|---|---|---|---|---|---|---|---|---|---|
| NVMe | PCIe | AIC | Mixed Use | Samsung | PM1725A, Dell Express Flash NVMe 1.6TB HHHL AIC | MZPLL1T6HEHP-000D3 | 06V6M | 34C36 | 1.2.1 | 1.6 TB | Cache, Capacity |
| NVMe | PCIe | AIC | Mixed Use | Samsung | PM1725A, Dell Express Flash NVMe 3.2TB HHHL AIC | MZPLL3T2HMLS-00003 | C2KKH | 34C36 | 1.2.1 | 3.2 TB | Cache, Capacity |
| NVMe | PCIe | AIC | Mixed Use | Samsung | PM1725A, Dell Express Flash NVMe 6.4TB HHHL AIC | MZPLL6T4HMLS-000D3 | 604N5 | 34C36 | 1.2.1 | 6.4 TB | Cache, Capacity |
| NVMe | PCIe | AIC | Mixed Use | Samsung | PM1725b, Dell Express Flash NVMe 1.6TB (MU) HHHL AIC | MZPLL1T6HAJQ-000D3 | FTX2R | NC07Y | 1.2.2 | 1.6 TB | Cache, Capacity |
| NVMe | PCIe | AIC | Mixed Use | Samsung | PM1725b, Dell Express Flash NVMe 3.2TB (MU) HHHL AIC | MZPLL3T2HAJQ-00005 | 73KJ7 | NC07Y | 1.2.2 | 3.2 TB | Cache, Capacity |
| NVMe | PCIe | AIC | Mixed Use | Samsung | PM1725b, Dell Express Flash NVMe 6.4TB (MU) HHHL AIC | MZPLL6T4HMLA-000D3 | FW2K0 | NC07Y | 1.2.2 | 6.4 TB | Cache, Capacity |
| NVMe | PCIe | AIC | Mixed Use | Samsung | PM1735 SP 3WPD, SSD, NVMe, HHHL, 512e, ISE | MZPLJ1T6HBJRAD3 | Y7D7D | 5CM3G | 2.5.0 | 1.6 TB | Cache, Capacity |
| NVMe | PCIe | AIC | Mixed Use | Samsung | PM1735 SP 3WPD, SSD, NVMe, HHHL, 512e, ISE | MZPLJ6T4HALAAD3 | 91FXC | 5CM3G | 2.5.0 | 6.4 TB | Cache, Capacity |
2.2 - Azure Local Support Matrix for 16G (Dell 2603)
NOTE
SBE package 4.2.2512.xxxx and newer will only support Azure Local solution versions 12.*.1001.* or 12.*.1002.* (HCI OS 24H2) and newer.
Dell will support the use of SBE package 4.2.2509.xxxx on Azure Local instances running version 11.* (HCI OS 23H2) until April 2026. Dell recommends that instances running version 11.* be upgraded to 12.* as soon as possible to remain in a supported state.
Supported Platforms
| Model | Supported Operating System |
|---|---|
| AX-760 | Windows Server 2022 Datacenter Windows Server 2025 Datacenter Azure Stack HCI-24H2 |
| AX-660 | Windows Server 2025 Datacenter Azure Stack HCI-24H2 |
| APEX MC-660 | Azure Stack HCI-24H2 |
| APEX MC-760 | Azure Stack HCI-24H2 |
Base Components
| Component | Type | Software Bundle | Minimum Supported Version | Supported Platforms | Supported OS |
|---|---|---|---|---|---|
| BIOS | Firmware DUP | 457WM | 2.9.4 | AX-660 AX-760 APEX MC-660 APEX MC-760 | NA |
| Chipset driver for 16G Intel platforms | Driver DUP | R40PW | 10.1.19928.8615 | AX-660 AX-760 APEX MC-660 APEX MC-760 | Windows Server 2022 Datacenter Windows Server 2025 Datacenter Azure Stack HCI-24H2 |
| iDRAC9 with Lifecycle Controller | Firmware DUP | 924YT | 7.30.10.50 | AX-660 AX-760 APEX MC-660 APEX MC-760 | NA |
| Expander Storage Backplane | Firmware DUP | J9JW2 | 1.61 | AX-760 APEX MC-760 | NA |
| NVMe Switch Storage Backplane | Firmware DUP | R39FM | 3.33 | AX-760 APEX MC-760 | NA |
| Non-expander Storage Backplane | Firmware DUP | 58MWX | 7.20 | AX-760 APEX MC-760 | NA |
| Non-expander Storage Backplane | Firmware DUP | 9T7YG | 7.20 | AX-660 APEX MC-660 | NA |
| iDRAC Service Module | Firmware DUP | 238XW | 6.1.0.0 | AX-660 AX-760 APEX MC-660 APEX MC-760 | NA |
| CPLD | Firmware DUP | XJG0V | 1.2.7 | AX-660 AX-760 APEX MC-660 APEX MC-760 | NA |
Network Adapters
| Component | Part Number | SDDC Advanced Qualification | RDMA Protocol | Firmware Software Bundle | Firmware Minimum Supported Version | Driver Software Bundle | Driver Minimum Supported Version | Supported OS | Supported Platforms |
|---|---|---|---|---|---|---|---|---|---|
| Broadcom 5720 Dual Port 1 GbE Network LOM Mezz Card | 5NN70 | Management | N/A | 32W7Y | 23.61.3 | WYPPJ | 236.1.155.0 | Windows Server 2022 Datacenter Windows Server 2025 Datacenter Azure Stack HCI-24H2 | AX-660 AX-760 APEX MC-660 APEX MC-760 | CV5V6 |
| Broadcom 57416 Dual Port 10Gb, Base-T, PCIe Adapter, Full Height | 3TM39 | Management Compute (Standard) | RoCEv2 | MJ0HT | 36.11.56.00 | 78X9T | 36.11.52.00 | Windows Server 2025 Datacenter Azure Stack HCI-24H2 | AX-660 AX-760 APEX MC-660 APEX MC-760 |
| Broadcom 57416 Dual Port 10GbE BASE-T Adapter, PCIe Low Profile | NC5VD | ||||||||
| Broadcom 57416 Dual Port 10GbE BASE-T Adapter, OCP NIC 3.0 | RN1M5 | ||||||||
| Broadcom 57504 Quad Port 10/25GbE, SFP28 Adapter, OCP NIC 3.0 | 3Y64D | Management Compute (Premium) Storage (Premium) | RoCEv2 | MJ0HT | 36.11.56.00 | 78X9T | 36.11.52.00 | Windows Server 2025 Datacenter Azure Stack HCI-24H2 | AX-660 AX-760 APEX MC-660 APEX MC-760 |
| Broadcom 57504 Quad Port 10/25GbE SFP28 Adapter, PCIe FH | J3D14 | ||||||||
| Emulex LPe36002 Dual Port Fibre Channel 64Gb Adapter, PCIe LP | 39T9X | N/A | N/A | 15J5T | 03.10.12 | 8XGGG | 12.34.10 | Azure Stack HCI-24H2 | AX-660 AX-760 |
| Emulex LightPulse LPe35002-M2 2-Port 32Gb Fibre Channel Adapter LP | 5KW3M | ||||||||
| Emulex LightPulse LPe35002-M2 2-Port 32Gb Fibre Channel Adapter FH | CGT2C | ||||||||
| Emulex LPe36002 Dual Port Fibre Channel 64Gb Adapter, PCIe FH | D1XM2 | ||||||||
| Intel E810-XXV Dual Port 25GbE SFP28 Adapter, PCIe LP | 6J1N1 | Management Compute (Premium) Storage (Premium) | iWARP,RoCEv2 | N11TD | 24.0.5 | PH5GK | 24.0.0 | Windows Server 2022 Datacenter Windows Server 2025 Datacenter Azure Stack HCI-24H2 | AX-660 AX-760 APEX MC-660 APEX MC-760 |
| Intel E810-CQDA2 Dual Port 100GbE QSFP28 Adapter, PCIe FH | 85F8F | ||||||||
| Intel E810-XXV Dual Port 25GbE SFP28 Adapter, PCIe FH | CD16M | ||||||||
| Intel E810-CQDA2 Dual Port 100GbE QSFP28 Adapter, PCIe LP | DWNRF | ||||||||
| Intel E810-XXVDA2 Dual Port 1/10/25GbE SFP28 Adapter, OCP NIC 3.0 | PWH3C | ||||||||
| Intel E810-XXVDA4 Quad Port 1/10/25GbE SFP28 Adapter, PCIe FH | VK88G | ||||||||
| Intel E810-XXVDA4 Quad Port 1/10/25GbE SFP28 Adapter, OCP NIC 3.0 | Y4VV5 | ||||||||
| Mellanox ConnectX-6 Dx Dual Port 100GbE QSFP56 PCIe Adapter, FH | 8P2T2 | Management Compute (Premium) Storage (Premium) | RoCEv2 | 2CMVW | 22.41.10.00 | G6M58 | 24.4.26429 | Windows Server 2022 Datacenter Windows Server 2025 Datacenter Azure Stack HCI-24H2 | AX-660 AX-760 APEX MC-660 APEX MC-760 |
| Mellanox ConnectX-6 Dx Dual Port 100GbE QSFP56 PCIe Adapter, LP | F6FXM | ||||||||
| Nvidia ConnectX-6 Lx Dual Port 10/25GbE SFP28 Adapter, PCIe LP | 6XJXK | Management Compute (Premium) Storage (Premium) | RoCEv2 | 1H4PM | 26.41.10.00 | G6M58 | 24.4.26429 | Windows Server 2022 Datacenter Windows Server 2025 Datacenter Azure Stack HCI-24H2 | AX-660 AX-760 APEX MC-660 APEX MC-760 |
| Nvidia ConnectX-6 Lx Dual Port 10/25GbE SFP28 Adapter, OCP NIC 3.0 | DN78C | ||||||||
| Nvidia ConnectX-6 Lx Dual Port 10/25GbE SFP28 Adapter, PCIe FH | R5WK9 | Management Compute (Premium) Storage (Premium) | RoCEv2 | 1H4PM | 26.41.10.00 | G6M58 | 24.4.26429 | Windows Server 2022 Datacenter Windows Server 2025 Datacenter Azure Stack HCI-24H2 | AX-760 APEX MC-760 |
| Marvell QLogic 2x32Gb QLE2772 FC HBA LP | JJW53 | N/A | N/A | 3XDWV | 17.10.04 | RF21G | 37.10.04 | Azure Stack HCI-24H2 | AX-660 AX-760 |
| Marvell QLogic 2x32Gb QLE2772 FC HBA FH | YM4FH | ||||||||
| Marvell QLogic 2x64Gb QLE2872C FC HBA LP | W72F2 | N/A | N/A | XMXP3 | 17.10.04 | RF21G | 37.10.04 | Azure Stack HCI-24H2 | AX-660 AX-760 |
| Marvell QLogic 2x64Gb QLE2872C FC HBA FH | X29W4 |
Network Switches
NOTE
A list of supported Network Switch models along with the supported firmware versions can be found here, Physical network requirements for Azure Local.PowerFlex
| Component | PowerFlex SDC Driver Version | Validated Platforms | Supported OS | Download Link | Extracted Package Location |
|---|---|---|---|---|---|
| PowerFlex Storage Data Client (SDC) | 4.5.2.2 | AX-660 AX-760 | Azure Stack HCI-24H2 | https://dl.dell.com/downloads/41X88_PowerFlex-Software-4.5.5.2-SDC-Driver.zip | PowerFlex_4.5.5200.104_Windows_SDC: EMC-ScaleIO-sdc-4.5-5200.104.msi |
| PowerFlex Storage Data Client (SDC) | 5.0 | AX-660 AX-760 | Azure Stack HCI-24H2 | https://dl.dell.com/downloads/09J62_PowerFlex-Software-5.0.0.0-SDC-Driver.zip | PowerFlex_5.0.0.941_Windows_SDC: EMC-ScaleIO-sdc-5.0-0.941.msi |
GPUs
| GPU Model | Vendor | Description | Part Number | Firmware version | Driver Version | GPU-P capable | Supported Platform | Supported OS |
|---|---|---|---|---|---|---|---|---|
| A16 | NVIDIA | NVIDIA Ampere A16, PCIe, 250W, 64GB Passive, Double Wide, Full Height GPU,V2 | D1P1T | 94.07.54.00.45 | 553.62 | Yes | AX-760 APEX MC-760 | Windows Server 2025 Datacenter Azure Stack HCI-24H2 |
| A2 | NVIDIA | NVIDIA Ampere A2, PCIe, 60W, 16GB Passive, Single Wide, Low Profile GPU, V2 | H98K0 | 94.07.5B.00.55 | 553.62 | Yes | AX-660 AX-760 APEX MC-660 APEX MC-760 | Windows Server 2025 Datacenter Azure Stack HCI-24H2 |
| A2 | NVIDIA | NVIDIA Ampere A2, PCIe, 60W, 16GB Passive, Single Wide, Full Height GPU, V2 | MG5JX | 94.07.5B.00.55 | 553.62 | Yes | AX-660 AX-760 APEX MC-660 APEX MC-760 | Windows Server 2025 Datacenter Azure Stack HCI-24H2 |
| A40 | NVIDIA | NVIDIA Ampere A40, PCIe, 300W, 48GB Passive, Double Wide, Full Height GPU | W6GX6 | 94.02.5C.00.0F | 553.62 | Yes | AX-760 APEX MC-760 | Windows Server 2025 Datacenter Azure Stack HCI-24H2 |
| L4 | NVIDIA | NVIDIA L4, PCIe, 72W, 24GB Passive, Single Wide Full Height GPU | NG3PY | 95.04.29.00.06 | 553.62 | Yes | AX-660 AX-760 APEX MC-660 APEX MC-760 | Windows Server 2025 Datacenter Azure Stack HCI-24H2 |
| L4 | NVIDIA | NVIDIA L4, PCIe, 72W, 24GB Passive, Single Wide Low Profile GPU | V9XT2 | 95.04.29.00.06 | 553.62 | Yes | AX-660 AX-760 APEX MC-660 APEX MC-760 | Windows Server 2025 Datacenter Azure Stack HCI-24H2 |
| L40 | NVIDIA | NVIDIA Ampere L40, PCIe, 300W, 48GB Passive, Double Wide, Full Height, Full Length, GPU with cable | VHNWT | 95.02.39.00.01 | 553.62 | Yes | AX-760 APEX MC-760 | Windows Server 2025 Datacenter Azure Stack HCI-24H2 |
| L40S | NVIDIA | NVIDIA Ampere L40S, PCIe, 350W, 48GB Passive, Double Wide, Full Height, Full Length, GPU with cable | 7WK28 | 95.02.66.00.02 | 553.62 | Yes | AX-760 APEX MC-760 | Windows Server 2025 Datacenter Azure Stack HCI-24H2 |
NOTE
Dell update packages are not available for GPU cards, please download the latest driver version from NVIDIA driver download page.Storage Controllers
| Component | Dell Part Number | Firmware Software Bundle | Firmware Minimum Supported Version | Driver Software Bundle | Driver Minimum Supported Version | Supported Platforms | Supported OS |
|---|---|---|---|---|---|---|---|
| BOSS-N1 | WW56V | C6MVR | 2.1.13.2037 | Inbox | Inbox | AX-660 AX-760 APEX MC-660 APEX MC-760 | Windows Server 2022 Datacenter Windows Server 2025 Datacenter Azure Stack HCI-24H2 |
| HBA355i | K6MCJ | CG0P9 | 33.15.00.00 | HDH8G | 2.61.74.00 | AX-660 AX-760 APEX MC-660 APEX MC-760 | Windows Server 2025 Datacenter Azure Stack HCI-24H2 |
| HBA355i | K6MCJ | CG0P9 | 33.15.00.00 | R31NP | 2.61.74.00 | AX-660 AX-760 APEX MC-660 APEX MC-760 | Windows Server 2022 Datacenter |
SATA M.2 SSD Boot Only
| Type | Drive Type | Form Factor | Endurance | Vendor | Series | Model | Device Part Number (P/N) | Firmware Software Bundle | Firmware Minimum Supported Version | Capacity | Use |
|---|---|---|---|---|---|---|---|---|---|---|---|
| NVMe | PCIe | M.2 | Read Intensive | Micron | 7400 | MTFDKBA960TDZ | PRV6C | N71F4 | 1.6.0 | 960GB | Boot |
| NVMe | PCIe | M.2 | Read Intensive | Micron | 7400 | MTFDKBG960TDZ | 0V8F7 | N71F4 | 1.6.0 | 960GB | Boot |
| NVMe | PCIe | M.2 | Read Intensive | Hynix | PE8010 | HFS960GDC8X099N | 21GXV | R2TTT | 1.3.0 | 960GB | Boot |
| NVMe | PCIe | M.2 | Read Intensive | Hynix | PE9010 | HFS960GEJ8X167N | 4H05X | YJG7C | 1.3.1 | 960GB | Boot |
| NVMe | PCIe | M.2 | Read Intensive | Micron | 7450 | MTFDKBAXXXTFR | PH7J6 | JHKXR | 1.4.0 | 960GB | Boot |
| NVMe | PCIe | M.2 | Read Intensive | Hynix | PE9010 | HFS960GDJ8X167N | XN5KG | 8X8YR | 1.2.1 | 960GB | Boot |
| NVMe | PCIe | M.2 | Read Intensive | Samsung | PM9D3a | MZVL6480HFLUAD3 | C82V9 | FTVJG | 1.0.1 | 480 GB | Boot |
| NVMe | PCIe | M.2 | Read Intensive | Samsung | PM9D3a | MZVL6960HFLBAD3 | 8M3JN | FTVJG | 1.0.1 | 960 GB | Boot |
SAS 3.5" HDD Capacity Only
| Type | Drive Type | Form Factor | Endurance | Vendor | Series | Model | Device Part Number (P/N) | Firmware Software Bundle | Firmware Minimum Supported Version | Capacity | Use |
|---|---|---|---|---|---|---|---|---|---|---|---|
| HDD | SAS | 3.5 | NA | HGST | Vela-A | HUS726T4TALS200 | NT1X2 | J5K8G | PU09 | 4 TB | Capacity |
| HDD | SAS | 3.5 | NA | Toshiba | MG10 | MG10SDA400NY | 9VN79 | 99TKP | EP02 | 4 TB | Capacity |
| HDD | SAS | 3.5 | NA | HGST | Vela-AP | HUS728T8TAL5200 | 44YFV | 8GM6M | RS09 | 8 TB | Capacity |
| HDD | SAS | 3.5 | NA | Toshiba | MG06 | MG06SCA800EY | FV725 | 4G5GY | EH0D | 8 TB | Capacity |
| HDD | SAS | 3.5 | NA | HGST | Leo-A He12 | HUH721212AL5200 | 9HXK6 | 04PM5 | NS11 | 12 TB | Capacity |
| HDD | SAS | 3.5 | NA | WD | Paris-C | WUH721816AL5200 | VF206 | GY6MD | US09 | 16 TB | Capacity |
| HDD | SAS | 3.5 | NA | Seagate | Cimarron BP | ST4000NM019B | 10N7R | 3P5N0 | LW0B | 4 TB | Capacity |
| HDD | SAS | 3.5 | NA | Seagate | Cimarron BP | ST8000NM024B | C5HD0 | NM6GP | LS0C | 8 TB | Capacity |
| HDD | SAS | 3.5 | NA | Toshiba | MG08SD | MG08SDA400NY | FN2YX | GTG81 | EK06 | 4 TB | Capacity |
| HDD | SAS | 3.5 | NA | Seagate | Evans BP | ST12000NM006J | M1C0T | XF65R | PSLG | 12 TB | Capacity |
| HDD | SAS | 3.5 | NA | Seagate | Evans BP | ST16000NM006J | 41DXR | XF65R | PSLG | 16 TB | Capacity |
| HDD | SAS | 3.5 | NA | Toshiba | MG08SD | MG08SDA800EY | NJWMG | F95CX | EL02 | 8 TB | Capacity |
| HDD | SAS | 3.5 | Read Intensive | Seagate | LongsPeak | ST20000NM004D | R3G03 | WCTTD | GS09 | 20 TB | Capacity |
| HDD | SAS | 3.5 | NA | Toshiba | MG10SD | MG10SDA800EY | VJDMM | 99TKP | EP02 | 8 TB | Capacity |
| HDD | SAS | 3.5 | NA | Seagate | CimarronBP(EWP) | DL4000NM019B | F7DTR | M7PKX | LBW4 | 4 TB | Capacity |
| HDD | SAS | 3.5 | NA | Toshiba | MG09 | MG09SCA12TEY | 0N96X | 20Y02 | EM06 | 12 TB | Capacity |
| HDD | SAS | 3.5 | NA | Seagate | Summit | ST12000NM007H | FN7VR | 3VY0D | SWS9 | 12 TB | Capacity |
| HDD | SAS | 3.5 | NA | Toshiba | MG09 | MG09SCA16TEY | MXC46 | 20Y02 | EM06 | 16 TB | Capacity |
| HDD | SAS | 3.5 | NA | Seagate | Summit | ST16000NM007H | R0G8W | C50CR | SYS9 | 16 TB | Capacity |
| HDD | SAS | 3.5 | NA | Toshiba | MG10 | MG10SCA20TEY | NT45N | 0H3CX | EN04 | 20 TB | Capacity |
| HDD | SAS | 3.5 | NA | WD | Paris-D PR2 | WUH722020BL5200 | 1D4CR | XRFX3 | VS19 | 20 TB | Capacity |
| HDD | SAS | 3.5 | NA | Seagate | Summit | ST20000NM007H | R5KP7 | C50CR | SYS9 | 20 TB | Capacity |
| HDD | SAS | 3.5 | NA | WD | London DP | WUH722420AL5200 | MTTCF | 444T3 | YS04 | 20 TB | Capacity |
| HDD | SAS | 3.5 | NA | WD | Paris-CP | WUH722012CL5200 | 849H4 | VK0PK | AS05 | 12 TB | Capacity |
| HDD | SAS | 3.5 | NA | WD | Paris-CP | WUH722016CL5200 | H8HN1 | VK0PK | AS05 | 16 TB | Capacity |
| HDD | SAS | 3.5 | NA | Toshiba | MG11SC | MG11SCA16TEY | GGWNH | 9GW4N | ES02 | 16 TB | Capacity |
| HDD | SAS | 3.5 | NA | Toshiba | MG11SC | MG11SCA20TEY | 2FX1T | 9GW4N | ES02 | 20 TB | Capacity |
SATA 2.5" SSD Capacity Only
| Type | Drive Type | Form Factor | Endurance | Vendor | Series | Model | Device Part Number (P/N) | Firmware Software Bundle | Firmware Minimum Supported Version | Capacity | Use |
|---|---|---|---|---|---|---|---|---|---|---|---|
| SSD | SATA | 2.5 | Read Intensive | Intel | S4520 | SSDSC2KB019TZR | 6J65H | VJPKG | DL7C | 1.92TB | Capacity |
| SSD | SATA | 2.5 | Read Intensive | SK Hynix | SE5110 | HFS1T9G3H2X069N | 962FP | 7XTPF | DZ03 | 1.92TB | Capacity |
| SSD | SATA | 2.5 | Read Intensive | Samsung | PM883a | MZ7LH1T9HALT0D3 | 9F9Y6 | 3GHD6 | HG61 | 1.92TB | Capacity |
| SSD | SATA | 2.5 | Read Intensive | Samsung | PM893 | MZ7L31T9HBLTAD3 | 0KYP4 | T3HX9 | HJ64 | 1.92TB | Capacity |
| SSD | SATA | 2.5 | Read Intensive | Samsung | PM893a | MZ7L31T9HELAAD3 | PTD53 | D5D3W | HL58 | 1.92TB | Capacity |
| SSD | SATA | 2.5 | Read Intensive | Micron | 5300 | MTFDDAK1T9TDS | GYGVV | KT63Y | J008 | 1.92TB | Capacity |
| SSD | SATA | 2.5 | Read Intensive | Micron | 5400 | MTFDDAK1T9TGA-1B | KXNX5 | RJ0WY | K003 | 1.92TB | Capacity |
| SSD | SATA | 2.5 | Read Intensive | Intel | S4520 | SSDSC2KB038TZR | KM4C4 | VJPKG | DL7C | 3.84TB | Capacity |
| SSD | SATA | 2.5 | Read Intensive | SK Hynix | SE5110 | HFS3T8G3H2X069N | 3GDK0 | 7XTPF | DZ03 | 3.84TB | Capacity |
| SSD | SATA | 2.5 | Read Intensive | Samsung | PM883a | MZ7LH3T8HALT0D3 | 5TVXD | 3GHD6 | HG61 | 3.84TB | Capacity |
| SSD | SATA | 2.5 | Read Intensive | Samsung | PM893 | MZ7L33T8HBLTAD3 | GCN5W | T3HX9 | HJ64 | 3.84TB | Capacity |
| SSD | SATA | 2.5 | Read Intensive | Samsung | PM893a | MZ7L33T8HELAAD3 | D7V89 | D5D3W | HL58 | 3.84TB | Capacity |
| SSD | SATA | 2.5 | Read Intensive | Micron | 5300 | MTFDDAK3T8TDT | 4H1RX | R9YDC | J408 | 3.84TB | Capacity |
| SSD | SATA | 2.5 | Read Intensive | Micron | 5400 | MTFDDAK3T8TGA-1B | CHF46 | JTW3W | K403 | 3.84TB | Capacity |
| SSD | SATA | 2.5 | Mixed Use | Intel | S4620 | SSDSC2KG019TZR | 6XW3M | VJPKG | DL7C | 1.92TB | Capacity |
| SSD | SATA | 2.5 | Mixed Use | SK Hynix | SE5130 | HFS1T9G3E2X149N | HCR09 | 4T2FN | DG00 | 1.92TB | Capacity |
| SSD | SATA | 2.5 | Mixed Use | SK Hynix | SE5031 | HFS1T9G32FEH-BA1 | GKTF1 | 2CY65 | DD02 | 1.92TB | Capacity |
| SSD | SATA | 2.5 | Mixed Use | Samsung | PM897a | MZ7L31T9HENAAD3 | GR4WN | V5XNY | HK58 | 1.92TB | Capacity |
| SSD | SATA | 2.5 | Mixed Use | Samsung | PM897 | MZ7L31T9HBNAAD3 | RRR7M | VRG4Y | HH64 | 1.92TB | Capacity |
| SSD | SATA | 2.5 | Mixed Use | Micron | 5300 | MTFDDAK1T9TDT | MMCDY | KT63Y | J008 | 1.92TB | Capacity |
| SSD | SATA | 2.5 | Mixed Use | Micron | 5400 | MTFDDAK1T9TGB-1B | XRXX2 | RJ0WY | K003 | 1.92TB | Capacity |
SAS 2.5" SSD Cache or Capacity
| Type | Drive Type | Form Factor | Endurance | Vendor | Series | Model | Device Part Number (P/N) | Firmware Software Bundle | Firmware Minimum Supported Version | Capacity | Use |
|---|---|---|---|---|---|---|---|---|---|---|---|
| SSD | SAS | 2.5 | Mixed Use | Samsung | PM1655 | MZILG800HCHQAD3 | 3CHC8 | 7MTXM | DWG9 | 800 GB | Cache,Capacity |
| SSD | SAS | 2.5 | Mixed Use | Samsung | PM1655 | MZILG1T6HCJRAD3 | 5RJND | 7MTXM | DWG9 | 1.6 TB | Cache,Capacity |
| SSD | SAS | 2.5 | Mixed Use | Kioxia | PM7 | KPM7XVUG1T60 | 4TRHM | T21WT | C10E | 1.6 TB | Cache,Capacity |
| SSD | SAS | 2.5 | Mixed Use | Kioxia | PM6 | KPM6XVUG800G | NNGV4 | NGPR2 | BA48 | 800 GB | Cache,Capacity |
| SSD | SAS | 2.5 | Mixed Use | Kioxia | PM7 | KPM7XVUG800G | X96H8 | T21WT | C10E | 800 GB | Cache,Capacity |
| SSD | SAS | 2.5 | Mixed Use | Samsung | PM1655a | MZILG1T6HFJAAD3 | J7MWC | 42TFH | DWB1 | 1.6 TB | Cache, Capacity |
| SSD | SAS | 2.5 | Mixed Use | Samsung | PM1655a | MZILG3T2HFLTAD3 | 03P3V | 42TFH | DWB1 | 3.2 TB | Cache, Capacity |
| SSD | SAS | 2.5 | Mixed Use | Samsung | PM1655a | MZILG6T4HBLCAD3 | 24VJM | 42TFH | DWB1 | 6.4 TB | Cache, Capacity |
SAS 2.5" SSD Capacity Only
| Type | Drive Type | Form Factor | Endurance | Vendor | Series | Model | Device Part Number (P/N) | Firmware Software Bundle | Firmware Minimum Supported Version | Capacity | Use |
|---|---|---|---|---|---|---|---|---|---|---|---|
| SSD | SAS | 2.5 | Read Intensive | Samsung | PM1653 | MZILG1T9HCJRAD3 | NRR34 | 3MV58 | DSG9 | 1.92 TB | Capacity |
| SSD | SAS | 2.5 | Read Intensive | Samsung | PM1653 | MZILG3T8HCLSAD3 | 9N32F | 3MV58 | DSG9 | 3.84 TB | Capacity |
| SSD | SAS | 2.5 | Read Intensive | Samsung | PM1653 | MZILG7T6HBLAAD3 | Y8H7M | 3MV58 | DSG9 | 7.68 TB | Capacity |
| SSD | SAS | 2.5 | Read Intensive | Kioxia | PM7 | KPM7XRUG1T92 | 6K35K | T21WT | C10E | 1.92 TB | Capacity |
| SSD | SAS | 2.5 | Read Intensive | Kioxia | PM7 | KPM7XRUG3T84 | MT0R5 | T21WT | C10E | 3.84 TB | Capacity |
| SSD | SAS | 2.5 | Read Intensive | Kioxia | PM7 | KPM7XRUG7T68 | 7N1WT | T21WT | C10E | 7.68 TB | Capacity |
| SSD | SAS | 2.5 | Read Intensive | Samsung | PM1653a | MZILG1T9HFJAAD3 | 8WKDX | 862D9 | DSB1 | 1.92 TB | Capacity |
| SSD | SAS | 2.5 | Read Intensive | Samsung | PM1653a | MZILG3T8HFLTAD3 | MP2TJ | 862D9 | DSB1 | 3.84 TB | Capacity |
| SSD | SAS | 2.5 | Read Intensive | Samsung | PM1653a | MZILG7T6HBLCAD3 | 00CK9 | 862D9 | DSB1 | 7.68 TB | Capacity |
NVMe 2.5" Cache or Capacity
| Type | Drive Type | Form Factor | Endurance | Vendor | Series | Model | Device Part Number (P/N) | Firmware Software Bundle | Firmware Minimum Supported Version | Capacity | Use |
|---|---|---|---|---|---|---|---|---|---|---|---|
| NVMe | PCIe | 2.5 | Mixed Use | Samsung | PM1735 SP 3WPD, SSD, NVMe, 2.5, 512e, ISE | MZWLJ1T6HBJRAD3 | 6GK00 | 5CM3G | 2.5.0 | 1.6 TB | Cache, Capacity |
| NVMe | PCIe | 2.5 | Mixed Use | Samsung | PM1735 SP 3WPD, SSD, Gen4 NVMe, 2.5, 512e, ISE | MZWLJ3T2HBJRAD3 | 15TVC | 5CM3G | 2.5.0 | 3.2TB | Cache,Capacity |
| NVMe | PCIe | 2.5 | Mixed Use | Samsung | PM1735 SP 3WPD, SSD, Gen4 NVMe, 2.5, 512e, ISE | MZWLJ6T4HALAAD3 | F6V5P | 5CM3G | 2.5.0 | 6.4TB | Cache,Capacity |
| NVMe | PCIe | 2.5 | Mixed Use | Kioxia | CM6 SP | KCM6XVUL1T60 | P03YC | GMM6V | 2.2.2 | 1.6 TB | Cache, Capacity |
| NVMe | PCIe | 2.5 | Mixed Use | Kioxia | CM6 SP | KCM6XVUL3T20 | 97GR0 | GMM6V | 2.2.2 | 3.2 TB | Cache, Capacity |
| NVMe | PCIe | 2.5 | Mixed Use | Kioxia | CM6 SP | KCM6XVUL6T40 | K916X | GMM6V | 2.2.2 | 6.4 TB | Cache, Capacity |
| NVMe | PCIe | 2.5 | Mixed Use | Samsung | PM1735 V2 SP 3WPD | MZWLR3T2HBLSAD3 | V69W3 | 5V3P7 | 2.5.0 | 3.2 TB | Cache, Capacity |
| NVMe | PCIe | 2.5 | Mixed Use | Samsung | PM1735 V2 SP 3WPD | MZWLR6T4HALAAD3 | H8D5M | 5V3P7 | 2.5.0 | 6.4 TB | Cache, Capacity |
| NVMe | PCIe | 2.5 | Mixed Use | Samsung | PM1735a | MZWLR1T6HCJRAD3 | H8GHV | 71KRG | 1.2.0 | 1.6 TB | Cache,Capacity |
| NVMe | PCIe | 2.5 | Mixed Use | Samsung | PM1735a | MZWLR3T2HCLSAD3 | 617H6 | 71KRG | 1.2.0 | 3.2 TB | Cache,Capacity |
| NVMe | PCIe | 2.5 | Mixed Use | Samsung | PM1735a | MZWLR6T4HBLAAD3 | 9F6Y3 | 71KRG | 1.2.0 | 6.4 TB | Cache,Capacity |
| NVMe | PCIe | 2.5 | Mixed Use | Kioxia | CM7 | KCM7XVUG1T60 | MP4F2 | K1JTM | 2.0.3 | 1.6 TB | Cache, Capacity |
| NVMe | PCIe | 2.5 | Mixed Use | Kioxia | CM7 | KCM7XVUG3T20 | XFNX0 | K1JTM | 2.0.3 | 3.2 TB | Cache, Capacity |
| NVMe | PCIe | 2.5 | Mixed Use | Kioxia | CM7 | KCM7XVUG6T40 | 8RJJ9 | K1JTM | 2.0.3 | 6.4 TB | Cache, Capacity |
| NVMe | PCIe | 2.5 | Mixed Use | Hynix | PS1030 | HFS1T6GEJVX171N | 1HYKD | VNYK2 | 1.3.0 | 1.6 TB | Cache, Capacity |
| NVMe | PCIe | 2.5 | Mixed Use | Hynix | PS1030 | HFS3T2GEJVX171N | 9VWPD | VNYK2 | 1.3.0 | 3.2 TB | Cache, Capacity |
| NVMe | PCIe | 2.5 | Mixed Use | Hynix | PS1030 | HFS6T4GEJVX171N | PYMY6 | VNYK2 | 1.3.0 | 6.4 TB | Cache, Capacity |
| NVMe | PCIe | 2.5 | Mixed Use | Samsung | PM1745 | MZWLO1T6HCJR-00AD3 | FVC2P | V7V0K | 1.0.0 | 1.6 TB | Cache, Capacity |
| NVMe | PCIe | 2.5 | Mixed Use | Samsung | PM1745 | MZWLO3T2HCLS-00AD3 | FDNHD | V7V0K | 1.0.0 | 3.2 TB | Cache, Capacity |
| NVMe | PCIe | 2.5 | Mixed Use | Samsung | PM1745 | MZWLO6T4HBLA-00AD3 | 64K9C | V7V0K | 1.0.0 | 6.4 TB | Cache, Capacity |
| NVMe | PCIe | 2.5 | Mixed Use | Micron | 7600 | MTFDLAL1T6THS | DCR2M | VJXKC | 1.0.0 | 1.6 TB | Cache, Capacity |
| NVMe | PCIe | 2.5 | Mixed Use | Micron | 7600 | MTFDLAL3T2THS | J9TN7 | VJXKC | 1.0.0 | 3.2 TB | Cache, Capacity |
| NVMe | PCIe | 2.5 | Mixed Use | Samsung | PM9D5a | MZWL6800H | 53M2M | X5N7N | 1.0.1 | 800 GB | Cache, Capacity |
| NVMe | PCIe | 2.5 | Mixed Use | Samsung | PM9D5a | MZWL61T6H | 2M4HN | X5N7N | 1.0.1 | 1.6 TB | Cache, Capacity |
| NVMe | PCIe | 2.5 | Mixed Use | Samsung | PM9D5a | MZWL63T2H | 85GHX | X5N7N | 1.0.1 | 3.2 TB | Cache, Capacity |
| NVMe | PCIe | 2.5 | Mixed Use | Samsung | PM9D5a | MZWL66T4H | D68YV | X5N7N | 1.0.1 | 6.4 TB | Cache, Capacity |
| NVMe | PCIe | 2.5 | Mixed Use | Micron | 9550 | MTFDLAL3T2THB | D0GXJ | 4WN4V | 1.1.0 | 3.2 TB | Cache, Capacity |
| NVMe | PCIe | 2.5 | Mixed Use | Micron | 9550 | MTFDLAL6T4THB | WC68V | 4WN4V | 1.1.0 | 6.4 TB | Cache, Capacity |
NVMe 2.5" Capacity Only
| Type | Drive Type | Form Factor | Endurance | Vendor | Series | Model | Device Part Number (P/N) | Firmware Software Bundle | Firmware Minimum Supported Version | Capacity | Use |
|---|---|---|---|---|---|---|---|---|---|---|---|
| NVMe | PCIe | 2.5 | Read Intensive | Samsung | PM1733 V2 | MZWLR3T8HBLSAD3 | G5N65 | 5V3P7 | 2.5.0 | 3.84 TB | Capacity |
| NVMe | PCIe | 2.5 | Read Intensive | Samsung | PM1733 V2 | MZWLR7T6HALAAD3 | DX74Y | 5V3P7 | 2.5.0 | 7.68 TB | Capacity |
| NVMe | PCIe | 2.5 | Read Intensive | Samsung | PM1733a | MZWLR1T9HCJRAD3 | 8PMRM | 71KRG | 1.2.0 | 1.92 TB | Capacity |
| NVMe | PCIe | 2.5 | Read Intensive | Samsung | PM1733a | MZWLR3T8HCLSAD3 | RJKM5 | 71KRG | 1.2.0 | 3.84 TB | Capacity |
| NVMe | PCIe | 2.5 | Read Intensive | Samsung | PM1733a | MZWLR7T6HBLAAD3 | R1J8J | 71KRG | 1.2.0 | 7.68 TB | Capacity |
| NVMe | PCIe | 2.5 | Read Intensive | Samsung | PM1733a | MZWLR15THBLAAD3 | D4CJG | 71KRG | 1.2.0 | 15.36 TB | Capacity |
| NVMe | PCIe | 2.5 | Read Intensive | Kioxia | CM6 | KCM6XRUL1T92 | N0VK0 | GMM6V | 2.2.2 | 1.92 TB | Capacity |
| NVMe | PCIe | 2.5 | Read Intensive | Kioxia | CM6 | KCM6XRUL3T84 | 8W2G5 | GMM6V | 2.2.2 | 3.84 TB | Capacity |
| NVMe | PCIe | 2.5 | Read Intensive | Kioxia | CM6 | KCM6XRUL7T68 | VD0JX | GMM6V | 2.2.2 | 7.68 TB | Capacity |
| NVMe | PCIe | 2.5 | Read Intensive | Kioxia | CM6 | KCM6XRUL15T3 | J91CR | GMM6V | 2.2.2 | 15.36 TB | Capacity |
| NVMe | PCIe | 2.5 | Read Intensive | Kioxia | CM7 | KCM7XRUG1T92 | M8YW0 | K1JTM | 2.0.3 | 1.92 TB | Capacity |
| NVMe | PCIe | 2.5 | Read Intensive | Kioxia | CM7 | KCM7XRUG3T84 | XHYGF | K1JTM | 2.0.3 | 3.84 TB | Capacity |
| NVMe | PCIe | 2.5 | Read Intensive | Kioxia | CM7 | KCM7XRUG7T68 | VV2M7 | K1JTM | 2.0.3 | 7.68 TB | Capacity |
| NVMe | PCIe | 2.5 | Read Intensive | Kioxia | CM7 | KCM7XRUG15T3 | DX2PD | K1JTM | 2.0.3 | 15.36 TB | Capacity |
| NVMe | PCIe | 2.5 | Read Intensive | Kioxia | CD7 | KCD7XRUG7T68 | 0RD61 | K6597 | 2.0.1 | 7.68 TB | Capacity |
| NVMe | PCIe | 2.5 | Read Intensive | Kioxia | CD8 | KCD8XRUG3T84 | N1MK1 | HV8P1 | 2.0.1 | 3.84 TB | Capacity |
| NVMe | PCIe | 2.5 | Read Intensive | Hynix | PS1010 | HFS1T9GEJVX171N | 7GGK1 | VNYK2 | 1.3.0 | 1.92 TB | Capacity |
| NVMe | PCIe | 2.5 | Read Intensive | Hynix | PS1010 | HFS3T8GEJVX171N | J4TDK | VNYK2 | 1.3.0 | 3.84 TB | Capacity |
| NVMe | PCIe | 2.5 | Read Intensive | Hynix | PS1010 | HFS7T6GEJVX171N | 2533N | VNYK2 | 1.3.0 | 7.68 TB | Capacity |
| NVMe | PCIe | 2.5 | Read Intensive | Hynix | PS1010 | HFS15T3EJVX171N | 8TY8G | VNYK2 | 1.3.0 | 15.36 TB | Capacity |
| NVMe | PCIe | 2.5 | Read Intensive | Hynix | PE8010 | HFS960GECTX088N | WR2FG | T1XKD | 1.3.0 | 960 GB | Capacity |
| NVMe | PCIe | 2.5 | Read Intensive | Hynix | PE8110 | HFS7T6GEETX099N | RG3T2 | TDGKY | 1.1.0 | 7.68 TB | Capacity |
| NVMe | PCIe | 2.5 | Read Intensive | Kioxia | CD8 | KCD8XRUG960G | YNGYD | HV8P1 | 2.0.1 | 960 GB | Capacity |
| NVMe | PCIe | 2.5 | Read Intensive | Micron | 7450 | MTFDKCC960TFR | KXT48 | TVCWT | 1.4.0 | 960 GB | Capacity |
| NVMe | PCIe | 2.5 | Read Intensive | Micron | 7500 | MTFDKCC960TGP | G7NCH | 5F07C | 1.2.0 | 960 GB | Capacity |
| NVMe | PCIe | 2.5 | Read Intensive | Samsung | PM9A3 | MZQL2960HCJRAD3 | 6HYWM | XMFKX | 1.1.1 | 960 GB | Capacity |
| NVMe | PCIe | 2.5 | Read Intensive | Samsung | PM1733 V2 | MZWLR1T9HBJRAD3 | WPR17 | 5V3P7 | 2.5.0 | 1.92 TB | Capacity |
| NVMe | PCIe | 2.5 | Read Intensive | Samsung | PM9A3 | MZQL21T9H | TGYF5 | XMFKX | 1.1.1 | 1.92TB | Capacity |
| NVMe | PCIe | 2.5 | Read Intensive | Micron | 7450 | MTFDKCC1T9TFR | JH61J | TVCWT | 1.4.0 | 1.92 TB | Capacity |
| NVMe | PCIe | 2.5 | Read Intensive | Micron | 7500 | MTFDKCC1T9TGP | M7RHM | 5F07C | 1.2.0 | 1.92 TB | Capacity |
| NVMe | PCIe | 2.5 | Read Intensive | Hynix | PE8110 | HFS1T9GEETX099N | 147DR | TDGKY | 1.1.0 | 1.92 TB | Capacity |
| NVMe | PCIe | 2.5 | Read Intensive | Micron | 7450 | MTFDKCC3T8TFR | NDK2D | TVCWT | 1.4.0 | 3.84 TB | Capacity |
| NVMe | PCIe | 2.5 | Read Intensive | Kioxia | CD7 | KCD7XRUG3T84 | RFYP9 | K6597 | 2.0.1 | 3.84 TB | Capacity |
| NVMe | PCIe | 2.5 | Read Intensive | Hynix | PE8010 | HFS3T8GECTX088N | V6WP5 | T1XKD | 1.3.0 | 3.84 TB | Capacity |
| NVMe | PCIe | 2.5 | Read Intensive | Samsung | PM9A3 | MZQL23T8HCLSAD3 | P7G03 | XMFKX | 1.1.1 | 3.84 TB | Capacity |
| NVMe | PCIe | 2.5 | Read Intensive | Micron | 7500 | MTFDKCC3T8TGP | GT3F3 | 5F07C | 1.2.0 | 3.84 TB | Capacity |
| NVMe | PCIe | 2.5 | Read Intensive | Intel | Arbordale Plus R P5316 | SSDPF2NV307TZ | 4KCVT | 4XT8T | 1.6.0 | 30.72 TB | Capacity |
| NVMe | PCIe | 2.5 | Read Intensive | Samsung | PM1743 | MZWLO3T8HCLS-00AD3 | 9GXVF | V7V0K | 1.0.0 | 3.84 TB | Capacity |
| NVMe | PCIe | 2.5 | Read Intensive | Samsung | PM1743 | MZWLO7T6HBLA-00AD3 | DNPR4 | V7V0K | 1.0.0 | 7.68 TB | Capacity |
| NVMe | PCIe | 2.5 | Read Intensive | Kioxia | CD8 | KCD8XRUG1T92 | NNKCT | HV8P1 | 2.0.1 | 1.92 TB | Capacity |
| NVMe | PCIe | 2.5 | Read Intensive | Samsung | PM9A3 | MZQL27T6HBLAAD3 | 30FX3 | XMFKX | 1.1.1 | 7.68TB | Capacity |
| NVMe | PCIe | 2.5 | Read Intensive | Micron | 7450 | MTFDKCC7T6TFR | 91KYJ | TVCWT | 1.4.0 | 7.68TB | Capacity |
| NVMe | PCIe | 2.5 | Read Intensive | Micron | 7500 | MTFDKCC7T6TGP | RTJFW | 5F07C | 1.2.0 | 7.68TB | Capacity |
| NVMe | PCIe | 2.5 | Read Intensive | Kioxia | CD8 | KCD8XRUG7T68 | MXD8J | HV8P1 | 2.0.1 | 7.68TB | Capacity |
| NVMe | PCIe | 2.5 | Read Intensive | SK Hynix | PE8110 | HFS960GEETX099N | 26WJ0 | TDGKY | 1.1.0 | 960GB | Capacity |
| NVMe | PCIe | 2.5 | Read Intensive | Samsung | PM1743 | MZWLO1T9HCJR-00AD3 | G64N5 | V7V0K | 1.0.0 | 1.92TB | Capacity |
| NVMe | PCIe | 2.5 | Read Intensive | SK Hynix | PE8110 | HFS3T8GEETX099N | 2V97V | TDGKY | 1.1.0 | 3.84TB | Capacity |
| NVMe | PCIe | 2.5 | Read Intensive | Samsung | PM1743 | MZWLO15THBLA-00AD3 | VPWMR | V7V0K | 1.0.0 | 15.36TB | Capacity |
| NVMe | PCIe | 2.5 | Read Intensive | Samsung | PM9D3a | MZWL6960HFJA-00AD3 | 71Y2J | X5N7N | 1.0.1 | 960 GB | Capacity |
| NVMe | PCIe | 2.5 | Read Intensive | Samsung | PM9D3a | MZVL61T9HBL1-00AD3 | 9MNPJ | FTVJG | 1.0.1 | 1.92 TB | Capacity |
| NVMe | PCIe | 2.5 | Read Intensive | Samsung | PM9D3a | MZWL63T8HFLT-00AD3 | 2H60T | X5N7N | 1.0.1 | 3.84 TB | Capacity |
| NVMe | PCIe | 2.5 | Read Intensive | Samsung | PM9D3a | MZWL67T6HBLC-00AD3 | VYT6X | X5N7N | 1.0.1 | 7.68 TB | Capacity |
| NVMe | PCIe | 2.5 | Read Intensive | Micron | 7600 | MTFDLAL1T9THG | N6RN7 | VJXKC | 1.0.0 | 1.92 TB | Capacity |
| NVMe | PCIe | 2.5 | Read Intensive | Micron | 7600 | MTFDLAL3T8THG | 7X0XC | VJXKC | 1.0.0 | 3.84 TB | Capacity |
| NVMe | PCIe | 2.5 | Read Intensive | Micron | 7600 | MTFDLAL7T6THG | Y4GJR | VJXKC | 1.0.0 | 7.68 TB | Capacity |
| NVMe | PCIe | 2.5 | Read Intensive | Micron | 7600 | MTFDLAL15T3THG | 5J26R | VJXKC | 1.0.0 | 15.36 TB | Capacity |
| NVMe | PCIe | 2.5 | Read Intensive | Micron | 9550 | MTFDLAL3T8THA | PFV73 | 4WN4V | 1.1.0 | 3.84 TB | Capacity |
| NVMe | PCIe | 2.5 | Read Intensive | Micron | 9550 | MTFDLAL7T6THA | 39JW6 | 4WN4V | 1.1.0 | 7.68 TB | Capacity |
| NVMe | PCIe | 2.5 | Read Intensive | Micron | 9550 | MTFDLAL15T3THA | R3GD7 | 4WN4V | 1.1.0 | 15.36 TB | Capacity |
2.3 - Azure Local Support Matrix for 17G (Dell 2603)
NOTE
SBE package 4.2.2512.xxxx and newer will only support Azure Local solution versions 12.*.1001.* or 12.*.1002.* (HCI OS 24H2) and newer.
Dell will support the use of SBE package 4.2.2509.xxxx on Azure Local instances running version 11.* (HCI OS 23H2) until April 2026. Dell recommends that instances running version 11.* be upgraded to 12.* as soon as possible to remain in a supported state.
Supported Platforms
| Model | Supported Operating System |
|---|---|
| AX-770 | Windows Server 2025 Datacenter Azure Stack HCI-24H2 |
| AX-670 | Windows Server 2025 Datacenter Azure Stack HCI-24H2 |
Base Components
| Component | Type | Software Bundle | Minimum Supported Version | Supported Platforms | Supported OS |
|---|---|---|---|---|---|
| BIOS | Firmware DUP | 11N9M | 1.7.5 | AX-670 AX-770 | NA |
| Chipset driver for 17G Intel platforms | Driver DUP | 7TXYY | 10.1.19928.8615 | AX-670 AX-770 | Windows Server 2025 Datacenter Azure Stack HCI-24H2 |
| iDRAC10 with Lifecycle Controller | Firmware DUP | YP95X | 1.30.10.50 | AX-670 AX-770 | NA |
| Passive Backplane (1U 8xE3 x2) | Firmware DUP | 0M4TD | 1.92 | AX-670 | NA |
| Passive Backplane (2U 8xE3 x2) | Firmware DUP | 7P6P5 | 1.92 | AX-770 | NA |
| iDRAC Service Module | Firmware DUP | 238XW | 6.1.0.0 | AX-670 AX-770 | NA |
| FPGA | Firmware DUP | RYRRC | 109.126.104 | AX-670 AX-770 | NA |
Network Adapters
| Component | Part Number | SDDC Advanced Qualification | RDMA Protocol | Firmware Software Bundle | Firmware Minimum Supported Version | Driver Software Bundle | Driver Minimum Supported Version | Supported OS | Supported Platforms |
|---|---|---|---|---|---|---|---|---|---|
| Emulex LPe37102 SecureHBA Dual Port Fibre Channel 32Gb Adapter, PCIe Low Profile +Sec | 2HGNX | NA | NA | 15J5T | 03.10.12 | 8XGGG | 14.4.624.1 | Windows Server 2025 Datacenter Azure Stack HCI-24H2 | AX-670 |
| Emulex LPe38102 SecureHBA Dual Port Fibre Channel 64Gb Adapter, PCIe Low Profile +Sec | TF3HV | ||||||||
| Emulex LPe38102 SecureHBA Dual Port Fibre Channel 64Gb Adapter, PCIe Full Height +Sec | D6PNX | NA | NA | 15J5T | 03.10.12 | 8XGGG | 14.4.624.1 | Windows Server 2025 Datacenter Azure Stack HCI-24H2 | AX-770 |
| Emulex LPe37102 SecureHBA Dual Port Fibre Channel 32Gb Adapter, PCIe Full Height +Sec | JWVMH | ||||||||
| NVIDIA/Mellanox ConnectX-6 Dx OCP3 | 769PV | Management Compute (Premium) Storage (Premium) | RoCEv2 | 0WM7T | 22.48.1000 | 3T3MK | 26.001.03 | Windows Server 2025 Datacenter Azure Stack HCI-24H2 | AX-670 AX-770 |
| NVIDIA/Mellanox ConnectX-6 Dx PCIe LP | PXKX5 | ||||||||
| NVIDIA/Mellanox ConnectX-6 Dx PCIe FH | 6PKY5 | Management Compute (Premium) Storage (Premium) | RoCEv2 | 0WM7T | 22.48.1000 | 3T3MK | 26.001.03 | Windows Server 2025 Datacenter Azure Stack HCI-24H2 | AX-770 |
| NVIDIA/Mellanox ConnectX-6 Lx PCIe LP | 74GDV | Management Compute (Premium) Storage (Premium) | RoCEv2 | KX0W4 | 26.48.1000 | 3T3MK | 26.001.03 | Windows Server 2025 Datacenter Azure Stack HCI-24H2 | AX-670 AX-770 |
| NVIDIA/Mellanox ConnectX-6 Lx OCP3 | 7GGY4 | ||||||||
| NVIDIA/Mellanox ConnectX-6 Lx PCIe FH | 17W36 | Management Compute (Premium) Storage (Premium) | RoCEv2 | KX0W4 | 26.48.1000 | 3T3MK | 26.001.03 | Windows Server 2025 Datacenter Azure Stack HCI-24H2 | AX-770 |
| QLogic QLE2772C Dual Port 32Gb Fibre Channel, PCIe Low Profile +Sec | K10X5 | NA | NA | 3XDWV | 17.10.04 | RF21G | 9.4.12.20 | Windows Server 2025 Datacenter Azure Stack HCI-24H2 | AX-670 |
| QLogic QLE2772C Dual Port 32Gb Fibre Channel, PCIe Full Height +Sec | 663P2 | NA | NA | 3XDWV | 17.10.04 | RF21G | 9.4.12.20 | Windows Server 2025 Datacenter Azure Stack HCI-24H2 | AX-770 |
| QLogic QLE2872C Dual Port 64Gb Fibre Channel, PCIe Low Profile +Sec | W72F2 | NA | NA | XMXP3 | 17.10.04 | RF21G | 9.4.12.20 | Windows Server 2025 Datacenter Azure Stack HCI-24H2 | AX-670 |
| QLogic QLE2872C Dual Port 64Gb Fibre Channel, PCIe Full Height +Sec | X29W4 | NA | NA | XMXP3 | 17.10.04 | RF21G | 9.4.12.20 | Windows Server 2025 Datacenter Azure Stack HCI-24H2 | AX-770 |
Network Switches
NOTE
A list of supported Network Switch models along with the supported firmware versions can be found here, Physical network requirements for Azure Local.PowerFlex
| Component | PowerFlex SDC Driver Version | Validated Platforms | Supported OS | Download Link | Extracted Package Location |
|---|---|---|---|---|---|
| PowerFlex Storage Data Client (SDC) | 4.5.2.2 | AX-670 AX-770 | Azure Stack HCI-24H2 | https://dl.dell.com/downloads/41X88_PowerFlex-Software-4.5.5.2-SDC-Driver.zip | PowerFlex_4.5.5200.104_Windows_SDC: EMC-ScaleIO-sdc-4.5-5200.104.msi |
| PowerFlex Storage Data Client (SDC) | 5.0 | AX-670 AX-770 | Azure Stack HCI-24H2 | https://dl.dell.com/downloads/09J62_PowerFlex-Software-5.0.0.0-SDC-Driver.zip | PowerFlex_5.0.0.941_Windows_SDC: EMC-ScaleIO-sdc-5.0-0.941.msi |
GPUs
| GPU Model | Vendor | Description | Part Number | Firmware Version | Driver Version | GPU-P capable | Supported Platform | Supported OS |
|---|---|---|---|---|---|---|---|---|
| A16 | NVIDIA | NVIDIA Ampere A16, PCIe, 250W, 64GB Passive, Double Wide, Full Height GPU,V2 | D1P1T | AX-770 | Windows Server 2025 Datacenter Azure Stack HCI-24H2 | |||
| L4 | NVIDIA | NVIDIA L4, PCIe, 72W, 24GB Passive, Single Wide Low Profile GPU | V9XT2 | AX-670 | Windows Server 2025 Datacenter Azure Stack HCI-24H2 | |||
| L4 | NVIDIA | NVIDIA L4, PCIe, 72W, 24GB Passive, Single Wide Full Height GPU | NG3PY | AX-770 | Windows Server 2025 Datacenter Azure Stack HCI-24H2 | |||
| L40S | NVIDIA | NVIDIA Ampere L40S, PCIe, 350W, 48GB Passive, Double Wide, Full Height, Full Length, GPU with cable | 7WK28 | AX-770 | Windows Server 2025 Datacenter Azure Stack HCI-24H2 | |||
| RTX PRO 6000 | NVIDIA | NVIDIA RTX PRO 6000 BSE 96GB 600W PCIe GPU | THH68 | AX-770 | Windows Server 2025 Datacenter Azure Stack HCI-24H2 |
NOTE
Dell update packages are not available for GPU cards, please download the latest driver version from NVIDIA driver download page.Storage Controllers
| Component | Dell Part Number | Firmware Software Bundle | Firmware Minimum Supported Version | Driver Software Bundle | Driver Minimum Supported Version | Supported Platforms | Supported OS |
|---|---|---|---|---|---|---|---|
| BOSS-N1 | NH7WD | PVDY9 | 2.2.13.2037 | Inbox | Inbox | AX-670 AX-770 | Windows Server 2025 Datacenter Azure Stack HCI-24H2 |
SATA M.2 SSD Boot Only
| Type | Drive Type | Form Factor | Endurance | Vendor | Series | Model | Device Part Number (P/N) | Firmware Software Bundle | Firmware Minimum Supported Version | Capacity | Use |
|---|---|---|---|---|---|---|---|---|---|---|---|
| NVMe | PCIe | M.2 | NA | Solidigm | PE9010 | HFS960GDJ8X167N | XN5KG | 8X8YR | 1.2.1 | 960GB | Boot |
| NVMe | PCIe | M.2 | NA | Solidigm | PE9010 | HFS960GEJ8X167N | 4H05X | YJG7C | 1.3.1 | 960GB | Boot |
| NVMe | PCIe | M.2 | NA | Micron | 7450 | MTFDKBAXXXTFR | PH7J6 | JHKXR | 1.4.0 | 960GB | Boot |
NVMe 2.5" Cache or Capacity
| Type | Drive Type | Form Factor | Endurance | Vendor | Series | Model | Device Part Number (P/N) | Firmware Software Bundle | Firmware Minimum Supported Version | Capacity | Use |
|---|---|---|---|---|---|---|---|---|---|---|---|
| NVMe | PCIe | E3.s | Mixed Use | Kioxia | CD8P | KCD8XPJE1T60 | R64H4 | 50PDK | 2.0.4 | 1.6TB | Cache, Capacity |
| NVMe | PCIe | E3.s | Mixed Use | Hynix | PE1030 | HFS1T6GFJCX180N | MXDXH | 0930W | 1.1.0 | 1.6TB | Cache, Capacity |
| NVMe | PCIe | E3.s | Mixed Use | Samsung | PM1745 | MZ3LO3T2HCLSAD3 | 7R3TT | 694C5 | 1.1.0 | 3.2TB | Cache, Capacity |
| NVMe | PCIe | E3.s | Mixed Use | Kioxia | CM7 | KCM7XVJE3T20 | 6J3Y1 | 0822W | 2.0.4 | 3.2TB | Cache, Capacity |
| NVMe | PCIe | E3.s | Mixed Use | Kioxia | CD8P | KCD8XPJE3T20 | GP5GV | 50PDK | 2.0.4 | 3.2TB | Cache, Capacity |
| NVMe | PCIe | E3.s | Mixed Use | Hynix | PS1030 | HFS3T2GFJCX171N | 734CX | WHGGM | 1.1.0 | 3.2TB | Cache, Capacity |
| NVMe | PCIe | E3.s | Mixed Use | Hynix | PE1030 | HFS3T2GFJCX180N | HCDFH | 0930W | 1.1.0 | 3.2TB | Cache, Capacity |
| NVMe | PCIe | E3.s | Mixed Use | Hynix | PS1030 | HFS6T4GFJCX171N | DH5XD | WHGGM | 1.1.0 | 6.4TB | Cache, Capacity |
| NVMe | PCIe | E3.s | Mixed Use | Samsung | PM1745 | MZ3LO6T4HBLAAD3 | FNPJC | 694C5 | 1.1.0 | 6.4TB | Cache, Capacity |
| NVMe | PCIe | E3.s | Mixed Use | Kioxia | CM7 | KCM7XVJE6T40 | V4DNH | 0822W | 2.0.4 | 6.4TB | Cache, Capacity |
NVMe 2.5" Capacity Only
| Type | Drive Type | Form Factor | Endurance | Vendor | Series | Model | Device Part Number (P/N) | Firmware Software Bundle | Firmware Minimum Supported Version | Capacity | Use |
|---|---|---|---|---|---|---|---|---|---|---|---|
| NVMe | PCIe | E3.s | Read Intensive | Kioxia | CD8P | KCD8XPJE1T92 | 59Y5J | 50PDK | 2.0.4 | 1.92TB | Capacity |
| NVMe | PCIe | E3.s | Read Intensive | Hynix | PE1010 | HFS1T9GFJCX180N | 9CC5X | 0930W | 1.1.0 | 1.92TB | Capacity |
| NVMe | PCIe | E3.s | Read Intensive | Samsung | PM1743 | MZ3LO3T8HCLSAD3 | 831H5 | 8K2NH | 1.1.0 | 3.84TB | Capacity |
| NVMe | PCIe | E3.s | Read Intensive | Kioxia | CM7 | KCM7XRJE3T84 | YGK8R | KCGDP | 2.0.0 | 3.84TB | Capacity |
| NVMe | PCIe | E3.s | Read Intensive | Hynix | PS1010 | HFS3T8GFJCX171N | 84M8H | WHGGM | 1.1.0 | 3.84TB | Capacity |
| NVMe | PCIe | E3.s | Read Intensive | Kioxia | CD8P | KCD8XPJE3T84 | 6RC59 | 50PDK | 2.0.4 | 3.84TB | Capacity |
| NVMe | PCIe | E3.s | Read Intensive | Hynix | PE1010 | HFS3T8GFJCX180N | 1NFG2 | 0930W | 1.1.0 | 3.84TB | Capacity |
| NVMe | PCIe | E3.s | Read Intensive | Samsung | PM1743 | MZ3LO7T6HBLAAD3 | NKGTX | 8K2NH | 1.1.0 | 7.68TB | Capacity |
| NVMe | PCIe | E3.s | Read Intensive | Kioxia | CM7 | KCM7XRJE7T68 | G27W5 | KCGDP | 2.0.0 | 7.68TB | Capacity |
| NVMe | PCIe | E3.s | Read Intensive | Hynix | PS1010 | HFS7T6GFJCX171N | DDKCG | WHGGM | 1.1.0 | 7.68TB | Capacity |
| NVMe | PCIe | E3.s | Read Intensive | Samsung | PM1743 | MZ3LO15THBLAAD3 | RRYKC | 8K2NH | 1.1.0 | 15.36TB | Capacity |
| NVMe | PCIe | E3.s | Read Intensive | Kioxia | CM7 | KCM7XRJE15T3 | YRN98 | KCGDP | 2.0.0 | 15.36TB | Capacity |
| NVMe | PCIe | E3.s | Read Intensive | Hynix | PS1010 | HFS15T3FJCX171N | HK6WK | WHGGM | 1.1.0 | 15.36TB | Capacity |
2.4 - Azure Local Support Matrix for 45n0c (Dell 2603)
NOTE
SBE package 4.2.2512.xxxx and newer will only support Azure Local solution versions 12.*.1001.* or 12.*.1002.* (HCI OS 24H2) and newer.
Dell will support the use of SBE package 4.2.2509.xxxx on Azure Local instances running version 11.* (HCI OS 23H2) until April 2026. Dell recommends that instances running version 11.* be upgraded to 12.* as soon as possible to remain in a supported state.
Supported Platforms
| Model | Supported Operating System |
|---|---|
| AX-4510c | Windows Server 2022 Datacenter Windows Server 2025 Datacenter Azure Stack HCI-24H2 |
| AX-4520c | Windows Server 2022 Datacenter Windows Server 2025 Datacenter Azure Stack HCI-24H2 |
| APEX MC-4510c | Azure Stack HCI-24H2 |
| APEX MC-4520c | Azure Stack HCI-24H2 |
Base Components
| Component | Type | Software Bundle | Minimum Supported Version | Supported Platforms | Supported OS |
|---|---|---|---|---|---|
| BIOS | Firmware DUP | PW2C4 | 1.22.1 | AX-4510c AX-4520c APEX MC-4510c APEX MC-4520c | NA |
| iDRAC9 with Lifecycle Controller | Firmware DUP | 924YT | 7.30.10.50 | AX-4510c AX-4520c APEX MC-4510c APEX MC-4520c | NA |
| Chipset driver for 15G Intel platforms | Driver DUP | C2MC3 | 10.1.19928.8615 | AX-4510c AX-4520c APEX MC-4510c APEX MC-4520c | Windows Server 2022 Datacenter Windows Server 2025 Datacenter Azure Stack HCI-24H2 |
| iDRAC Service Module | Firmware DUP | 238XW | 6.1.0.0 | AX-4510c AX-4520c APEX MC-4510c APEX MC-4520c | NA |
| Chassis Manager | Firmware DUP | WC84H | 5 | AX-4510c AX-4520c APEX MC-4510c APEX MC-4520c | NA |
| CPLD | Firmware DUP | G1YRC | 1.0.5 | AX-4510c AX-4520c APEX MC-4510c APEX MC-4520c | NA |
Network Adapters
| Component | Part Number | SDDC Advanced Qualification | RDMA Protocol | Firmware Software Bundle | Firmware Minimum Supported Version | Driver Software Bundle | Driver Minimum Supported Version | Supported OS | Supported Platforms |
|---|---|---|---|---|---|---|---|---|---|
| Broadcom 57504 Quad Port 10/25GbE SFP28 Adapter, PCIe FH | J3D14 | Management Compute (Premium) Storage (Premium) | RoCEv2 | MJ0HT | 36.11.56.00 | 78X9T | 236.1.155.0 | Windows Server 2025 Datacenter Azure Stack HCI-24H2 | AX-4520c APEX MC-4520c |
| Intel E823 | KJMHJ | Management Compute (Premium) Storage (Premium) | iWARP,RoCEv2 | N11TD | 24.0.5 | PH5GK | 24.0.0 | Windows Server 2022 Datacenter Windows Server 2025 Datacenter Azure Stack HCI-24H2 | AX-4510c AX-4520c APEX MC-4510c APEX MC-4520c |
| Intel E810-CQDA2 Dual Port 100GbE QSFP28 Adapter, PCIe FH | 85F8F | Management Compute (Premium) Storage (Premium) | iWARP,RoCEv2 | N11TD | 24.0.5 | PH5GK | 24.0.0 | Windows Server 2022 Datacenter Windows Server 2025 Datacenter Azure Stack HCI-24H2 | AX-4520c APEX MC-4520c |
| Intel E810-XXV Dual Port 25GbE SFP28 Adapter, PCIe FH | CD16M | ||||||||
| Mellanox ConnectX-6 Dx Dual Port 100GbE QSFP56 PCIe Adapter, FH | 8P2T2 | Management Compute (Premium) Storage (Premium) | RoCEv2 | 2CMVW | 22.41.10.00 | G6M58 | 24.4.26429 | Windows Server 2022 Datacenter Windows Server 2025 Datacenter Azure Stack HCI-24H2 | AX-4520c APEX MC-4520c |
| Nvidia ConnectX-6 Lx Dual Port 10/25GbE SFP28 Adapter, PCIe FH | R5WK9 | Management Compute (Premium) Storage (Premium) | RoCEv2 | 1H4PM | 26.41.10.00 | G6M58 | 24.4.26429 | Windows Server 2022 Datacenter Windows Server 2025 Datacenter Azure Stack HCI-24H2 | AX-4520c APEX MC-4520c |
Network Switches
NOTE
A list of supported Network Switch models along with the supported firmware versions can be found here, Physical network requirements for Azure Local.GPUs
| GPU Model | Vendor | Description | Part Number | Firmware version | Driver Version | GPU-P capable | Supported Platform | Supported OS |
|---|---|---|---|---|---|---|---|---|
| A2 | NVIDIA | NVIDIA Ampere A2, PCIe, 60W, 16GB Passive, Single Wide, Full Height GPU, V2 | MG5JX | 94.07.5B.00.55 | 528.89 WHQL | Yes | AX-4520c APEX MC-4520c | Windows Server 2025 Datacenter Azure Stack HCI-24H2 |
| L4 | NVIDIA | NVIDIA L4, PCIe, 72W, 24GB Passive, Single Wide Full Height GPU | NG3PY | 95.04.29.00.06 | 528.89 WHQL | Yes | AX-4520c APEX MC-4520c | Windows Server 2025 Datacenter Azure Stack HCI-24H2 |
NOTE
Dell update packages are not available for GPU cards, please download the latest driver version from NVIDIA driver download page.Storage Controllers
| Component | Dell Part Number | Firmware Software Bundle | Firmware Minimum Supported Version | Driver Software Bundle | Driver Minimum Supported Version | Supported Platforms | Supported OS |
|---|---|---|---|---|---|---|---|
| BOSS-N1 | M88HH | 67GHR | 2.1.13.2037 | Inbox | AX-4510c AX-4520c APEX MC-4510c APEX MC-4520c | Windows Server 2022 Datacenter Windows Server 2025 Datacenter Azure Stack HCI-24H2 |
NVMe 2.5" Capacity Only
| Type | Drive Type | Form Factor | Endurance | Vendor | Series | Model | Device Part Number (P/N) | Firmware Software Bundle | Firmware Minimum Supported Version | Capacity | Use |
|---|---|---|---|---|---|---|---|---|---|---|---|
| NVMe | PCIe | M.2 | Read Intensive | Micron | 7400 | MTFDKBG1T9TDZ | G18YX | N71F4 | 1.6.0 | 1.92TB | Capacity |
| NVMe | PCIe | M.2 | Read Intensive | Micron | 7400 | MTFDKBG3T8TDZ | 2RN2N | N71F4 | 1.6.0 | 3.84TB | Capacity |
| NVMe | PCIe | M.2 | Read Intensive | Hynix | PE8010 | HFS960GDC8X099N | 21GXV | R2TTT | 1.3.0 | 960GB | Capacity |
| NVMe | PCIe | M.2 | Mixed Use | Hynix | PE8030 | HFS800GDC8X088N | 31XDY | R2TTT | 1.3.0 | 800GB | Capacity |
| NVMe | PCIe | M.2 | Mixed Use | Micron | 7450 | MTFDKBA800TFS | F9MKX | JHKXR | 1.4.0 | 800GB | Capacity |
| NVMe | PCIe | M.2 | Mixed Use | Hynix | PE9030 | HFS800GDJ8X167N | FYWN9 | 9GH86 | 1.2.1 | 800GB | Capacity |
| NVMe | PCIe | M.2 | Read Intensive | Hynix | PE9010 | HFS960GDJ8X167N | XN5KG | 8X8YR | 1.2.1 | 960GB | Capacity |
| NVMe | PCIe | M.2 | Read Intensive | Hynix | PE9010 | HFS960GEJ8X167N | 4H05X | YJG7C | 1.3.1 | 960GB | Capacity |
| NVMe | PCIe | M.2 | Read Intensive | Micron | 7450 | MTFDKBA960TFR | PH7J6 | JHKXR | 1.4.0 | 960GB | Capacity |
| NVMe | PCIe | M.2 | Read Intensive | Micron | 7450 | MTFDKBG1T9TFR | J927V | JHKXR | 1.4.0 | 1.92TB | Capacity |
| NVMe | PCIe | M.2 | Read Intensive | Hynix | PE8110 | HFS1T9GDE0X088N | MY5M4 | 19H08 | 1.1.0 | 1.92TB | Capacity |
| NVMe | PCIe | M.2 | Read Intensive | Micron | 7450 | MTFDKBG3T8TFR | 5FP33 | JHKXR | 1.4.0 | 3.84TB | Capacity |
| NVMe | PCIe | M.2 | Read Intensive | Hynix | PE8110 | HFS3T8GDE0X088N | 5JR5H | 19H08 | 1.1.0 | 3.84TB | Capacity |
2.5 - Azure Local Golden Images (Dell 2603)
NOTE
SBE package 4.2.2512.xxxx and newer will only support Azure Local solution versions 12.*.1001.* or 12.*.1002.* (HCI OS 24H2) and newer.
Dell will support the use of SBE package 4.2.2509.xxxx on Azure Local instances running version 11.* (HCI OS 23H2) until April 2026. Dell recommends that instances running version 11.* be upgraded to 12.* as soon as possible to remain in a supported state.
The Dell Technologies provided operating system golden image for Azure Local instances is for imaging AX servers prior to deploying an Azure Local instance. This image is based on the Azure Stack HCI OS, with Microsoft customization and Dell Technologies customization. This image includes drivers provided by Dell Technologies.
Azure Local Golden Images for Solution versions 12.2604.1003.* - 12.2609.1003.* with Dell SBE 5.0.2603.*
Azure Local Golden Images for Solution versions 12.2510.1002.* - 12.2603.1002.* with Dell SBE 5.0.2603.*
2.6 - Azure Local Dell Solution Builder Extensions Release Notes (Dell 2603)
Overview
Solution Builder Extensions (SBE) for Azure Local. Firmware, Driver, and WDAC Supplemental policy for lifecycle management for Azure Local instances running on Dell AX servers.
Important Caveats
-
AX 17G SBE 5.0.2603.1709 does not contain the NVIDIA ConnectX-6 NIC firmware. This is due to an iDRAC defect that prevents the SBE from updating the NVIDIA ConnectX-6 NIC firmware. The NVIDIA ConnectX-6 NIC firmware in 17G AX servers must be manually updated to version 26.48.1000 for ConnectX-6 LX and version 22.48.1000 for ConnectX-6 DX prior to Azure Local instance creation.
-
Secure Boot 2023 Certificates must be installed on each instance machine in order for the BIOS version to be upgraded to the versions that are included in this SBE release. The Secure Boot 2023 Certificates are installed as part of installing Solution version 12.2603.1002.* or newer, which is a prerequisite for installing these new SBE versions.
-
NVIDIA ConnectX NIC resets have been observed by customers under certain workloads. Affected driver version ‘25.1.26647.0’ and corresponding firmware was introduced in the SBE ‘4.2.2506.n’. SBE ‘4.2.2509.n’ and ‘4.2.2512.n’ will downgrade the NVIDIA ConnectX driver to version ‘24.4.26429.0’ and firmware versions ‘26.41.10.00’, ‘22.41.10.00’, and ‘14.32.20.04’ when installing SBE ‘5.0.2603.1641’, ‘5.0.2603.1522’, or ‘5.0.2603.1407’. Manually downgrading the firmware is no longer required. For reference, see KB000376360.
-
Dell Micron 7450 and 7500 NVMe SSDs occasionally enter a panic state. For details and instructions, see KB000368482. From the SBE table above, find the version relevant to your product and install the SBE with updated firmware that resolves the defect for the Micron 7450 and 7500 drives.
New for This Release
SBE 5.2603.1709
- New for AX-670 and AX-770 Platforms
- Driver and Firmware 2603 Update
- To install this SBE version, Azure Local instances that are already deployed must be running solution versions
12.*.1003.*and12.*.1002.*
SBE 5.2603.1641
- Driver and Firmware 2603 Update
- Added Secure Boot 2023 certificate prerequisite check prior to BIOS update
- Added automated capability for downgrading NVIDIA ConnectX-6 NIC firmware if necessary
- To install this SBE version, Azure Local instances that are already deployed must be running solution versions
12.*.1003.*and12.2603.1002.*
SBE 5.2603.1522
- Driver and Firmware 2603 Update
- Added Secure Boot 2023 certificate prerequisite check prior to BIOS update
- Added automated capability for downgrading NVIDIA ConnectX-6 NIC firmware if necessary
- To install this SBE version, Azure Local instances that are already deployed must be running solution versions
12.*.1003.*and12.2603.1002.*
SBE 5.2603.1407
- Driver and Firmware 2603 Update
- Added Secure Boot 2023 certificate prerequisite check prior to BIOS update
- Added automated capability for downgrading NVIDIA ConnectX-6 NIC firmware if necessary
- To install this SBE version, Azure Local instances that are already deployed must be running solution versions
12.*.1003.*and12.2603.1002.*
Prerequisites
Update Firmware and Drivers Prior to Azure Local Instance Deployment
Drivers and firmware need to be installed on the servers that will be the instance members prior to deployment from the Azure Portal or using an ARM Template. This requirement is independent of the installation of the SBE. Machines imaged with Dell provided golden images will include the required Dell provided Out-of-Box drivers, but the firmware versions must still be validated and possibly updated prior to the instance deployment. The most current driver and firmware versions listed in the support matrix are recommended.
The Azure Local support matrix for Dell AX servers can be found here, Support Matrix | Solutions for Microsoft Azure.
iDRAC Access from Host OS
The iDRAC pass-through NIC must be enabled and have an IP address assigned to it. iDRAC pass-through NIC is enabled by default and has an APIPA (Automatic Private IP Addressing) IP address assigned. This IP address must be accessible by the iDRAC NIC Remote NDIS Compatible Device in the host operating system. This is a dedicated link to the host OS and cannot be accessed outside the host OS.
iDRAC access health checks are introduced starting with the December 2024 SBE releases. These health checks verify that the required iDRAC access has been implemented on each server that will be an instance member. The iDRAC access health checks run automatically as part of the standard built-in SBE health checks. These health checks must complete successfully for the SBE installation to proceed. Failure remediation instructions are provided in case the health check fails.
Manual iDRAC Access Verification
The following procedures provide a manual method for verifying the required iDRAC access. The iDRAC access health checks provide automated and more comprehensive verification method.
Example iDRAC Pass-through settings
The iDRAC NIC Remote NDIS Compatible Device in the host operating system is used by the SBE CAU plug-in to update firmware. This NIC must be enabled and have an IP address assigned to it. By default, this NIC is enabled and has an APIPA IP address assigned to it that can access the iDRAC pass-through IP address. DHCP client should not be disabled on this NIC.
This is a dedicated link to iDRAC from the host OS and cannot be accessed outside the host OS.
The IP address can be obtained using the following PowerShell command:
Get-NetAdapter -InterfaceDescription "Remote NDIS Compatible Device" | Get-NetIPAddress -AddressFamily IPv4 | Select-Object -Property IPAddress
Example:
IPAddress
---------
169.254.0.2
Azure Local instances using Non-Transparent, Unauthenticated Network Proxy
Azure Local instances using non-transparent, unauthenticated network proxy must have the iDRAC pass-through IP address in the network proxy exclusion list. For information on how to configure the non-transparent, unauthenticated network proxy see, Configure proxy settings for Azure Local.
The following example shows how to configure the APIPA IP address range 169.254.0.0/16 to be in the network proxy exclusion list.
$NoProxy = "localhost,127.0.0.1,.svc,10.0.0.0/8,172.16.0.0/12,192.168.0.0/16,.contoso.com,node1,node2,ClusterName,169.254.0.0/16"
[Environment]::SetEnvironmentVariable("NO_PROXY", $NoProxy, "Machine")
Download Connector – Automated download of future SBE release
Overview
Download Connector is a component in the SBE (Solutions Builder Extensions) that automates the downloading of new SBE bundles as they become available for your cluster. Once an SBE that includes the Download Connector is installed on your cluster, manually downloading and importing follow-on SBE version is no longer required. The update service will automate the downloading of the next available SBE for your Azure Local instance in a similar manner to how the download of the solution upgrade is automated. The Download Connector is part of the SBE version 4.1.2505.1501 and newer.
SBE versions that include the Download Connector also include system and update health checks that proactively verify the ability of the Download Connector to access the required remote resource when it comes time to download the next SBE for your cluster. System health checks are run once per day and update health checks are run at the initial phase of the update process.
Firewall Requirements
The SBE Download Connector running in the Azure Local instance needs to periodically connect to the internet resources to download SBE bundles for your cluster. The following outbound connectivity is required.
| Endpoint Description | Endpoint URL | Port |
|---|---|---|
| SBE bundle download | dl.dell.com/* | 443 |
| SBE download catalog | downloads.dell.com/filestore/Prod/SbeDownloadCatalog/AX_SBE_Download_Catalog.xml | 443 |
| SBE download catalog redirection | aka.ms/DellAzureLocalSBEDownloadCatalog | 443 |
| Digicert Certificate Revocation Status | http://crl3.digicert.com/* | 80 |
| Digicert Certificate Revocation Status | http://crl4.digicert.com/* | 80 |
Installation
Automated Download and Extraction
SBE releases starting with 4.1.2505.1501 and newer include the Download Connector that automates downloading and extracting the SBE.
Note
Manual download and SBE bundle extraction are unnecessary when an SBE with this capability is already installed or partially installed on the Azure Local instance.Manual Download and Extract
CAUTION
Steps 3 and 4 must be completed to ensure that the latest SBE Discovery manifest is used.This step is required only when an SBE is not installed in the Azure Local instance (SBE version ‘2.1.0.0’) or the installed SBE is older than version ‘4.1.2505.1501’
SBE bundle zip file has the naming convention Bundle_SBE_Dell_AS-HCI-AX-GenerationNumber_VersionNumber.zip.
-
Download the SBE bundle zip file for your Dell AX server generation using the download link above. The SBE bundles are specific to the AX 14G platforms, AX 15G platforms, and AX 16G platforms
-
Extract the three SBE files from the SBE bundle zip file. There are two xml files and one zip file. Example:
- SBE_Dell_AS-HCI-AX-16G-45n0c_4.2.2506.1600.xml
- SBE_Dell_AS-HCI-AX-16G-45n0c_4.2.2506.1600.zip
- SBE_Discovery_Dell.xml
-
Navigate to https://aka.ms/AzureStackSBEUpdate/DellEMC and press
Ctrl + Sto download the SBE_Discovery_Dell.xml file -
Replace the SBE_Discovery_Dell.xml file that was in the SBE bundle zip with the file downloaded in step 3
There are two options for installing the SBE package. The SBE package can be installed as part of instance creation or imported after instance creation is successfully completed. The importing method is also used to update the SBE to a newer version when the currently running SBE does not include Download Connector capability.
Installing SBE as Part of Instance Creation
Starting with June 2025 Dell golden image release, the SBE files are included in the golden image and already placed in the C:\SBE directory. The following 3 steps do not need to be performed.
- On each server that will be an instance member, create the following directory:
C:\SBE - Copy the three SBE files to the directory
C:\SBEon each server that will be an instance member - Proceed to deploying the instance from the Azure Portal or an ARM template
Importing the SBE After Successful Azure Local Instance Creation
-
Create a directory on a cluster shared volume (CSV) for sideloading the SBE, e.g.,
C:\ClusterStorage\Infrastructure_1\SBE\SBE-AX-16G-45n0c_4.2.2506.1600 -
Copy the three extracted SBE files to this directory
-
Load the SBE files by running the following command with the path to the directory that holds the three extracted SBE files
Add-SolutionUpdate -SourceFolder "C:\ClusterStorage\Infrastructure_1\SBE\SBE-AX-16G-45n0c_4.2.2506.1600" -
Check the state of the SBE that was just added. The state needs to be
Ready.Get-SolutionUpdate | Where-Object -Property PackageType -EQ "SBE" -
Verify that the Azure Local instance is in a healthy state and is ready for the SBE installation by running the following commands on one of the Azure Local instance machines:
Get-SolutionUpdate | Where-Object { $_.State -imatch "Ready" -and $_.PackageType -eq "SBE" } | Start-SolutionUpdate -PrepareOnly -
Wait for the health check to complete. The solution update state will report
HealthCheckingwhile the health check is in progress. -
After the health check completes, run the following command if the solution update state reports
HealthCheckFailed:$Result = (Get-SolutionUpdate | Where-Object {$_.State -imatch "Ready" -and $_.PackageType -eq "SBE"}).HealthCheckResult $Result | Where-Object { ($_.Status -ne "SUCCESS" -and $_.Severity -eq "CRITICAL" ) } | Format-List -Property Title, Status, Severity, Description, Remediation, TargetResourceName, TargetResourceType
All tests with Critical severity must have the Success status before continuing to the next step.
-
Start the SBE installation by running the following command:
Get-SolutionUpdate | Where-Object { $_.State -imatch "Ready" -and $_.PackageType -eq "SBE" } | Start-SolutionUpdate -
The SBE installation progress can be checked by running the following command:
Get-SolutionUpdate | Where-Object -Property PackageType -EQ "SBE" | Format-List -Property ResourceID, Description, State, SBEVersion, UpdateStateProperties, HealthState
For more information see, Update Azure Local via PowerShell.
Known Issues
SBE Installation May Fail with Firmware CAU Plug-in CAU Scan Error
Description
The SBE installation may fail when the Dell firmware CAU plug-in is running the CAU scan operation to identify server components that require firmware updates. The SBE installation workflow terminates and reports the following error when this condition occurs.
Microsoft.HardwareUpdatePlugin (2) plug-in reported a failure while attempting to scan for applicable updates on node <NodeName>
Additional information reported by the plug-in: (ClusterUpdateException) Encountered Exception while running ScanAsync
Note
HardwareUpdatePlugin (2) refers to the firmware CAU plug-in in the Dell SBE.Workaround
-
Identify the failing node name from the error message.
-
Reboot iDRAC on that node via WebUI by logging in to iDRAC, selecting the menu Maintenance > Diagnostics > Reboot iDRAC.
Note
iDRAC takes a few minutes to reboot. The session to the iDRAC WebUI will drop and automatically re-establish when iDRAC completes the reboot process. -
Wait for iDRAC to complete its reboot and verify you can log in.
-
Restart the SBE installation from Azure Update Manager or from PowerShell by running the following command on one of the Azure Local instance nodes:
Get-SolutionUpdate | Where-Object { $_.State -eq "InstallationFailed" -and $_.PackageType -eq "SBE" } | Start-SolutionUpdate
Background
The Dell firmware CAU plug-in implements the CAU scan operation to identify components that require firmware updates prior to running the CAU run operation. Azure Local machine components that do not require firmware updates are excluded from the CAU run operation. The firmware CAU plug-in obtains a list of machine components and their firmware versions from iDRAC. This error occurs when iDRAC does not respond correctly to the component inventory request issued by the firmware CAU plug-in.
Partially Installed SBE Version 4.0.0.0 When SBE Is Installed as Part of Cluster Deployment
Description
Get-SolutionUpdateEnvironment reports partially installed SBE when installing the SBE as part of Azure Local instance deployment. SBE version 4.0.0.0 indicates a partially installed Solution Builder Extension (SBE).
Get-SolutionUpdateEnvironment
ResourceId : redmond
SbeFamily : AX-16G-45n0c
HardwareModel : AX-760
LastChecked : 08/01/2026 14:09:31
PackageVersions : {Solution: 12.2512.1002.16, Services: 10.2512.0.9, Platform: 12.2512.0.3021, SBE: 4.0.0.0}
CurrentVersion : 12.2512.1002.16
CurrentSbeVersion : 4.0.0.0
LastUpdated :
State : UpdateAvailable
HealthState : Success
HealthCheckResult : {Storage Services Physical Disks Summary, Storage Services Physical Disks Summary, Storage Services Physical Disks Summary, Storage Services Physical Disks Summary...}
HealthCheckDate : 07/01/2026 17:50:07
AdditionalData : {[SBEAdditionalData, Solution Builder extension is partially installed. Please install the latest Solution Builder Extension provided by your hardware vendor. For more information, see https://aka.ms/SBE.]}
Workaround
Reinstall the same SBE version using the SBE import method or automated download method after Azure Local instance deployment successfully completes.
Background
The SBE driver CAU plug-in expects all drivers and firmware in the SBE payload to be installed on the server during or prior to deployment. However, some of the drivers in the SBE payload may not apply to the server model or components in the server model. Microsoft is aware of this limitation and is working to resolve this issue in a future release.
The partially installed SBE issue can also occur if a component firmware version installed on the server is different than what is in the SBE payload. The SBE cannot update firmware or drivers during Azure Local instance deployment.
SBE installation will not downgrade drivers that have a newer version than the same driver in the SBE payload
Dell supports the driver and firmware versions listed here, Support Matrix | Solutions for Microsoft Azure.
Description
The SBE driver CAU plug-in will not attempt to downgrade installed drivers that are higher version than the ones in its payload unless otherwise specified by Dell.
AMD DRTM (Dynamic Root of Trust for Measurement) Driver Fails to Update on AX AMD Platforms When the DRTM Device Was Originally Enabled at Azure Local Instance Deployment Time and Later Disabled
Description
SBE installation fails because the driver CAU plug-in in the SBE is unable to update the AMD DRTM driver to a newer version that is in the SBE payload. The AMD DRTM driver is one of the AMD Chipset drivers in the SBE package. The AMD DRTM driver update fails because the AMD DRTM setting was originally enabled but later disabled.
Workaround
Verify that the AMD DRTM BIOS setting is on. Re-enable the AMD DRTM setting if it is off.
The DRTM option is in the BIOS configuration: System Security -> TPM Advanced Settings -> AMD DRTM
Make sure to suspend and drain the Azure Local cluster node prior to rebooting the node. Make sure that BitLocker protection is disabled for the boot volume on the cluster node before making BIOS configuration changes. Disable BitLocker if it is enabled for the boot volume C:\ prior to rebooting the server for the BIOS changes to take effect. Reenable BitLocker for the boot drive after the server successfully reboots.
Background
AMD DRTM is an advanced security feature that is available on modern AMD CPUs and is used to protect the secure boot enclaves. The AMD DRTM setting is enabled by default on AX servers with AMD CPUs that support the DRTM feature. AMD DRTM should not be disabled.
Previous Releases
3 - Azure Local Support Matrix (Dell 2512)
3.1 - Azure Local Support Matrix for 14G-15G (Dell 2512)
NOTE
SBE package 4.2.2512.xxxx and newer will only support Azure Local solution versions 12.*.1001.* or 12.*.1002.* (HCI OS 24H2) and newer.
Dell will support the use of SBE package 4.2.2509.xxxx on Azure Local instances running version 11.* (HCI OS 23H2) until April 2026. Dell recommends that instances running version 11.* be upgraded to 12.* as soon as possible to remain in a supported state.
Supported Platforms
| Model | Supported Operating System |
|---|---|
| AX-640 | Windows Server 2022 Datacenter Azure Stack HCI-24H2 |
| AX-740xd | Windows Server 2022 Datacenter Azure Stack HCI-24H2 |
| AX-6515 | Windows Server 2022 Datacenter Windows Server 2025 Datacenter Azure Stack HCI-24H2 |
| AX-7525 | Windows Server 2022 Datacenter Windows Server 2025 Datacenter Azure Stack HCI-24H2 |
| AX-650 | Windows Server 2022 Datacenter Windows Server 2025 Datacenter Azure Stack HCI-24H2 |
| AX-750 | Windows Server 2022 Datacenter Windows Server 2025 Datacenter Azure Stack HCI-24H2 |
Base Components
| Component | Type | Software Bundle | Minimum Supported Version | Supported Platforms | Supported OS |
|---|---|---|---|---|---|
| BIOS | Firmware DUP | 9M80P | 2.25.0 | AX-640 AX-740xd | NA | T4VCN | 2.24.0 |
| BIOS | Firmware DUP | 74JWM | 2.22.0 | AX-6515 | NA |
| BIOS | Firmware DUP | 2KY3W | 2.22.0 | AX-7525 | NA |
| BIOS | Firmware DUP | 8388K | 1.19.2 | AX-650 AX-750 | NA | 12YN5 | 1.18.1 |
| iDRAC9 with Lifecycle Controller | Firmware DUP | VP556 | 7.00.00.183 | AX-640 AX-740xd | NA |
| iDRAC9 with Lifecycle Controller | Firmware DUP | KYWDC | 7.20.80.50 | AX-6515 AX-7525 AX-650 AX-750 | NA |
| Non-expander Storage Backplane | Firmware DUP | VV85D | 4.35 | AX-6515 AX-640 AX-740xd | NA |
| Non-expander Storage Backplane | Firmware DUP | G69W6 | 7.16 | AX-7525 AX-750 | NA |
| Non-expander Storage Backplane | Firmware DUP | 5DV1W | 7.16 | AX-650 | NA |
| NVMe Switch Storage Backplane | Firmware DUP | 5XJWN | 1.05 | AX-750 | NA |
| Expander Storage Backplane | Firmware DUP | H9PV3 | 1.2 | AX-7525 AX-750 | NA |
| Expander Storage Backplane | Firmware DUP | 60K1J | 2.52 | AX-640 AX-740xd | NA |
| Expander Storage Backplane | Firmware DUP | 2F90T | 2.46 | AX-6515 | NA |
| Chipset driver for 14G Intel platforms | Driver DUP | 4DDMJ | 10.1.19913.8607 | AX-640 AX-740xd | Windows Server 2022 Datacenter Azure Stack HCI-24H2 |
| Chipset driver for 15G AMD platforms | Driver DUP | N28TF | 6.11.12.245 | AX-6515 AX-7525 | Windows Server 2022 Datacenter Windows Server 2025 Datacenter Azure Stack HCI-24H2 |
| Chipset driver for 15G Intel platforms | Driver DUP | C2MC3 | 10.1.19928.8615 | AX-650 AX-750 | Windows Server 2022 Datacenter Windows Server 2025 Datacenter Azure Stack HCI-24H2 |
| iDRAC Service Module | Firmware DUP | 258RC | 5.4.0.0 | AX-640 AX-740xd AX-6515 AX-7525 AX-650 AX-750 | NA |
| CPLD | Firmware DUP | 9N4DH | 1.0.6 | AX-640 | NA |
| CPLD | Firmware DUP | G65GH | 1.1.4 | AX-740xd | NA |
| CPLD | Firmware DUP | 79XGF | 1.0.7 | AX-6515 | NA |
| CPLD | Firmware DUP | 4NMC7 | 1.2.0 | AX-7525 | NA |
| CPLD | Firmware DUP | FCTDF | 1.1.1 | AX-650 AX-750 | NA |
Network Adapters
| Component | Part Number | SDDC Advanced Qualification | RDMA Protocol | Firmware Software Bundle | Firmware Minimum Supported Version | Driver Software Bundle | Driver Minimum Supported Version | Supported OS | Supported Platforms |
|---|---|---|---|---|---|---|---|---|---|
| Broadcom 5720 Dual Port 1GbE On-Board LOM | JDN4V | Management | NA | 5V215 | 23.31.1 | JDV91 | 233.1.181.0 | Windows Server 2022 Datacenter Windows Server 2025 Azure Stack HCI-24H2 | AX-650 |
| Broadcom 5720 Dual Port 1 GbE Network LOM Mezz Card | KJMHJ | Management | N/A | 5V215 | 23.31.1 | JDV91 | 233.1.181.0 | Windows Server 2022 Datacenter Windows Server 2025 Azure Stack HCI-24H2 | AX-6515 |
| Broadcom 5720 Dual Port 1GbE On-Board LOM | 6V45N | Management | NA | 5V215 | 23.31.1 | JDV91 | 233.1.181.0 | Windows Server 2022 Datacenter Windows Server 2025 Azure Stack HCI-24H2 | AX-750 |
| Broadcom 5720 Dual Port 1GbE On-Board LOM | 74H08 | Management | NA | 5V215 | 23.31.1 | JDV91 | 233.1.181.0 | Windows Server 2022 Datacenter Windows Server 2025 Azure Stack HCI-24H2 | AX-7525 |
| Broadcom 57504 Quad Port 10/25GbE SFP28 Adapter, PCIe FH | J3D14 | Management Compute (Premium) Storage (Premium) | RoCEv2 | HVN2R | 23.31.18.10 | T5K6M | 233.1.181.0 | Windows Server 2025 Datacenter Azure Stack HCI-24H2 | AX-4520c |
| Broadcom 57412 2 Port 10Gb SRP+ + 5720 2 Port 1 GB Base-T, rNDC | NWMNX | Management Compute (Standard) | Not Supported | HVN2R | 23.31.18.10 | T5K6M | 233.1.181.0 | Windows Server 2022 Datacenter Windows Server 2025 Datacenter Azure Stack HCI-24H2 | AX-640 AX-740xd |
| Broadcom BCM57414 25G SFP Dual Port OCP3 Mezz, V3 | 24FG6 | Management Compute (Standard) | Not Supported | HVN2R | 23.31.18.10 | T5K6M | 233.1.181.0 | Windows Server 2022 Datacenter Windows Server 2025 Datacenter Azure Stack HCI-24H2 | AX-6515 |
| Broadcom 57416 Dual Port 10 GbE SFP+ Network LOM Mezz Card | 6XH9X | ||||||||
| Broadcom 57414 Dual Port 25 Gb E SFP+ Network LOM Mezz Card | 930PP | ||||||||
| Broadcom 57416 Dual Port 10 GbE BaseT Network LOM Mezz Card | J4RN3 | ||||||||
| Broadcom BCM57414 25G SFP Dual Port OCP3 Mezz | NHN45 | ||||||||
| Broadcom 57416 Dual Port 10 Gb E SFP+ Network LOM Mezz Card | WC9TR | ||||||||
| Broadcom 57412 Dual Port 10GbE SFP+, OCP NIC 3.0 | CP610 | Management Compute (Standard) | Not Supported | HVN2R | 23.31.18.10 | T5K6M | 233.1.181.0 | Windows Server 2022 Datacenter Windows Server 2025 Datacenter Azure Stack HCI-24H2 | AX-7525 AX-650 AX-750 |
| Broadcom 57414 Dual Port 10/25GbE SFP28, OCP NIC 3.0 | KHCTP | ||||||||
| Broadcom 57416 Dual Port 10GbE BASE-T Adapter, OCP NIC 3.0 | T6HR8 | ||||||||
| Broadcom 57504 Quad Port 10/25GbE,SFP28, OCP NIC 3.0 | X1KR4 | ||||||||
| Intel X710 DP 10Gb DA/SFP+ Ethernet, NDC | 6VDPG | Management Compute (Standard) | N/A | DC20J | 24.0.5 | PH5GK | 24.0.0 | Windows Server 2022 Datacenter Windows Server 2025 Datacenter Azure Stack HCI-24H2 | AX-7525 AX-640 AX-740xd |
| Intel X710-T4L Quad Port 10GbE BASE-T, OCP NIC 3.0 | 50RV4 | Management Compute (Standard) | N/A | DC20J | 24.0.5 | PH5GK | 24.0.0 | Windows Server 2022 Datacenter Windows Server 2025 Datacenter Azure Stack HCI-24H2 | AX-7525 AX-650 AX-750 |
| Intel(R) Ethernet 10G 4P X710-T4L-t Adapter | ND4PT | ||||||||
| Intel X710 Quad Port 10GbE SFP+, OCP NIC 3.0 | VF81P | ||||||||
| Intel X710-T2L Dual Port 10GbE BASE-T, OCP NIC 3.0 | VMFKR | ||||||||
| Intel X710 Dual Port 10GbE SFP+, OCP NIC 3.0 | YJYK1 | ||||||||
| Intel E823 | KJMHJ | Management Compute (Premium) Storage (Premium) | iWARP,RoCEv2 | N11TD | 24.0.5 | PH5GK | 24.0.0 | Windows Server 2022 Datacenter Windows Server 2025 Datacenter Azure Stack HCI-24H2 | AX-4510c AX-4520c |
| Intel E810-XXV Dual Port 25GbE SFP28 Adapter, PCIe LP | 6J1N1 | Management Compute (Premium) Storage (Premium) | iWARP,RoCEv2 | N11TD | 24.0.5 | PH5GK | 24.0.0 | Windows Server 2022 Datacenter Windows Server 2025 Datacenter Azure Stack HCI-24H2 | AX-7525 AX-650 AX-750 |
| Intel E810-CQDA2 Dual Port 100GbE QSFP28 Adapter, PCIe FH | 85F8F | ||||||||
| Intel E810-XXV Dual Port 25GbE SFP28 Adapter, PCIe FH | CD16M | ||||||||
| Intel E810-CQDA2 Dual Port 100GbE QSFP28 Adapter, PCIe LP | DWNRF | ||||||||
| Mellanox ConnectX-6 Dx Dual Port 100GbE QSFP56 PCIe Adapter, LP | F6FXM | Management Compute (Premium) Storage (Premium) | RoCEv2 | 2CMVW | 22.41.10.00 | G6M58 | 24.04.03 | Windows Server 2022 Datacenter Windows Server 2025 Datacenter Azure Stack HCI-24H2 | AX-6515 AX-7525 AX-650 AX-750 |
| Mellanox ConnectX-6 Dx Dual Port 100GbE QSFP56 PCIe Adapter, FH | 8P2T2 | Management Compute (Premium) Storage (Premium) | RoCEv2 | 2CMVW | 22.41.10.00 | G6M58 | 24.04.03 | Windows Server 2022 Datacenter Windows Server 2025 Datacenter Azure Stack HCI-24H2 | AX-7525 AX-650 AX-750 |
| Mellanox ConnextX-4 Lx Dual Port 25Gbe DA/SFP Network Adapter, LP | 20NJD | Management Compute (Premium) Storage (Premium) | RoCEv2 | XGP2X | 14.32.20.04 | G6M58 | 24.04.03 | Windows Server 2022 Datacenter Windows Server 2025 Datacenter Azure Stack HCI-24H2 | AX-640 AX-740xd |
| Mellanox ConnectX-4 Lx Dual Port 25GbE DA/SFP rNDC | R887V | Management Compute (Premium) Storage (Premium) | RoCEv2 | XGP2X | 14.32.20.04 | G6M58 | 24.04.03 | Windows Server 2022 Datacenter Windows Server 2025 Datacenter Azure Stack HCI-24H2 | AX-640 R640 Storage Spaces Direct RN |
| Mellanox ConnextX-4 Lx Dual Port 25Gbe DA/SFP Network Adapter, FH | MRT0D | Management Compute (Premium) Storage (Premium) | RoCEv2 | XGP2X | 14.32.20.04 | G6M58 | 24.04.03 | Windows Server 2022 Datacenter Windows Server 2025 Datacenter Azure Stack HCI-24H2 | AX-740xd |
| Mellanox ConnectX-4 LX Dual Port 10/25GbE SFP28 Adapter, FH, V2 | YGRX3 | ||||||||
| Mellanox Connectx-5 EX Dual Port 100GbE QSFP20 PCIe Adapter, FH | 71C1T | Management Compute (Premium) Storage (Premium) | RoCEv2 | XY16R | 16.35.30.06 | G6M58 | 24.04.03 | Windows Server 2022 Datacenter Windows Server 2025 Datacenter Azure Stack HCI-24H2 | AX-6515 AX-7525 AX-640 AX-740xd AX-650 AX-750 |
| Mellanox Connectx-5 EX Dual Port 100GbE QSFP20 PCIe Adapter, LP | 9FTMY | ||||||||
| Mellanox ConnectX-5 Dual Port 10/25GbE SFP28 Adapter, PCIe FH, V2 | F7V1F | ||||||||
| Mellanox ConnectX-5 Dual Port 10/25GbE SFP28 Adapter, PCIe LP, V2 | JGWVY | ||||||||
| Mellanox ConnectX-5 Dual Port 25GbE SFP28 Adapter, FH | TDNNT | ||||||||
| Mellanox ConnectX-5 Dual Port 25GbE SFP28 Adapter, LP | V5DG9 | ||||||||
| NVIDIA ConnectX-6LX Dual Port 25G GbE SFP28 | DN78C | Management Compute (Premium) Storage (Premium) | RoCEv2 | 1H4PM | 26.41.10.00 | G6M58 | 24.04.03 | Windows Server 2022 Datacenter Windows Server 2025 Datacenter Azure Stack HCI-24H2 | AX-650 AX-750 AX-7525 |
| Nvidia ConnectX-6 Lx Dual Port 10/25GbE SFP28 Adapter, PCIe LP | 6XJXK | Management Compute (Premium) Storage (Premium) | RoCEv2 | 1H4PM | 26.41.10.00 | G6M58 | 24.04.03 | Windows Server 2022 Datacenter Windows Server 2025 Datacenter Azure Stack HCI-24H2 | AX-6515 AX-7525 AX-650 AX-750 |
| Nvidia ConnectX-6 Lx Dual Port 10/25GbE SFP28 Adapter, PCIe FH | R5WK9 | ||||||||
| QLogic 57800 2x10Gb DA/SFP+ +2x1Gb BT NDC | 165T0 | Management | N/A | 9KYR0 | 16.20.00 | VYWY1 | 36.20.02 | Windows Server 2022 Datacenter Azure Stack HCI-24H2 | AX-640 AX-740xd |
| QLogic 57800 2x10Gb BT + 2x1Gb BT NDC | G8RPD | ||||||||
| QLogic FastLinQ 41162 Dual Port 10GbE BASE-T and Dual Port 1GbE BASE-T, rNDC | 0D1WT | Management Compute (Premium) | iWARP | W93NY | 16.30.09 | RXJPP | 36.30.16 | Windows Server 2022 Datacenter Windows Server 2025 Datacenter Azure Stack HCI-24H2 | AX-640 AX-740xd |
| QLogic FastLinQ 41164 Quad Port 10GbE BASE-T, rNDC | X1TD1 | Management Compute (Premium) | iWARP | W93NY | 16.30.09 | RXJPP | 36.30.16 | Windows Server 2022 Datacenter Windows Server 2025 Datacenter Azure Stack HCI-24H2 | AX-6515 AX-7525 AX-640 AX-740xd AX-650 AX-750 |
| QLogic FastLinQ 41164 Quad Port 10GbE SFP+, rNDC | XVVY1 | ||||||||
| QLogic FastLinQ 41262 Dual Port 25Gb SFP28 Adapter, LP | 415DX | Management Compute (Premium) Storage (Premium) | iWARP | W93NY | 16.30.09 | RXJPP | 36.30.16 | Windows Server 2022 Datacenter Windows Server 2025 Datacenter Azure Stack HCI-24H2 | AX-6515 AX-7525 AX-640 AX-740xd |
| QLogic FastLinQ 41262 Dual Port 25Gbe SFP28, rNDC | 4KF8J | ||||||||
| QLogic FastLinQ 41262 Dual Port 25Gb SFP28 Adapter, FH | 51GRM |
Network Switches
NOTE
A list of supported Network Switch models along with the supported firmware versions can be found here, Physical network requirements for Azure Local.GPUs
| GPU Model | Vendor | Description | Part Number | Firmware version | Driver Version | GPU-P capable | Supported Platform | Supported OS |
|---|---|---|---|---|---|---|---|---|
| A10 | NVIDIA | NVIDIA Ampere A10, PCIe, 150W, 24GB,GPU, V2 | 6KNWW | 94.02.5C.00.04 | 528.89 WHQL | Yes | AX-750 AX-7525 | Azure Stack HCI-24H2 |
| A16 | NVIDIA | NVIDIA Ampere A16, PCIe, 250W, 64GB Passive, Double Wide, Full Height GPU | 8F04V | 94.07.54.00.45 | 528.89 WHQL | Yes | AX-750 AX-7525 | Azure Stack HCI-24H2 |
| A16 | NVIDIA | NVIDIA Ampere A16, PCIe, 250W, 64GB Passive, Double Wide, Full Height GPU,V2 | D1P1T | 94.07.54.00.45 | 528.89 WHQL | Yes | AX-750 AX-7525 | Azure Stack HCI-24H2 |
| A2 | NVIDIA | NVIDIA Ampere A2, PCIe, 60W, 16GB Passive, Single Wide, Low Profile GPU, V2 | H98K0 | 94.07.5B.00.55 | 528.89 WHQL | Yes | AX-650 AX-750 AX-7525 | Azure Stack HCI-24H2 |
| A2 | NVIDIA | NVIDIA Ampere A2, PCIe, 60W, 16GB Passive, Single Wide, Full Height GPU, V2 | MG5JX | 94.07.5B.00.55 | 528.89 WHQL | Yes | AX-750 AX-7525 | Azure Stack HCI-24H2 |
| A30 | NVIDIA | NVIDIA Ampere A30, PCIe, 165W, 24GB Passive, Double Wide, Full Height GPU | W3C1G | 92.00.58.00.01 | 528.89 WHQL | No | AX-750 AX-7525 | Azure Stack HCI-24H2 |
| A30 | NVIDIA | NVIDIA Ampere A30, PCIe, 165W, 24GB Passive, Double Wide, Full Height GPU, V2 | RV08M | 92.00.58.00.01 | 528.89 WHQL | No | AX-750 AX-7525 | Azure Stack HCI-24H2 |
| A40 | NVIDIA | NVIDIA Ampere A40, PCIe, 300W, 48GB Passive, Double Wide, Full Height GPU | W6GX6 | 94.02.5C.00.0F | 528.89 WHQL | Yes | AX-750 AX-7525 | Azure Stack HCI-24H2 |
| L4 | NVIDIA | NVIDIA L4, PCIe, 72W, 24GB Passive, Single Wide Low Profile GPU | V9XT2 | 95.04.29.00.06 | 528.89 WHQL | Yes | AX-650 AX-750 AX-7525 | Azure Stack HCI-24H2 |
| L4 | NVIDIA | NVIDIA L4, PCIe, 72W, 24GB Passive, Single Wide Full Height GPU | NG3PY | 95.04.29.00.06 | 528.89 WHQL | Yes | AX-750 AX-7525 | Azure Stack HCI-24H2 |
| L40 | NVIDIA | NVIDIA Ampere L40, PCIe, 300W, 48GB Passive, Double Wide, Full Height, Full Length, GPU with cable | VHNWT | 95.02.39.00.01 | 553.62 | Yes | AX-750 AX-7525 | Azure Stack HCI-24H2 |
| T4 | NVIDIA | NVIDIA Tesla T4 16GB, PCIe, 70W, 16GB Passive, Single Wide, Full Height GPU | HCKJM | 90.04.96.00.01 | 528.89 WHQL | No | AX-750 | Azure Stack HCI-24H2 |
| T4 | NVIDIA | NVIDIA Tesla T4 16GB, PCIe, 70W, Passive, Single Wide, Low Profile GPU | 7PH29 | 90.04.96.00.01 | 528.89 WHQL | No | AX-750 | Azure Stack HCI-24H2 |
NOTE
Dell update packages are not available for GPU cards, please download the latest driver version from NVIDIA driver download page.Storage Controllers
| Component | Dell Part Number | Firmware Software Bundle | Firmware Minimum Supported Version | Driver Software Bundle | Driver Minimum Supported Version | Supported Platforms | Supported OS |
|---|---|---|---|---|---|---|---|
| BOSS-S1 | 2MFVD | 3P39V | 2.5.13.3024 | 7004G | 1.2.0.1055 | AX-6515 AX-7525 AX-640 AX-740xd | Windows Server 2022 Datacenter Azure Stack HCI-24H2 |
| BOSS-S2 | FGNRW | TTR5R | 2.5.13.4009 | 7004G | 1.2.0.1055 | AX-7525 AX-650 AX-750 | Windows Server 2022 Datacenter Azure Stack HCI-24H2 |
| HBA330 Controller, 12Gps Mini Card | P2R3R | 124X2 | 16.17.01.00 | Inbox | 2.51.27.80 | AX-640 AX-740XD AX-6515 | Windows Server 2022 Datacenter Azure Stack HCI-24H2 |
| HBA330 Controller, 12Gps Mini Card, LP | J7TNV | NKNVC | 16.17.01.00 | Inbox | 2.51.27.80 | AX-740xd | Windows Server 2022 Datacenter Azure Stack HCI-24H2 |
| HBA355i | K6MCJ | CG0P9 | 33.15.00.00 | R31NP | 2.61.74.00 | AX-7525 AX-650 AX-750 | Windows Server 2022 Datacenter Azure Stack HCI-23H2 |
| HBA355i | K6MCJ | CG0P9 | 33.15.00.00 | HDH8G | 2.61.74.00 | AX-7525 AX-650 AX-750 | Windows Server 2025 Datacenter Azure Stack HCI-24H2 |
SATA M.2 SSD Boot Only
| Type | Drive Type | Form Factor | Endurance | Vendor | Series | Model | Device Part Number (P/N) | Firmware Software Bundle | Firmware Minimum Supported Version | Capacity | Use |
|---|---|---|---|---|---|---|---|---|---|---|---|
| SSD | SATA | M.2 | NA | Intel | S3520 | SSDSC2BB120G7R | 394XT | CHJGV | DL43 | 120 GB | Boot |
| SSD | SATA | M.2 | NA | Micron | 5100 | MTFDDAV240TCB | TC2RP | H6NHD | E013 | 240 GB | Boot |
| SSD | SATA | M.2 | NA | Micron | 5100 | MTFDDAV480TCB | GPGC0 | H6NHD | E013 | 480 GB | Boot |
| SSD | SATA | M.2 | NA | Micron | 5300 | MTFDDAV240TDU | T2GFX | KT63Y | J008 | 240 GB | Boot |
| SSD | SATA | M.2 | NA | Micron | 5300 | MTFDDAV480TDS | 7RKD7 | KT63Y | J008 | 480 GB | Boot |
| SSD | SATA | M.2 | Read Intensive | Intel | Youngsville RR S4520 | SSDSCKKB240GZR | CM88M | VJPKG | DL7C | 240 GB | Boot |
| SSD | SATA | M.2 | Read Intensive | Intel | Youngsville S4510 | SSDSCKKB240G8R | DMC15 | Y1P10 | DL6R | 240 GB | Boot |
| SSD | SATA | M.2 | Read Intensive | Micron | 5400 | MTFDDAV240TGC-1BC1ZABDA | T4MJ3 | RJ0WY | K003 | 240 GB | Boot |
SAS 2.5" HDD Capacity Only
| Type | Drive Type | Form Factor | Endurance | Vendor | Series | Model | Device Part Number (P/N) | Firmware Software Bundle | Firmware Minimum Supported Version | Capacity | Use |
|---|---|---|---|---|---|---|---|---|---|---|---|
| HDD | SAS | 2.5 | NA | Seagate | Avenger | ST2000NX0463 | TMVN7 | GW3V7 | NT32 | 2 TB | Capacity |
| HDD | SAS | 2.5 | NA | Seagate | Skybolt | DL2400MM0159 | RWR8F | DRHV4 | ST5J | 2.4 TB | Capacity |
| HDD | SAS | 2.5 | NA | Seagate | Skybolt | ST2400MM0159 | 36YG1 | 7N5DH | ST7G | 2.4 TB | Capacity |
| HDD | SAS | 2.5 | NA | Toshiba | AL15SE | AL15SEB24EQY | F9NWJ | J11N2 | EF09 | 2.4 TB | Capacity |
| HDD | SAS | 2.5 | NA | Seagate | Skybolt ServoBP | BL2400MM0159 | 1D0F5 | 00P56 | SBSA | 2.4TB | Capacity |
SATA 2.5" HDD Capacity Only
| Type | Drive Type | Form Factor | Endurance | Vendor | Series | Model | Device Part Number (P/N) | Firmware Software Bundle | Firmware Minimum Supported Version | Capacity | Use |
|---|---|---|---|---|---|---|---|---|---|---|---|
| HDD | SATA | 2.5 | NA | Seagate | Avenger | ST2000NX0423 | VR92X | GMW4P | NB33 | 2 TB | Capacity |
SATA 3.5" HDD Capacity Only
| Type | Drive Type | Form Factor | Endurance | Vendor | Series | Model | Device Part Number (P/N) | Firmware Software Bundle | Firmware Minimum Supported Version | Capacity | Use |
|---|---|---|---|---|---|---|---|---|---|---|---|
| HDD | SATA | 3.5 | NA | HGST | Aries K Plus | HUS726020ALA610 | 8NP2N | KH52Y | KV46 | 2 TB | Capacity |
| HDD | SATA | 3.5 | NA | HGST | Aries K Plus | HUS726040ALA610 | 61FFW | KH52Y | KV46 | 4 TB | Capacity |
| HDD | SATA | 3.5 | NA | HGST | Rainier MLK | HUS722T2TALA600 | V9H6C | V3DJM | MU03 | 2 TB | Capacity |
| HDD | SATA | 3.5 | NA | Toshiba | Tomcat R | MG04ACA200NY | NPVM6 | 6D4CG | FK5D | 2 TB | Capacity |
| HDD | SATA | 3.5 | NA | Toshiba | Tomcat R | MG04ACA400NY | 95M6K | 6D4CG | FK5D | 4 TB | Capacity |
| HDD | SATA | 3.5 | NA | Seagate | Nemo | ST2000NM0018-2F3130 | W8FW5 | CMK5N | EA04 | 2 TB | Capacity |
| HDD | SATA | 3.5 | NA | Seagate | Makara BP | ST2000NM0145-2DC104 | WG9R0 | M5GJ1 | DB34 | 2 TB | Capacity |
| HDD | SATA | 3.5 | NA | Seagate | Makara BP | ST4000NM0265-2DC107 | MWHY9 | M5GJ1 | DB34 | 4 TB | Capacity |
| HDD | SATA | 3.5 | NA | HGST | Vela-A | HUS726T4TALA6L0 | YH3T9 | HV5HH | PV09 | 4 TB | Capacity |
| HDD | SATA | 3.5 | NA | HGST | Vela-AP | HUS728T8TALE6L0 | 1WMVC | T0RX4 | RT09 | 8 TB | Capacity |
| HDD | SATA | 3.5 | NA | HGST | Libra HE10 | HUH721008ALE600 | KRV2W | H12N2 | LT21 | 8 TB | Capacity |
| HDD | SATA | 3.5 | NA | Seagate | Makara Plus | ST8000NM0205-2FF112 | 92MDW | MR6RH | PB53 | 8 TB | Capacity |
| HDD | SATA | 3.5 | NA | Toshiba | MG06 | MG06ACA800EY | 9X09C | PT7D8 | GA09 | 8 TB | Capacity |
| HDD | SATA | 3.5 | NA | HGST | Leo-A He12 | HUH721212ALE600 | T2YHT | JCYF6 | NT11 | 12 TB | Capacity |
| HDD | SATA | 3.5 | NA | Toshiba | MG07 | MG07ACA12TEY | 753F0 | 0942Y | GB03 | 12 TB | Capacity |
| HDD | SATA | 3.5 | NA | Toshiba | MG08AC | MG08ACA16TEY | HPGJ4 | WTNDC | GC04 | 16 TB | Capacity |
| HDD | SATA | 3.5 | NA | Toshiba | MG08AD | MG08ADA400NY | W2M9N | F73C5 | GD05 | 4 TB | Capacity |
| HDD | SATA | 3.5 | NA | Seagate | Cimarron | ST4000NM016A-2HZ130 | XPJ47 | RWK48 | CAJD | 4 TB | Capacity |
| HDD | SATA | 3.5 | NA | Seagate | Cimarron | ST8000NM012A-2KE131 | F4JXT | TF6TF | CALF | 8 TB | Capacity |
| HDD | SATA | 3.5 | NA | Seagate | Evans BP | ST12000NM002J-2TY133 | KTJTY | 4MPD6 | PALB | 12 TB | Capacity |
| HDD | SATA | 3.5 | NA | Seagate | Evans BP | ST16000NM002J-2TW133 | JWV1P | 4MPD6 | PALB | 16 TB | Capacity |
| HDD | SATA | 3.5 | NA | Toshiba | MG08AD | MG08ADA800EY | T5XR5 | 65CDF | GE02 | 8 TB | Capacity |
| HDD | SATA | 3.5 | NA | Seagate | Cimarron BP | ST8000NM023B-2TJ133 | J7W80 | P183W | LA0C | 8 TB | Capacity |
| HDD | SATA | 3.5 | NA | Seagate | Cimarron BP | ST4000NM018B-2TF130 | 6KR2M | T04YV | LC0A | 4 TB | Capacity |
| HDD | SATA | 3.5 | NA | Seagate | Cimarron BP | ST8000NM023B-2TJ133 | J7W80 | P183W | LA0C | 8 TB | Capacity |
SAS 3.5" HDD Capacity Only
| Type | Drive Type | Form Factor | Endurance | Vendor | Series | Model | Device Part Number (P/N) | Firmware Software Bundle | Firmware Minimum Supported Version | Capacity | Use |
|---|---|---|---|---|---|---|---|---|---|---|---|
| HDD | SAS | 3.5 | NA | HGST | Aries K Plus | HUS726020ALS210 | VH6FW | 8W7XP | KU46 | 2 TB | Capacity |
| HDD | SAS | 3.5 | NA | HGST | Aries K Plus | HUS726040ALS210 | X4FKY | 8W7XP | KU46 | 4 TB | Capacity |
| HDD | SAS | 3.5 | NA | Toshiba | Tomcat R | MG04SCA20ENY | HHX14 | RG9MK | EG03 | 2 TB | Capacity |
| HDD | SAS | 3.5 | NA | Toshiba | Tomcat R | MG04SCA40ENY | 1MVTT | RG9MK | EG03 | 4 TB | Capacity |
| HDD | SAS | 3.5 | NA | Seagate | Makara BP | ST2000NM0155 | 7RCGV | XKD4M | DT34 | 2 TB | Capacity |
| HDD | SAS | 3.5 | NA | Seagate | Makara BP | ST4000NM0295 | 5JH5X | XKD4M | DT34 | 4 TB | Capacity |
| HDD | SAS | 3.5 | NA | HGST | Vela-A | HUS726T4TALS200 | NT1X2 | J5K8G | PU09 | 4 TB | Capacity |
| HDD | SAS | 3.5 | NA | HGST | Vela-AP | HUS728T8TAL5200 | 44YFV | 8GM6M | RS09 | 8 TB | Capacity |
| HDD | SAS | 3.5 | NA | HGST | Libra HE10 | HUH721008AL5200 | KRDKK | MGW91 | LS21 | 8 TB | Capacity |
| HDD | SAS | 3.5 | NA | Seagate | Makara Plus | ST8000NM0185 | M40TH | 6421F | PT55 | 8 TB | Capacity |
| HDD | SAS | 3.5 | NA | Toshiba | MG06 | MG06SCA800EY | FV725 | 4G5GY | EH0D | 8 TB | Capacity |
| HDD | SAS | 3.5 | NA | HGST | Leo-A He12 | HUH721212AL5200 | 9HXK6 | 04PM5 | NS11 | 12 TB | Capacity |
| HDD | SAS | 3.5 | NA | Seagate | Mobula BP | ST12000NM0158 | YMN53 | VTX9C | RSL5 | 12 TB | Capacity |
| HDD | SAS | 3.5 | NA | Toshiba | MG07 | MG07SCA12TEY | DK7C9 | NFFHM | EI0D | 12 TB | Capacity |
| HDD | SAS | 3.5 | NA | Toshiba | MG07 | MG07SCA12TEY | KFJ7G | NFFHM | EI0D | 12 TB | Capacity |
| HDD | SAS | 3.5 | NA | Toshiba | MG09 | MG09SCA12TEY | 0N96X | 20Y02 | EM06 | 12 TB | Capacity |
| HDD | SAS | 3.5 | NA | Toshiba | MG08SC | MG08SCA16TEY | 8MG73 | 9N3RR | EJ09 | 16 TB | Capacity |
| HDD | SAS | 3.5 | NA | Toshiba | MG08SC | MG08SCA16TEY | 4N7V0 | 9N3RR | EJ09 | 16 TB | Capacity |
| HDD | SAS | 3.5 | NA | Toshiba | MG08SC | MG08SCA16TEY | 24HF9 | 9N3RR | EJ09 | 16 TB | Capacity |
| HDD | SAS | 3.5 | NA | Seagate | Evans | ST16000NM010G | CNXPV | 3YP54 | ESL9 | 16 TB | Capacity |
| HDD | SAS | 3.5 | NA | WD | Paris-C | WUH721816AL5200 | VF206 | GY6MD | US09 | 16 TB | Capacity |
| HDD | SAS | 3.5 | NA | Seagate | Cimarron | ST4000NM017A | KRM6X | J12RT | CSJA | 4 TB | Capacity |
| HDD | SAS | 3.5 | NA | Seagate | Cimarron | ST8000NM014A | 0N660 | 0HG6Y | CSLE | 8 TB | Capacity |
| HDD | SAS | 3.5 | NA | Seagate | Cimarron BP | ST4000NM019B | 10N7R | 3P5N0 | LW0B | 4 TB | Capacity |
| HDD | SAS | 3.5 | NA | Seagate | Cimarron BP | ST8000NM024B | C5HD0 | NM6GP | LS0C | 8 TB | Capacity |
| HDD | SAS | 3.5 | NA | Toshiba | MG08SD | MG08SDA400NY | FN2YX | GTG81 | EK06 | 4 TB | Capacity |
| HDD | SAS | 3.5 | NA | Seagate | Evans BP | ST12000NM006J | M1C0T | XF65R | PSLG | 12 TB | Capacity |
| HDD | SAS | 3.5 | NA | Seagate | Evans BP | ST16000NM006J | 41DXR | XF65R | PSLG | 16 TB | Capacity |
| HDD | SAS | 3.5 | NA | Toshiba | MG08SD | MG08SDA800EY | NJWMG | F95CX | EL02 | 8 TB | Capacity |
| HDD | SAS | 3.5 | NA | Seagate | Cimarron BP | ST8000NM024B | C5HD0 | NM6GP | LS0C | 8 TB | Capacity |
| HDD | SAS | 3.5 | NA | Seagate | EvansBP | ST16000NM006J | 41DXR | XF65R | PSLG | 16 TB | Capacity |
| HDD | SAS | 3.5 | NA | Seagate | LongsPeak | ST20000NM004D | R3G03 | WCTTD | GS09 | 20 TB | Capacity |
| HDD | SAS | 3.5 | NA | Toshiba | MG10SD | MG10SDA800EY | VJDMM | 99TKP | EP02 | 8 TB | Capacity |
SATA 2.5" SSD Cache or Capacity
| Type | Drive Type | Form Factor | Endurance | Vendor | Series | Model | Device Part Number (P/N) | Firmware Software Bundle | Firmware Minimum Supported Version | Capacity | Use |
|---|---|---|---|---|---|---|---|---|---|---|---|
| SSD | SATA | 2.5 | Mixed Use | Intel | Youngsville-RR | SSDSC2KG019TZR | 8RXV5 | VJPKG | DL7C | 1.92 TB | Cache, Capacity |
| SSD | SATA | 2.5 | Mixed Use | Toshiba | HK4 | THNSF8800CCSE | VCRY6 | H3XHN | DACB | 800 GB | Cache, Capacity |
| SSD | SATA | 2.5 | Mixed Use | Toshiba | HK4 | THNSF81D60CSE | DMF5Y | H3XHN | DACB | 1.6 TB | Cache, Capacity |
| SSD | SATA | 2.5 | Mixed Use | Micron | 5300 | MTFDDAK960TDT | XMWMK | KT63Y | J008 | 960 GB | Cache, Capacity |
| SSD | SATA | 2.5 | Mixed Use | Micron | 5300 | MTFDDAK1T9TDT | MMCDY | KT63Y | J008 | 1.92 TB | Cache, Capacity |
| SSD | SATA | 2.5 | Mixed Use | Micron | 5400 | MTFDDAK3T8TGB-1BC1ZABDA | 34JK8 | JTW3W | K403 | 3.84 TB | Cache,Capacity |
| SSD | SATA | 2.5 | Mixed Use | Samsung | SM863a | MZ7KM960HMJP0D3 | DD4G0 | 97D8J | GD57 | 960 GB | Cache, Capacity |
| SSD | SATA | 2.5 | Mixed Use | Samsung | SM863a | MZ7KM1T9HMJP0D3 | K5P0T | 97D8J | GD57 | 1.92 TB | Cache, Capacity |
| SSD | SATA | 2.5 | Mixed Use | Samsung | SM883 | MZ7KH960HAJR0D3 | YDHYX | 3J3JR | HF58 | 960 GB | Cache, Capacity |
| SSD | SATA | 2.5 | Mixed Use | Samsung | SM883 | MZ7KH1T9HAJR0D3 | 71K37 | 3J3JR | HF58 | 1.92 TB | Cache, Capacity |
| SSD | SATA | 2.5 | Mixed Use | Intel | S4600 | SSDSC2KG960G7R | TR3MY | V141M | DL5C | 960 GB | Cache, Capacity |
| SSD | SATA | 2.5 | Mixed Use | Intel | S4600 | SSDSC2KG019T7R | MWKF2 | V141M | DL5C | 1.92 TB | Cache, Capacity |
| SSD | SATA | 2.5 | Mixed Use | Intel | S4610 | SSDSC2KG960G8R | X31G3 | 4DW70 | DL6B | 960 GB | Cache, Capacity |
| SSD | SATA | 2.5 | Mixed Use | Intel | S4610 | SSDSC2KG019T8R | F8N2K | 4DW70 | DL6B | 1.92 TB | Cache, Capacity |
| SSD | SATA | 2.5 | Mixed Use | Intel | S4610 | SSDSC2KG019T8R | 55J8H | 4DW70 | DL6B | 1.92 TB | Cache, Capacity |
| SSD | SATA | 2.5 | Mixed Use | Micron | 5200 | MTFDDAK960TDN | HY1F8 | W2X8N | F005 | 960 GB | Cache, Capacity |
| SSD | SATA | 2.5 | Mixed Use | Micron | 5200 | MTFDDAK1T9TDN | XKF5Y | W2X8N | F005 | 1.92 TB | Cache, Capacity |
| SSD | SATA | 2.5 | Mixed Use | Kioxia | HK6-V | KHK6YVSE960G | XW4D1 | W0YR1 | DBC4 | 960 GB | Cache, Capacity |
| SSD | SATA | 2.5 | Mixed Use | Kioxia | HK6-V | KHK6YVSE1T92 | 0DXJ7 | W0YR1 | DBC4 | 1.92 TB | Cache, Capacity |
| SSD | SATA | 2.5 | Mixed Use | Hynix | SE5130 | HFS960G3E2X149N | G162V | 4T2FN | DG00 | 960GB | Cache,Capacity |
| SSD | SATA | 2.5 | Mixed Use | Hynix | SE5130 | HFS1T9G3E2X149N | HCR09 | 4T2FN | DG00 | 1.92TB | Cache,Capacity |
| SSD | SATA | 2.5 | Mixed Use | Intel | Youngsville-RR | SSDSC2KG960GZR | 8MHYH | VJPKG | DL7C | 960 GB | Cache,Capacity |
| SSD | SATA | 2.5 | Mixed Use | Intel | Youngsville-RR | SSDSC2KG019TZR | 8RXV5 | VJPKG | DL7C | 1.92 TB | Cache,Capacity |
| SSD | SATA | 2.5 | Mixed Use | Intel | Youngsville RR (New) (S4620) | SSDSC2KG960GZR | DYMD0 | VJPKG | DL7C | 960 GB | Cache,Capacity |
| SSD | SATA | 2.5 | Mixed Use | Intel | Youngsville RR (New) (S4620) | SSDSC2KG019TZR | 6XW3M | VJPKG | DL7C | 1.92 TB | Cache,Capacity |
| SSD | SATA | 2.5 | Mixed Use | Samsung | PM897 | MZ7L3960HBLTAD3 | 96KT6 | VRG4Y | HH64 | 960 GB | Cache,Capacity |
| SSD | SATA | 2.5 | Mixed Use | Samsung | PM897 | MZ7L31T9HBNAAD3 | RRR7M | VRG4Y | HH64 | 1.92 TB | Cache,Capacity |
SATA 2.5" SSD Capacity Only
| Type | Drive Type | Form Factor | Endurance | Vendor | Series | Model | Device Part Number (P/N) | Firmware Software Bundle | Firmware Minimum Supported Version | Capacity | Use |
|---|---|---|---|---|---|---|---|---|---|---|---|
| SSD | SATA | 2.5 | Read Intensive | Intel | Youngsville-RR | SSDSC2KB960GZR | F6H8H | VJPKG | DL7C | 960 GB | Capacity |
| SSD | SATA | 2.5 | Read Intensive | Intel | Youngsville-RR | SSDSC2KB019TZR | VYYW8 | VJPKG | DL7C | 1.92 TB | Capacity |
| SSD | SATA | 2.5 | Read Intensive | Intel | Youngsville-RR | SSDSC2KB038TZR | WNPN1 | VJPKG | DL7C | 3.84 TB | Capacity |
| SSD | SATA | 2.5 | Read Intensive | Intel | Youngsville RR (New) (S4520) | SSDSC2KB960GZR | 5M8Y4 | VJPKG | DL7C | 960 GB | Capacity |
| SSD | SATA | 2.5 | Read Intensive | Intel | Youngsville RR (New) (S4520) | SSDSC2KB019TZR | 6J65H | VJPKG | DL7C | 1.92 TB | Capacity |
| SSD | SATA | 2.5 | Read Intensive | Intel | Youngsville RR (New) (S4520) | SSDSC2KB038TZR | KM4C4 | VJPKG | DL7C | 3.84 TB | Capacity |
| SSD | SATA | 2.5 | Read Intensive | Micron | 5200 | MTFDDAK1T9TDD | VJ36D | W2X8N | F005 | 1.92 TB | Capacity |
| SSD | SATA | 2.5 | Read Intensive | Micron | 5300 | MTFDDAK1T9TDS | GYGVV | KT63Y | J008 | 1.92 TB | Capacity |
| SSD | SATA | 2.5 | Read Intensive | Micron | 5400 | MTFDDAK3T8TGA-1BC1ZABDA | CHF46 | JTW3W | K403 | 3.84 TB | Capacity |
| SSD | SATA | 2.5 | Read Intensive | Micron | 5400 SED | MTFDDAK3T8TGA-1BC16ABDA | 2DXDK | JTW3W | K403 | 3.84 TB | Capacity |
| SSD | SATA | 2.5 | Read Intensive | Kioxia | HK6-R | KHK6YRSE1T92 | 919J7 | W0YR1 | DBC4 | 1.92 TB | Capacity |
| SSD | SATA | 2.5 | Read Intensive | Kioxia | HK6-R | KHK6YRSE3T84 | 8PYG5 | W0YR1 | DBC4 | 3.84 TB | Capacity |
| SSD | SATA | 2.5 | Read Intensive | Samsung | PM883a | MZ7LH1T9HALT0D3 | 9F9Y6 | 3GHD6 | HG61 | 1.92 TB | Capacity |
| SSD | SATA | 2.5 | Read Intensive | Samsung | PM883 | MZ7LH1T9HMLT0D3 | Y24T6 | 93P7P | HE59 | 1.92 TB | Capacity |
| SSD | SATA | 2.5 | Read Intensive | Hynix | SE5110 | HFS1T9G3H2X069N | 962FP | 7XTPF | DZ03 | 1.92 TB | Capacity |
| SSD | SATA | 2.5 | Read Intensive | Hynix | SE4011 | HFS1T9G32FEH-7A10A | 0XMV9 | 3DTV4 | DE08 | 1.92 TB | Capacity |
| SSD | SATA | 2.5 | Read Intensive | Intel | S4510 | SSDSC2KB019T8R | 33R2T | 4DW70 | DL6B | 1.92 TB | Capacity |
| SSD | SATA | 2.5 | Read Intensive | Intel | S4500 | SSDSC2KB019T7R | XCN15 | V141M | DL5C | 1.92 TB | Capacity |
| SSD | SATA | 2.5 | Read Intensive | Intel | S4500 | SSDSC2KB038T7R | 3RRN8 | V141M | DL5C | 3.84 TB | Capacity |
| SSD | SATA | 2.5 | Read Intensive | Intel | S4510 | SSDSC2KB038T8R | 1RHK2 | 4DW70 | DL6B | 3.84 TB | Capacity |
| SSD | SATA | 2.5 | Read Intensive | Samsung | PM883 | MZ7LH3T8HMLT0D3 | FYP5F | 93P7P | HE59 | 3.84 TB | Capacity |
| SSD | SATA | 2.5 | Read Intensive | Samsung | PM883a | MZ7LH3T8HALT0D3 | 5TVXD | 3GHD6 | HG61 | 3.84 TB | Capacity |
| SSD | SATA | 2.5 | Read Intensive | Hynix | SE4011 | HFS3T8G32FEH-7410A | D6C0R | 3DTV4 | DE08 | 3.84 TB | Capacity |
| SSD | SATA | 2.5 | Read Intensive | Hynix | SE5110 | HFS3T8G3H2X069N | 3GDK0 | 7XTPF | DZ03 | 3.84 TB | Capacity |
| SSD | SATA | 2.5 | Read Intensive | Micron | 5300 | MTFDDAK3T8TDT | 4H1RX | R9YDC | J408 | 3.84 TB | Capacity |
| SSD | SATA | 2.5 | Read Intensive | Intel | Youngsville-RR | SSDSC2KB019TZR | VYYW8 | VJPKG | DL7C | 1.92 TB | Capacity |
| SSD | SATA | 2.5 | Read Intensive | Intel | Youngsville-RR | SSDSC2KB038TZR | WNPN1 | VJPKG | DL7C | 3.84 TB | Capacity |
| SSD | SATA | 2.5 | Read Intensive | Samsung | PM893 | MZ7L31T9HBLTAD3 | 0KYP4 | T3HX9 | HJ64 | 1.92 TB | Capacity |
| SSD | SATA | 2.5 | Read Intensive | Samsung | PM893 | MZ7L33T8HBLTAD3 | GCN5W | T3HX9 | HJ64 | 3.84 TB | Capacity |
| SSD | SATA | 2.5 | Mixed Use | Hynix | SE5031 | HFS960G32FEH-BA10A | 7GR2K | 2CY65 | DD02 | 960 GB | Capacity |
| SSD | SATA | 2.5 | Mixed Use | Hynix | SE5031 | HFS1T9G32FEH-BA10A | GKTF1 | 2CY65 | DD02 | 1.92 TB | Capacity |
SAS 2.5" SSD Cache or Capacity
| Type | Drive Type | Form Factor | Endurance | Vendor | Series | Model | Device Part Number (P/N) | Firmware Software Bundle | Firmware Minimum Supported Version | Capacity | Use |
|---|---|---|---|---|---|---|---|---|---|---|---|
| SSD | SAS | 2.5 | Mixed Use | Samsung | PM1655 | MZILG800HCHQAD3 | 3CHC8 | 7MTXM | DWG9 | 800 GB | Cache,Capacity |
| SSD | SAS | 2.5 | Mixed Use | Samsung | PM1655 | MZILG1T6HCJRAD3 | 5RJND | 7MTXM | DWG9 | 1.6 TB | Cache,Capacity |
| SSD | SAS | 2.5 | Write Intensive | Kioxia | PM6 | KPM6XMUG800G | H6GCD | NGPR2 | BA48 | 800 GB | Cache, Capacity |
| SSD | SAS | 2.5 | Write Intensive | Kioxia | PM6 | KPM6XMUG1T60 | 5GDXH | NGPR2 | BA48 | 1.6 TB | Cache, Capacity |
| SSD | SAS | 2.5 | Mixed Use | Kioxia | PM6 | KPM6XVUG800G | JTKH5 | NGPR2 | BA48 | 800 GB | Cache, Capacity |
| SSD | SAS | 2.5 | Mixed Use | Kioxia | PM6 | KPM6XVUG1T60 | GD3N0 | NGPR2 | BA48 | 1.6 TB | Cache, Capacity |
| SSD | SAS | 2.5 | Mixed Use | Kioxia | PM6 | KPM6XVUG3T20 | NKM7P | NGPR2 | BA48 | 3.2 TB | Cache,Capacity |
| SSD | SAS | 2.5 | Mixed Use | Kioxia | PM6 | KPM6XVUG6T40 | 6NW3J | NGPR2 | BA48 | 6.4 TB | Cache,Capacity |
| SSD | SAS | 2.5 | Write Intensive | Kioxia | Phoenix M4 | PX05SMB080Y | CN3JH | 1DJXX | AS10 | 800 GB | Cache, Capacity |
| SSD | SAS | 2.5 | Mixed Use | Kioxia | Phoenix M4 | PX05SVB096Y | 503M7 | 1DJXX | AS10 | 960 GB | Cache, Capacity |
| SSD | SAS | 2.5 | Write Intensive | Kioxia | Phoenix M4 | PX05SMB160Y | GVTYD | 1DJXX | AS10 | 1.6 TB | Cache, Capacity |
| SSD | SAS | 2.5 | Mixed Use | Kioxia | Phoenix M4 | PX05SVB192Y | V0K7V | 1DJXX | AS10 | 1.92 TB | Cache, Capacity |
| SSD | SAS | 2.5 | Mixed Use | Kioxia | Phoenix M4 | PX05SVB384Y | 3DDFT | 1DJXX | AS10 | 3.84 TB | Cache, Capacity |
| SSD | SAS | 2.5 | Write Intensive | Kioxia | Phoenix M5-M | KPM5XMUG800G | DHRVV | CPP97 | B02A | 800 GB | Cache, Capacity |
| SSD | SAS | 2.5 | Write Intensive | Kioxia | Phoenix M5-M | KPM5XMUG1T60 | W9G88 | CPP97 | B02A | 1.6 TB | Cache, Capacity |
| SSD | SAS | 2.5 | Mixed Use | Samsung | PM1645a | MZILT800HBHQ0D3 | GW8T1 | VJY6V | DWA4 | 800 GB | Cache, Capacity |
| SSD | SAS | 2.5 | Mixed Use | Samsung | PM1645a | MZILT1T6HBJR0D3 | 3TCV6 | VJY6V | DWA4 | 1.6 TB | Cache, Capacity |
| SSD | SAS | 2.5 | Mixed Use | Samsung | PM1645 | MZILT1T6HAJQ0D3 | DR0HX | 4PPHJ | DWF8 | 1.6 TB | Cache, Capacity |
| SSD | SAS | 2.5 | Mixed Use | WD | Bear Cove Quantum | WUSTR6480BSS200 | 6VJC9 | 8W5WF | G138 | 800 GB | Cache, Capacity |
| SSD | SAS | 2.5 | Mixed Use | WD | Bear Cove Quantum | WUSTR6416BSS200 | 6NF96 | 8W5WF | G138 | 1.6 TB | Cache, Capacity |
| SSD | SAS | 2.5 | Mixed Use | Kioxia | Phoenix M5-V | KPM5XVUG960G | WFGTH | CPP97 | B02A | 960 GB | Cache, Capacity |
| SSD | SAS | 2.5 | Mixed Use | Kioxia | Phoenix M5-V | KPM5XVUG1T92 | 2WVYG | CPP97 | B02A | 1.92 TB | Cache, Capacity |
| SSD | SAS | 2.5 | Mixed Use | Kioxia | Phoenix M5-V | KPM5XVUG3T84 | 91W3V | CPP97 | B02A | 3.84 TB | Cache, Capacity |
| SSD | SAS | 2.5 | Mixed Use | Kioxia | PM6 FIPS | KPM6WVUG960G | WMWKG | 6DH0W | BD48 | 960 GB | Cache, Capacity |
| SSD | SAS | 2.5 | Mixed Use | Kioxia | PM6 FIPS | KPM6WVUG1T92 | DHWH5 | 6DH0W | BD48 | 1.92 TB | Cache, Capacity |
| SSD | SAS | 2.5 | Mixed Use | Kioxia | PM6 FIPS | KPM6WVUG3T84 | 81H9C | 6DH0W | BD48 | 3.84 TB | Cache, Capacity |
| SSD | SAS | 2.5 | Mixed Use | Kioxia | PM7 | KPM7XVUG800G | X96H8 | T21WT | C10E | 800 GB | Cache,Capacity |
| SSD | SAS | 2.5 | Mixed Use | Kioxia | PM7 | KPM7XVUG1T60 | 4TRHM | T21WT | C10E | 1.6 TB | Cache,Capacity |
| SSD | SAS | 2.5 | Mixed Use | Kioxia | PM7 (FIPS) | KPM7WVUG800G | 81G77 | 57MM2 | C40E | 800GB | Cache,Capacity |
| SSD | SAS | 2.5 | Mixed Use | Kioxia | PM7 (FIPS) | KPM7WVUG1T60 | G4NY4 | 57MM2 | C40E | 1.6TB | Cache,Capacity |
| SSD | SAS | 2.5 | Mixed Use | Kioxia | PM7 (FIPS) | KPM7WVUG3T20 | RGP9J | 57MM2 | C40E | 3.2TB | Cache,Capacity |
| SSD | SAS | 2.5 | Mixed Use | Kioxia | PM7 (FIPS) | KPM7WVUG3T84 | FMP6K | 57MM2 | C40E | 3.84TB | Cache,Capacity |
| SSD | SAS | 2.5 | Mixed Use | Kioxia | PM6 | KPM6WVUG960G | J92FY | 6DH0W | BD48 | 960 GB | Cache,Capacity |
| SSD | SAS | 2.5 | Mixed Use | Kioxia | PM6 | KPM6WVUG1T92 | 1081V | 6DH0W | BD48 | 1.92 TB | Cache,Capacity |
| SSD | SAS | 2.5 | Mixed Use | Kioxia | PM6 | KPM6WVUG3T84 | MD4YN | 6DH0W | BD48 | 3.84 TB | Cache,Capacity |
| SSD | SAS | 2.5 | Mixed Use | Kioxia | PM6 | KPM6XVUG800G | NNGV4 | NGPR2 | BA48 | 800 GB | Cache,Capacity |
| SSD | SAS | 2.5 | Mixed Use | Kioxia | PM6 | KPM6XVUG1T60 | CHJJJ | NGPR2 | BA48 | 1.6 TB | Cache,Capacity |
| SSD | SAS | 2.5 | Mixed Use | WD | Bear Cove Plus | WUSTR6416ASS200 | 8W6HC | 7HYHH | K968 | 1.6 TB | Cache,Capacity |
SAS 2.5" SSD Capacity Only
| Type | Drive Type | Form Factor | Endurance | Vendor | Series | Model | Device Part Number (P/N) | Firmware Software Bundle | Firmware Minimum Supported Version | Capacity | Use |
|---|---|---|---|---|---|---|---|---|---|---|---|
| SSD | SAS | 2.5 | Read Intensive | WD | Bear Cove Plus | WUSTR1519ASS200 | 5ND33 | 7HYHH | K968 | 1.92 TB | Capacity |
| SSD | SAS | 2.5 | Read Intensive | WD | Bear Cove Plus | WUSTR1538ASS200 | YW17N | 7HYHH | K968 | 3.84 TB | Capacity |
| SSD | SAS | 2.5 | Read Intensive | WD | Bear Cove Quantum | WUSTVA119BSS200 | 02X38 | 8W5WF | G138 | 1.92 TB | Capacity |
| SSD | SAS | 2.5 | Read Intensive | WD | Bear Cove Quantum | WUSTVA138BSS200 | FP1KF | 8W5WF | G138 | 3.84 TB | Capacity |
| SSD | SAS | 2.5 | Read Intensive | Samsung | PM1643 | MZILT1T9HAJQ0D3 | F0VFY | J3RRK | DSF8 | 1.92 TB | Capacity |
| SSD | SAS | 2.5 | Read Intensive | Samsung | PM1643 | MZILT3T8HALS0D3 | X8F87 | J3RRK | DSF8 | 3.84 TB | Capacity |
| SSD | SAS | 2.5 | Read Intensive | Samsung | PM1643 | MZILT7T6HMLA0D3 | RVYD5 | J3RRK | DSF8 | 7.68 TB | Capacity |
| SSD | SAS | 2.5 | Read Intensive | Samsung | PM1643a | MZILT1T9HBJR0D3 | TMTW9 | D7RNT | DSA4 | 1.92 TB | Capacity |
| SSD | SAS | 2.5 | Read Intensive | Samsung | PM1643a | MZILT3T8HBLS0D3 | CRNPH | D7RNT | DSA4 | 3.84 TB | Capacity |
| SSD | SAS | 2.5 | Read Intensive | Samsung | PM1633a | MZILS1T9HEJH0D3 | 086DD | XNGNT | DSLA | 1.92 TB | Capacity |
| SSD | SAS | 2.5 | Read Intensive | Samsung | PM1633a | MZILS3T8HMLH0D3 | JR1HP | XNGNT | DSLA | 3.84 TB | Capacity |
| SSD | SAS | 2.5 | Read Intensive | Samsung | PM1643a | MZILT960HBHQ0D3 | K74WN | D7RNT | DSA4 | 960 GB | Capacity |
| SSD | SAS | 2.5 | Read Intensive | Samsung | PM1643a | MZILT7T6HALA0D3 | 84C40 | D7RNT | DSA4 | 7.68 TB | Capacity |
| SSD | SAS | 2.5 | Read Intensive | Samsung | PM1653 | MZILG1T9HCJRAD3 | NRR34 | 3MV58 | DSG9 | 1.92 TB | Capacity |
| SSD | SAS | 2.5 | Read Intensive | Samsung | PM1653 | MZILG3T8HCLSAD3 | 9N32F | 3MV58 | DSG9 | 3.84 TB | Capacity |
| SSD | SAS | 2.5 | Read Intensive | Samsung | PM1653 | MZILG7T6HBLAAD3 | Y8H7M | 3MV58 | DSG9 | 7.68 TB | Capacity |
| SSD | SAS | 2.5 | Read Intensive | Kioxia | PM6 | KPM6XRUG1T92 | 4CN85 | NGPR2 | BA48 | 1.92 TB | Capacity |
| SSD | SAS | 2.5 | Read Intensive | Kioxia | PM6 | KPM6XRUG3T84 | H9TT5 | NGPR2 | BA48 | 3.84 TB | Capacity |
| SSD | SAS | 2.5 | Read Intensive | Kioxia | PM6 | KPM6XRUG7T68 | PD02Y | NGPR2 | BA48 | 7.68 TB | Capacity |
| SSD | SAS | 2.5 | Read Intensive | Kioxia | PM6 FIPS | KPM6WRUG1T92 | 7F2D1 | 6DH0W | BD48 | 1.92 TB | Capacity |
| SSD | SAS | 2.5 | Read Intensive | Kioxia | PM6 FIPS | KPM6WRUG3T84 | FH1W9 | 6DH0W | BD48 | 3.84 TB | Capacity |
| SSD | SAS | 2.5 | Read Intensive | Kioxia | PM6 | KPM6WRUG1T92 | H1P07 | 6DH0W | BD48 | 1.92 TB | Capacity |
| SSD | SAS | 2.5 | Read Intensive | Kioxia | PM6 | KPM6WRUG3T84 | 3VHY3 | 6DH0W | BD48 | 3.84 TB | Capacity |
| SSD | SAS | 2.5 | Read Intensive | Kioxia | PM6 | KPM6WRUG7T68 | 5T78C | 6DH0W | BD48 | 7.68 TB | Capacity |
| SSD | SAS | 2.5 | Read Intensive | Kioxia | PM6 | KPM6XRUG1T92 | VRTN9 | NGPR2 | BA48 | 1.92 TB | Capacity |
| SSD | SAS | 2.5 | Read Intensive | Kioxia | PM6 | KPM6XRUG3T84 | 2XVX2 | NGPR2 | BA48 | 3.84 TB | Capacity |
| SSD | SAS | 2.5 | Read Intensive | Kioxia | PM6 | KPM6XRUG7T68 | YM0T1 | NGPR2 | BA48 | 7.68 TB | Capacity |
| SSD | SAS | 2.5 | Read Intensive | Kioxia | PM7 (FIPS) | KPM7WRUG1T92 | VGMCD | 57MM2 | C40E | 1.92TB | Capacity |
| SSD | SAS | 2.5 | Read Intensive | Kioxia | PM7 (FIPS) | KPM7WRUG3T84 | YTVTF | 57MM2 | C40E | 3.84TB | Capacity |
| SSD | SAS | 2.5 | Read Intensive | Kioxia | PM7 (FIPS) | KPM7WRUG7T68 | HCTYM | 57MM2 | C40E | 7.68TB | Capacity |
| SSD | SAS | 2.5 | Read Intensive | Kioxia | Phoenix M5-R | KPM5XRUG1T92 | TDNP7 | CPP97 | B02A | 1.92 TB | Capacity |
| SSD | SAS | 2.5 | Read Intensive | Kioxia | Phoenix M5-R | KPM5XRUG3T84 | N85XX | CPP97 | B02A | 3.84 TB | Capacity |
| SSD | SAS | 2.5 | Read Intensive | Kioxia | Phoenix M4 | PX05SRB384Y | XCRDV | 1DJXX | AS10 | 3.84 TB | Capacity |
| SSD | SAS | 2.5 | Read Intensive | Seagate | LangeBP | XS3840SE70114 | KXDCD | NKGWD | 3D03 | 3.84 TB | Capacity |
| SSD | SAS | 2.5 | Read Intensive | Seagate | LangeBP | XS1920SE70114 | D4VFW | NKGWD | 3D03 | 1.92 TB | Capacity |
| SSD | SAS | 2.5 | Read Intensive | Kioxia | PM7 | KPM7XRUG1T92 | 6K35K | T21WT | C10E | 1.92 TB | Capacity |
| SSD | SAS | 2.5 | Read Intensive | Kioxia | PM7 | KPM7XRUG3T84 | MT0R5 | T21WT | C10E | 3.84 TB | Capacity |
| SSD | SAS | 2.5 | Read Intensive | Kioxia | PM7 | KPM7XRUG7T68 | 7N1WT | T21WT | C10E | 7.68 TB | Capacity |
Value SAS 2.5" SSD
| Type | Drive Type | Form Factor | Endurance | Vendor | Series | Model | Device Part Number (P/N) | Firmware Software Bundle | Firmware Minimum Supported Version | Capacity | Use |
|---|---|---|---|---|---|---|---|---|---|---|---|
| SSD | VSAS | 2.5 | Read Intensive | Seagate | LangeBP SED | XS1920SE70134 | K9T53 | G04C8 | 4S0C | 1.92 TB | Capacity |
| SSD | VSAS | 2.5 | Read Intensive | Seagate | LangeBP SED | XS3840SE70134 | 4KPKF | G04C8 | 4S0C | 3.84 TB | Capacity |
| SSD | VSAS | 2.5 | Read Intensive | Seagate | LangeBP SED | XS7680SE70134 | 2THYF | G04C8 | 4S0C | 7.68 TB | Capacity |
| SSD | VSAS | 2.5 | Mixed Use | Kioxia | Phoenix RM5 | KRM5XVUG3T84 | X78JM | NDG7N | B710 | 3.84 TB | Cache, Capacity |
| SSD | VSAS | 2.5 | Mixed Use | Seagate | LangeBP ISE | XS3840LE70154 | NWGX3 | NX13G | 4D0C | 3.84 TB | Cache, Capacity |
| SSD | VSAS | 2.5 | Mixed Use | Seagate | Cooper (Nytro 2550) | XS960LE70095 | 2M1NG | RRWVT | CPE9 | 960GB | Cache,Capacity |
| SSD | VSAS | 2.5 | Mixed Use | Seagate | Cooper (Nytro 2550) | XS1920LE70095 | K805Y | RRWVT | CPE9 | 1.92TB | Cache,Capacity |
| SSD | VSAS | 2.5 | Mixed Use | Seagate | Cooper (Nytro 2550) | XS3840LE70095 | FT95M | RRWVT | CPE9 | 3.84TB | Cache,Capacity |
| SSD | VSAS | 2.5 | Read Intensive | Kioxia | Phoenix RM5 | KRM5XRUG7T68 | 5XD2F | NDG7N | B710 | 7.68 TB | Capacity |
| SSD | VSAS | 2.5 | Read Intensive | Seagate | Lange ISE | XS7680SE70074 | 2PKRH | H3VHX | EC16 | 7.68 TB | Capacity |
| SSD | VSAS | 2.5 | Read Intensive | Seagate | LangeBP ISE | XS7680SE70154 | 5KW0F | NX13G | 4D0C | 7.68 TB | Capacity |
| SSD | VSAS | 2.5 | Mixed Use | Seagate | LangeBP SED | XS960LE70134 | 2RDWT | G04C8 | 4S0C | 960 GB | Cache, Capacity |
| SSD | VSAS | 2.5 | Mixed Use | Seagate | LangeBP SED | XS1920LE70134 | N6DRV | G04C8 | 4S0C | 1.92 TB | Cache, Capacity |
| SSD | VSAS | 2.5 | Mixed Use | Seagate | LangeBP SED | XS3840LE70134 | YM9HP | G04C8 | 4S0C | 3.84 TB | Cache, Capacity |
| SSD | VSAS | 2.5 | Mixed Use | Kioxia | RM6 | KRM6VVUG960G | 42XXC | 5WMK8 | BJ07 | 960 GB | Cache, Capacity |
| SSD | VSAS | 2.5 | Mixed Use | Kioxia | RM6 | KRM6VVUG1T92 | N15JP | 5WMK8 | BJ07 | 1.92 TB | Cache, Capacity |
| SSD | VSAS | 2.5 | Mixed Use | Kioxia | RM6 | KRM6VVUG3T84 | FXYGR | 5WMK8 | BJ07 | 3.84 TB | Cache, Capacity |
| SSD | VSAS | 2.5 | Read Intensive | Kioxia | RM6 | KRM6VRUG1T92 | 1FGWG | 5WMK8 | BJ07 | 1.92 TB | Capacity |
| SSD | VSAS | 2.5 | Read Intensive | Kioxia | RM6 | KRM6VRUG3T84 | XNXD2 | 5WMK8 | BJ07 | 3.84 TB | Capacity |
| SSD | VSAS | 2.5 | Read Intensive | Kioxia | RM6 | KRM6VRUG7T68 | 5MHY8 | 5WMK8 | BJ07 | 7.68 TB | Capacity |
| SSD | VSAS | 2.5 | Read Intensive | Kioxia | RM7 | KRM7VVUG960G | 05MT7 | 1YD58 | CA0C | 960 GB | Capacity |
| SSD | VSAS | 2.5 | Read Intensive | Kioxia | RM7 | KRM7VVUG1T92 | 59XF2 | 1YD58 | CA0C | 1.92 TB | Capacity |
| SSD | VSAS | 2.5 | Read Intensive | Kioxia | RM7 | KRM7VVUG3T84 | M0JVN | 1YD58 | CA0C | 3.84 TB | Capacity |
| SSD | vSAS | 2.5 | Read Intensive | Kioxia | RM7 | KRM7VRUG7T68 | D480G | 1YD58 | CA0C | 7.68 TB | Capacity |
| SSD | vSAS | 2.5 | Read Intensive | Seagate | Cooper | XS7680SE70145 | 1J46N | RRWVT | CPE9 | 7.68 TB | Capacity |
NVMe 2.5" Cache or Capacity
| Type | Drive Type | Form Factor | Endurance | Vendor | Series | Model | Device Part Number (P/N) | Firmware Software Bundle | Firmware Minimum Supported Version | Capacity | Use |
|---|---|---|---|---|---|---|---|---|---|---|---|
| NVMe | PCIe | 2.5 | Write Intensive | Intel | Optane P4800x SSD/NVMe, 375GB U.2 2.5" SFF | SSDPE21K375GAT | 3DM57 | HMRK7 | E201DP38 | 375 GB | Cache, Capacity |
| NVMe | PCIe | 2.5 | Mixed Use | Samsung | PM1725A, Dell Express Flash NVMe 1.6TB 2.5" SFF | MZWLL1T6HEHP-000D3 | JD6CH | 34C36 | 1.2.1 | 1.6 TB | Cache, Capacity |
| NVMe | PCIe | 2.5 | Mixed Use | Samsung | PM1725A, Dell Express Flash NVMe 3.2TB 2.5" SFF | MZWLL3T2HMJP-000D3 | JDMHM | 34C36 | 1.2.1 | 3.2 TB | Cache, Capacity |
| NVMe | PCIe | 2.5 | Mixed Use | Samsung | PM1725A, Dell Express Flash NVMe 6.4TB 2.5" SFF | MZWLL6T4HMLS-000D3 | Y3XT2 | 34C36 | 1.2.1 | 6.4 TB | Cache, Capacity |
| NVMe | PCIe | 2.5 | Mixed Use | Samsung | PM1725b, Dell Express Flash NVMe 1.6TB 2.5" SFF | MZWLL1T6HAJQ-000D3 | 4WDXY | NC07Y | 1.2.2 | 1.6 TB | Cache, Capacity |
| NVMe | PCIe | 2.5 | Mixed Use | Samsung | PM1725b, Dell Express Flash NVMe 3.2TB 2.5" SFF | MZWLL3T2HAJQ-000D3 | K60N7 | NC07Y | 1.2.2 | 3.2 TB | Cache, Capacity |
| NVMe | PCIe | 2.5 | Mixed Use | Samsung | PM1725b, Dell Express Flash NVMe 6.4TB 2.5" SFF | MZWLL6T4HMLA-000D3 | 08NMX | NC07Y | 1.2.2 | 6.4 TB | Cache, Capacity |
| NVMe | PCIe | 2.5 | Mixed Use | Intel | P4600, Dell Express Flash NVMe 1.6TB 2.5" SFF | SSDPE2KE016T7T | F5P84 | CR0HC | QDV1DP17 | 1.6 TB | Cache, Capacity |
| NVMe | PCIe | 2.5 | Mixed Use | Intel | P4600, Dell Express Flash NVMe 3.2TB 2.5" SFF | SSDPE2KE032T7T | MCV6J | CR0HC | QDV1DP17 | 3.2 TB | Cache, Capacity |
| NVMe | PCIe | 2.5 | Mixed Use | Intel | P4610, Dell Express Flash NVMe 1.6TB 2.5" SFF | SSDPE2KE016T8T | 58V30 | GD4X4 | VDV1DP25 | 1.6 TB | Cache, Capacity |
| NVMe | PCIe | 2.5 | Mixed Use | Intel | P4610, Dell Express Flash NVMe 3.2TB 2.5" SFF | SSDPE2KE032T8T | 2CN1T | GD4X4 | VDV1DP25 | 3.2 TB | Cache, Capacity |
| NVMe | PCIe | 2.5 | Mixed Use | Intel | P4610, Dell Express Flash NVMe 6.4TB 2.5" SFF | SSDPE2KE064T8T | X27HY | GD4X4 | VDV1DP25 | 6.4 TB | Cache, Capacity |
| NVMe | PCIe | 2.5 | Mixed Use | KIOXIA | DELL EXPRESS FLASH KIOXIA CM6 MU 1.6TB U.2 FIPS | KCM6FVUL1T60 | G7N00 | WJD95 | 3.1.7 | 1.6 TB | Cache, Capacity |
| NVMe | PCIe | 2.5 | Mixed Use | Samsung | PM1735 SP 3WPD, SSD, NVMe, 2.5, 512e, ISE | MZWLJ1T6HBJRAD3 | 6GK00 | 5CM3G | 2.5.0 | 1.6 TB | Cache, Capacity |
| NVMe | PCIe | NA | Mixed Use | Samsung | PM1735 SP 3WPD, SSD, Gen4 NVMe, 2.5, 512e, ISE | MZWLJ3T2HBJRAD3 | 15TVC | 5CM3G | 2.5.0 | 3.2TB | Cache,Capacity |
| NVMe | PCIe | NA | Mixed Use | Samsung | PM1735 SP 3WPD, SSD, Gen4 NVMe, 2.5, 512e, ISE | MZWLJ6T4HALAAD3 | F6V5P | 5CM3G | 2.5.0 | 6.4TB | Cache,Capacity |
| NVMe | PCIe | 2.5 | Mixed Use | Kioxia | CM6 SP | KCM6XVUL1T60 | P03YC | GMM6V | 2.2.2 | 1.6 TB | Cache, Capacity |
| NVMe | PCIe | 2.5 | Mixed Use | Kioxia | CM6 SP | KCM6XVUL3T20 | 97GR0 | GMM6V | 2.2.2 | 3.2 TB | Cache, Capacity |
| NVMe | PCIe | 2.5 | Mixed Use | Kioxia | CM6 SP | KCM6XVUL6T40 | K916X | GMM6V | 2.2.2 | 6.4 TB | Cache, Capacity |
| NVMe | PCIe | 2.5 | Mixed Use | Intel | P5600 SP 3WPD | D7 P5600 Series 1.6TB | C9X5T | CGXH7 | 1.2.4 | 1.6 TB | Cache, Capacity |
| NVMe | PCIe | 2.5 | Mixed Use | Intel | P5600 SP 3WPD | D7 P5600 Series 3.2TB | PRKTM | CGXH7 | 1.2.4 | 3.2 TB | Cache, Capacity |
| NVMe | PCIe | 2.5 | Mixed Use | Intel | Arbordale Plus RR P5620 | SSDPF2KE016T1E | 82TVJ | 12W9R | 1.5.0 | 1.6 TB | Cache,Capacity |
| NVMe | PCIe | 2.5 | Mixed Use | Intel | Arbordale Plus RR P5620 | SSDPF2KE032T1E | TY3M5 | 12W9R | 1.5.0 | 3.2 TB | Cache,Capacity |
| NVMe | PCIe | 2.5 | Mixed Use | Intel | Arbordale Plus RR P5620 | SSDPF2KE064T1E | 5WCR8 | 12W9R | 1.5.0 | 6.4TB | Cache, Capacity |
| NVMe | PCIe | 2.5 | Mixed Use | Samsung | PM1735 V2 SP 3WPD | MZWLR1T6HBJRAD3 | 0MNMV | 5V3P7 | 2.5.0 | 1.6 TB | Cache, Capacity |
| NVMe | PCIe | 2.5 | Mixed Use | Samsung | PM1735 V2 SP 3WPD | MZWLR3T2HBLSAD3 | V69W3 | 5V3P7 | 2.5.0 | 3.2 TB | Cache, Capacity |
| NVMe | PCIe | 2.5 | Mixed Use | Samsung | PM1735 V2 SP 3WPD | MZWLR6T4HALAAD3 | H8D5M | 5V3P7 | 2.5.0 | 6.4 TB | Cache, Capacity |
| NVMe | PCIe | 2.5 | Mixed Use | Samsung | PM1735a | MZWLR1T6HCJRAD3 | H8GHV | 71KRG | 1.2.0 | 1.6 TB | Cache,Capacity |
| NVMe | PCIe | 2.5 | Mixed Use | Samsung | PM1735a | MZWLR3T2HCLSAD3 | 617H6 | 71KRG | 1.2.0 | 3.2 TB | Cache,Capacity |
| NVMe | PCIe | 2.5 | Mixed Use | Samsung | PM1735a | MZWLR6T4HBLAAD3 | 9F6Y3 | 71KRG | 1.2.0 | 6.4 TB | Cache,Capacity |
| NVMe | PCIe | 2.5 | Mixed Use | Kioxia | CM7 | KCM7XVUG1T60 | MP4F2 | K1JTM | 2.0.3 | 1.6 TB | Cache, Capacity |
| NVMe | PCIe | 2.5 | Mixed Use | Kioxia | CM7 | KCM7XVUG3T20 | XFNX0 | K1JTM | 2.0.3 | 3.2 TB | Cache, Capacity |
| NVMe | PCIe | 2.5 | Mixed Use | Kioxia | CM7 | KCM7XVUG6T40 | 8RJJ9 | K1JTM | 2.0.3 | 6.4 TB | Cache, Capacity |
| NVMe | PCIe | 2.5 | Mixed Use | Hynix | PS1030 | HFS1T6GEJVX171N | 1HYKD | 9M65G | 1.2.0 | 1.6 TB | Cache, Capacity |
| NVMe | PCIe | 2.5 | Mixed Use | Hynix | PS1030 | HFS3T2GEJVX171N | 9VWPD | 9M65G | 1.2.0 | 3.2 TB | Cache, Capacity |
| NVMe | PCIe | 2.5 | Mixed Use | Hynix | PS1030 | HFS6T4GEJVX171N | PYMY6 | 9M65G | 1.2.0 | 6.4 TB | Cache, Capacity |
| NVMe | PCIe | 2.5 | Mixed Use | Samsung | PM1745 | MZWLO1T6HCJR-00AD3 | FVC2P | V7V0K | 1.0.0 | 1.6 TB | Cache, Capacity |
| NVMe | PCIe | 2.5 | Mixed Use | Samsung | PM1745 | MZWLO3T2HCLS-00AD3 | FDNHD | V7V0K | 1.0.0 | 3.2 TB | Cache, Capacity |
| NVMe | PCIe | 2.5 | Mixed Use | Samsung | PM1745 | MZWLO6T4HBLA-00AD3 | 64K9C | V7V0K | 1.0.0 | 6.4 TB | Cache, Capacity |
NVMe 2.5" Capacity Only
| Type | Drive Type | Form Factor | Endurance | Vendor | Series | Model | Device Part Number (P/N) | Firmware Software Bundle | Firmware Minimum Supported Version | Capacity | Use |
|---|---|---|---|---|---|---|---|---|---|---|---|
| NVMe | PCIe | 2.5 | Read Intensive | Toshiba | CD5 | KCD5XLUG960G | DRC9H | T79D5 | 1.2.0 | 960 GB | Capacity |
| NVMe | PCIe | 2.5 | Read Intensive | Toshiba | CD5 | KCD5XLUG3T84 | 17C57 | T79D5 | 1.2.0 | 3.84 TB | Capacity |
| NVMe | PCIe | 2.5 | Read Intensive | Intel | P4510 | SSDPE2KX040T8T | 5GMK0 | GD4X4 | VDV1DP25 | 4 TB | Capacity |
| NVMe | PCIe | 2.5 | Read Intensive | KIOXIA | DELL EXPRESS FLASH KIOXIA CM6 RI 1.92TB U.2 FIPS | KCM6FRUL1T92 | TXP72 | WJD95 | 3.1.7 | 1.92 TB | Capacity |
| NVMe | PCIe | 2.5 | Read Intensive | Intel | P5500 | SSDPF2KX019T9T | WPP9G | CGXH7 | 1.2.4 | 1.92 TB | Capacity |
| NVMe | PCIe | 2.5 | Read Intensive | Intel | P5500 | SSDPF2KX038T9T | KRT3G | CGXH7 | 1.2.4 | 3.84 TB | Capacity |
| NVMe | PCIe | 2.5 | Read Intensive | Intel | P5500 | SSDPF2KX076T9T | RNN67 | CGXH7 | 1.2.4 | 7.68 TB | Capacity |
| NVMe | PCIe | 2.5 | Read Intensive | Samsung | PM1733 V2 | MZWLR3T8HBLSAD3 | G5N65 | 5V3P7 | 2.5.0 | 3.84 TB | Capacity |
| NVMe | PCIe | 2.5 | Read Intensive | Samsung | PM1733 V2 | MZWLR7T6HALAAD3 | DX74Y | 5V3P7 | 2.5.0 | 7.68 TB | Capacity |
| NVMe | PCIe | 2.5 | Read Intensive | Samsung | PM1733 V2 | MZWLR15THALAAD3 | 182NW | 5V3P7 | 2.5.0 | 15.36 TB | Capacity |
| NVMe | PCIe | 2.5 | Read Intensive | Samsung | PM1733a | MZWLR1T9HCJRAD3 | 8PMRM | 71KRG | 1.2.0 | 1.92 TB | Capacity |
| NVMe | PCIe | 2.5 | Read Intensive | Samsung | PM1733a | MZWLR3T8HCLSAD3 | RJKM5 | 71KRG | 1.2.0 | 3.84 TB | Capacity |
| NVMe | PCIe | 2.5 | Read Intensive | Samsung | PM1733a | MZWLR7T6HBLAAD3 | R1J8J | 71KRG | 1.2.0 | 7.68 TB | Capacity |
| NVMe | PCIe | 2.5 | Read Intensive | Samsung | PM1733a | MZWLR15THBLAAD3 | D4CJG | 71KRG | 1.2.0 | 15.36 TB | Capacity |
| NVMe | PCIe | 2.5 | Read Intensive | Kioxia | CM6 | KCM6XRUL1T92 | N0VK0 | GMM6V | 2.2.2 | 1.92 TB | Capacity |
| NVMe | PCIe | 2.5 | Read Intensive | Kioxia | CM6 | KCM6XRUL3T84 | 8W2G5 | GMM6V | 2.2.2 | 3.84 TB | Capacity |
| NVMe | PCIe | 2.5 | Read Intensive | Kioxia | CM6 | KCM6XRUL7T68 | VD0JX | GMM6V | 2.2.2 | 7.68 TB | Capacity |
| NVMe | PCIe | 2.5 | Read Intensive | Kioxia | CM6 | KCM6XRUL15T3 | J91CR | GMM6V | 2.2.2 | 15.36 TB | Capacity |
| NVMe | PCIe | 2.5 | Read Intensive | Intel | Arbordale Plus RR P5520 | SSDPF2KX019T1E | 0HVC7 | 12W9R | 1.5.0 | 1.92 TB | Capacity |
| NVMe | PCIe | 2.5 | Read Intensive | Intel | Arbordale Plus RR P5520 | SSDPF2KX038T1E | 77MRY | 12W9R | 1.5.0 | 3.84 TB | Capacity |
| NVMe | PCIe | 2.5 | Read Intensive | Intel | Arbordale Plus RR P5520 | SSDPF2KX076T1E | 90M2J | 12W9R | 1.5.0 | 7.68 TB | Capacity |
| NVMe | PCIe | 2.5 | Read Intensive | Intel | Arbordale Plus R P5316 | SSDPF2NV307TZ | 4KCVT | 4XT8T | 1.6.0 | 30.72 TB | Capacity |
| NVMe | PCIe | 2.5 | Mixed Use | Kioxia | CM7 | KCM7XRUG1T92 | M8YW0 | K1JTM | 2.0.3 | 1.92 TB | Capacity |
| NVMe | PCIe | 2.5 | Mixed Use | Kioxia | CM7 | KCM7XRUG3T84 | XHYGF | K1JTM | 2.0.3 | 3.84 TB | Capacity |
| NVMe | PCIe | 2.5 | Mixed Use | Kioxia | CM7 | KCM7XRUG7T68 | VV2M7 | K1JTM | 2.0.3 | 7.68 TB | Capacity |
| NVMe | PCIe | 2.5 | Mixed Use | Kioxia | CM7 | KCM7XRUG15T3 | DX2PD | K1JTM | 2.0.3 | 15.36 TB | Capacity |
| NVMe | PCIe | 2.5 | Read Intensive | Kioxia | CD7 | KCD7XRUG7T68 | 0RD61 | K6597 | 2.0.1 | 7.68 TB | Capacity |
| NVMe | PCIe | 2.5 | Read Intensive | Kioxia | CD8 | KCD8XRUG1T92 | NNKCT | HV8P1 | 2.0.1 | 1.92 TB | Capacity |
| NVMe | PCIe | 2.5 | Read Intensive | Kioxia | CD8 | KCD8XRUG3T84 | N1MK1 | HV8P1 | 2.0.1 | 3.84 TB | Capacity |
| NVMe | PCIe | 2.5 | Read Intensive | Kioxia | CD8 | KCD8XRUG7T68 | MXD8J | HV8P1 | 2.0.1 | 7.68 TB | Capacity |
| NVMe | PCIe | 2.5 | Read Intensive | Hynix | PS1010 | HFS1T9GEJVX171N | 7GGK1 | 9M65G | 1.2.0 | 1.92 TB | Capacity |
| NVMe | PCIe | 2.5 | Read Intensive | Hynix | PS1010 | HFS3T8GEJVX171N | J4TDK | 9M65G | 1.2.0 | 3.84 TB | Capacity |
| NVMe | PCIe | 2.5 | Read Intensive | Hynix | PS1010 | HFS7T6GEJVX171N | 2533N | 9M65G | 1.2.0 | 7.68 TB | Capacity |
| NVMe | PCIe | 2.5 | Read Intensive | Hynix | PS1010 | HFS15T3EJVX171N | 8TY8G | 9M65G | 1.2.0 | 15.36 TB | Capacity |
| NVMe | PCIe | 2.5 | Read Intensive | Hynix | PE8110 | HFS7T6GEETX099N | RG3T2 | TDGKY | 1.1.0 | 7.68 TB | Capacity |
| NVMe | PCIe | 2.5 | Read Intensive | Samsung | PM1743 | MZWLO3T8HCLS-00AD3 | 9GXVF | V7V0K | 1.0.0 | 3.84 TB | Capacity |
| NVMe | PCIe | 2.5 | Read Intensive | Samsung | PM1743 | MZWLO7T6HBLA-00AD3 | DNPR4 | V7V0K | 1.0.0 | 7.68 TB | Capacity |
| NVMe | PCIe | 2.5 | Read Intensive | Samsung | PM9D3a | MZWL6960HFJA-00AD3 | 71Y2J | X5N7N | 1.0.1 | 960 GB | Capacity |
| NVMe | PCIe | 2.5 | Read Intensive | Samsung | PM9D3a | MZVL61T9HBL1-00AD3 | NYPRM | FTVJG | 1.0.1 | 1.92 TB | Capacity |
| NVMe | PCIe | 2.5 | Read Intensive | Samsung | PM9D3a | MZWL63T8HFLT-00AD3 | 2H60T | X5N7N | 1.0.1 | 3.84 TB | Capacity |
| NVMe | PCIe | 2.5 | Read Intensive | Samsung | PM9D3a | MZWL67T6HBLC-00AD3 | VYT6X | X5N7N | 1.0.1 | 7.68 TB | Capacity |
NVMe Add-in Cards
| Type | Drive Type | Form Factor | Endurance | Vendor | Series | Model | Device Part Number (P/N) | Firmware Software Bundle | Firmware Minimum Supported Version | Capacity | Use |
|---|---|---|---|---|---|---|---|---|---|---|---|
| NVMe | PCIe | AIC | Mixed Use | Samsung | PM1725A, Dell Express Flash NVMe 1.6TB HHHL AIC | MZPLL1T6HEHP-000D3 | 06V6M | 34C36 | 1.2.1 | 1.6 TB | Cache, Capacity |
| NVMe | PCIe | AIC | Mixed Use | Samsung | PM1725A, Dell Express Flash NVMe 3.2TB HHHL AIC | MZPLL3T2HMLS-00003 | C2KKH | 34C36 | 1.2.1 | 3.2 TB | Cache, Capacity |
| NVMe | PCIe | AIC | Mixed Use | Samsung | PM1725A, Dell Express Flash NVMe 6.4TB HHHL AIC | MZPLL6T4HMLS-000D3 | 604N5 | 34C36 | 1.2.1 | 6.4 TB | Cache, Capacity |
| NVMe | PCIe | AIC | Mixed Use | Samsung | PM1725b, Dell Express Flash NVMe 1.6TB (MU) HHHL AIC | MZPLL1T6HAJQ-000D3 | FTX2R | NC07Y | 1.2.2 | 1.6 TB | Cache, Capacity |
| NVMe | PCIe | AIC | Mixed Use | Samsung | PM1725b, Dell Express Flash NVMe 3.2TB (MU) HHHL AIC | MZPLL3T2HAJQ-00005 | 73KJ7 | NC07Y | 1.2.2 | 3.2 TB | Cache, Capacity |
| NVMe | PCIe | AIC | Mixed Use | Samsung | PM1725b, Dell Express Flash NVMe 6.4TB (MU) HHHL AIC | MZPLL6T4HMLA-000D3 | FW2K0 | NC07Y | 1.2.2 | 6.4 TB | Cache, Capacity |
| NVMe | PCIe | AIC | Mixed Use | Samsung | PM1735 SP 3WPD, SSD, NVMe, HHHL, 512e, ISE | MZPLJ1T6HBJRAD3 | Y7D7D | 5CM3G | 2.5.0 | 1.6 TB | Cache, Capacity |
| NVMe | PCIe | AIC | Mixed Use | Samsung | PM1735 SP 3WPD, SSD, NVMe, HHHL, 512e, ISE | MZPLJ6T4HALAAD3 | 91FXC | 5CM3G | 2.5.0 | 6.4 TB | Cache, Capacity |
3.2 - Azure Local Support Matrix for 16G (Dell 2512)
NOTE
SBE package 4.2.2512.xxxx and newer will only support Azure Local solution versions 12.*.1001.* or 12.*.1002.* (HCI OS 24H2) and newer.
Dell will support the use of SBE package 4.2.2509.xxxx on Azure Local instances running version 11.* (HCI OS 23H2) until April 2026. Dell recommends that instances running version 11.* be upgraded to 12.* as soon as possible to remain in a supported state.
Supported Platforms
| Model | Supported Operating System |
|---|---|
| AX-760 | Windows Server 2022 Datacenter Windows Server 2025 Datacenter Azure Stack HCI-24H2 |
| AX-660 | Windows Server 2025 Datacenter Azure Stack HCI-24H2 |
| MC-660 | Azure Stack HCI-24H2 |
| MC-760 | Azure Stack HCI-24H2 |
Base Components
| Component | Type | Software Bundle | Minimum Supported Version | Supported Platforms | Supported OS |
|---|---|---|---|---|---|
| BIOS | Firmware DUP | GPMNW | 2.8.2 | AX-660 AX-760 MC-660 MC-760 | NA | W23G7 | 2.7.5 |
| Chipset driver for 16G Intel platforms | Driver DUP | R40PW | 10.1.19928.8615 | AX-660 AX-760 MC-660 MC-760 | Windows Server 2022 Datacenter Windows Server 2025 Datacenter Azure Stack HCI-24H2 |
| iDRAC9 with Lifecycle Controller | Firmware DUP | KYWDC | 7.20.80.50 | AX-660 AX-760 MC-660 MC-760 | NA |
| Expander Storage Backplane | Firmware DUP | J9JW2 | 1.61 | AX-760 MC-760 | NA |
| NVMe Switch Storage Backplane | Firmware DUP | R39FM | 3.33 | AX-760 MC-760 | NA |
| Non-expander Storage Backplane | Firmware DUP | 58MWX | 7.2 | AX-760 MC-760 | NA |
| Non-expander Storage Backplane | Firmware DUP | 9T7YG | 7.2 | AX-660 MC-660 | NA |
| iDRAC Service Module | Firmware DUP | 258RC | 5.4.0.0 | AX-660 AX-760 MC-660 MC-760 | NA |
| CPLD | Firmware DUP | XJG0V | 1.2.7 | AX-660 AX-760 MC-660 MC-760 | NA |
Network Adapters
| Component | Part Number | SDDC Advanced Qualification | RDMA Protocol | Firmware Software Bundle | Firmware Minimum Supported Version | Driver Software Bundle | Driver Minimum Supported Version | Supported OS | Supported Platforms |
|---|---|---|---|---|---|---|---|---|---|
| Broadcom 5720 Dual Port 1 GbE Network LOM Mezz Card | 5NN70 | Management | N/A | 5V215 | 23.31.1 | JDV91 | 233.1.181.0 | Windows Server 2022 Datacenter Windows Server 2025 Datacenter Azure Stack HCI-24H2 | AX-660 AX-760 MC-660 MC-760 |
| Broadcom 57504 Quad Port 10/25GbE, SFP28 Adapter | 3Y64D | Management Compute (Premium) Storage (Premium) | RoCEv2 | HVN2R | 23.31.18.10 | T5K6M | 233.1.181.0 | Windows Server 2025 Datacenter Azure Stack HCI-24H2 | AX-660 AX-760 MC-660 MC-760 |
| Broadcom 57504 Quad Port 10/25GbE SFP28 Adapter, PCIe FH | J3D14 | ||||||||
| Broadcom 57416 Dual Port 10Gb, Base-T, PCIe Adapter, Full Height | 3TM39 | Management Compute (Premium) | N/A | HVN2R | 23.31.18.10 | T5K6M | 233.1.181.0 | Windows Server 2025 Datacenter Azure Stack HCI-24H2 | AX-660 AX-760 MC-660 MC-760 |
| Broadcom 57416 Dual Port 10GbE BASE-T Adapter, PCIe Low Profile | NC5VD | ||||||||
| Broadcom 57416 Dual Port 10GbE BASE-T Adapter, OCP NIC 3.0 | RN1M5 | ||||||||
| Intel E810-XXV Dual Port 25GbE SFP28 Adapter, PCIe LP | 6J1N1 | Management Compute (Premium) Storage (Premium) | iWARP,RoCEv2 | N11TD | 24.0.5 | PH5GK | 24.0.0 | Windows Server 2022 Datacenter Windows Server 2025 Datacenter Azure Stack HCI-24H2 | AX-660 AX-760 MC-660 MC-760 |
| Intel E810-CQDA2 Dual Port 100GbE QSFP28 Adapter, PCIe FH | 85F8F | ||||||||
| Intel E810-XXV Dual Port 25GbE SFP28 Adapter, PCIe FH | CD16M | ||||||||
| Intel E810-CQDA2 Dual Port 100GbE QSFP28 Adapter, PCIe LP | DWNRF | ||||||||
| Intel E810-XXVDA2 Dual Port 1/10/25GbE SFP28 Adapter | PWH3C | ||||||||
| Intel E810-XXVDA4 Quad Port 1/10/25GbE SFP28 Adapter, PCIe FH | VK88G | ||||||||
| Intel E810-XXVDA4 Quad Port 1/10/25GbE SFP28 Adapter | Y4VV5 | ||||||||
| Mellanox ConnectX-6 Dx Dual Port 100GbE QSFP56 PCIe Adapter, FH | 8P2T2 | Management Compute (Premium) Storage (Premium) | RoCEv2 | 2CMVW | 22.41.10.00 | G6M58 | 24.4.26429 | Windows Server 2022 Datacenter Windows Server 2025 Datacenter Azure Stack HCI-24H2 | AX-660 AX-760 MC-660 MC-760 |
| Mellanox ConnectX-6 Dx Dual Port 100GbE QSFP56 PCIe Adapter, LP | F6FXM | ||||||||
| Nvidia ConnectX-6 Lx Dual Port 10/25GbE SFP28 Adapter, PCIe LP | 6XJXK | Management Compute (Premium) Storage (Premium) | RoCEv2 | 1H4PM | 26.41.10.00 | G6M58 | 24.4.26429 | Windows Server 2022 Datacenter Windows Server 2025 Datacenter Azure Stack HCI-24H2 | AX-660 AX-760 MC-660 MC-760 |
| Nvidia ConnectX-6 Lx Dual Port 10/25GbE SFP28 Adapter | DN78C | ||||||||
| Nvidia ConnectX-6 Lx Dual Port 10/25GbE SFP28 Adapter, PCIe FH | R5WK9 | Management Compute (Premium) Storage (Premium) | RoCEv2 | 1H4PM | 26.41.10.00 | G6M58 | 24.4.26429 | Windows Server 2022 Datacenter Windows Server 2025 Datacenter Azure Stack HCI-24H2 | AX-760 MC-760 |
Network Switches
NOTE
A list of supported Network Switch models along with the supported firmware versions can be found here, Physical network requirements for Azure Local.GPUs
| GPU Model | Vendor | Description | Part Number | Firmware version | Driver Version | GPU-P capable | Supported Platform | Supported OS |
|---|---|---|---|---|---|---|---|---|
| A16 | NVIDIA | NVIDIA Ampere A16, PCIe, 250W, 64GB Passive, Double Wide, Full Height GPU,V2 | D1P1T | 94.07.54.00.45 | 553.62 | Yes | AX-760 MC-760 | Azure Stack HCI-24H2 |
| A2 | NVIDIA | NVIDIA Ampere A2, PCIe, 60W, 16GB Passive, Single Wide, Low Profile GPU, V2 | H98K0 | 94.07.5B.00.55 | 553.62 | Yes | AX-660 AX-760 MC-660 MC-760 | Azure Stack HCI-24H2 |
| A2 | NVIDIA | NVIDIA Ampere A2, PCIe, 60W, 16GB Passive, Single Wide, Full Height GPU, V2 | MG5JX | 94.07.5B.00.55 | 553.62 | Yes | AX-660 AX-760 MC-660 MC-760 | Azure Stack HCI-24H2 |
| A40 | NVIDIA | NVIDIA Ampere A40, PCIe, 300W, 48GB Passive, Double Wide, Full Height GPU | W6GX6 | 94.02.5C.00.0F | 553.62 | Yes | AX-760 MC-760 | Azure Stack HCI-24H2 |
| L4 | NVIDIA | NVIDIA L4, PCIe, 72W, 24GB Passive, Single Wide Full Height GPU | NG3PY | 95.04.29.00.06 | 553.62 | Yes | AX-660 AX-760 MC-660 MC-760 | Azure Stack HCI-24H2 |
| L4 | NVIDIA | NVIDIA L4, PCIe, 72W, 24GB Passive, Single Wide Low Profile GPU | V9XT2 | 95.04.29.00.06 | 553.62 | Yes | AX-660 AX-760 MC-660 MC-760 | Azure Stack HCI-24H2 |
| L40 | NVIDIA | NVIDIA Ampere L40, PCIe, 300W, 48GB Passive, Double Wide, Full Height, Full Length, GPU with cable | VHNWT | 95.02.39.00.01 | 553.62 | Yes | AX-760 MC-760 | Azure Stack HCI-24H2 |
| L40S | NVIDIA | NVIDIA Ampere L40S, PCIe, 350W, 48GB Passive, Double Wide, Full Height, Full Length, GPU with cable | 7WK28 | 95.02.66.00.02 | 553.62 | Yes | AX-760 MC-760 | Azure Stack HCI-24H2 |
NOTE
Dell update packages are not available for GPU cards, please download the latest driver version from NVIDIA driver download page.Storage Controllers
| Component | Dell Part Number | Firmware Software Bundle | Firmware Minimum Supported Version | Driver Software Bundle | Driver Minimum Supported Version | Supported Platforms | Supported OS |
|---|---|---|---|---|---|---|---|
| BOSS-N1 | WW56V | C6MVR | 2.1.13.2037 | Inbox | Inbox | AX-660 AX-760 MC-660 MC760 | Windows Server 2022 Datacenter Windows Server 2025 Datacenter Azure Stack HCI-24H2 |
| HBA355i | K6MCJ | CG0P9 | 33.15.00.00 | HDH8G | 2.61.74.00 | AX-660 AX-760 MC-660 MC760 | Windows Server 2025 Datacenter Azure Stack HCI-24H2 |
| HBA355i | K6MCJ | CG0P9 | 33.15.00.00 | R31NP | 2.61.74.00 | AX-660 AX-760 MC-660 MC760 | Windows Server 2022 Datacenter |
SATA M.2 SSD Boot Only
| Type | Drive Type | Form Factor | Endurance | Vendor | Series | Model | Device Part Number (P/N) | Firmware Software Bundle | Firmware Minimum Supported Version | Capacity | Use |
|---|---|---|---|---|---|---|---|---|---|---|---|
| NVMe | PCIe | M.2 | Read Intensive | Micron | 7400 | MTFDKBA960TDZ | PRV6C | N71F4 | 1.6.0 | 960GB | Boot |
| NVMe | PCIe | M.2 | Read Intensive | Micron | 7400 | MTFDKBG960TDZ | 0V8F7 | N71F4 | 1.6.0 | 960GB | Boot |
| NVMe | PCIe | M.2 | Read Intensive | Hynix | PE8010 | HFS960GDC8X099N | 21GXV | R2TTT | 1.3.0 | 960GB | Boot |
| NVMe | PCIe | M.2 | Read Intensive | Hynix | PE9010 | HFS960GEJ8X167N | 4H05X | YJG7C | 1.3.1 | 960GB | Boot |
| NVMe | PCIe | M.2 | Read Intensive | Micron | 7450 | MTFDKBAXXXTFR | PH7J6 | JHKXR | 1.4.0 | 960GB | Boot |
| NVMe | PCIe | M.2 | Read Intensive | Hynix | PE9010 | HFS960GDJ8X167N | XN5KG | 8X8YR | 1.2.1 | 960GB | Boot |
| NVMe | PCIe | M.2 | Read Intensive | Samsung | PM9D3a | MZVL6480HFLUAD3 | C82V9 | FTVJG | 1.0.1 | 480 GB | Boot |
| NVMe | PCIe | M.2 | Read Intensive | Samsung | PM9D3a | MZVL6960HFLBAD3 | 8M3JN | FTVJG | 1.0.1 | 960 GB | Boot |
SAS 3.5" HDD Capacity Only
| Type | Drive Type | Form Factor | Endurance | Vendor | Series | Model | Device Part Number (P/N) | Firmware Software Bundle | Firmware Minimum Supported Version | Capacity | Use |
|---|---|---|---|---|---|---|---|---|---|---|---|
| HDD | SAS | 3.5 | NA | HGST | Vela-A | HUS726T4TALS200 | NT1X2 | J5K8G | PU09 | 4 TB | Capacity |
| HDD | SAS | 3.5 | NA | Toshiba | MG10 | MG10SDA400NY | 9VN79 | 99TKP | EP02 | 4 TB | Capacity |
| HDD | SAS | 3.5 | NA | HGST | Vela-AP | HUS728T8TAL5200 | 44YFV | 8GM6M | RS09 | 8 TB | Capacity |
| HDD | SAS | 3.5 | NA | Toshiba | MG06 | MG06SCA800EY | FV725 | 4G5GY | EH0D | 8 TB | Capacity |
| HDD | SAS | 3.5 | NA | HGST | Leo-A He12 | HUH721212AL5200 | 9HXK6 | 04PM5 | NS11 | 12 TB | Capacity |
| HDD | SAS | 3.5 | NA | WD | Paris-C | WUH721816AL5200 | VF206 | GY6MD | US09 | 16 TB | Capacity |
| HDD | SAS | 3.5 | NA | Seagate | Cimarron BP | ST4000NM019B | 10N7R | 3P5N0 | LW0B | 4 TB | Capacity |
| HDD | SAS | 3.5 | NA | Seagate | Cimarron BP | ST8000NM024B | C5HD0 | NM6GP | LS0C | 8 TB | Capacity |
| HDD | SAS | 3.5 | NA | Toshiba | MG08SD | MG08SDA400NY | FN2YX | GTG81 | EK06 | 4 TB | Capacity |
| HDD | SAS | 3.5 | NA | Seagate | Evans BP | ST12000NM006J | M1C0T | XF65R | PSLG | 12 TB | Capacity |
| HDD | SAS | 3.5 | NA | Seagate | Evans BP | ST16000NM006J | 41DXR | XF65R | PSLG | 16 TB | Capacity |
| HDD | SAS | 3.5 | NA | Toshiba | MG08SD | MG08SDA800EY | NJWMG | F95CX | EL02 | 8 TB | Capacity |
| HDD | SAS | 3.5 | Read Intensive | Seagate | LongsPeak | ST20000NM004D | R3G03 | WCTTD | GS09 | 20 TB | Capacity |
| HDD | SAS | 3.5 | NA | Toshiba | MG10SD | MG10SDA800EY | VJDMM | 99TKP | EP02 | 8 TB | Capacity |
| HDD | SAS | 3.5 | NA | Seagate | CimarronBP(EWP) | DL4000NM019B | F7DTR | M7PKX | LBW4 | 4 TB | Capacity |
| HDD | SAS | 3.5 | NA | Toshiba | MG09 | MG09SCA12TEY | 0N96X | 20Y02 | EM06 | 12 TB | Capacity |
| HDD | SAS | 3.5 | NA | Seagate | Summit | ST12000NM007H | FN7VR | 3VY0D | SWS9 | 12 TB | Capacity |
| HDD | SAS | 3.5 | NA | Toshiba | MG09 | MG09SCA16TEY | MXC46 | 20Y02 | EM06 | 16 TB | Capacity |
| HDD | SAS | 3.5 | NA | Seagate | Summit | ST16000NM007H | R0G8W | C50CR | SYS9 | 16 TB | Capacity |
| HDD | SAS | 3.5 | NA | Toshiba | MG10 | MG10SCA20TEY | NT45N | 0H3CX | EN04 | 20 TB | Capacity |
| HDD | SAS | 3.5 | NA | WD | Paris-D PR2 | WUH722020BL5200 | 1D4CR | XRFX3 | VS19 | 20 TB | Capacity |
| HDD | SAS | 3.5 | NA | Seagate | Summit | ST20000NM007H | R5KP7 | C50CR | SYS9 | 20 TB | Capacity |
| HDD | SAS | 3.5 | NA | WD | London DP | WUH722420AL5200 | MTTCF | FN2N1 | YS01 | 20 TB | Capacity |
| HDD | SAS | 3.5 | NA | WD | Paris-CP | WUH722012CL5200 | 849H4 | VK0PK | AS05 | 12 TB | Capacity |
SATA 2.5" SSD Capacity Only
| Type | Drive Type | Form Factor | Endurance | Vendor | Series | Model | Device Part Number (P/N) | Firmware Software Bundle | Firmware Minimum Supported Version | Capacity | Use |
|---|---|---|---|---|---|---|---|---|---|---|---|
| SSD | SATA | 2.5 | Read Intensive | Intel | S4520 | SSDSC2KB019TZR | 6J65H | VJPKG | DL7C | 1.92TB | Capacity |
| SSD | SATA | 2.5 | Read Intensive | SK Hynix | SE5110 | HFS1T9G3H2X069N | 962FP | 7XTPF | DZ03 | 1.92TB | Capacity |
| SSD | SATA | 2.5 | Read Intensive | Samsung | PM883a | MZ7LH1T9HALT0D3 | 9F9Y6 | 3GHD6 | HG61 | 1.92TB | Capacity |
| SSD | SATA | 2.5 | Read Intensive | Samsung | PM893 | MZ7L31T9HBLTAD3 | 0KYP4 | T3HX9 | HJ64 | 1.92TB | Capacity |
| SSD | SATA | 2.5 | Read Intensive | Samsung | PM893a | MZ7L31T9HELAAD3 | PTD53 | D5D3W | HL58 | 1.92TB | Capacity |
| SSD | SATA | 2.5 | Read Intensive | Micron | 5300 | MTFDDAK1T9TDS | GYGVV | KT63Y | J008 | 1.92TB | Capacity |
| SSD | SATA | 2.5 | Read Intensive | Micron | 5400 | MTFDDAK1T9TGA-1BC1ZABDA | KXNX5 | RJ0WY | K003 | 1.92TB | Capacity |
| SSD | SATA | 2.5 | Read Intensive | Intel | S4520 | SSDSC2KB038TZR | KM4C4 | VJPKG | DL7C | 3.84TB | Capacity |
| SSD | SATA | 2.5 | Read Intensive | SK Hynix | SE5110 | HFS3T8G3H2X069N | 3GDK0 | 7XTPF | DZ03 | 3.84TB | Capacity |
| SSD | SATA | 2.5 | Read Intensive | Samsung | PM883a | MZ7LH3T8HALT0D3 | 5TVXD | 3GHD6 | HG61 | 3.84TB | Capacity |
| SSD | SATA | 2.5 | Read Intensive | Samsung | PM893 | MZ7L33T8HBLTAD3 | GCN5W | T3HX9 | HJ64 | 3.84TB | Capacity |
| SSD | SATA | 2.5 | Read Intensive | Samsung | PM893a | MZ7L33T8HELAAD3 | D7V89 | D5D3W | HL58 | 3.84TB | Capacity |
| SSD | SATA | 2.5 | Read Intensive | Micron | 5300 | MTFDDAK3T8TDT | 4H1RX | R9YDC | J408 | 3.84TB | Capacity |
| SSD | SATA | 2.5 | Read Intensive | Micron | 5400 | MTFDDAK3T8TGA-1BC1ZABDA | CHF46 | JTW3W | K403 | 3.84TB | Capacity |
| SSD | SATA | 2.5 | Mixed Use | Intel | S4620 | SSDSC2KG019TZR | 6XW3M | VJPKG | DL7C | 1.92TB | Capacity |
| SSD | SATA | 2.5 | Mixed Use | SK Hynix | SE5130 | HFS1T9G3E2X149N | HCR09 | 4T2FN | DG00 | 1.92TB | Capacity |
| SSD | SATA | 2.5 | Mixed Use | SK Hynix | SE5031 | HFS1T9G32FEH-BA10A | GKTF1 | 2CY65 | DD02 | 1.92TB | Capacity |
| SSD | SATA | 2.5 | Mixed Use | Samsung | PM897a | MZ7L31T9HENAAD3 | GR4WN | V5XNY | HK58 | 1.92TB | Capacity |
| SSD | SATA | 2.5 | Mixed Use | Samsung | PM897 | MZ7L31T9HBNAAD3 | RRR7M | VRG4Y | HH64 | 1.92TB | Capacity |
| SSD | SATA | 2.5 | Mixed Use | Micron | 5300 | MTFDDAK1T9TDT | MMCDY | KT63Y | J008 | 1.92TB | Capacity |
| SSD | SATA | 2.5 | Mixed Use | Micron | 5400 | MTFDDAK1T9TGB-1BC1ZABDA | XRXX2 | RJ0WY | K003 | 1.92TB | Capacity |
SAS 2.5" SSD Cache or Capacity
| Type | Drive Type | Form Factor | Endurance | Vendor | Series | Model | Device Part Number (P/N) | Firmware Software Bundle | Firmware Minimum Supported Version | Capacity | Use |
|---|---|---|---|---|---|---|---|---|---|---|---|
| SSD | SAS | 2.5 | Mixed Use | Samsung | PM1655 | MZILG800HCHQAD3 | 3CHC8 | 7MTXM | DWG9 | 800 GB | Cache,Capacity |
| SSD | SAS | 2.5 | Mixed Use | Samsung | PM1655 | MZILG1T6HCJRAD3 | 5RJND | 7MTXM | DWG9 | 1.6 TB | Cache,Capacity |
| SSD | SAS | 2.5 | Mixed Use | Kioxia | PM7 | KPM7XVUG1T60 | 4TRHM | T21WT | C10E | 1.6 TB | Cache,Capacity |
| SSD | SAS | 2.5 | Mixed Use | Kioxia | PM6 | KPM6XVUG800G | NNGV4 | NGPR2 | BA48 | 800 GB | Cache,Capacity |
| SSD | SAS | 2.5 | Mixed Use | Kioxia | PM7 | KPM7XVUG800G | X96H8 | T21WT | C10E | 800 GB | Cache,Capacity |
SAS 2.5" SSD Capacity Only
| Type | Drive Type | Form Factor | Endurance | Vendor | Series | Model | Device Part Number (P/N) | Firmware Software Bundle | Firmware Minimum Supported Version | Capacity | Use |
|---|---|---|---|---|---|---|---|---|---|---|---|
| SSD | SAS | 2.5 | Read Intensive | Samsung | PM1653 | MZILG1T9HCJRAD3 | NRR34 | 3MV58 | DSG9 | 1.92 TB | Capacity |
| SSD | SAS | 2.5 | Read Intensive | Samsung | PM1653 | MZILG3T8HCLSAD3 | 9N32F | 3MV58 | DSG9 | 3.84 TB | Capacity |
| SSD | SAS | 2.5 | Read Intensive | Samsung | PM1653 | MZILG7T6HBLAAD3 | Y8H7M | 3MV58 | DSG9 | 7.68 TB | Capacity |
| SSD | SAS | 2.5 | Read Intensive | Kioxia | PM7 | KPM7XRUG1T92 | 6K35K | T21WT | C10E | 1.92 TB | Capacity |
| SSD | SAS | 2.5 | Read Intensive | Kioxia | PM7 | KPM7XRUG3T84 | MT0R5 | T21WT | C10E | 3.84 TB | Capacity |
| SSD | SAS | 2.5 | Read Intensive | Kioxia | PM7 | KPM7XRUG7T68 | 7N1WT | T21WT | C10E | 7.68 TB | Capacity |
NVMe 2.5" Cache or Capacity
| Type | Drive Type | Form Factor | Endurance | Vendor | Series | Model | Device Part Number (P/N) | Firmware Software Bundle | Firmware Minimum Supported Version | Capacity | Use |
|---|---|---|---|---|---|---|---|---|---|---|---|
| NVMe | PCIe | 2.5 | Mixed Use | Samsung | PM1735 SP 3WPD, SSD, NVMe, 2.5, 512e, ISE | MZWLJ1T6HBJRAD3 | 6GK00 | 5CM3G | 2.5.0 | 1.6 TB | Cache, Capacity |
| NVMe | PCIe | 2.5 | Mixed Use | Samsung | PM1735 SP 3WPD, SSD, Gen4 NVMe, 2.5, 512e, ISE | MZWLJ3T2HBJRAD3 | 15TVC | 5CM3G | 2.5.0 | 3.2TB | Cache,Capacity |
| NVMe | PCIe | 2.5 | Mixed Use | Samsung | PM1735 SP 3WPD, SSD, Gen4 NVMe, 2.5, 512e, ISE | MZWLJ6T4HALAAD3 | F6V5P | 5CM3G | 2.5.0 | 6.4TB | Cache,Capacity |
| NVMe | PCIe | 2.5 | Mixed Use | Kioxia | CM6 SP | KCM6XVUL1T60 | P03YC | GMM6V | 2.2.2 | 1.6 TB | Cache, Capacity |
| NVMe | PCIe | 2.5 | Mixed Use | Kioxia | CM6 SP | KCM6XVUL3T20 | 97GR0 | GMM6V | 2.2.2 | 3.2 TB | Cache, Capacity |
| NVMe | PCIe | 2.5 | Mixed Use | Kioxia | CM6 SP | KCM6XVUL6T40 | K916X | GMM6V | 2.2.2 | 6.4 TB | Cache, Capacity |
| NVMe | PCIe | 2.5 | Mixed Use | Samsung | PM1735 V2 SP 3WPD | MZWLR3T2HBLSAD3 | V69W3 | 5V3P7 | 2.5.0 | 3.2 TB | Cache, Capacity |
| NVMe | PCIe | 2.5 | Mixed Use | Samsung | PM1735 V2 SP 3WPD | MZWLR6T4HALAAD3 | H8D5M | 5V3P7 | 2.5.0 | 6.4 TB | Cache, Capacity |
| NVMe | PCIe | 2.5 | Mixed Use | Samsung | PM1735a | MZWLR1T6HCJRAD3 | H8GHV | 71KRG | 1.2.0 | 1.6 TB | Cache,Capacity |
| NVMe | PCIe | 2.5 | Mixed Use | Samsung | PM1735a | MZWLR3T2HCLSAD3 | 617H6 | 71KRG | 1.2.0 | 3.2 TB | Cache,Capacity |
| NVMe | PCIe | 2.5 | Mixed Use | Samsung | PM1735a | MZWLR6T4HBLAAD3 | 9F6Y3 | 71KRG | 1.2.0 | 6.4 TB | Cache,Capacity |
| NVMe | PCIe | 2.5 | Mixed Use | Kioxia | CM7 | KCM7XVUG1T60 | MP4F2 | K1JTM | 2.0.3 | 1.6 TB | Cache, Capacity |
| NVMe | PCIe | 2.5 | Mixed Use | Kioxia | CM7 | KCM7XVUG3T20 | XFNX0 | K1JTM | 2.0.3 | 3.2 TB | Cache, Capacity |
| NVMe | PCIe | 2.5 | Mixed Use | Kioxia | CM7 | KCM7XVUG6T40 | 8RJJ9 | K1JTM | 2.0.3 | 6.4 TB | Cache, Capacity |
| NVMe | PCIe | 2.5 | Mixed Use | Hynix | PS1030 | HFS1T6GEJVX171N | 1HYKD | 9M65G | 1.2.0 | 1.6 TB | Cache, Capacity |
| NVMe | PCIe | 2.5 | Mixed Use | Hynix | PS1030 | HFS3T2GEJVX171N | 9VWPD | 9M65G | 1.2.0 | 3.2 TB | Cache, Capacity |
| NVMe | PCIe | 2.5 | Mixed Use | Hynix | PS1030 | HFS6T4GEJVX171N | PYMY6 | 9M65G | 1.2.0 | 6.4 TB | Cache, Capacity |
| NVMe | PCIe | 2.5 | Mixed Use | Samsung | PM1745 | MZWLO1T6HCJR-00AD3 | FVC2P | V7V0K | 1.0.0 | 1.6 TB | Cache, Capacity |
| NVMe | PCIe | 2.5 | Mixed Use | Samsung | PM1745 | MZWLO3T2HCLS-00AD3 | FDNHD | V7V0K | 1.0.0 | 3.2 TB | Cache, Capacity |
| NVMe | PCIe | 2.5 | Mixed Use | Samsung | PM1745 | MZWLO6T4HBLA-00AD3 | 64K9C | V7V0K | 1.0.0 | 6.4 TB | Cache, Capacity |
NVMe 2.5" Capacity Only
| Type | Drive Type | Form Factor | Endurance | Vendor | Series | Model | Device Part Number (P/N) | Firmware Software Bundle | Firmware Minimum Supported Version | Capacity | Use |
|---|---|---|---|---|---|---|---|---|---|---|---|
| NVMe | PCIe | 2.5 | Read Intensive | Samsung | PM1733 V2 | MZWLR3T8HBLSAD3 | G5N65 | 5V3P7 | 2.5.0 | 3.84 TB | Capacity |
| NVMe | PCIe | 2.5 | Read Intensive | Samsung | PM1733 V2 | MZWLR7T6HALAAD3 | DX74Y | 5V3P7 | 2.5.0 | 7.68 TB | Capacity |
| NVMe | PCIe | 2.5 | Read Intensive | Samsung | PM1733a | MZWLR1T9HCJRAD3 | 8PMRM | 71KRG | 1.2.0 | 1.92 TB | Capacity |
| NVMe | PCIe | 2.5 | Read Intensive | Samsung | PM1733a | MZWLR3T8HCLSAD3 | RJKM5 | 71KRG | 1.2.0 | 3.84 TB | Capacity |
| NVMe | PCIe | 2.5 | Read Intensive | Samsung | PM1733a | MZWLR7T6HBLAAD3 | R1J8J | 71KRG | 1.2.0 | 7.68 TB | Capacity |
| NVMe | PCIe | 2.5 | Read Intensive | Samsung | PM1733a | MZWLR15THBLAAD3 | D4CJG | 71KRG | 1.2.0 | 15.36 TB | Capacity |
| NVMe | PCIe | 2.5 | Read Intensive | Kioxia | CM6 | KCM6XRUL1T92 | N0VK0 | GMM6V | 2.2.2 | 1.92 TB | Capacity |
| NVMe | PCIe | 2.5 | Read Intensive | Kioxia | CM6 | KCM6XRUL3T84 | 8W2G5 | GMM6V | 2.2.2 | 3.84 TB | Capacity |
| NVMe | PCIe | 2.5 | Read Intensive | Kioxia | CM6 | KCM6XRUL7T68 | VD0JX | GMM6V | 2.2.2 | 7.68 TB | Capacity |
| NVMe | PCIe | 2.5 | Read Intensive | Kioxia | CM6 | KCM6XRUL15T3 | J91CR | GMM6V | 2.2.2 | 15.36 TB | Capacity |
| NVMe | PCIe | 2.5 | Read Intensive | Kioxia | CM7 | KCM7XRUG1T92 | M8YW0 | K1JTM | 2.0.3 | 1.92 TB | Capacity |
| NVMe | PCIe | 2.5 | Read Intensive | Kioxia | CM7 | KCM7XRUG3T84 | XHYGF | K1JTM | 2.0.3 | 3.84 TB | Capacity |
| NVMe | PCIe | 2.5 | Read Intensive | Kioxia | CM7 | KCM7XRUG7T68 | VV2M7 | K1JTM | 2.0.3 | 7.68 TB | Capacity |
| NVMe | PCIe | 2.5 | Read Intensive | Kioxia | CM7 | KCM7XRUG15T3 | DX2PD | K1JTM | 2.0.3 | 15.36 TB | Capacity |
| NVMe | PCIe | 2.5 | Read Intensive | Kioxia | CD7 | KCD7XRUG7T68 | 0RD61 | K6597 | 2.0.1 | 7.68 TB | Capacity |
| NVMe | PCIe | 2.5 | Read Intensive | Kioxia | CD8 | KCD8XRUG3T84 | N1MK1 | HV8P1 | 2.0.1 | 3.84 TB | Capacity |
| NVMe | PCIe | 2.5 | Read Intensive | Hynix | PS1010 | HFS1T9GEJVX171N | 7GGK1 | 9M65G | 1.2.0 | 1.92 TB | Capacity |
| NVMe | PCIe | 2.5 | Read Intensive | Hynix | PS1010 | HFS3T8GEJVX171N | J4TDK | 9M65G | 1.2.0 | 3.84 TB | Capacity |
| NVMe | PCIe | 2.5 | Read Intensive | Hynix | PS1010 | HFS7T6GEJVX171N | 2533N | 9M65G | 1.2.0 | 7.68 TB | Capacity |
| NVMe | PCIe | 2.5 | Read Intensive | Hynix | PS1010 | HFS15T3EJVX171N | 8TY8G | 9M65G | 1.2.0 | 15.36 TB | Capacity |
| NVMe | PCIe | 2.5 | Read Intensive | Hynix | PE8010 | HFS960GECTX088N | WR2FG | T1XKD | 1.3.0 | 960 GB | Capacity |
| NVMe | PCIe | 2.5 | Read Intensive | Hynix | PE8110 | HFS7T6GEETX099N | RG3T2 | TDGKY | 1.1.0 | 7.68 TB | Capacity |
| NVMe | PCIe | 2.5 | Read Intensive | Kioxia | CD8 | KCD8XRUG960G | YNGYD | HV8P1 | 2.0.1 | 960 GB | Capacity |
| NVMe | PCIe | 2.5 | Read Intensive | Micron | 7450 | MTFDKCC960TFR | KXT48 | TVCWT | 1.4.0 | 960 GB | Capacity |
| NVMe | PCIe | 2.5 | Read Intensive | Micron | 7500 | MTFDKCC960TGP | G7NCH | 5F07C | 1.2.0 | 960 GB | Capacity |
| NVMe | PCIe | 2.5 | Read Intensive | Samsung | PM9A3 | MZQL2960HCJRAD3 | 6HYWM | XMFKX | 1.1.1 | 960 GB | Capacity |
| NVMe | PCIe | 2.5 | Read Intensive | Samsung | PM1733a | MZWLR1T9HCJRAD3 | 8PMRM | 71KRG | 1.2.0 | 1.92 TB | Capacity |
| NVMe | PCIe | 2.5 | Read Intensive | Samsung | PM1733 V2 | MZWLR1T9HBJRAD3 | WPR17 | 5V3P7 | 2.5.0 | 1.92 TB | Capacity |
| NVMe | PCIe | 2.5 | Read Intensive | Samsung | PM9A3 | MZQL21T9H | TGYF5 | XMFKX | 1.1.1 | 1.92TB | Capacity |
| NVMe | PCIe | 2.5 | Read Intensive | Micron | 7450 | MTFDKCC1T9TFR | JH61J | TVCWT | 1.4.0 | 1.92 TB | Capacity |
| NVMe | PCIe | 2.5 | Read Intensive | Micron | 7500 | MTFDKCC1T9TGP | M7RHM | 5F07C | 1.2.0 | 1.92 TB | Capacity |
| NVMe | PCIe | 2.5 | Read Intensive | Hynix | PE8110 | HFS1T9GEETX099N | 147DR | TDGKY | 1.1.0 | 1.92 TB | Capacity |
| NVMe | PCIe | 2.5 | Read Intensive | Micron | 7450 | MTFDKCC3T8TFR | NDK2D | TVCWT | 1.4.0 | 3.84 TB | Capacity |
| NVMe | PCIe | 2.5 | Read Intensive | Kioxia | CD7 | KCD7XRUG3T84 | RFYP9 | K6597 | 2.0.1 | 3.84 TB | Capacity |
| NVMe | PCIe | 2.5 | Read Intensive | Hynix | PE8010 | HFS3T8GECTX088N | V6WP5 | T1XKD | 1.3.0 | 3.84 TB | Capacity |
| NVMe | PCIe | 2.5 | Read Intensive | Samsung | PM9A3 | MZQL23T8HCLSAD3 | P7G03 | XMFKX | 1.1.1 | 3.84 TB | Capacity |
| NVMe | PCIe | 2.5 | Read Intensive | Micron | 7500 | MTFDKCC3T8TGP | GT3F3 | 5F07C | 1.2.0 | 3.84 TB | Capacity |
| NVMe | PCIe | 2.5 | Read Intensive | Intel | Arbordale Plus R P5316 | SSDPF2NV307TZ | 4KCVT | 4XT8T | 1.6.0 | 30.72 TB | Capacity |
| NVMe | PCIe | 2.5 | Read Intensive | Samsung | PM1743 | MZWLO3T8HCLS-00AD3 | 9GXVF | V7V0K | 1.0.0 | 3.84 TB | Capacity |
| NVMe | PCIe | 2.5 | Read Intensive | Samsung | PM1743 | MZWLO7T6HBLA-00AD3 | DNPR4 | V7V0K | 1.0.0 | 7.68 TB | Capacity |
| NVMe | PCIe | 2.5 | Read Intensive | Kioxia | CD8 | KCD8XRUG1T92 | NNKCT | HV8P1 | 2.0.1 | 1.92 TB | Capacity |
| NVMe | PCIe | 2.5 | Read Intensive | Samsung | PM9A3 | MZQL27T6HBLAAD3 | 30FX3 | XMFKX | 1.1.1 | 7.68TB | Capacity |
| NVMe | PCIe | 2.5 | Read Intensive | Micron | 7450 | MTFDKCC7T6TFR | 91KYJ | TVCWT | 1.4.0 | 7.68TB | Capacity |
| NVMe | PCIe | 2.5 | Read Intensive | Micron | 7500 | MTFDKCC7T6TGP | RTJFW | 5F07C | 1.2.0 | 7.68TB | Capacity |
| NVMe | PCIe | 2.5 | Read Intensive | Kioxia | CD8 | KCD8XRUG7T68 | MXD8J | HV8P1 | 2.0.1 | 7.68TB | Capacity |
| NVMe | PCIe | 2.5 | Read Intensive | SK Hynix | PE8110 | HFS960GEETX099N | 26WJ0 | TDGKY | 1.1.0 | 960GB | Capacity |
| NVMe | PCIe | 2.5 | Read Intensive | Samsung | PM1743 | MZWLO1T9HCJR-00AD3 | G64N5 | V7V0K | 1.0.0 | 1.92TB | Capacity |
| NVMe | PCIe | 2.5 | Read Intensive | SK Hynix | PE8110 | HFS3T8GEETX099N | 2V97V | TDGKY | 1.1.0 | 3.84TB | Capacity |
| NVMe | PCIe | 2.5 | Read Intensive | Samsung | PM1743 | MZWLO15THBLA-00AD3 | VPWMR | V7V0K | 1.0.0 | 15.36TB | Capacity |
| NVMe | PCIe | 2.5 | Read Intensive | Samsung | PM9D3a | MZWL6960HFJA-00AD3 | 71Y2J | X5N7N | 1.0.1 | 960 GB | Capacity |
| NVMe | PCIe | 2.5 | Read Intensive | Samsung | PM9D3a | MZVL61T9HBL1-00AD3 | NYPRM | FTVJG | 1.0.1 | 1.92 TB | Capacity |
| NVMe | PCIe | 2.5 | Read Intensive | Samsung | PM9D3a | MZWL63T8HFLT-00AD3 | 2H60T | X5N7N | 1.0.1 | 3.84 TB | Capacity |
| NVMe | PCIe | 2.5 | Read Intensive | Samsung | PM9D3a | MZWL67T6HBLC-00AD3 | VYT6X | X5N7N | 1.0.1 | 7.68 TB | Capacity |
3.3 - Azure Local Support Matrix for 45n0c (Dell 2512)
NOTE
SBE package 4.2.2512.xxxx and newer will only support Azure Local solution versions 12.*.1001.* or 12.*.1002.* (HCI OS 24H2) and newer.
Dell will support the use of SBE package 4.2.2509.xxxx on Azure Local instances running version 11.* (HCI OS 23H2) until April 2026. Dell recommends that instances running version 11.* be upgraded to 12.* as soon as possible to remain in a supported state.
Supported Platforms
| Model | Supported Operating System |
|---|---|
| AX-4510c | Windows Server 2022 Datacenter Windows Server 2025 Datacenter Azure Stack HCI-24H2 |
| AX-4520c | Windows Server 2022 Datacenter Windows Server 2025 Datacenter Azure Stack HCI-24H2 |
| MC-4510c | Azure Stack HCI-24H2 |
| MC-4520c | Azure Stack HCI-24H2 |
Base Components
| Component | Type | Software Bundle | Minimum Supported Version | Supported Platforms | Supported OS |
|---|---|---|---|---|---|
| BIOS | Firmware DUP | FP79X | 1.21.1 | AX-4510c AX-4520c MC-4510c MC-4520c | NA | 0YP04 | 1.19.1 |
| iDRAC9 with Lifecycle Controller | Firmware DUP | KYWDC | 7.20.80.50 | AX-4510c AX-4520c MC-4510c MC-4520c | NA |
| Chipset driver for 15G Intel platforms | Driver DUP | C2MC3 | 10.1.19928.8615 | AX-4510c AX-4520c MC-4510c MC-4520c | Windows Server 2022 Datacenter Windows Server 2025 Datacenter Azure Stack HCI-24H2 |
| iDRAC Service Module | Firmware DUP | 258RC | 5.4.0.0 | AX-4510c AX-4520c MC-4510c MC-4520c | NA |
| Chassis Manager | Firmware DUP | WC84H | 5 | AX-4510c AX-4520c MC-4510c MC-4520c | NA |
| CPLD | Firmware DUP | G1YRC | 1.0.5 | AX-4510c AX-4520c MC-4510c MC-4520c | NA |
Network Adapters
| Component | Part Number | SDDC Advanced Qualification | RDMA Protocol | Firmware Software Bundle | Firmware Minimum Supported Version | Driver Software Bundle | Driver Minimum Supported Version | Supported OS | Supported Platforms |
|---|---|---|---|---|---|---|---|---|---|
| Broadcom 57504 Quad Port 10/25GbE SFP28 Adapter, PCIe FH | J3D14 | Management Compute (Premium) Storage (Premium) | RoCEv2 | HVN2R | 23.31.18.10 | T5K6M | 1.10.3 | Windows Server 2025 Datacenter Azure Stack HCI-24H2 | AX-4520c MC-4520c |
| Intel E823 | KJMHJ | Management Compute (Premium) Storage (Premium) | iWARP,RoCEv2 | N11TD | 24.0.5 | PH5GK | 24.0.0 | Windows Server 2022 Datacenter Windows Server 2025 Datacenter Azure Stack HCI-24H2 | AX-4510c AX-4520c MC-4510c MC-4520c |
| Intel E810-CQDA2 Dual Port 100GbE QSFP28 Adapter, PCIe FH | 85F8F | Management Compute (Premium) Storage (Premium) | iWARP,RoCEv2 | N11TD | 24.0.5 | PH5GK | 24.0.0 | Windows Server 2022 Datacenter Windows Server 2025 Datacenter Azure Stack HCI-24H2 | AX-4520c MC-4520c |
| Intel E810-XXV Dual Port 25GbE SFP28 Adapter, PCIe FH | CD16M | ||||||||
| Mellanox ConnectX-6 Dx Dual Port 100GbE QSFP56 PCIe Adapter, FH | 8P2T2 | Management Compute (Premium) Storage (Premium) | RoCEv2 | 2CMVW | 22.41.10.00 | G6M58 | 24.4.26429 | Windows Server 2022 Datacenter Windows Server 2025 Datacenter Azure Stack HCI-24H2 | AX-4520c MC-4520c |
| Nvidia ConnectX-6 Lx Dual Port 10/25GbE SFP28 Adapter, PCIe FH | R5WK9 | Management Compute (Premium) Storage (Premium) | RoCEv2 | 1H4PM | 26.41.10.00 | G6M58 | 24.4.26429 | Windows Server 2022 Datacenter Windows Server 2025 Datacenter Azure Stack HCI-24H2 | AX-4520c MC-4520c |
Network Switches
NOTE
A list of supported Network Switch models along with the supported firmware versions can be found here, Physical network requirements for Azure Local.GPUs
| GPU Model | Vendor | Description | Part Number | Firmware version | Driver Version | GPU-P capable | Supported Platform | Supported OS |
|---|---|---|---|---|---|---|---|---|
| A2 | NVIDIA | NVIDIA Ampere A2, PCIe, 60W, 16GB Passive, Single Wide, Full Height GPU, V2 | MG5JX | 94.07.5B.00.55 | 528.89 WHQL | Yes | AX-4520c MC-4520c | Azure Stack HCI-24H2 |
| L4 | NVIDIA | NVIDIA L4, PCIe, 72W, 24GB Passive, Single Wide Full Height GPU | NG3PY | 95.04.29.00.06 | 528.89 WHQL | Yes | AX-4520c MC-4520c | Azure Stack HCI-24H2 |
NOTE
Dell update packages are not available for GPU cards, please download the latest driver version from NVIDIA driver download page.Storage Controllers
| Component | Dell Part Number | Firmware Software Bundle | Firmware Minimum Supported Version | Driver Software Bundle | Driver Minimum Supported Version | Supported Platforms | Supported OS |
|---|---|---|---|---|---|---|---|
| BOSS-N1 | M88HH | 67GHR | 2.1.13.2037 | Inbox | AX-4510c AX-4520c MC-4510c MC-4520c | Windows Server 2022 Datacenter Windows Server 2025 Datacenter Azure Stack HCI-24H2 |
NVMe 2.5" Capacity Only
| Type | Drive Type | Form Factor | Endurance | Vendor | Series | Model | Device Part Number (P/N) | Firmware Software Bundle | Firmware Minimum Supported Version | Capacity | Use |
|---|---|---|---|---|---|---|---|---|---|---|---|
| NVMe | PCIe | M.2 | Read Intensive | Micron | 7400 | MTFDKBG1T9TDZ | G18YX | N71F4 | 1.6.0 | 1.92TB | Capacity |
| NVMe | PCIe | M.2 | Read Intensive | Micron | 7400 | MTFDKBG3T8TDZ | 2RN2N | N71F4 | 1.6.0 | 3.84TB | Capacity |
| NVMe | PCIe | M.2 | Read Intensive | Hynix | PE8010 | HFS960GDC8X099N | 21GXV | R2TTT | 1.3.0 | 960GB | Capacity |
| NVMe | PCIe | M.2 | Mixed Use | Hynix | PE8030 | HFS800GDC8X088N | 31XDY | R2TTT | 1.3.0 | 800GB | Capacity |
| NVMe | PCIe | M.2 | Mixed Use | Micron | 7450 | MTFDKBA800TFS | F9MKX | JHKXR | 1.4.0 | 800GB | Capacity |
| NVMe | PCIe | M.2 | Mixed Use | Hynix | PE9030 | HFS800GDJ8X167N | FYWN9 | 9GH86 | 1.2.1 | 800GB | Capacity |
| NVMe | PCIe | M.2 | Read Intensive | Hynix | PE9010 | HFS960GDJ8X167N | XN5KG | 8X8YR | 1.2.1 | 960GB | Capacity |
| NVMe | PCIe | M.2 | Read Intensive | Hynix | PE9010 | HFS960GEJ8X167N | 4H05X | YJG7C | 1.3.1 | 960GB | Capacity |
| NVMe | PCIe | M.2 | Read Intensive | Micron | 7450 | MTFDKBA960TFR | PH7J6 | JHKXR | 1.4.0 | 960GB | Capacity |
| NVMe | PCIe | M.2 | Read Intensive | Micron | 7450 | MTFDKBG1T9TFR | J927V | JHKXR | 1.4.0 | 1.92TB | Capacity |
| NVMe | PCIe | M.2 | Read Intensive | Hynix | PE8110 | HFS1T9GDE0X088N | MY5M4 | 19H08 | 1.1.0 | 1.92TB | Capacity |
| NVMe | PCIe | M.2 | Read Intensive | Micron | 7450 | MTFDKBG3T8TFR | 5FP33 | JHKXR | 1.4.0 | 3.84TB | Capacity |
| NVMe | PCIe | M.2 | Read Intensive | Hynix | PE8110 | HFS3T8GDE0X088N | 5JR5H | 19H08 | 1.1.0 | 3.84TB | Capacity |
3.4 - Azure Local Golden Images (Dell 2512)
NOTE
SBE package 4.2.2512.xxxx and newer will only support Azure Local solution versions 12.*.1001.* or 12.*.1002.* (HCI OS 24H2) and newer.
Dell will support the use of SBE package 4.2.2509.xxxx on Azure Local instances running version 11.* (HCI OS 23H2) until April 2026. Dell recommends that instances running version 11.* be upgraded to 12.* as soon as possible to remain in a supported state.
The Dell Technologies provided operating system golden image for Azure Local instances is for imaging AX servers prior to deploying an Azure Local instance. This image is based on the Azure Stack HCI OS, with Microsoft customization and Dell Technologies customization. This image includes drivers provided by Dell Technologies.
Azure Local Golden Images for Solution versions 12.2510.1002.* - 12.2603.1002.* with Dell SBE 4.2.2512.*
3.5 - Azure Local Dell Solution Builder Extensions Release Notes (Dell 2512)
Overview
Solution Builder Extensions (SBE) for Azure Local. Firmware, Driver, and WDAC Supplemental policy for lifecycle management for Azure Local instances running on Dell AX servers.
| SBE Release Version | Download links | Supported Servers | Driver and Firmware versions | HCI OS Version | Supported Solution Version |
|---|---|---|---|---|---|
| 4.2.2512.1616 | https://www.dell.com/support/home/en-us/drivers/driversdetails?driverid=52Y76 | AX-660 AX-760 AX-4510C AX-4520C APEX MC-660 APEX MC-760 APEX MC-4510C APEX MC-4520C |
Azure Local Support Matrix for 16G (2512) | Solutions for Microsoft Azure Azure Local Support Matrix for AX-4500 (2512) | Solutions for Microsoft Azure |
24H2 | 12.*.1002.* 12.*.1001.* |
| 4.2.2512.1514 | https://www.dell.com/support/home/en-us/drivers/driversdetails?driverid=DTD2M | AX-650 AX-750 AX-6515 AX-7525 |
Azure Local Support Matrix for 14G-15G (2512) | Solutions for Microsoft Azure | 24H2 | 12.*.1002.* 12.*.1001.* |
| 4.2.2512.1403 | https://www.dell.com/support/home/en-us/drivers/driversdetails?driverid=VJ48M | AX-640 AX-740xd |
Azure Local Support Matrix for 14G-15G (2512) | Solutions for Microsoft Azure | 24H2 | 12.*.1002.* 12.*.1001.* |
Important Caveats
-
NVIDIA ConnectX NIC resets have been observed by customers under certain workloads. Affected driver version
25.1.26647.0and corresponding firmware was introduced in the SBE4.2.2506.n. SBE4.2.2509.nand4.2.2512.nwill downgrade the NVIDIA ConnectX driver to version24.4.26429.0, but the ConnectX firmware must be manually downgraded prior to installing SBE4.2.2512.n. For details and instructions, see KB000376360. -
Dell Micron 7450 and 7500 NVMe SSDs occasionally enter a panic state. For details and instructions, see KB000368482. From the SBE table above, find the version relevant to your product and install the SBE with updated firmware that resolves the defect for the Micron 7450 and 7500 drives.
-
SBE versions
4.2.2512.1616and4.2.2512.1514include the same BIOS version as previously released SBE versions4.2.2509.1625and4.1.2509.1516for the 16G, 45n0c, AX-650, and AX-750. New Azure Local instance deployments may have newer BIOS versions as listed in the Dell 2512 support matrix. The installation of SBE4.2.2512.nwill not downgrade the BIOS version in this case. The supported BIOS versions are listed in the Dell 2512 support matrix.
New for This Release
SBE 4.2.2512.1616
- Driver and Firmware 2512 Update
- Added server component health checks
- Added checks for downloading the latest SBE discovery manifest during updates that use automated SBE download
- Added support for APEX MC branded nodes
- To install this SBE version, Azure Local instances that are already deployed must be running solution version
12.*.1001.*or12.*.1002.*
SBE 4.2.2512.1514
- Driver and Firmware 2512 Update
- Added server component health checks
- Added checks for downloading the latest SBE discovery manifest during updates that use automated SBE download
- To install this SBE version, Azure Local instances that are already deployed must be running solution version
12.*.1001.*or12.*.1002.*
SBE 4.2.2512.1403
- Driver and Firmware 2512 Update
- Added server component health checks
- Added checks for downloading the latest SBE discovery manifest during updates that use automated SBE download
- To install this SBE version, Azure Local instances that are already deployed must be running solution version
12.*.1001.*or12.*.1002.*
Prerequisites
Update Firmware and Drivers Prior to Azure Local Instance Deployment
Drivers and firmware need to be installed on the servers that will be the instance members prior to deployment from the Azure Portal or using an ARM Template. This requirement is independent of the installation of the SBE. The machines imaged with Dell provided golden image will include the required Dell provided Out-of-Box drivers, but the firmware versions must still be validated and possibly updated prior to the instance deployment. The most current driver and firmware versions listed in the support matrix are recommended.
The Azure Local support matrix for Dell AX servers can be found here, Support Matrix | Solutions for Microsoft Azure.
iDRAC Access from Host OS
The iDRAC pass-through NIC must be enabled and have an IP address assigned to it. iDRAC pass-through NIC is enabled by default and has an APIPA (Automatic Private IP Addressing) IP address assigned. This IP address must be accessible by the iDRAC NIC Remote NDIS Compatible Device in the host operating system. This is a dedicated link to the host OS and cannot be accessed outside the host OS.
iDRAC access health checks are introduced starting with the December 2024 SBE releases. These health checks verify that the required iDRAC access has been implemented on each server that will be an instance member. The iDRAC access health checks run automatically as part of the standard built-in SBE health checks. These health checks must complete successfully for the SBE installation to proceed. Failure remediation instructions are provided in case the health check fails.
Manual iDRAC Access Verification
The following procedures provide a manual method for verifying the required iDRAC access. The iDRAC access health checks provide automated and more comprehensive verification method.
Example iDRAC Pass-through settings
The iDRAC NIC Remote NDIS Compatible Device in the host operating system is used by the SBE CAU plug-in to update firmware. This NIC must be enabled and have an IP address assigned to it. By default, this NIC is enabled and has an APIPA IP address assigned to it that can access the iDRAC pass-through IP address. DHCP client should not be disabled on this NIC.
This is a dedicated link to iDRAC from the host OS and cannot be accessed outside the host OS.
The IP address can be obtained using the following PowerShell command:
Get-NetAdapter -InterfaceDescription "Remote NDIS Compatible Device" | Get-NetIPAddress -AddressFamily IPv4 | Select-Object -Property IPAddress
Example:
IPAddress
---------
169.254.0.2
Azure Local instances using Non-Transparent, Unauthenticated Network Proxy
Azure Local instances using non-transparent, unauthenticated network proxy must have the iDRAC pass-through IP address in the network proxy exclusion list. For information on how to configure the non-transparent, unauthenticated network proxy see, Configure proxy settings for Azure Local.
The following example shows how to configure the APIPA IP address range 169.254.0.0/16 to be in the network proxy exclusion list.
$NoProxy = "localhost,127.0.0.1,.svc,10.0.0.0/8,172.16.0.0/12,192.168.0.0/16,.contoso.com,node1,node2,ClusterName,169.254.0.0/16"
[Environment]::SetEnvironmentVariable("NO_PROXY", $NoProxy, "Machine")
Download Connector – Automated download of future SBE release
Overview
Download Connector is a component in the SBE (Solutions Builder Extensions) that automates the downloading of new SBE bundles as they become available for your cluster. Once an SBE that includes the Download Connector is installed on your cluster, manually downloading and importing follow-on SBE version is no longer required. The update service will automate the downloading of the next available SBE for your Azure Local instance in a similar manner to how the download of the solution upgrade is automated. The Download Connector is part of the SBE version 4.1.2505.1501 and newer.
SBE versions that include the Download Connector also include system and update health checks that proactively verify the ability of the Download Connector to access the required remote resource when it comes time to download the next SBE for your cluster. System health checks are run once per day and update health checks are run at the initial phase of the update process.
Firewall Requirements
The SBE Download Connector running in the Azure Local instance needs to periodically connect to the internet resources to download SBE bundles for your cluster. The following outbound connectivity is required.
| Endpoint Description | Endpoint URL | Port |
|---|---|---|
| SBE bundle download | dl.dell.com/* | 443 |
| SBE download catalog | downloads.dell.com/filestore/Prod/SbeDownloadCatalog/AX_SBE_Download_Catalog.xml | 443 |
| SBE download catalog redirection | aka.ms/DellAzureLocalSBEDownloadCatalog | 443 |
| Digicert Certificate Revocation Status | http://crl3.digicert.com/* | 80 |
| Digicert Certificate Revocation Status | http://crl4.digicert.com/* | 80 |
Installation
Download and Extract
CAUTION
Steps 3 and 4 must be completed to ensure that the latest SBE Discovery manifest is used.SBE bundle zip file has the naming convention Bundle_SBE_Dell_AS-HCI-AX-GenerationNumber_VersionNumber.zip.
-
Download the SBE bundle zip file for your Dell AX server generation using the download link above. The SBE bundles are specific to the AX 14G platforms, AX 15G platforms, and AX 16G platforms
-
Extract the three SBE files from the SBE bundle zip file. There are two xml files and one zip file. Example:
- SBE_Dell_AS-HCI-AX-16G-45n0c_4.2.2506.1600.xml
- SBE_Dell_AS-HCI-AX-16G-45n0c_4.2.2506.1600.zip
- SBE_Discovery_Dell.xml
-
Navigate to https://aka.ms/AzureStackSBEUpdate/DellEMC and press
Ctrl + Sto download the SBE_Discovery_Dell.xml file -
Replace the SBE_Discovery_Dell.xml file that was in the SBE bundle zip with the file downloaded in step 3
There are two options for installing the SBE package. The SBE package can be installed as part of instance creation or imported after instance creation is successfully completed. The importing method is also used to update the SBE to a newer version when the currently running SBE does not include Download Connector capability.
Automated Download and Extraction
SBE release starting with 4.1.2505.1501 and newer include the Download Connector that automates downloading and extracting the SBE. Manual download and SBE bundle extraction are unnecessary when an SBE with this capability is already installed on the Azure Local instance.
Installing SBE as Part of Instance Creation
Starting with June 2025 Dell golden image release, the SBE files are included in the golden image and already placed in the C:\SBE directory. The following 3 steps do not need to be performed.
- On each server that will be an instance member, create the following directory:
C:\SBE - Copy the three SBE files to the directory
C:\SBEon each server that will be an instance member - Proceed to deploying the instance from the Azure Portal or an ARM template
Importing the SBE After Successful Azure Local Instance Creation
-
Create a directory on a cluster shared volume (CSV) for sideloading the SBE, e.g.,
C:\ClusterStorage\Infrastructure_1\SBE\SBE-AX-16G-45n0c_4.2.2506.1600 -
Copy the three extracted SBE files to this directory
-
Load the SBE files by running the following command with the path to the directory that holds the three extracted SBE files
Add-SolutionUpdate -SourceFolder "C:\ClusterStorage\Infrastructure_1\SBE\SBE-AX-16G-45n0c_4.2.2506.1600" -
Check the state of the SBE that was just added. The state needs to be
Ready.Get-SolutionUpdate | Where-Object -Property PackageType -EQ "SBE" -
Verify that the Azure Local instance is in a healthy state and is ready for the SBE installation by running the following commands on one of the Azure Local instance machines:
Get-SolutionUpdate | Where-Object { $_.State -imatch "Ready" -and $_.PackageType -eq "SBE" } | Start-SolutionUpdate -PrepareOnly -
Wait for the health check to complete. The solution update state will report
HealthCheckingwhile the health check is in progress. -
After the health check completes, run the following command if the solution update state reports
HealthCheckFailed:$Result = (Get-SolutionUpdate | Where-Object {$_.State -imatch "Ready" -and $_.PackageType -eq "SBE"}).HealthCheckResult $Result | Where-Object { ($_.Status -ne "SUCCESS" -and $_.Severity -eq "CRITICAL" ) } | Format-List -Property Title, Status, Severity, Description, Remediation, TargetResourceName, TargetResourceType
All tests with Critical severity must have the Success status before continuing to the next step.
-
Start the SBE installation by running the following command:
Get-SolutionUpdate | Where-Object { $_.State -imatch "Ready" -and $_.PackageType -eq "SBE" } | Start-SolutionUpdate -
The SBE installation progress can be checked by running the following command:
Get-SolutionUpdate | Where-Object -Property PackageType -EQ "SBE" | Format-List -Property ResourceID, Description, State, SBEVersion, UpdateStateProperties, HealthState
For more information see, Update Azure Local via PowerShell.
Known Issues
SBE Installation May Fail With Driver CAU Plug-In Error When Attempting to Delete NVIDIA ConnectX Driver That Is Not Installed
Description
The failure occurs in the driver CAU plug-in when driver downgrade option is specified for a given driver and the driver is not found in the driver store. This failure occurs in the following conditions:
- Cluster nodes were not imaged using Dell provided Azure Local golden image
- NVIDIA ConnectX NIC is not installed in the cluster nodes
- A previous version of an AX SBE is not installed
Workaround
Run the following script on each instance machine after completing step 5 “Verify that the Azure Local instance is in a healthy state and is ready for the SBE installation” in the Importing the SBE After Successful Azure Local Instance Creation section or when the failure is encountered during the SBE installation.
#Run this script on each node in the cluster.
$ConnectXDriverFileName = "mlx5.inf"
$InstalledConnectXDriver = Get-WindowsDriver -Online | Where-Object -Property OriginalFileName -IMatch $ConnectXDriverFileName
if (-not $InstalledConnectXDriver) {
Write-Output "Out-of-Box NVIDIA ConnectX driver not found on node: $($env:COMPUTERNAME)"
Write-Output "Checking SBE installation status on cluster: $((Get-Cluster).Name)"
$SBEWithPackagePaths = Get-SolutionUpdate | Where-Object { ($_.PackageType -eq "SBE") -and ($_.PackagePath -ne $null) -and ($_.PackagePath -notlike "https*") }
if ($SBEWithPackagePaths) {
$SBEPackagePath = ($SBEWithPackagePaths | Select-Object -First 1).PackagePath
$MlxDriverInfBaseFilePath = Join-Path -Path $SBEPackagePath -ChildPath "DriversGE\Network\Mellanox"
$MlxDriverInfFilePath = Get-ChildItem -Path $MlxDriverInfBaseFilePath -Filter $ConnectXDriverFileName -Recurse
Write-Output "SBE payload NVIDIA ConnectX driver file path: $($MlxDriverInfFilePath.FullName)"
if (Test-Path -Path $MlxDriverInfFilePath.FullName) {
Write-Output "Importing NVIDIA ConnectX driver..."
pnputil.exe /add-driver $MlxDriverInfFilePath.FullName /install
if (Get-WindowsDriver -Online | Where-Object -Property OriginalFileName -IMatch $ConnectXDriverFileName) {
Write-Output "NVIDIA ConnectX driver has been added to the driver store"
} else {
Write-Output "NVIDIA ConnectX driver is still not found in the driver store on node: $($env:COMPUTERNAME)"
}
} else {
Write-Output "Failed to resolve path: $($MlxDriverInfFilePath.FullName)"
}
} else {
Write-Output "SBE package path not found"
}
} else {
Write-Output "Found NVIDIA ConnectX driver version: $($InstalledConnectXDriver.Version) in the driver store"
Write-Output "No further action is required on this node"
}
Background
This SBE installation failure is resolved in the Azure Local Solution version 12.2512.1002.* and newer.
The driver CAU plug-in driver downgrade option is used in special cases. Currently, it is only used in the case of NVIDIA ConnectX NIC driver.
Partially Installed SBE Version 4.0.0.0 When SBE Is Installed as Part of Cluster Deployment
Description
Get-SolutionUpdateEnvironment reports partially installed SBE when installing the SBE as part of Azure Local instance deployment. SBE version 4.0.0.0 indicates a partially installed Solution Builder Extension (SBE).
Get-SolutionUpdateEnvironment
ResourceId : redmond
SbeFamily : AX-16G-45n0c
HardwareModel : AX-760
LastChecked : 08/01/2026 14:09:31
PackageVersions : {Solution: 12.2512.1002.16, Services: 10.2512.0.9, Platform: 12.2512.0.3021, SBE: 4.0.0.0}
CurrentVersion : 12.2512.1002.16
CurrentSbeVersion : 4.0.0.0
LastUpdated :
State : UpdateAvailable
HealthState : Success
HealthCheckResult : {Storage Services Physical Disks Summary, Storage Services Physical Disks Summary, Storage Services Physical Disks Summary, Storage Services Physical Disks Summary...}
HealthCheckDate : 07/01/2026 17:50:07
AdditionalData : {[SBEAdditionalData, Solution Builder extension is partially installed. Please install the latest Solution Builder Extension provided by your hardware vendor. For more information, see https://aka.ms/SBE.]}
Workaround
Reinstall the same SBE version using the SBE import method or automated download method after Azure Local instance deployment successfully completes.
Background
The SBE driver CAU plug-in expects all drivers and firmware in the SBE payload to be installed on the server during or prior to deployment. However, some of the drivers in the SBE payload may not apply to the server model or components in the server model. Microsoft is aware of this limitation and is working to resolve this issue in a future release.
The partially installed SBE issue, can also occur if a component firmware version installed on the server is different than what is in the SBE payload. The SBE cannot update firmware or drivers during Azure Local instance deployment.
SBE installation will not downgrade drivers that have a newer version than the same driver in the SBE payload
Dell supports the driver and firmware versions listed here, Support Matrix | Solutions for Microsoft Azure.
Description
The SBE driver CAU plug-in will not attempt to downgrade installed drivers that are higher version than the ones in its payload unless otherwise specified by Dell.
AMD DRTM (Dynamic Root of Trust for Measurement) Driver Fails to Update on AX AMD Platforms When the DRTM Device Was Originally Enabled at Azure Local Instance Deployment Time and Later Disabled
Description
SBE installation fails because the driver CAU plug-in in the SBE is unable to update the AMD DRTM driver to a newer version that is in the SBE payload. The AMD DRTM driver is one of the AMD Chipset drivers in the SBE package. The AMD DRTM driver update fails because the AMD DRTM setting was originally enabled but later disabled.
Workaround
Verify that the AMD DRTM BIOS setting is on. Turn back on the AMD DRTM setting if it is off.
The DRTM option is in the BIOS configuration: System Security -> TPM Advanced Settings -> AMD DRTM
Make sure to suspend and drain the Azure Local cluster node prior to rebooting the node. Make sure that BitLocker protection is disabled for the boot volume on the cluster node before making BIOS configuration changes. Disable BitLocker if it is enabled for the boot volume C:\ prior to rebooting the server for the BIOS changes to take effect. Reenable BitLocker for the boot drive after the server successfully reboots.
Background
AMD DRTM is an advanced security feature that is available on modern AMD CPUs and is used to protect the secure boot enclaves. The AMD DRTM setting is enabled by default on AX servers with AMD CPUs that support the DRTM feature. AMD DRTM should not be disabled.
Previous Releases
4 - Azure Stack HCI Support Matrix (Archive)
4.1 - Azure Stack HCI Firmware and Driver Matrix for Legacy Windows Server Operating Systems (Windows Server 2016)
Introduction
This matrix is for Windows Server operating systems that have exited Microsoft mainstream support. This Windows Server operating system is no longer being validated by Dell for use with hyperconverged cluster deployments. The table in the below link is a snapshot of the last firmware and driver versions that were validated by Dell engineering for use with this legacy Windows Server version.
Customers that are still running this Windows Server version for their hyperconverged cluster deployments are encouraged to perform an in-place upgrade to the Windows Server 2022 operating system per instructions at the following link.
NOTE
To find a particular driver or firmware download, take the Software Bundle ID and append it to the following URL:
https://www.dell.com/support/home/en-us/drivers/driversdetails?driverid=
For example:
https://www.dell.com/support/home/en-us/drivers/driversdetails?driverid=2R28V
Storage Spaces Direct Ready Nodes and AX nodes Supported Firmware versions
| Component | Type | Category | Software Bundle | Minimum Supported Version | Supported Systems |
|---|---|---|---|---|---|
| BIOS | Firmware DUP | BIOS | W77H1 | 2.16.1 | AX-640 R640 AX-740xd R740xd |
| BIOS | Firmware DUP | BIOS | CKFTD | 2.16.1 | R440 |
| BIOS | Firmware DUP | BIOS | VHNTJ | 2.16.1 | R740xd2 |
| BIOS | Firmware DUP | BIOS | 61GYN | 2.9.3 | AX-6515 |
| BIOS | Firmware DUP | BIOS | C45MX | 2.9.3 | AX-7525 |
| BIOS | Firmware DUP | BIOS | G7K8G | 1.8.2 | AX-650 AX-750 |
| iDRAC9 with Lifecycle Controller | Firmware DUP | BMC | KMYV9 | 6.10.00.00 | All |
| Non-expander Storage Backplane | Firmware DUP | Storage-Backplane | VV85D | 4.35 | AX-640 AX-740xd R640 R740xd |
| Non-expander Storage Backplane | Firmware DUP | Storage-Backplane | 6NNVP | 3.72 | AX-7525 AX-650 AX-750 |
| NVMe Switch Storage Backplane | Firmware DUP | Storage-Backplane | 5XJWN | 1.05 | AX-750 |
| Expander Storage Backplane | Firmware DUP | Storage-Backplane | H9PV3 | 1.20 | AX-750 AX-7525 |
| Expander Storage Backplane | Firmware DUP | Storage-Backplane | 60K1J | 2.52 | All |
| Intel S3520, M.2, SSD, RI, 240 GB, 480 GB | Firmware DUP | BOSS (Boot) | CHJGV | DL43 | All |
| Micron 5100, M.2, SSD, 240 GB, 480 GB | Firmware DUP | BOSS (Boot) | YM8KY | E013 | All |
| Micron 5300, M.2, SSD, 240 GB, 480 GB | Firmware DUP | BOSS (Boot) | PWVX5 | J004 | All |
| CPLD | Firmware DUP | CPLD | 1GW62 | 1.0.10 | R440 |
| CPLD | Firmware DUP | CPLD | 9N4DH | 1.0.6 | AX-640 R640 |
| CPLD | Firmware DUP | CPLD | G65GH | 1.1.4 | AX-740xd R740xd |
| CPLD | Firmware DUP | CPLD | R13D8 | 1.0.4 | R740xd2 |
| CPLD | Firmware DUP | CPLD | 79XGF | 1.0.7 | AX-6515 |
| CPLD | Firmware DUP | CPLD | XTPX5 | 1.1.15 | AX-7525 |
| CPLD | Firmware DUP | CPLD | N9YTC | 1.0.8 | AX-650 AX-750 |
| iDRAC Service Module OS DUP | Application | iSM | XJ9W8 | 4.3.0.0 | All |
(1) The "Non-expander Storage Backplane" is applicable only to R640 12-drive and R740xd 18-drive chassis configurations.
Storage Spaces Direct Ready Nodes and AX nodes Firmware and Drivers for Windows Server 2016
| Component | Category | Part Number | Firmware |
Drivers |
||
|---|---|---|---|---|---|---|
| Software Bundle | Minimum Supported Version | Software Bundle | Minimum Supported Version | |||
| Mellanox ConnectX-4 Lx Dual Port 25GbE DA/SFP rNDC Mellanox ConnextX-4 Lx Dual Port 25GbE DA/SFP Network Adapter, LP Mellanox ConnextX-4 Lx Dual Port 25GbE DA/SFP Network Adapter, FH |
Network / RDMA | R887V 20NJD MRT0D |
YTPJW | 14.31.20.06 | F3Y6R | 02.80.02 - Installer 2.80.25134.0 - Driver |
| Mellanox Connectx-5 EX Dual Port 100GbE QSFP20 PCIe Adapter, FH Mellanox Connectx-5 EX Dual Port 100GbE QSFP20 PCIe Adapter, LP Mellanox ConnectX-5 Dual Port 25GbE SFP28 Adapter, FH Mellanox ConnectX-5 Dual Port 25GbE SFP28 Adapter, LP |
Network / RDMA | 71C1T 9FTMY TDNNT V5DG9 |
3CJ0V | 16.31.20.06 | F3Y6R | 02.80.02 - Installer 2.80.25134.0 - Driver |
Mellanox ConnectX-6 Dx Dual Port 100GbE QSFP56 PCIe Adapter, LP Mellanox ConnectX-6 Dx Dual Port 100GbE QSFP56 PCIe Adapter, FH |
Network / RDMA | F6FXM 8P2T2 |
1XPGP | 22.31.20.06 | F3Y6R | 02.80.02 - Installer 2.80.25134.0 - Driver |
| Qlogic FastLinQ 41262 Dual Port 25Gbe SFP28, rNDC QLogic FastLinQ 41262 Dual Port 25Gb SFP28 Adapter, LP QLogic FastLinQ 41262 Dual Port 25Gb SFP28 Adapter, FH |
Network / iWARP | 4KF8J 415DX 51GRM |
TD0M9 | 15.20.16 | RYX52 | 35.20.14 - Installer 8.53.1.0 - Driver |
| QLogic FastLinQ 41162 Dual Port 10GbE BASE-T & Dual Port 1GbE BASE-T, rNDC |
Network / NDC | 0D1WT | TD0M9 | 15.20.16 | RYX52 | 35.20.14 - Installer 8.53.1.0 - Driver |
| QLogic FastLinQ 41164 Quad Port 10GbE SFP+, rNDC | Network / NDC | XVVY1 | TD0M9 | 15.20.16 | RYX52 | 35.20.14 - Installer 8.53.1.0 - Driver |
| QLogic FastLinQ 41164 Quad Port 10GbE BASE-T, rNDC | Network / NDC | X1TD1 | TD0M9 | 15.20.16 | RYX52 | 35.20.14 - Installer 8.53.1.0 - Driver |
| Intel X710 DP 10Gb DA/SFP+, +I350 DP 1Gb Ethernet, NDC |
Network / NDC | 6VDPG | DK4G2 | 20.0.17 | 284J6 | 20.0.0 - Installer 1.13.104.0 - Driver |
| Qlogic 57800 2x10Gb BT + 2x1Gb BT NDC QLogic 57800 2x10Gb DA/SFP+ +2x1Gb BT NDC |
Network / NDC | G8RPD 165T0 |
899FK | 15.20.13 | MJP9W | 35.20.04 - Installer |
| Broadcom 5720 Dual Port 1 GbE Network LOM Mezz Card | Network / NDC | KJMHJ | M18WH | 21.80.9 | 49X84 | 21.80.3 - Installer 214.0.0.6 - Driver |
| Broadcom 57412 2 Port 10Gb SRP+ + 5720 2 Port 1 GB Base-T, rNDC | Network / NDC | NWMNX | YPXWJ | 21.85.21.91 | XYJ8C | 218.0.169.0 - Installer 21.80.16.60 - Driver |
| Broadcom 57416 Dual Port 10 Gb E SFP+ Network LOM Mezz Card | Network / NDC | WC9TR | YPXWJ | 21.85.21.91 | XYJ8C | 218.0.169.0 - Installer 21.80.16.60 - Driver |
| Broadcom 57414 Dual Port 25 Gb E SFP+ Network LOM Mezz Card | Network / NDC / OCP | 930PP | YPXWJ | 21.85.21.91 |
XYJ8C | 218.0.169.0 - Installer 21.80.16.60 - Driver |
| HBA330 Controller, 12Gps Mini Card HBA330 Controller, 12Gps Mini Card, LP |
Storage-HBA | P2R3R J7TNV |
124X2 NKNVC |
16.17.01.00 | P1NP6 |
2.51.25.01 - Windows Server 2016 |
| BOSS-S1 | BOSS-S1 | 2MFVD | 3P39V | 2.5.13.3024 | 8KKVC | 1.2.0.1052 |
| Chipset driver for Intel platforms | Chipset | Not applicable | Not applicable | Not applicable | MPXXJ |
10.1.18807.8279 |
SAS 2.5” HDD Drives - Capacity Only
| Form Factor | Type | Vendor | Model | Model | Device Part Number (P/N) | Software Bundle | Minimum Supported Version | Capacity | Use |
|---|---|---|---|---|---|---|---|---|---|
| 2.5" | 7.2K 12Gbps SAS HDD | Seagate | Avenger | ST2000NX0463 | TMVN7 | GW3V7 | NT32 | 2 TB | Capacity |
| 2.5" | 10K 12 Gbps SAS HDD | Seagate | Skybolt | DL2400MM0159 | RWR8F | HYJ6K | ST5C | 2.4 TB | Capacity |
| 2.5" | 10K 12 Gbps SAS HDD | Toshiba | AL15SE | AL15SEB24EQY | F9NWJ | 0T1RG | EF06 | 2.4 TB | Capacity |
| 2.5" | 10K 12 Gbps SAS HDD | Seagate | Skybolt | ST2400MM0159 | 36YG1 | DY8C3 | ST76 | 2.4 TB | Capacity |
SATA 2.5” HDD Drives - Capacity Only
| Form Factor | Type | Vendor | Series | Model | Device Part Number (P/N) | Software Bundle | Minimum Supported Version | Capacity | Use |
|---|---|---|---|---|---|---|---|---|---|
| 2.5" | 7.2K 6Gbps SATA HDD | Seagate | Avenger | ST2000NX0423 | VR92X | GMW4P | NB33 | 2 TB | Capacity |
SATA 3.5” HDD Drives - Capacity Only
| Form Factor | Type | Vendor | Series | Model | Device Part Number (P/N) | Software Bundle | Minimum Supported Version | Capacity | Use |
|---|---|---|---|---|---|---|---|---|---|
| 3.5" | HDD | Hitachi | Aries K Plus | HUS726020ALA610 HUS726040ALA610 |
8NP2N 61FFW |
X59KC | KV45 | 2 TB 4 TB |
Capacity |
| 3.5" | HDD | Hitachi | Rainier MLK | HUS722T2TALA600 | V9H6C | V3DJM | MU03 | 2 TB | Capacity |
| 3.5" | HDD | Toshiba | Tomcat R | MG04ACA200NY MG04ACA400NY |
NPVM6 95M6K |
V47C4 |
FK5D | 2 TB 4 TB |
Capacity |
| 3.5" | HDD | Seagate | Nemo | ST2000NM0018-2F3130 | W8FW5 | CMK5N | EA04 | 2 TB | Capacity |
| 3.5" | HDD | Seagate | Makara BP | ST2000NM0145-2DC104 ST4000NM0265-2DC107 |
WG9R0 MWHY9 |
M5GJ1 | DB34 | 2 TB 4 TB |
Capacity |
| 3.5" | HDD | Hitachi | Vela-A | HUS726T4TALA6L0 | YH3T9 | 3CFT0 | PV07 | 4 TB | Capacity |
| 3.5" | HDD | Hitachi | Vela-AP | HUS728T8TALE6L0 | 1WMVC | N26JT | RT07 | 8 TB | Capacity |
| 3.5" | HDD | Hitachi | Libra HE10 | HUH721008ALE600 | KRV2W | H12N2 | LT21 | 8 TB | Capacity |
| 3.5" | HDD | Seagate | Makara Plus | ST8000NM0205-2FF112 | 92MDW | MR6RH | PB53 | 8 TB | Capacity |
| 3.5" | HDD | Toshiba | MG06 | MG06ACA800EY | 9X09C | PT7D8 | GA09 | 8 TB | Capacity |
| 3.5" | HDD | Hitachi | Leo-A He12 | HUH721212ALE600 | T2YHT | 0HF04 | NT10 | 12 TB | Capacity |
| 3.5" | HDD | Toshiba | MG07 | MG07ACA12TEY | 753F0 | 0942Y | GB03 | 12 TB | Capacity |
| 3.5" | HDD | Toshiba | MG08AC | MG08ACA16TEY | HPGJ4 | MGF80 | GC02 | 16 TB | Capacity |
| 3.5" | HDD | Toshiba | MG08AD | MG08ADA400NY | W2M9N | 7NJXF | GD03 | 4 TB | Capacity |
| 3.5" | HDD | Seagate | Cimarron | ST4000NM016A-2HZ130 ST8000NM012A-2KE131 |
XPJ47 F4JXT |
179WV V1521 |
CAJC CALD |
4 TB 8 TB |
Capacity |
| 3.5" | HDD | Seagate | Cimarron BP | ST4000NM018B-2TF130 ST8000NM023B-2TJ133 |
6KR2M J7W80 |
J4X0T 4P5X3 |
LC09 LA0A |
4 TB 8 TB |
Capacity |
SAS 3.5” HDD Drives - Capacity Only
| Form Factor | Type | Vendor | Series | Model | Device Part Number (P/N) | Software Bundle | Minimum Supported Version | Capacity | Use |
|---|---|---|---|---|---|---|---|---|---|
| 3.5" | HDD | Hitachi | Aries K Plus | HUS726020ALS210 HUS726040ALS210 |
VH6FW X4FKY |
68X4C | KU45 | 2 TB 4 TB |
Capacity |
| 3.5" | HDD | Toshiba | Tomcat R | MG04SCA20ENY MG04SCA40ENY |
HHX14 1MVTT |
RG9MK | EG03 | 2 TB 4 TB |
Capacity |
| 3.5" | HDD | Seagate | Makara BP | ST2000NM0155 ST4000NM0295 |
7RCGV 5JH5X |
3CRY1 | DT32 | 2 TB 4 TB |
Capacity |
| 3.5" | HDD | Hitachi | Vela-A | HUS726T4TALS200 | NT1X2 | 1DM5F | PU07 | 4 TB | Capacity |
| 3.5 | HDD | Hitachi | Vela-AP | HUS728T8TAL5200 | 44YFV | 6JJPV | RS07 | 8 TB | Capacity |
| 3.5" | HDD | Hitachi | Libra HE10 | HUH721008AL5200 | KRDKK | MGW91 | LS21 | 8 TB | Capacity |
| 3.5" | HDD | Seagate | Makara Plus | ST8000NM0185 | M40TH/VFP4M | 6421F | PT55 | 8 TB | Capacity |
| 3.5" | HDD | Toshiba | MG06 | MG06SCA800EY | FV725 |
4G5GY | EH0D | 8 TB | Capacity |
| 3.5" | HDD | Hitachi | Leo-A He12 | HUH721212AL5200 | 9HXK6 | 230YX | NS10 | 12 TB | Capacity |
| 3.5" | HDD | Toshiba | MG07 | MG07SCA12TEY | DK7C9/KFJ7G | GT72W | EI0C | 12 TB | Capacity |
| 3.5" | HDD | Seagate | Evans | ST12000NM009G | 7KT9W | NJ4NN | ESL7 | 12 TB | Capacity |
| 3.5" | HDD | Seagate | Mobula BP | ST12000NM0158 | YMN53 | VTX9C | RSL5 | 12 TB | Capacity |
| 3.5" | HDD | Toshiba | MG08SC | MG08SCA16TEY | 8MG73 | 9N3RR | EJ09 | 16 TB | Capacity |
| 3.5" | HDD | Toshiba | MG08SC | MG08SCA16TEY | 4N7V0 | 9N3RR | EJ09 | 16 TB | Capacity |
| 3.5" | HDD | Toshiba | MG08SC | MG08SCA16TEY | 24HF9 | 9N3RR | EJ09 | 16 TB | Capacity |
| 3.5" | HDD | Seagate | Evans | ST16000NM010G | CNXPV | NJ4NN | ESL7 | 16 TB | Capacity |
| 3.5" | HDD | WD | Paris-C | WUH721816AL5200 | VF206 | 19MP7 | US06 | 16 TB | Capacity |
| 3.5" | HDD | Seagate | Cimarron | ST4000NM017A ST8000NM014A |
KRM6X 0N660 |
WTX15 PRFRJ |
CSJA CSLC |
4 TB 8 TB |
Capacity |
| 3.5 | HDD | Seagate | Cimarron BP | ST4000NM019B ST8000NM024B |
10N7R C5HD0 |
912Y9 DTGXD |
LW0A LS0A |
4 TB 8 TB |
Capacity |
| 3.5 | HDD | Toshiba | MG08SD | MG08SDA400NY | FN2YX | N5XN3 | EK05 | 4 TB | Capacity |
SATA 2.5” SSD Drives - Cache or Capacity
| Endurance | Vendor | Series | Model | Device Part Number (P/N) | Software Bundle | Minimum Supported Version | Capacity | Use |
|---|---|---|---|---|---|---|---|---|
| Mixed Use | Toshiba | HK4 | THNSF8800CCSE THNSF81D60CSE |
VCRY6 DMF5Y |
H3XHN | DACB | 800 GB 1.6 TB |
Cache, Capacity |
| Mixed Use | Micron | 5300 | MTFDDAK960TDT MTFDDAK1T9TDT |
XMWMK MMCDY |
X5R54 | J004 | 960 GB 1.92 TB |
Cache, Capacity |
| Mixed Use | Samsung | SM863a | MZ7KM960HMJP0D3 MZ7KM1T9HMJP0D3 |
DD4G0 K5P0T |
97D8J | GD57 | 960 GB 1.92 TB |
Cache, Capacity |
| Mixed Use | Samsung | SM883 | MZ7KH960HAJR0D3 MZ7KH1T9HAJR0D3 |
YDHYX 71K37 |
3J3JR | HF58 | 960 GB 1.92 TB |
Cache, Capacity |
| Mixed Use | Intel | S4600 | SSDSC2KG960G7R SSDSC2KG019T7R |
TR3MY MWKF2 |
V141M | DL5C | 960 GB 1.92 TB |
Cache, Capacity |
| Mixed Use | Intel | S4610 | SSDSC2KG960G8R SSDSC2KG019T8R |
X31G3 F8N2K/55J8H |
2674V | DL69 | 960 GB 1.92 TB |
Cache, Capacity |
| Mixed Use | Micron | 5200 | MTFDDAK960TDN MTFDDAK1T9TDN |
HY1F8 XKF5Y |
H72VG | F005 | 960 GB 1.92 TB |
Cache, Capacity |
| Mixed Use | Toshiba | HK6-V | KHK6YVSE960G KHK6YVSE1T92 |
XW4D1 0DXJ7 |
W0YR1 | DBC4 | 960 GB 1.92 TB |
Cache, Capacity |
| Mixed Use | Hynix | SE5031 | HFS960G32FEH-BA10A HFS1T9G32FEH-BA10A |
7GR2K GKTF1 |
7X9WV | DD02 | 960 GB 1.92 TB |
Cache, Capacity |
| Mixed Use | Intel | Youngsville-RR | SSDSC2KG960GZR SSDSC2KG019TZR |
8MHYH 8RXV5 |
PN1T8 | DL70 | 960 GB 1.92 TB |
Cache, Capacity |
| Mixed Use | Samsung | PM897 | MZ7L3960HBLTAD3 MZ7L31T9HBNAAD3 MZ7L33T8HBNAAD3 |
96KT6 RRR7M N04DW |
2PV21 | HH53 | 960 GB 1.92 TB 3.84 TB |
Cache, Capacity |
SATA 2.5” SSD Drives - Capacity Only
| Endurance | Vendor | Series | Model | Device Part Number (P/N) | Software Bundle | Minimum Supported Version | Capacity | Use |
|---|---|---|---|---|---|---|---|---|
| Read Intensive | Micron | 5200 | MTFDDAK1T9TDD | VJ36D | H72VG | F005 | 1.92 TB | Capacity Only |
| Read Intensive | Micron | 5300 | MTFDDAK1T9TDS | GYGVV | X5R54 | J004 | 1.92 TB | Capacity Only |
| Read Intensive | Toshiba | HK6-R | KHK6YRSE1T92 KHK6YRSE3T84 |
919J7 8PYG5 |
W0YR1 | DBC4 | 1.92 TB 3.84 TB |
Capacity Only |
| Read Intensive | Samsung | PM883a | MZ7LH1T9HALT0D3 | 9F9Y6 | 882YH | HG58 | 1.92 TB | Capacity Only |
| Read Intensive | Samsung | PM883 | MZ7LH1T9HMLT0D3 | Y24T6 | 93P7P | HE59 | 1.92 TB | Capacity Only |
| Read Intensive | Hynix | SE4011 | HFS1T9G32FEH-7A10A | 0XMV9 | MFCH2 | DE07 | 1.92 TB | Capacity Only |
| Read Intensive | Intel | S4510 | SSDSC2KB019T8R | 33R2T | 2674V | DL69 | 1.92 TB | Capacity Only |
| Read Intensive | Intel | S4500 | SSDSC2KB019T7R SSDSC2KB038T7R |
XCN15 3RRN8 |
V141M | DL5C | 1.92 TB 3.84 TB |
Capacity Only |
| Read Intensive | Intel | S4510 | SSDSC2KB038T8R | 1RHK2 | 2674V | DL69 | 3.84 TB | Capacity Only |
| Read Intensive | Samsung | PM883 | MZ7LH3T8HMLT0D3 | FYP5F | 93P7P | HE59 | 3.84 TB | Capacity Only |
| Read Intensive | Samsung | PM883a | MZ7LH3T8HALT0D3 | 5TVXD | 882YH | HG58 | 3.84 TB | Capacity Only |
| Read Intensive | Hynix | SE4011 | HFS3T8G32FEH-7410A | D6C0R | MFCH2 | DE07 | 3.84 TB | Capacity Only |
| Read Intensive | Micron | 5300 | MTFDDAK3T8TDT | 4H1RX | PXMD3 | J404 | 3.84 TB | Capacity Only |
| Read Intensive | Hynix | SE5110 | HFS1T9G3H2X069N HFS3T8G3H2X069N |
962FP 3GDK0 |
8KVKG | DZ02 | 1.92 TB 3.84 TB |
Capacity Only |
| Read Intensive | Intel | Youngsville-RR | SSDSC2KB960GZR SSDSC2KB019TZR SSDSC2KB038TZR |
F6H8H VYYW8 WNPN1 |
PN1T8 | DL70 | 960 GB 1.92 TB 3.84 TB |
Capacity Only |
| Read Intensive | Samsung | PM893 | MZ7L31T9HBLTAD3 MZ7L33T8HBLTAD3 |
0KYP4 GCN5W |
5MKJ8 | HJ53 | 1.92 TB 3.84 TB |
Capacity Only |
SAS 2.5” SSD Drives - Cache or Capacity
| Endurance | Vendor | Series | Model | Supported Config | Device Part Number (P/N) | Software Bundle | Minimum Supported Version | Capacity | Use |
|---|---|---|---|---|---|---|---|---|---|
| Write Intensive | Toshiba | Phoenix M4 | PX05SMB080Y PX05SMB160Y |
Hyb, AF | CN3JH GVTYD |
1DJXX | AS10 | 800 GB 1.6 TB |
Cache, Capacity |
| Mixed Use | Toshiba | Phoenix M4 | PX05SVB096Y PX05SVB192Y PX05SVB384Y |
Hyb, AF | 503M7 V0K7V 3DDFT |
1DJXX | AS10 | 960 GB 1.92 TB 3.84 TB |
Cache, Capacity |
| Write Intensive | Toshiba | Phoenix M5-M | KPM5XMUG800G KPM5XMUG1T60 |
Hyb, AF | DHRVV W9G88 |
4P9DW | B026 | 800 GB 1.6 TB |
Cache, Capacity |
| Mixed Use | Samsung | PM1645a | MZILT800HBHQ0D3 MZILT1T6HBJR0D3 |
Hyb, AF | GW8T1 3TCV6 |
VJY6V | DWA4 | 800 GB 1.6 TB |
Cache, Capacity |
| Mixed Use | Samsung | PM1645 | MZILT1T6HAJQ0D3 | Hyb, AF | DR0HX | C9JP2 | DWF8 | 1.6 TB | Cache, Capacity |
| Mixed Use | WD | Bear Cove Quantum | WUSTR6480BSS200 WUSTR6416BSS200 |
Hyb, AF | 6VJC9 6NF96 |
X95FJ | G130 | 800 GB 1.6 TB |
Cache, Capacity |
| Mixed Use | Toshiba | Phoenix M5-V | KPM5XVUG960G KPM5XVUG1T92 KPM5XVUG3T84 |
Hyb, AF | WFGTH 2WVYG 91W3V |
4P9DW | B026 | 960 GB 1.92 TB 3.84 TB |
Cache, Capacity |
| Write Intensive | Kioxia | PM6 | KPM6XMUG800G KPM6XMUG1T60 |
Hyb, AF | H6GCD 5GDXH |
6K5N9 | BA0D | 800 GB 1.6 TB |
Cache, Capacity |
| Mixed Use | Kioxia | PM6 | KPM6XVUG800G KPM6XVUG1T60 KPM6XVUG6T40 |
Hyb, AF | JTKH5 GD3N0 6NW3J |
6K5N9 | BA0D | 800 GB 1.6 TB 6.4 TB |
Cache, Capacity |
| Mixed Use | Kioxia | PM6, FIPS | KPM6WVUG960G KPM6WVUG1T92 KPM6WVUG3T84 |
Hyb, AF | WMWKG DHWH5 81H9C |
376CY | BD0D | 960 GB 1.92 TB 3.84 TB |
Cache, Capacity |
SAS 2.5” SSD Drives - Capacity Only
| Endurance | Vendor | Series | Model | Device Part Number (P/N) | Software Bundle | Minimum Supported Version | Capacity | Use |
|---|---|---|---|---|---|---|---|---|
| Read Intensive | WD | Bear Cove Plus | WUSTR1519ASS200 WUSTR1538ASS200 |
5ND33 YW17N |
358PN | K960 | 1.92 TB 3.84 TB |
Capacity Only |
| Read Intensive | WD | Bear Cove Quantum | WUSTVA119BSS200 WUSTVA138BSS200 |
02X38 FP1KF |
1GGR2 | G10A | 1.92 TB 3.84 TB |
Capacity Only |
| Read Intensive | Samsung | PM1643 | MZILT1T9HAJQ0D3 MZILT3T8HALS0D3 MZILT7T6HMLA0D3 |
F0VFY X8F87 RVYD5 |
J3RRK | DSF8 | 1.92 TB 3.84 TB 7.68 TB |
Capacity Only |
| Read Intensive | Samsung | PM1643a | MZILT1T9HBJR0D3 MZILT3T8HBLS0D3 MZILT7T6HALA0D3 |
TMTW9 CRNPH 84C40 |
D7RNT | DSA4 | 1.92 TB 3.84 TB 7.68 TB |
Capacity Only |
| Read Intensive | Samsung | PM1633a | MZILS3T8HMLH0D3 | JR1HP | XNGNT | DSLA | 3.84 TB | Capacity Only |
| Read Intensive | Toshiba | Phoenix M5-R | KPM5XRUG1T92 KPM5XRUG3T84 |
TDNP7 N85XX |
4P9DW | B026 | 1.92 TB 3.84 TB |
Capacity Only |
| Read Intensive | Toshiba | Phoenix M4 | PX05SRB384Y | XCRDV | 1DJXX | AS10 | 3.84 TB | Capacity Only |
| Read Intensive | Kioxia | PM6 | KPM6XRUG1T92 KPM6XRUG3T84 KPM6XRUG7T68 |
4CN85 H9TT5 PD02Y |
2N1R6 | BA0B | 1.92 TB 3.84 TB 7.68 TB |
Capacity Only |
| Read Intensive | Kioxia | PM6 | KPM6WRUG1T92 KPM6WRUG3T84 |
7F2D1 FH1W9 |
376CY | BD0D | 1.92 TB 3.84 TB |
Capacity Only |
Value SAS 2.5” SSD Drives - Cache or Capacity
| Endurance | Vendor | Series | Model | Device Part Number (P/N) | Software Bundle | Minimum Supported Version | Capacity | Use |
|---|---|---|---|---|---|---|---|---|
| Mixed Use | Toshiba | Phoenix RM5 | KRM5XVUG3T84 |
X78JM |
12D7W | B70C | 3.84 TB |
Cache, Capacity |
| Mixed Use | Seagate | LangeBP | XS3840LE70154 | NWGX3 | NX13G | 4D0C | 3.84 TB | Cache, Capacity |
| Mixed Use | Seagate | LangeBP,SED | XS960LE70134 XS1920LE70134 XS3840LE70134 |
2RDWT N6DRV YM9HP |
G04C8 | 4S0C | 960 GB 1.92 TB 3.84 TB |
Cache, Capacity |
| Mixed Use | Kioxia | RM6,SED | KRM6VVUG960G KRM6VVUG1T92 KRM6VVUG3T84 |
42XXC N15JP FXYGR |
3P4FR | BJ02 | 960 GB 1.92 TB 3.84 TB |
Cache, Capacity |
| Read Intensive | Toshiba | Phoenix RM5 | KRM5XRUG7T68 | 5XD2F | 12D7W | B70C | 7.68 TB | Capacity Only |
| Read Intensive | Seagate | Lange | XS7680SE70074 | 2PKRH | H3VHX | EC16 | 7.68 TB | Capacity Only |
| Read Intensive | Seagate | LangeBP | XS7680SE70154 | 5KW0F | NX13G | 4D0C | 7.68 TB | Capacity Only |
| Read Intensive | Seagate | LangeBP,SED | XS1920SE70134 XS3840SE70134 XS7680SE7013 |
K9T53 4KPKF 2THYF |
G04C8 | 4S0C | 1.92 TB 3.84 TB 7.68 TB |
Capacity Only |
| Read Intensive | Kioxia | RM6,SED | KRM6VRUG1T92 KRM6VRUG3T84 KRM6VRUG7T68 |
1FGWG XNXD2 5MHY8 |
3P4FR | BJ02 | 1.92 TB 3.84 TB 7.68 TB |
Capacity Only |
NVMe Drives - Cache or Capacity
NOTE
Intel Optane P4800x is supported only on the R640 Storage Spaces Direct Ready Node.| Platform | Vendor | Form Factor | Description | Model Number | Device Part Number (P/N) | Software Bundle | Minimum Supported Version | Capacity | Use |
|---|---|---|---|---|---|---|---|---|---|
| NVMe only | Intel | 2.5" | Optane P4800x SSD/NVMe, 375 GB U.2 2.5" SFF | SSDPE21K375GAT | 3DM57 | HD2YY | E201DP38 | 375 GB | Cache, Capacity |
| NVMe only | Samsung | 2.5" | PM1725A |
MZWLL1T6HEHP-000D3 MZWLL3T2HMJP-000D3 MZWLL6T4HMLS-000D3 |
JD6CH JDMHM Y3XT2 |
34C36 |
1.2.1 | 1.6 TB 3.2 TB 6.4 TB |
Cache, Capacity |
| NVMe only | Samsung | 2.5" | PM1725b |
MZWLL1T6HAJQ-000D3 MZWLL3T2HAJQ-000D3 MZWLL6T4HMLA-000D3 |
4WDXY K60N7 08NMX |
3F3N1 | 1.2.2 | 1.6 TB 3.2 TB 6.4 TB |
Cache, Capacity |
| NVMe only | Intel | 2.5" | P4600 |
SSDPE2KE016T7T SSDPE2KE032T7T |
F5P84 MCV6J |
CR0HC | QDV1DP17 | 1.6 TB 3.2 TB |
Cache, Capacity |
| NVMe only | Intel | 2.5" | P4610 |
SSDPE2KE016T8T SSDPE2KE032T8T SSDPE2KE064T8T |
58V30 2CN1T X27HY |
GD4X4 | VDV1DP25 | 1.6 TB 3.2 TB 6.4 TB |
Cache, Capacity |
| NVMe only | KIOXIA | 2.5" | CM6,FIPS | Dell Ent NVMe FIPS CM6 MU 1.6 TB | G7N00 | T79D5 | 1.2.0 | 1.6 TB | Cache, Capacity |
| NVMe only | Samsung | 2.5" | PM1735 | Dell Ent NVMe AGN MU U.2 1.6 TB | 6GK00 | RP8RC | 2.3.0 | 1.6 TB | Cache, Capacity |
| NVMe only | Samsung | 2.5" | PM1735 V2 | Dell Ent NVMe v2 AGN MU U.2 1.6 TB Dell Ent NVMe v2 AGN MU U.2 3.2 TB Dell Ent NVMe v2 AGN MU U.2 6.4 TB |
0MNMV V69W3 H8D5M |
TRCC6 | 2.3.0 | 1.6 TB 3.2 TB 6.4 TB |
Cache, Capacity |
| NVMe only | Kioxia | 2.5" | CM6 SP | Dell Ent NVMe CM6 MU 1.6 TB Dell Ent NVMe CM6 MU 3.2 TB Dell Ent NVMe CM6 MU 6.4 TB |
P03YC 97GR0 K916X |
511TX | 2.1.8 | 1.6 TB 3.2 TB 6.4 TB |
Cache, Capacity |
| NVMe only | Intel | 2.5" | P5600 SP | Dell Ent NVMe P5600 MU U.2 1.6 TB Dell Ent NVMe P5600 MU U.2 3.2 TB |
C9X5T PRKTM |
J7FTF | 1.2.4 | 1.6 TB 3.2 TB |
Cache, Capacity |
| NVMe only | Intel | 2.5" | Arbordale Plus RR | SSDPF2KE016T1E SSDPF2KE032T1E |
82TVJ TY3M5 |
J55N8 | 1.0.0 | 1.6 TB 3.2 TB |
Cache, Capacity |
NVMe Drives - Capacity Only
NOTE
Toshiba CD5 960 GB capacity is supported only on the R640 Storage Spaces Direct Ready Node.| Endurance | Vendor | Series | Model | Device Part Number (P/N) | Software Bundle | Minimum Supported Version | Capacity | Use |
|---|---|---|---|---|---|---|---|---|
| Read Intensive |
Toshiba | CD5 | KCD5XLUG960G KCD5XLUG3T84 |
DRC9H 17C57 |
T79D5 | 1.2.0 | 960 GB 3.84 TB |
Capacity Only |
| Intel | P4510 | SSDPE2KX040T8T | 5GMK0 | GD4X4 | VDV1DP25 | 4 TB | Capacity Only | |
| Read Intensive | KIOXIA | CM6 | Dell Ent NVMe FIPS CM6 RI 1.92 TB | TXP72 | T79D5 | 1.2.0 | 1.92 TB | Capacity Only |
| Read Intensive | Intel | P5500 | Dell Ent NVMe P5500 RI U.2 1.92 TB Dell Ent NVMe P5500 RI U.2 3.84 TB Dell Ent NVMe P5500 RI U.2 7.68 TB |
WPP9G KRT3G RNN67 |
XXN1D | 1.2.3 | 1.92 TB 3.84 TB 7.68 TB |
Capacity Only |
| Read Intensive | Samsung | PM1733 V2 | Dell Ent NVMe v2 AGN RI U.2 3.84 TB Dell Ent NVMe v2 AGN RI U.2 7.68 TB |
G5N65 DX74Y |
FJK0C | 2.2.0 | 3.84 TB 7.68 TB |
Capacity Only |
| Read Intensive | Kioxia | CM6,SP | KCM6XRUL1T92 KCM6XRUL3T84 KCM6XRUL7T86 |
N0VK0 8W2G5 VD0JX |
511TX | 2.1.8 | 1.92 TB 3.84 TB 7.68 TB |
Capacity Only |
| Read Intensive | Intel | Arbordale Plus RR | SSDPF2KX019T1E SSDPF2KX038T1E SSDPF2KX076T1E |
0HVC7 77MRY 90M2J |
J55N8 | 1.0.0 | 1.92 TB 3.84 TB 7.68 TB |
Capacity Only |
NVMe PCIe Add In Card (AIC) - Cache or Capacity
| Platform | Vendor | Form Factor | Description | Model Number | Device Part Number (P/N) | Software Bundle | Minimum Supported Version | Capacity | Use |
|---|---|---|---|---|---|---|---|---|---|
| NVMe only | Samsung | PCIe AIC | PM1725A |
MZPLL1T6HEHP-000D3 MZPLL6T4HMLS-000D3 |
06V6M 604N5 |
34C36 | 1.2.1 | 1.6 TB 6.4 TB |
Cache, Capacity |
| NVMe only | Samsung | PCIe AIC | PM1725b |
MZPLL1T6HAJQ-000D3 MZPLL6T4HMLA-000D3 |
FTX2R FW2K0 |
3F3N1 | 1.2.2 | 1.6 TB 6.4 TB |
Cache, Capacity |
| NVMe only | Samsung | PCIe AIC | PM1735 |
MZPLJ1T6HBJR-00AD3 MZPLJ6T4HALA-00AD3 |
Y7D7D 91FXC |
RDKVC | 2.4.0 | 1.6 TB 6.4 TB |
Cache, Capacity |
